Weidmuller, Inc.    Richmond, VA 23236
May 01, 2007 Featuring vibration-proof, tension clamp connections, Z-Compact mini terminal blocks are UL-rated for 300 V, 20 A and carry UL 94 V-0 flammability rating. Model ZDU 2.5N single-level feedthrough terminal measures 1.4 in. long and mounts on TS-35 DIN-rail. Unit features one pluggable jumpering channel per terminal block and is offered in 3 and 4 branch configurations. Dual level versions, such as ZDK 2.5/3AN, are also available, offering 6 connections and 2 jumpering channels.

Littelfuse, Inc.    Des Plaines, IL 60016
May 01, 2007 Offered in surface-mount 3.3 x 3.3 mm QFN package, SIDACtor® Q2L transient voltage SLIC protector is designed to meet 500 A rating for 2 x 10 µs GR 1089 waveform. Fixed-voltage protector is available in various Vdrm/Vs values and can withstand surge events required in GR-1089-CORE Issue 4, ITU K.20/21 Enhanced levels, and IEC-61000-4-5. When used in place of programmable SLIC protection devices, SIDACtor Q2L removes need for additional components.

Stanley Assembly Technologies    Cleveland, OH 44143-2328
May 01, 2007 Lightweight EA series dc electric threaded fastening tools features compact housing, brushless dc servo motor, and ergonomic handle with multiple light sets for 360° operator viewing. Series also includes angle-style EA tools which use Zerol® spiral bevel gear geometry for durability.

Slaughter Company    Lake Forest, IL 60045
May 01, 2007 Multifunctional 6330 offers test modes for AC Hipot, DC Hipot, Ground Bond, Insulation Resistance, Functional Run, and Line Leakage. In Functional Run mode, unit can monitor min and max readings for voltage, current, power, power factor, and leakage current. This allows manufacturers to ensure DUT is operating as intended. Tester offers 10 memory locations, with 20 steps per memory, and single step mode. For remote testing, 6330 has PLC remote control with safety interlock.

Esco Tool    Medfield, MA 02052
May 01, 2007 Featuring 3 hp motor, APS-438 uses fiberglass reinforced blades to cut alloyed materials up to 4 in. thick. It is available with PanelHog® Quick-Clamp Assembly, which adjusts to fit all types of boiler tube panel sections. Assembly comes with 2 in. wide steel track sections that attach securely using wedge-style clamps. Cut-line indicator gauge facilitates setup and alignment, permitting clean, straight cuts without rework. Assembly eliminates need for tack welding tabs and hot spots.

Energen, Inc.    Lowell, MA 01854
May 01, 2007 Able to achieve image stability to 35 µrad, Energen Image Stabilization System consists of gyrosensor that measures vibration, lens assembly with CCD, digital signal processor, and resident software that enables fully automatic operation. System senses vibration and counteracts its effect (up to 100 Hz) via software-controlled optical elements so that CCD effectively sees Hi-Res image. Applications include mobile-, ground-, air-, or space-based observation platforms.

EAO Switch Corp.    Milford, CT 06460
May 01, 2007 Solid metal S.series features front plate and anti-pull-off keys constructed from Zamak. RoHS-compliant product, sealed to IP67 against water and dust, is resistant to heat, shock, and vibration. In addition to blue, red, yellow, or green LED key illumination, design options include 12 or 16 keys and choice of standard, telephone, or hexi-decimal II configurations. Display and control options include full color front plate designs as well as precision custom laser engraving.

Winkle Industries    Alliance, OH 44601
May 01, 2007 Designed to replace traditional contactors and discharge resistors, OptiCon magnet controllers utilize solid-state IGBTs that provide true control of electrical current to magnets. Three models, rated for 150, 250, and 350 A service, can be installed into new equipment or retrofit into existing systems. Each can be used with any magnet or magnet system, optimizing power delivered to magnet while minimizing excess heat. Controllers also eliminate occurrence of damaging voltage spikes.

Wittenstein, Inc. (formerly Alpha Gear Drives, Inc.)    Bartlett, IL 60103
May 01, 2007 Suited as component of servo and stepper motor applications, alphira® low-backlash planetary gearhead is offered in 4 sizes and 5 reduction ratios. Maintenance-free product is housed in unvarnished aluminum case and exhibits greater than 95% efficiency. Designed for cyclic and continuous operation, gearhead has 20,000 hr service life and is built with lifelong lubrication and sealing.

Anver Corp. - Anver.Com    Hudson, MA 01749
May 01, 2007 Designed for loading and unloading compact boxes weighing up to 95 lb, VT-Series incorporates pad attachment that features two 4 x 9 in. soft rubber suction cups with extended lips that conform to distortion of boxes being lifted from top. System has 100% duty cycle with instant attach and release, heavy-duty vacuum pump, and wire-reinforced tube. To prevent back injuries, series has adjustable up/down controls built into handle and 360° swivel top for unrestricted rotation.

Greenerd Press & Machine Co., Inc.    Nashua, NH 03061
May 01, 2007 Available in various configurations, hydraulic presses feature micro adjustment feature for depth control when die blueing. Models are available in tonnages up to 10,000 tons and with bed sizes exceeding 240 in. While motorized rolling bolsters meet ANSI B11.2-1995 R-2000 standards and facilitate die changes, optional booking rams are available that promote access to underside of top die mold. Along with 4-corner leveling, presses come with knockout and eject capabilities.

General Air Products, Inc.    Exton, PA 19341
May 01, 2007 Self-contained air-cooled Model TAE M10 Process Chiller has features to prevent clouding or browning during fermentation. It features standard quick chill capability to 20-25°F and is enclosed in 30 x 22 in. galvanized steel cabinet with optional caster wheels for mobility. Condenser and airflow properties permit operation in temperatures to 105°F, and low water pressure drop is less than 2 psi. Stainless steel accumulation tank is completely sealed.

Danfoss VLT Drives    Loves Park, IL 61111
May 01, 2007 VLT® Micro Drive offers side-by-side mounting without any de-rating, heat management and coated electronics, ability to copy settings via local control panel, and IP20 protection. It features automatic energy optimizer function, automatic motor adaptation, electronic thermal relay, and logic controller. Compact 2.75 x 6 x 6 in. unit comes in single-phase 200-240 Vac 0.25-2 hp, 3-phase 200-240 Vac 1/3-2 hp, and 3-phase 380-480 Vac 0.5-3 hp configurations.

Elma Electronic Inc.    Fremont, CA 94538
May 01, 2007 Available individually or in conjunction with Elma's 19 in. rackmount enclosures, front panels, or cabinet products, 19 in. front panel frames are designed for applications that do not specify inclusion of complete card frames. Patch fields, displays, interfaces, and other front panel designs can be built up in combination with this solution. In addition to custom design, painting, silk-screening, and component integration services are available.

APEM Components    Haverhill, MA 01835
May 01, 2007 While UL-approved 8000 Series comes standard with push on-push off functionality, it is also available in momentary contact style. Termination options include solder lug and PC in vertical and right-angle configurations. Offered in single- and double-pole configurations, switches are rated for 3 A at 250 Vac, 6 A @ 125 Vac, and 4 A @ 30 Vdc. Expected life is 30,000 cycles at full load, and gold or gold over silver plated contacts are available.

Oaktree Systems, Inc.    Calverton, NY 11933
May 01, 2007 Designed for use by every revenue-generating or revenue-involved staffer/manager in nonprofit organizations, communitEbuilder integrates all direct mail, gift, online, and event databases into one work and information center. Web-based, multi-location, multi-user system manages files with 15,000 to 10+ million records and eliminates prospect duplication and overlap. Specialized modules cover specific event types, and custom modules can be added to meet client requirements.

Oce'-USA, Inc.    Chicago, IL 60656
May 01, 2007 Outsourcing solution integrates Oce ATS (Automated Tracking Software) System with Oce MAX(TM) business performance management system. With it, users can annually track millions of pieces of inbound, outbound, and accountable interoffice mail as well as overnight and courier deliveries. Tracking capabilities extend from requestor's desktop to recipient's desktop, across enterprise, while driving continuous process improvements using Six Sigma® methodology.

Parlano, Inc.    Chicago, IL 60606
May 01, 2007 Featuring complete integration with MS Office Live Communications Server 2005 unified communications platform, MindAlign(TM) 2007 offers federated persistent group chat capability utilizing SIP/SIMPLE unified communications standard. Software offers identity management, protection from spam and viruses, and word filtering as well as ability to transition between different forms of communication directly within MindAlign.

Efficient Frontier    Mountain View, CA 94043
May 01, 2007 Efficient Frontier for Agencies enables advertising agencies to deliver paid search advertising technology and campaign management to their clients. Available for traditional and interactive ad agencies of any size, this integrated SEM solution combines client services with bid management technology based on Wall Street analytics and portfolio management approach. Choice of partner-reseller relationship, white-label, or co-branded offering is available.

Gresham Storage Solutions    Austin, TX 78752-3714
May 01, 2007 Clareti® Virtual Tape Library (VTL) v2.0 delivers integrated data protection management and heterogeneous tape library consolidation. Offering visibility, scalability, and management for existing third-party tape backup application environments, solution combines storage analytics and reporting. Software is built on scalable multi-node architecture and enables users to monitor resource usage and system fidelity in detail as their backup data grows.
