Miller Electric Mfg. Co.    Appleton, WI 54912 1079
Mar 20, 2006 Syncrowave® 200 AC/DC TIG/Stick welder provides 5-200 A output power (150 A at 40-percent duty cycle), enough to weld ¼-in. aluminum with ac TIG. Single-knob adjustment controls pulse rate from 1-15 pulses/sec, and Syncro-Start(TM) technology allows operators to choose soft, standard, or hot starting, depending on material thickness and tungsten diameter. Syncrowave 200 comes with Weldcraft® WP17 Super Flex air-cooled TIG torch with 12.5 ft braided nylon power cable.

EGS ELECTRICAL GROUP ? APPLETON    Rosemont, IL 60018
Mar 20, 2006 UL-Classified to interchange with equivalent Crouse-Hinds Form 7® parts, FM7(TM) Series products have bodies with corrosion-fighting epoxy powder coat. They are available in Grayloy iron, malleable iron, or aluminum, with Wedge-Lok(TM) clip covers. Flat back design allows for secure mounting and wiring room. Able to connect and change direction of conduit runs, conduit bodies also serve as wire pulling fittings, make bends in conduit system, and provide openings for wire splicing.

American Sensor Technologies, Inc.    Mt. Olive, NJ 07828
Mar 20, 2006 Designed for use with gas, liquid, or solid media, digital AccuGauge features weld-free, 17-4PH SS sensing element. It measures pressure in psi, bar, kg/cm ², in. Hg, in. H2O, and ATM with less than +0.5% FS accuracy over -10 to +160ºF operating temperature range. Housed in rugged NEMA 4 polycarbonate body, media isolated product features automatic power-off and large 4-digit LCD display. Gauge suits high proof and burst pressure applications.

Allegro MicroSystems Inc.    Worcester, MA 01615
Mar 20, 2006 Designed for PWM control of dc motors, A3950 is capable of peak output currents to ±2.8 A and operating voltages to 36 V. PHASE and ENABLE input terminals are provided for use in controlling speed as well as direction of rotation and torque of dc motor with externally applied PWM control signals. To reduce output power dissipation, internal synchronous rectification control circuitry switches on appropriate DMOS outputs to short out body diodes during PWM operation.

Hancor, Inc.    Findlay, OH 45839
Mar 20, 2006 Engineered with secure, overlapping joints, sidewall openings, and open bottom, LandSaver(TM) meets demands of subsurface storm water management applications. Open bottom design retains storm water and then lets it infiltrate slowly into soil, assisting in recharging groundwater. Chamber can also be used for detention to relieve peak flows through outlet control structure. Chamber suits commercial, industrial, recreational, and residential developments.

Extech Instruments Corp.    Nashua, NH 03063
Mar 20, 2006 Operating from rechargeable lithium ion battery or ac power adapter, portable S2500THS features automatic thermal print contrast and is in-field programmable for firmware, font, and logo setup. Microprocessor with integrated CPU manages all features supported by printer and has built-in Flash and SRAM memory. Along with IrDA communication system, MS-DOS and Windows compliant unit offers multiple communication interfaces and optional integrated Bluetooth(TM) radio.

FCI/Burndy Products    Manchester, NH 03108
Mar 20, 2006 Delivering 6 tons of crimping force, Y81KFT 4-POINT(TM) dieless HYPRESS(TM) incorporates latchless flip-top style head that facilitates tool removal from continuous conductor runs. Unit weighs 12 lb and has ergonomically sound design for termination and splicing. Suited for use on copper, aluminum, compressed, compact, stranded, solid, and flex conductors, product comes with molded, high-impact plastic case. Head rotates 360° relative to handles and is mated to rapid advance pump.

Bunting Magnetics Company    Newton, KS 67114 0468
Mar 20, 2006 Available in belt widths from 12-60 in., Grinder/Shredder Feed Conveyors catch ferrous and nonferrous metal contaminants in conveyed material before they damage grinders or ruin product. They may be combined with any of 3 Bunting Metal Detectors that sense all conductive metals and have self-diagnostics for adjustable operation; all metal detectors have Product-Effect Compensation and EMI/RFI filters. Integrated, dual-function conveyors have 6 in. high side guards with wipers.

METFAB Technologies, Inc.    Warwick, RI 02888
Mar 20, 2006 METFAB Control Panels are custom-engineered with HMI, appropriate displays, enclosures and mounting arms or devices, as well as all electrical and pneumatic fittings needed to match OEM or contractor project requirements. Fully integrated into application, panels can be supplied, containerized, as pre-wired modules with multi-conductor cables. Integral PLC provides all graphics, DAQ, analysis, and networking capabilities customized to performance and budget requirements.

Virtio Corporation    Campbell, CA 95008
Mar 20, 2006 Providing complete simulated environment for TI's OMAP3430 hardware and software platform, VPOM-3430 Virtual Platform lets designers focus on converging mobile phones with advanced video and imaging technologies and build and test software for systems early in development process. Platform also lets designers utilize OMAP3430 multimedia technologies prior to silicon availability. Once hardware is available, Virtual Platform continues to provide visibility at later stages of design.

Kontron    Poway, CA 92064
Mar 20, 2006 Expanding design options for telecom and network equipment manufacturers, Model AT8400 features PCI-Express and Gigabit Ethernet switching infrastructure and SAS controller. AdvancedMC-Bays can be populated with variety of field-replaceable modules. Suitable for dual-star and full-mesh configurations in 14- and 16-slot systems, board can be managed via SNMP, TELNET, CLI, either in-band or out-of-band via 10/100Base-T Ethernet or RS232.

SIXNET    Clifton Park, NY 12065 0767
Mar 20, 2006 Industrial-rated for operation from -40 to +75°C, 5-port EtherTRAK ET-5MS-OEM-2 draws less than 2 W and offers real-time secure performance with SNMP network management, RSTP support rings, and automatic switchover on segment failure. Unit also has self-test/alarm output signal plus authentication and encryption features. OEMs can create their own Ethernet switch by adding packaging, power supply, and connectors, or they can embed board into existing product or system.

BRUKER AXS Inc    Madison, WI 53711-5373
Mar 20, 2006 QUANTAX(TM) QUAD features XFlash® QUAD 4-channel, 40 mm² silicon drift detector for energy-dispersive spectroscopy (EDS) systems mounted on electron microscopes. Cooled by Peltier element, XFlash QUAD detector requires no liquid nitrogen. Standard energy resolution is better than 133 eV at 10,000 cps. Powered by ESPRIT(TM) software, system is suited for field emission scanning electron microscopes, environmental, and low vacuum scanning electron microscopes.

Datatronics    Romoland, CA 92585 8916
Mar 20, 2006 Measuring 0.493 x 0.493 in. with 0.315 in. seated profile, DR359 Series surface mount inductor/transformer features both parallel and series functionality. Parallel windings feature inductance range from 0.419-1,005.0 mH (±20%), with DCR from 0.00195-1.6600 ohms. Series windings inductance ranges from 1.676 to 4,020 mH (+25%), with DCR from 0.0078-6.640 ohms. Manufactured from UL94V-0 materials to handle harsh conditions, product is designed for hand-held electronic devices.

Pernicka Corp.    Fort Collins, CO 80524
Mar 20, 2006 Addressing high-reliability semiconductor applications, Model 700G Cumulative Helium Leak Detection (CHLD) Test System determines absolute integrity of any type of hermetic package. It uses single-step process and detects leak rates down to one-tenth of one-trillionth of 1 atmospheric cc/sec. System fully implements Mil-Std 750 Method 1071 Procedure CH1-CH2 and features CFC-free operation, enabling medical devices to be 100% tested before use.

Saelig Co., Inc.    Pittsford, NY 14534
Mar 20, 2006 Software utilities let users view, convert, share, and store files used in engineering organizations that need AutoCAD drawing conversion tools, architectural management solutions, and data exchange between different CAD systems. Solutions include DWG to Image Converter, batch DWG and DXF bi-directional converter and file version utility, DWG/DXF to PDF Converter, PDF to DXF Converter, DWF to DWG/DXF Converter, and DWG/DXF to DWF Converter.

Microtune GmbH & Co. KG.    Ingolstadt 85055  Germany
Mar 20, 2006 Integrated into handheld TV devices, Mobile MicroTuner(TM) MT2260 permits users to watch multi-channel broadcast TV with full-motion digital pictures and near CD-quality sound. Multi-band, single-chip MT2260 supports U.S. and European handset devices based on DVB-H industry standard, while single-band MT2262 supports L-band frequency range dedicated to U.S.-based mobile TV broadcast service. Both exceed Mobile and Portable DVB-T/H Radio Access Interface specification.

Atmel Corp.    San Jose, CA 95131
Mar 20, 2006 Featuring on-chip bootloader, AT90USB1286 and AT90USB1287 AVR® Flash MCUs have 128 Kbytes of in-system programmable Flash, 8 Kbytes of RAM, and 4 Kbytes of EEPROM. AT90USB1286 has USB interface for applications needing to communicate with host, while AT90USB1287 complies with USB On-the-Go standard for dual role devices. Products include hardware multiplier, 1 USART, SPI, and TWI, two 8-bit and 16-bit timers, 8-channel 10-bit ADC, and 48 programmable I/Os.

u-blox AG    Schweiz   Switzerland
Mar 20, 2006 Single-chip ATR0630 IC integrates ANTARIS® 4 GPS receiver, including ROM-based software, in 7 x 10 mm 96-pin BGA package. Device supports serial EEPROM memory, and on-chip USB connectivity makes ANTARIS 4-based products plug-and-play compatible in any PC environment by emulating standard COM port to operating system. Featuring 62 mW power consumption, product is suited for mobile phones, PDAs, and smartphones.

Anadigics, Inc.    Warren, NJ 07059
Mar 20, 2006 Penta-Band AWT6223 and AWT6225 power amplifiers are available in 6 x 8 x 1 mm modules and include internal voltage regulators. AWT6223 offers single-package GPRS/EDGE/WCDMA solution by combining IMT-band WCDMA operation with quad-band polar EDGE functionality, while 6225 integrates IMT-band WCDMA PA with quad-band GSM/GPRS capabilities. Using InGaP-Plus(TM) technology, HSDPA compliant products feature bipolar and field-effect transistor structures on same InGaP GaAs die.
