Paul N. Gardner Co., Inc.    Pompano Beach, FL 33060 6608
May 23, 2008 Suited for outdoor/indoor use, IP5X-rated PosiTector DPM II measures and records relative humidity, air temperature, surface temperature, dew point temperature, and difference between surface and dew point temperatures. Unit features graphic LCD with multilingual support, audio and visual alarm, bi-color indicator light, and graph mode that charts parameters. Internal Memory stores 2,500 datasets in 100 batches with touch of button, while USB and IR ports enable downloading to PC or printer.

Electro Standards Laboratories    Cranston, RI 02921 3403
May 23, 2008 Model 7356 6-Channel RJ45 Cat 5 A/B Switch allows users access to 2 separate devices, ports A and B, via connection through a device connected to common port for each of switch's 6 channels. Each channel is individual switch that is independently controlled, and switch ports are transparent to all data. Product offers users flexibility for manual control via front panel pushbuttons or remote control from RS232 serial port located on rear of unit.

Jeio Tech, Inc.    Des Plaines, IL 60018
May 23, 2008 Consisting of 3 models, IS-971 Incubated and Refrigerated Floor Model Shaker Series includes choice of orbital/reciprocating action shaking motion with speed range from 10-300 cycles/min and maximum orbit diameter of 70 mm. Run time can be programmed from 1.0 sec up to 1,000 hr. Model IS-971 has temperature range of 5°C above room temperature to 60°C, while Models IS-971R and IS-971RF have temperature ranges from 4-60°C. Temperature uniformity is ±1.0°C at 38°C.

Advantech Automation Corp.    Cincinnati, OH 45240
May 23, 2008 With peer-to-peer functionality provided in firmware, ADAM-6000 distributed Ethernet I/O modules can actively update input channel status to specific output channels. Data will transfer automatically, with no extra controller or programming needed. GCL software utility, also included, adds control logic between input and output, and can create equivalent instructions to simple ladder logic instructions on PLC's. It also supports flexible cascade function locally or over Ethernet network.

Gigahertz-Optik Inc.    Newburyport, MA 01950 4009
May 23, 2008 GB modular goniometric bench can perform PC remote controlled angular dependent light measurements of LEDs in conjunction with standard optometer or light analyzer. Rotary tables form base of GB system used for horizontal and axial rotation of light source, and GB modules include adapters for various types of LEDs, enabling individualized measurement set-ups. For measurements outside darkroom, GBE-LTE light tight enclosure can be added to bench.

Trijay Technologies International Corp.    Newport Beach, CA 92663
May 23, 2008 Law Enforcement version of Model ST4EXLE mobile biometric identification terminal features integrated optical fingerprint scanner digital camera with flash to enable evidence gathering, remote photo capture, and capturing and matching of fingerprint templates. Built-in Secure Access Module also supports use of digital keys for card schemes requiring high security, while GSM/GPRS module provides high-speed data transfer and voice calls over mobile networks.

Meritech, Inc.    Golden, CO 80401
May 23, 2008 With ability to remove microbial pathogens from gloved and bare hands, five automated hand hygiene systems clean hands using high-pressure, low-volume water spray in 10 sec. Suited for foodservice, healthcare, and all facilities where hand hygiene and preventing cross contamination are required, products help prevent spread of disease.

NTE Electronics, Inc.    Bloomfield, NJ 07003
May 23, 2008 Available in blue, green, red, white, amber, and red/white/blue colors, LED tubing contains 15 bright LEDs that are encased in flexible clear encapsulate. Measuring approximately 1 ft long, up to 15 individual tubes can be connected in series and powered by one 12 Vdc power supply. Available accessories include multi-strip surface mount connector, surface mount multi-strip L connector, rotatable mounting clip, multi-strip electrical connector, and power supply adapter.

TRX, Inc.    Atlanta, GA 30329
May 23, 2008 Part of Online Booking product suite, RESX Professional Services provide consulting and outsourced services to travel management companies and corporations using RESX online booking tool, allowing travelers to create policy-compliant and on-budget travel reservations via hosted Web interface. Services include Site Audit, where corporate travel sites are reviewed and analyzed; implementation services for new RESX sites; customized development for site add-ins; and site administration.

Panda Software    Glendale, CA 91204
May 23, 2008 Suited for SMBs, Panda Managed Office Protection(TM) provides Web console that allows organizations to manage protection remotely. Collective Intelligence automatically detects, correlates, and responds to malware found across entire network of PCs. Updated information to protect against zero-day attacks can be configured by administrator from web console and can also be forced on demand. With periodic security audits of network, program helps enforce compliance.

Ambric, Inc    Beaverton,, OR 97006
May 23, 2008 Ambric aDesigner(TM) utilizes structured object programming model and performance analysis capabilities to enable optimization of program execution across hundreds of processors. IDE allows for seamless programming across processors, leveraging channel communication built into the Am2000 MPPA and enabling users to synchronize debugging across all processors. Designs can be tuned during both simulation and real-time hardware execution.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Designed for TV transmitters utilizing analog/digital modulation formats, MRF6VP3450H delivers more than 450 W peak power at P1 dB with 50% efficiency across UHF band. Using DVB-T 64 QAM OFDM signal at 90 W average output power, typical 860 MHz 50 V performance is 28% drain efficiency and 23 dB gain, with adjacent channel power ratio at 4 MHz offset of -62 dBc in 4 kHz bandwidth. Rugged 50 V LDMOS unit handles very high impedance mismatches without damage and incorporates ESD protection.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Featuring 32-bit MCF5234 processor based on V2 ColdFire core, M5234BCCKIT Hardware Toolkit enables developers to evaluate embedded applications using IXXAT's IEEE® 1588 protocol stack and TCP/IP stack from CMX Systems. Kit incorporates 10/100 Mbps Ethernet controller, 16- or 32-channel enhanced Time Processor Unit, and National Semiconductor's DP83640 PHYTER® Ethernet PHY transceiver, which time stamps Ethernet packets as they enter board at physical layer.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Designed to help reduce board space and power consumption, MC9S08SH32 (SH32) and S9S08SG32 (SG32) provide flexibility and functionality developers need to design embedded applications. While SH32 suits general-purpose consumer and industrial applications, SG32 has extended temperature range (+125°C) designed for general-purpose automotive applications. Memory options include up to 1,024 B RAM and 16 or 32 Kb flash, and integrated 10-bit Adc converter has built-in temperature sensor.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Manufactured on 90 nm CMOS technology, MPC5123 combines 400 MHz Power Architecture(TM) e300 core with multimedia co-processor. It offers variety of on-chip peripherals and comes bundled with Linux® OS-based starter kit that helps reduce application complexity. While on-chip integrated display controller provides support for LCD/TFT displays, 128 Kb on-chip SRAM and embedded memory buffers help ensure balanced system performance and system bus throughput while reducing latency demands.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Combining on-chip color LCD and touch-screen controllers, 32-bit ColdFire® MCF5227x devices accelerate deployment of graphical display interfaces with touch-based control without requiring developers to design-in numerous discrete controllers and other components. On-chip connectivity options, which include CAN module, as well as USB host, device, and OTG module, promote flexibility to standardize or upgrade serial communications. Four low-power modes optimize power consumption.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Operating at 40 MHz with bus speeds up to 20 MHz, S08AC60/48/32 integrated 8-bit S08AC MCUs provide flexible, scalable, general-purpose solutions with which to expand flash memory range and performance options for control modules in white goods. Products offer 60, 48, and 32 K flash memory, respectively, and feature on-chip timers as well as ADC. To enhance system integrity, MCUs integrate hardware and software safety features to help meet IEC 60730 class B regulation.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Flexis(TM) JM family includes 32-bit MCF51JM128 ColdFire® MCUs and 8-bit MC9S08JM60 devices. Software- and pin-compatible, they enable designers to migrate from 8-bit designs to complex application designs that require 32-bit performance. MCUs integrate CAN module and USB controller supporting USB 2.0 full-speed host, device, and On-The-Go configurations, and include up to 128 Kb flash memory and up to 16 Kb SRAM. Featuring 2.7-5.5 V operating range, units operate from -40 to 105°C.

Freescale Semiconductor    AUSTIN, TX 78735-8598
May 23, 2008 Offering selectable 1.5-12 g range, triple-axis Series MMA73xxL tackles various sensing functions, such as fall, tilt, motion, positioning, shock, and vibration in mobile phones, hard disk drives, media players, and games. Self-test diagnostic feature verifies accelerometer is in working order at any time before or after it is implemented in design. Housed in 3 x 5 x 1 mm LGA package, devices operate at 2.2-3.6 V and consume 400 µA while offering response time of 1 ms.

Micro Pneumatic Logic, Inc.    Pompano Beach, FL 33069
May 23, 2008 Rated between 0.01-0.75 in. H₂0, MPL 5000X miniature pressure switch features proof pressure of 1.0 psi with burst pressure of 25 psi. Switch performs in operating temperature range of -40 to 120°F and utilizes metal contacts. Suited for PCB mounting, it can be incorporated into miniature assemblies for medical applications like nebulizers, portable oxygen concentrators, and other forms of drug delivery systems.
