AMETEK Solartron Metrology    Gastonia, NC 19301
Oct 30, 2007 Available in 23.5 and 27.5 mm models, DZ Series Probes provide 1 and 2 mm measuring range, respectively. Transducers are sealed using Viton® boot to exclude dust and moisture and meet IP65 requirements. Tips with M2 thread are available for various applications and can be replaced in field without returning them to factory. Offered in digital versions only, probes facilitate setup since neither electrical zero nor sensitivity are needed.

Bussmann Div., Cooper Industries    St. Louis, MO 63178
Oct 30, 2007 Cooper Bussmann® Quik-Spec(TM) Safety Switch features IP-20 finger-safe CUBEFuse® integration with current-limiting Class J performance for reducing arc-flash hazards. Flange-operated handle can be operated with electrical gloves and is lockable with up to 3 padlocks to protect maintenance workers. Heavy-duty switch meets NEC® 110.9 requirements and is listed to UL98 and UL50. Optional easyID(TM) fuse-viewing window is available.

Envirosight LLC, Video Pipeline Inspection    Randolph, NJ 07869
Oct 30, 2007 Wireless equipment for QuickView pipeline zoom camera consists of compact transmitter that is part of QuickView operator vest and receiver that connects to remote viewing or recording device. Video can be transmitted in real-time up to 1,000 ft line-of-sight and 300 ft otherwise using one of 8 user-selectable channels in 5.725-5.875 GHz range. System includes transmitter holster that also attaches to vest.

Astrosyn International Technology Ltd    Kent   United Kingdom
Oct 30, 2007 Lawtronics HSK extruded aluminum units consist of 2 sliding channels together with end panels, enabling electronics to be worked on while top half of casing is slid open. Able to house toroidal transformer of up to 100 VA, uninterlocking heatsink enclosures allow eurocard boards to slide into internal card guides and 2 boards can be mounted within. Free-standing or 3U rack mount models are available in 160 or 220 mm lengths with normal wall thickness of 2 mm.

Flomatic Valves Div., The Danfoss Group    Glens Falls, NY 12801
Oct 30, 2007 Hydro Stat(TM) Model C3100 constant pressure pump control valve reduces rapid pump cycling and maintains preset operating pressure which is field adjustable. It features low lead alloy body and bell housing that has threaded female ID x male OD on inlet and outlet connections as well as corrosion-resistant internal components with Nylon reinforced Buna-N diaphragm. Valve can be installed vertical or horizontal and in wall casing.

Anti-Seize Technology Industries, Inc.    Franklin Park, IL 60131
Oct 30, 2007 Offering smooth consistency, Tuf-Set(TM) blue pipe-thread sealant stays flexible to resist vibrations and thermal expansions or contractions found in HVAC industry. Product has no PTFE or heavy metals, and can be used on all metal and most plastic pipe connections. Able to withstand temperatures from -40 to 400°F and liquid pressures to 10,000 psid, Tuf-Set is non-seizing to allow disassembly and corrosion inhibiting for sealing wide variety of chemicals.

Ametek Chatillon, Test & Calibration Instruments Div.    Largo, FL 33773
Oct 30, 2007 Suited for corrosive applications, XR-Series features back plates that vent instead of blowing out and solid front design that prevents internal components from becoming projectiles in case of rupture. All-welded gauge-to-seal design and seamless Bourdon tubes minimize leak paths while promoting burst or rupture pressure performance. Two models are available, XR--81 and XR-86, respectively built with USG Model 1981 and 1986 gauges featuring 316L stainless steel and MONEL® internals.

Dueco, Inc.    Waukesha, WI 53187
Oct 30, 2007 In addition to 255 hp, 660 lb torque IHC MaxxxForceDT, and Automatic Allison 3500_RDS_P transmission, 2008 4300 SBA 4x2 features PHEV propulsion system that minimizes fuel use and emissions. Unit can recharge at off-hours using electricity from nation's electric grid or at any point with conventional diesel engine. Battery management systems, in conjunction with control technology, also powers Terex material handling aerial device (TLM50M) for up to 8 hr of aerial lift operation time.

CIT Relay & Switch: Division of Circuit Interruption Technology, Inc.    Maple Grove, MN 55369
Oct 30, 2007 Available with no frame and cap or square/round frame with cap, CL1200 Series momentary lighted SPST pushbutton switches feature polycarbonate cover, 6/6 Nylon actuator and housing, and silver-plated stainless steel contacts with terminals of silver-plated brass. Various combinations of frame colors and cap colors are available, in lighted or non-lighted configurations. Optional LED colors include standard or super bright red, green, yellow, and blue as well as bi-color versions.

Rockwell Automation    Milwaukee, WI 53204
Oct 30, 2007 FactoryTalk Historian SE collects stores, analyzes, and visualizes production data using data capture and storage engines, which can be used within process, discrete, and hybrid environments. It utilizes variety of reporting tools such as time-series trends, bar charts, pie charts, and tabular trends an also features compressed storage data algorithms that contain vast amounts of data in small storage formats so users can retrieve data quickly over short or long time spans.

Schurter, Inc.    Santa Rosa, CA 95403
Oct 30, 2007 Available with single-pole momentary actuation, vandal-proof MSM switch is also offered in double-pole and sealed microswitch versions. MSM DP momentary switch has 2 separate switching contacts that can be used as NO, NC, or as change-over. MSM SPDT and DPDT switches have seal protection to front of actuator as well as to panel with sealing o-ring. IP67 microswitch option provides integrated seal between actuator and microswitch as well as around switch terminals.

MetalOptics    Austin, TX 78758
Oct 30, 2007 Suited for high bay, retail, warehouse, and manufacturing applications, GreenBay(TM) high-intensity fluorescent lighting fixtures are designed to minimize packaging, material waste, weight, and floor space requirements. Packaging design uses pallet configuration that eliminates individual boxes, and interlocking tabs that remove need for cardboard protecting each fixture. Units are shipped with lamps, power cords, and hangers installed, minimizing installation time.

Durable Mecco    Franklin Park, IL 60131
Oct 30, 2007 Delivering hand protection, Safety First Stamp Grip provides 4 in. diameter shield and acts as extension of hand stamp, offering alternative for operators who prefer to hold stamps in-hand. Unit is molded from urethane with striking anvil made from heat-treated shock steel.

Karcher    Camas, WA 98607
Oct 30, 2007 Operating on 460 V, 3-phase electrical power, pressure washers generate instant hot water spray when upon trigger pull with nine 4,500 kW heating elements. Products deliver cleaning power from 3.5-4.2 gpm and pressure 2,000-3,000 psi with integral belt-driven, industrial-duty, tri-plunger, high-pressure pump that accepts water at up to 180°F. Features include automatic start/stop; spring-loaded, insulated trigger gun with variable pressure wand; and detergent injection system.

Aremco Products, Inc.    Valley Cottage, NY 10989
Oct 30, 2007 Used to protect metal components and structures in industrial applications, Corr-Paint(TM) CP2060 adheres to marginally prepared metal surfaces and is resistant to corrosion, chemicals, thermal shock, salt spray, and UV rays. Silicon carbide filled protective coating is offered as 2-part, 100% solids, epoxy-novolac, abrasion resistant system that mixes to thick paste and can be applied via trowel or spatula. It sets and cures fully at room temperature in 24 hr.

IMI Sensors, Div. of PCB Piezotronics    Depew, NY 14043-2495
Oct 30, 2007 Suited for monitoring unbalance and misalignment on motors, pump sets, and other rotating equipment, Model 682A08 Vibration Transmitter is ICP® accelerometer signal conditioner that retransmits acceleration or velocity signal as 4-20 mA signal for trending and simple interface with PLC, DCS, and SCADA systems. DIN rail mounted and 24 Vdc powered unit comes with selectable low pass filters at 1 or 10 kHz and high pass filters at 3 or 10 Hz.

Master Bond, Inc.    Hackensack, NJ 07601
Oct 30, 2007 With elongation of greater than 60%, Type EP21TDCSFL is 100% reactive epoxy adhesive that has has 1:1 mix ratio by weight/volume, does not contain diluents/solvents, cures at room temperature, and offers mechanical shock resistance and low outgassing properties. Features include volume resistivity of less than 10^-3 W cm, tensile shear strength of greater than 1,500 psi, T-peel of greater than 30 pli, and thermal conductivity of 11 BTU/in./ft²/hr/°F.

HBM, Inc.    Marlborough, MA 01752 3014
Oct 30, 2007 Featuring integrated Advanced Plug & Measure (APM) technology, QuantumX comes with 8 connectors each of which independently recognizes and supports all transducer technologies. Up to 128 CAN signals can be acquired on one connector. Transducers fitted with TEDS technology are automatically recognized as soon as they are connected to instrument, while transducers without TEDS are configured using expandable sensor database.

ADLINK Technology Inc.    Irvine, CA 92618
Oct 30, 2007 High Speed Link (HSL) U Series digital, distributed I/O slave modules have flat-bottom housing for tight spaces as well as connector options. With 16 discrete input and 16 discrete output channels, Model HSL-DI16DO16-UJ-N/P offers separate I/O connectors to allow debugging without affecting other I/O channels, while Model HSL-DI16DO16-US-N/P offers shrouded connectors with latch-lock. Model HSL-DI16-UL features 16 discrete input channels and pulse stretcher function.

Rubbermaid Commercial Products LLC    Winchester, VA 22601
Oct 30, 2007 With capacity to clean 850 square ft/fill, Rubbermaid Pulse(TM) Floor Cleaning System carries 21 oz of cleaning solution on-board and is refilled automatically with Rubbermaid Pulse(TM)Caddy. Microfiber system has ergonomic trigger handle that delivers 3 streams of cleaning solution whenever needed, and full-length view windows to see how much liquid is left. Quick Connect frame facilitates switching to 11 or 24 in. Rubbermaid microfiber frame.
