X-Rite, Inc.
Grandville, MI 49418 2567
Sep 30, 2008 MatchRite® iVue(TM) helps retail paint departments match paints with color samples. It can operate in horizontal or vertical position and projects ¼ or ½ in. dia ring of light onto item to show exactly where colors are being measured. Weighing about 5 lb, solution utilizes solid-state technology; requires calibration once per week; and measures samples, even on curved surfaces, from distance of 1.5 in.

Z-Communications, Inc.
San Diego, CA 92126
Sep 30, 2008 Operating in S-band from 2,300-2,450 MHz with tuning voltage range of 0.5-4.5 Vdc, RoHS-compliant V804ME14-LF features typical phase noise of -99 dBc/Hz @ 10 kHz offset and typical tuning sensitivity of 52 MHz/V. Product delivers typical output power of 4.5 dBm at 5 Vdc supply while drawing 25 mA (typ) over -40 to 85ºC range and features 2nd harmonic suppression of -20 dBc (typ). VCO comes in 0.50 x 0.50 x 0.13 in. MINI package with low shield.

Z-Communications, Inc.
San Diego, CA 92126
Sep 30, 2008 Operating in L-band from 1,190-1,610 MHz with tuning voltage range of 0.5-8.5 Vdc, RoHS-compliant V585ME04-LF features typical phase noise of -97 dBc/Hz @ 10 kHz offset and typical tuning sensitivity of 90 MHz/V. It delivers typical output power of 6.75 dBm at 5 Vdc supply while drawing only 15 mA (typ) over -40 to +85ºC range and comes in 0.50 x 0.50 x 0.22 in. MINI package. Solution is suited for automated surface mount assembly and reflow.

Keyence Corporation of America
Woodcliff Lake, NJ 07675
Sep 30, 2008 Featuring edge-to-edge mounting and side-exit cabling, SL-V Safety Light Curtain incorporates green indicator lights for when beam axes are aligned and red lights to indicate curtain blockage. Up to 3 curtains, or 240 beams maximum, can be connected in series and curtain lengths are available up to 94.09 in. Built-in external device monitoring function as well as muting and interlock functions are included. Recessed lens cover and aluminum-framed brackets offer further protection.

Rofin-Baasel Inc.
Boxborough, MA 01719
Sep 30, 2008 Eliminating first-pulse effect, sweet spot resonator® prevents variation in weld penetration depth and creates even weld profile. Pulse-to-pulse stability and large depth of field enable optimal results to be obtained in manual welding applications. Using MicroWeld(TM) function, unit allows processing of delicate components with weld spot diameters smaller than 100 µm. In addition to processing highly reflective materials, resonator is suited for seam welding on sheet metal.

Koch Knight LLC
East Canton, OH 44730
Sep 30, 2008 Available in standard ceramic or glaze-resistant construction, 1 in. FLEXISADDLE(TM) LPD® features high open area and aerodynamic design that results in low pressure drop and efficient heat transfer, optimizing capacity of regenerative thermal oxidizers in ethanol industry. Ceramic, 3-rib structure limits nesting and withstands chamber loading, minimizing dead areas that collect particulate.

Densitron Corp.
Santa Fe Springs, CA 90670
Sep 30, 2008 Measuring 85 x 55 mm with 2.9 in. diagonal active area, Negative Mode LCDs with Tri Color LED Backlights deliver touch capability in form factor of many handheld and rack size applications. Units offer optimal cell gap control making them suited for audio, instrumentation, medical equipment, and industrial indoor meters. LCDs are also available in single colors with and without touchscreen.

Millipore Corp.
Bedford, MA 01730
Sep 30, 2008 Available in 10-, 20-, and 30- in. sizes, Solvex(TM) Solvent Filters provide validated and sterile filtration for solvent-based active pharmaceutical ingredients (APIs) and are suitable for filtration of wide variety of organic solvents. Product design promotes consistent, repeatable manufacturing process characterized by high-capacity, low extractable, and resistance to thermal and hydraulic stress. Unit can be reused multiple times, and steamed in place up to 135°C.

Millipore Corp.
Bedford, MA 01730
Sep 30, 2008 Featuring configurable 500 L container, Mobius MIX500 disposable mixer can be used with Mobius process containers, Lynx® connectors, Opticap® filters, connectors, and tubing. Magnetically-driven, instant-on impeller minimizes particle generation and enables risk-free media and buffer preparation. Unit is suitable for mixing pharmaceutical ingredients from intermediates to final drug products and for preparation of process solutions, such as buffers and media.

Milton Roy (UK) Ltd
Wokingham Berkshir RG41 2FD  United Kingdom
Sep 30, 2008 With 4 versions and large variety of liquid ends available, Roytronic® is mechanically actuated diaphragm electromagnetic pumping system for chemical products, fluorinated products, and amines. IP65 resistant product offers thick wall IXEF reinforced thermoplastic construction and integrated metal-plastic structural and magnetic components. Features include 12.1 Lph maximum output, 17.3 bar maximum pressure, 50°C maximum temperature of pumped chemical, and accuracy ±2% of adjusted output.

BVM Ltd
Southampton Hampsh SO30 0GH  United Kingdom
Sep 30, 2008 Designed for video-intensive and sound-rich applications, Model LV-66A Mini-ITX format embedded motherboard can also be used as Network Access Server, POS engine, or in ATM application. Based on VIA C7 1.5 GHz fanless processor with up to 4 Gb of 667 MHz front-side bus SDRAM and powered from standard 20-pin ATX PSU, it offers storage, multimedia, and connectivity options, including Serial ATA with RAID support, UltraDMA IDE, 8 USB 2.0, 2 Giga LAN, and 2 COM ports.

Electri-Flex Co.
Roselle, IL 60172 1994
Sep 30, 2008 Comprised of nylon conduit, connectors, and accessories, Corrlok® System suits passenger rail vehicle wiring, industrial control equipment, robots, and machine tool applications. Available in CL, CLR, CLL and CLFR conduits, Corrlok is lightweight, liquidtight, and withstands tough environments. One-piece connectors come in straight and angled, flanged, and threaded models. Mounting brackets, reducers, and specialty connectors including metric and PG threads are also available.

Scapa North America
Windsor, CT 06095
Sep 30, 2008 Providing permanent bonds to glass, foil, metal, composite, and plastic substrates, Scapa acrylic foam tapes (AFT) help protect solar panel assembly from corrosion, vibration, and other stresses found in outdoor applications. Formulated to withstand UV, weather, and temperature variations as well as thermal movement, tapes maintain adhesion even at sub-zero temperatures, offer aging and weathering properties, and do not absorb moisture or become brittle with age.

Nixalite Of America Inc.
East Moline, IL 61244
Sep 30, 2008 Bird Buffer(TM) electronic aerosol generator converts liquid Fog Force grape food flavoring into tiny nano-particles which, when blown into air at 90 mph, create invisible haze that stays suspended in air for 6 hr. Birds that fly through haze associate location with repellent's effect and leave area for good. When used indoors, haze does not damage paint. Applications include packing/processing facilities, airport equipment and plane storage, and landfills and recycling centers.

CTC International, Inc.
West Caldwell, NJ 07006
Sep 30, 2008 With ability to wind rolls up to 10 in. dia on core sizes ranging from 1-3 in. ID, VTR Turret Rewinder operates directly in line with press, providing single pass non-stop finished roll label production. Standard features include automatic core glue, automatic tail glue, doctor blade glue wheels, PLC control, automatic swing back core stop, and it requires no mechanical press connections. Turret can also be used for off-line finishing applications.

Calex Instrumentation Ltd
Leighton Buzzard Be LU7 8TE  United Kingdom
Sep 30, 2008 With response time of 240 msec, PyroEpsilon non-contact temperature sensors provide linear 4-20 mA output representing target temperature plus 4-20 mA input to control sensor's emissivity setting. Model PE21 has 2:1 optics making it suitable for applications where sensor can be mounted close to target, Model PE151 is designed for small/distant targets and has optical resolution of 15:1, while Model PE301 is intended for very small/distant targets and has optical resolution of 30:1.

Quantum3D Inc.
San Jose, CA 95119
Sep 30, 2008 Certifiable to DO-178B for software and DO-254 for hardware, Sentiris AV1 combines video- and graphics-processing capabilities with dual RGB and dual HD-SDI outputs to enable 3D graphics in cockpits and mission-critical applications. Suited for harsh environments, unit meets shock, vibration, temperature, and other requirements of MIL-STD-810F. It offers 512 MB ECC-protected DDR2 memory and 8 lanes of PCI Express, and comes standard as conduction-cooled XMC.

Phihong USA
Fremont, CA 94539
Sep 30, 2008 Model POE60U-560G 60 W midspan can power wireless access point arrays and thin client computer terminals that require up to 52 W of low voltage dc power. Available in non-vented case with 10BASE-T, 100BASE-T, and 1000BASE-T data rates and UNH IOL test report, Model POE45-120 is 45 W dc-dc gigabit-compatible splitter that divides power and data and converts from PoE source to regulated low voltage dc power source that can be mounted adjacent to any Ethernet device.

Regal Components, Inc.
Clearwater, FL 33762
Sep 30, 2008 Featuring heads that are finished and chamfered for proper seating and annealed to facilitate machining, Regal Thru-Tuff(TM) M-2 HSS Ejector Pins are stocked in 6, 8, and 10 in. lengths in fractional (TT type) diameters, and .0005, .001, .002, and .005 in. standard oversize (TTO type) diameters. Available in straight/shoulder styles, they are suitable for molding nylon and other parts with high glass content resins. Modifications such as heat flats, vents, and spherical radii are optional.

DATAMARS INC.
Peachtree City, GA 30269
Sep 30, 2008 Suited for applications in industrial laundry sector where manual count and sorting processes are required, Model R-IN1300 MID features light weight and compact design, and when manually sorting textiles, allows operators to identify multiple items in one sweep, reading up to 50 LaundryChips(TM)/sec. ISO 18000-3 13.56 MHz RFID reader/writer has full ISO tag compatibility and web server configuration as well as application software for efficient management of data.
