Bosch Sensortec    Reutlinge 72770  Germany
Dec 02, 2009 Supplied in 3 x 3 x 0.9 mm package, BMA120 recognizes spatial position and positional changes of mobile devices and classifies them within random movement, rotational movement, tapping, and fast/slow categories. Programmable interrupt controller directs mobile phone functions according to targeted movements of device. Supporting 4 programmable measuring ranges from ±2 to ±16 g, sensor provides SPI and I²C interfaces and interrupt output as well as low-power and programmable sleep modes.

Maxim Integrated Products    Sunnyvale, CA 94086
Dec 01, 2009 Targeted at SFP+ Ethernet and Fibre Channel applications, MAX3799 delivers up to 14 Gbps performance while consuming 320 mW. Device offers programmable receive functions such as data rate; LOS threshold, squelch, and polarity; CML output level; and signal-path polarity. Programmable transmit functions include modulation current, bias current, polarity, deemphasis, eye-crossing adjustment, and eye safety control. Housed in 5 x 5 mm, 32-pin TQFN package, chip operates from -40 to +85°C.

Maxim Integrated Products    Sunnyvale, CA 94086
Dec 01, 2009 Offering ±10% accurate current limit that can be programmed from 250-1,500 mA with external resistor, MAX14523A/MAX14523B/MAX14523C protect host devices against damage caused by faulty load conditions, and provide reverse-current blocking to prevent current from being dumped back into source. Low shutdown current of 0.5 µA makes devices suited for cell phones, MP3 players, and other battery-powered applications. Housed in 3 x 3 mm TDFN package, units operate from -40 to +125°C.

SUYIN Connector GmbH    Pfarrkirchen 84347  Germany
Dec 01, 2009 Designed to mount SFP transceivers, right-angle SMT SFP/SMA Connector consists of bottom plate with 20-pin, surface mount contact unit; high temperature-resistant plastic insulation cover in accordance with UL94 V-0; and cage, which is mounted on PCB using 8 press-fit connections. Maximum contact resistance is 20 mW and minimum insulator resistance is 500 MW. For LED signal indication on front panel, both versions can be fitted with light pipes.

Maxim Integrated Products    Sunnyvale, CA 94086
Dec 01, 2009 Models MAX9617 and MAX9618 zero-drift, rail-to-rail operational amplifiers are packaged in 6-pin SC70 and 8-pin SC70 packages, respectively. They feature 10 µV input-offset voltage, input-voltage noise of 1 µVP-P from 0.1-10 Hz, as well as 5 nV/°C input-offset-voltage drift. Consuming 59 µA of quiescent current per amplifier, units are specified for temperatures from -40 to +125°C. Amplifiers have rail-to-rail inputs and outputs and operate from 1.8-5.5 V supplies.

Advantech Automation Corp.    Cincinnati, OH 45240
Dec 01, 2009 As embedded controller for chamber applications, fanless ARK-3202 is powered by Intel® ATOM(TM) CPU and supplied in rugged chassis. I/O interfaces - DVI and VGA dual displays, mic in, line out, dual Giga LAN, optional 8-bit DIO, USB 2.0, GPS, and serial ports with RS-422/485 auto flow control - promote application adaptability. Solution also supports range of Mini PCIe interface communication modules, including WLAN and HSDPA, for wireless in-vehicle applications.

Animatics Corp.    Santa Clara, CA 95054
Dec 01, 2009 Measuring 3.68 x 1.815 x 0.35 in., Model RTC-3000 can operate virtually any small brushed or brushless DC servo. Stand-alone system includes controller, amplifier, logic power supplies, and program interpreter with 32 k program memory and 32 k data storage. General purpose I/O provides several channels of 10-bit analog input, while AniLink(TM) port links to peripherals such as LCD displays. Up to 120 RTC-3000 systems can be combined on single RS-485 network.

Atmel Corporation    San Jose, CA 95131
Dec 01, 2009 Offering 512 bytes or 1 KB in-system programmable flash, 6-pin tinyAVR® MCU models ATtiny4/5/9 process up to 12 MIPS at 12 MHz to reduce time in active mode and increase time in sleep modes. Pin- and code-compatible products facilitate migration between projects with different requirements. While 8-bit ADC is specific to ATtiny5, all models feature 32 Bytes internal SRAM, one 16-bit timer/counter with PWM channels, analog comparator, and 1.8-5.5 V operation.

Synology Inc.    Taipei 103  Taiwan
Dec 01, 2009 Supporting 3.5 and/or 2.5 in. 2 TB hard drives, Synology DS210j/DS410j respectively feature 3/2 USB ports and support up to 4/8 TB storage. Each is powered by 800 MHz CPU and features 128 MB DDRII RAM and one Gigabit LAN port. Cable-less design facilitates installation, and Disk Station Manager v2.2 firmware optimizes file sharing and multimedia content streaming capabilities. Other features include DLNA-compliant media server and support for iPhone(TM) and Apple® Time Machine®.

DP Technology Corp.    Camarillo, CA 93012
Dec 01, 2009 ESPRIT® emphasizes use of milling/turning in any combination and on any type of machine tool. FreeForm 5-axis composite machining cycle lets users independently define machining patterns and tool orientation strategies to be used when creating simultaneous 5-axis tool path. It includes 20 machining strategies (cycles) in one, providing range of possibilities. Also, composite machining cycle enables simultaneous 5-axis machining of diverse parts for various industries through one UI.

Semikron Inc    Wilton, NH 03086
Dec 01, 2009 SEMiXBOX is IGBT-based modular power assembly that allows for different variations with 1- or 3-phase inverter, rectifier, and chopper, providing any required topology up to 180 A. Consisting of 1 or 2 main box sections, it is composed of SEMiX diodes, thyristors, or IGBTs assembled onto compact cooling system with heat sink and fan coupled to low-inductance DC link. Assembly is enclosed in IP20 unit and is EMI-shielded. Current sensing system is optionally available.

Semikron Inc    Wilton, NH 03086
Dec 01, 2009 Semistack power electronics platform with SKiiP intelligent power modules allows users to connect stacks in parallel, supporting applications from 450 kW for solar to 2.5 MW for wind power. System's 3 half bridge phase modules are arranged in vertical configuration, linked via low-inductance DC connector. It is available as power assembly with mounting brackets or as cabinet with cooling circuit and AC and DC connections, with choice of air or water-cooling.

Bosch Rexroth Corporation    Hoffman Estates, IL 60192-3707
Dec 01, 2009 Model TC08 valves measure 16.8 mm wide and offer flow of 600 L/min and TC15 units measure 21 mm wide and provide 1,100 L/min flow. Double 3/2-way functions enable full nominal flow on all valves, even during simultaneous operation, and minimize energy consumption and cycle times. Electrical connections are enabled by DIN 15217 and M8x1 plug connectors. Valves suit wide range of applications/tasks in automation.

Semikron Inc    Wilton, NH 03086
Dec 01, 2009 SEMITRANS 2, with 34 mm wide case, and SEMITRANS 3 and 4 modules, measuring 62 mm wide, are 1,200 V modules for use in AC/DC converters in 20-300 kW power range. Available with V-IGBT chips, units offer rated current of 150-600 A and have IGBT switching speed of 5000 A/µs, enabling module overvoltage of 75 V. Insulation strength is 4,000 V/min and modules are also available with blocking voltage of 600 and 1,700 V. Products come in single-switch, half-bridge, or chopper topology.

Microchip Technology, Inc.    Chandler, AZ 85224 6199
Dec 01, 2009 Model PIC24FJ64GA104 general-purpose MCUs feature 16 MIPS performance, 32 or 64 Kb Flash, 8 Kb RAM, and ability to reconfigure digital I/O pins via peripheral pin select. In addition, PIC24FJ64GB004 units also provide full-speed USB 2.0 peripheral, embedded host, and OTG solution. Both 16-bit MCUs feature nanoWatt XLP technology for low power consumption and mTouch(TM) capacitive touch sensing. They are available in 28-pin QFN, SOIC, and PDIP packages and 44-pin QFN and TQFP packages.

Miller Electric Mfg. Co.    Appleton, WI 54912 1079
Dec 01, 2009 FILTAIR MWX-S Mobile Fume Extractor includes self-cleaning feature with pulse-jet technology that restores filter life in 1 min. Created for welding applications with high arc-on time and/or processes that produce large amounts of fumes, it has MERV-15 rated nanofiber filters which capture up to 95% of welding fume particulates. Unit also features 875-CFM extraction capacity and 7-, 10-, and 12 ft, externally supported extraction arm equipped with large bell-shaped hood.

Heyco Products    Toms River, NJ 08753
Dec 01, 2009 Designed to protect flat, round, or multiple cables at panel entry points, Snap-In Ratcheting Strain Relief can be pre-assembled offline for final assembly at later time - or remote location. Fingertip pressure allows installation into standard round or Double D hole with no tools required. Accommodating wire range from .115-.575 in., wire locking ratchet fits panel mounting hole size of .875 in. with .770 in. flats.

Micro-Epsilon UK Ltd    Cheshire   United Kingdom
Dec 01, 2009 Supplied in compact housing with integrated controller, scanCONTROL 2700/2710 series are typically used to measure angles, steps, and positions in automation solutions where space is restricted. Same is also possible for profiles such as adhesive beading, weld seams, grooves, and gaps. While scanCONTROL 2700 acts as pure data supplier and provides measured points, scanCONTROL 2710 calculates information directly in sensor.

Mettler Toledo, Inc.    Columbus, OH 43240
Dec 01, 2009 As dimensioning, weighing, and identification solution, CSN840 Pallet(TM) can measure all shapes and surfaces of up to 2,500 x 2,500 x 2,600 mm pallets. Image capture feature takes picture of each pallet measured, and images are stored in searchable database to facilitate damage claims and audits. Along with taring function, additional capabilities include remote monitoring functionality and automated data capture of dimensions, weight, and ID.

Industrial Magnetics, Inc.    Boyne City, MI 49712
Dec 01, 2009 Used for ferrous metal parts handling, TPCA Magnetic Transporter® utilizes rare earth, permanent magnet circuit to pick and place sheet metal parts in automated transfers or lift-assist material handling applications. Design minimizes use of shop air and offers instantaneous pickup and release of heavier parts or complete parts assemblies without electricity. Options include solenoid control valves, custom pole shoes, and magnet-mounted control valves.
