Xspect Solutions Inc.    Wixom, MI 48393
Jun 03, 2009 Designed to use multiple scanning measuring probes, including one for grind burn detection, INOVA measures internal gear diameters greater than 12 mm, gear face widths up to 500 mm, and gears with helix angles less than 90°. Z-axis with integral rotary table is positioned independently from X and Y axes. Additional features include black granite guideways, pneumatic vibration dampening system, 3- or 6-jaw chuck. CNC controller is installed in 19 in. cabinet with PC and power unit.

Imperial Systems, Inc.    Jackson Center, PA 16133
Jun 03, 2009 Featuring heavy-duty, fully welded steel construction and OSHA safety yellow paint, High Speed Abort Gate can be located prior to inlet of dust collection system to prevent ingress of flame or burning ember. It can be actuated by leak detection or broken bag sensors and may also be placed on return air side of dust collector to redirect contaminated air to safe location. Other features include gate accelerating springs; fail-safe electro-magnets; steel gate seals; and limit switches.

Ondrives Ltd.    Chesterfield, Derbyshire S41 9RN  United Kingdom
Jun 03, 2009 Safety overload couplings feature minimal response times, resulting in nearly instant torque break, ensuring safety of personnel working on fitted machines. They are insensitive to thermal fluctuations and contact with any lubricants. Also, units include compensation of misalignments, high torsional stiffness without restoring forces, and backlash-free torque transmission. Version with spider element can compensate for crashes and vibrations and is electrically isolating.

Advantech Technologies, Inc.    Irvine, CA 92618
Jun 03, 2009 Measuring 18.9 x 6.38 x 13.1 cm, ARK-1388 fanless and embedded industrial PC leverages 1.06 GHz Intel® Core(TM)2 Duo ULV or Celeron® M ULV processor and Intel 945GM GM chipset to deliver required computing and multi-media performance. Product operates from -20 to +60°C and works with 12/24 V systems. I/O includes 4 serial, LVDS and VGA dual independent display, 4 USB, LAN, DIO with isolation and relay function, and amplified audio line-out. Safe boot and safe shutdown functions are standard.

Peek Traffic Corporation    Palmetto, FL 34221
Jun 03, 2009 Compliant with US FHWA Advanced Transportation Controller standard, ATC-2000(TM) uses NTCIP communications natively and is compatible with traffic management systems. Interchangeable system of I/O modules, D modules, and communications modules makes this system adaptable to many types of network and protocol environments. Programmable via multiple means, Linux-based solution runs dual traffic engine that lets users switch between NEMA phase-based and pre-timed interval-based operation.

Ampacet Corp.    Tarrytown, NY 10591-5130
Jun 03, 2009 Suited for appliance and electronics manufacturing operations, FormulaX LiquidMetals Color(TM) Masterbatch achieves look of chrome and aluminum without use of secondary treatments. Colorant is added into extruder or injection molder along with base resin, and can be used with polypropylene, polystyrene, polycarbonate, ABS, PET, and Nylon. Unlike finished metal parts, which may dent and scratch, molded plastic bodies and housings incorporate metal look-alike effect throughout part.

Applied Kilovolts Ltd    Portslade East Sus BN41 1PB  United Kingdom
Jun 03, 2009 Suited for quadrupole and ion trap mass spectrometers using electron multiplier or photomultiplier detectors, modular DC series can be configured with 1-3 outputs of up to ±15 kV. Dynamic Control(TM) technology within output stages ensures fast and accurate settling after polarity change, with minimal overshoot. Output is stable, with ripple of 500 ppm p/p and drift of less than 0.01%/hr after 1 hr warm up, and modules provide true zero volt crossing and full linear control.

Festo Corp.    Hauppauge, NY 11788
Jun 03, 2009 Suited for use in medical and semiconductor applications, Compact Pressure Sensor SPAB offers pressure measuring range of 0-10 bar or -1 to +1 bar. At 30 x 30 mm, unit includes 2-part, 3-color display and also displays switching status. Data can be transferred to other SPAB pressure sensors. Unit is available with NPN or PNP switching outputs, digital or analog outputs, M8 or cable electrical connection, and NPT, G, or R thread fittings.

GETAC Inc.    Lake Forest, CA 92630
Jun 03, 2009 Suited for mobile field workers, Model V100 is based on 1.4 GHz Intel Penryn processor with 800 MHz FSB and 3 MB L2 cache. It includes 4 GB RAM, HDD up to 320 GB, 802.11n wireless network capabilities, and ExpressCard slot. Fully compliant with MIL-STD 810F and IP54 standards, convertible features Magnesium Alloy design, shock-mounted HDD, sealed I/O caps and doors, and swiveling LED screen. Other features include 10/100/1000 Ethernet, integrated GPS and Bluetooth, and waterproof keyboard.

Selco Products Co.    Reno, NV 89521-5908
Jun 03, 2009 Consuming 4.3-7.1 W, CL Series LED Lighting Assemblies are self-contained, electronically controlled lighting fixtures that emit constant light output of 240-400 lumens (depending on model) with inputs from 9-29 Vdc. They are resistant to vibration and shock resistance, operate from -40 to +60°C, and come in waterproof housing. Also available, CL Series Single Package LED Components range from 0.5-5 W, with flux output to 330 lm, and are available in Warm, Neutral, and Cool White.

Cablecraft Motion Controls    New Haven, IN 46774
Jun 03, 2009 Self-lubricating and PTFE-lined, rod end bearings and spherical bearings operate within -65 to +325°F range and come in several models with various bore diameter, plating, ball, race, and thread options/configurations. Rod end bearings are available with male and female threads in wide and narrow series and are Government-approved to AS81935. Spherical bearings feature narrow and wide series with and without staking grooves and are Government-approved to AS81820.

Greenray Industries Inc.    Mechanicsburg, PA 17055
Jun 03, 2009 Housed in 4-pin dual-inline package, ZYH1002/1003 Series OCXOs require 195 mW at +25°C with slope of -3.4 MW/°C, making them suited for applications that require low power consumption and/or battery power. Standard frequencies are 10-20 MHz, but any frequency from 10-50 MHz is available. ZYH1002 output is CMOS compatible with 50/50 ±5% duty cycle, while ZYH1003 provides clipped sinewave output of 1 Vp-p into 10 kW load. Standard input supply voltage is +5 Vdc.

Milwaukee Electric Tool Corp.    Brookfield, WI 53005-2550
Jun 03, 2009 Capable of charging up to 5 small electronic devices (2 at one time), M12 Cordless Power Port is compatible with cell phones and MP3 players that draw up to 3 A through dc outlet or 750 mA via USB port. Portable charger and power supply runs on M12 LITHIUM-ION battery, and is compatible with all M12 platform.

Electro Standards Laboratories    Cranston, RI 02921 3403
Jun 03, 2009 Capable of providing single channel A/B switching, Model 7268 allows user to share single HD15 interface device among 2 other devices connected to A and B ports. Unit switches all 15 pins simultaneously and latching relays maintain connection and switch position during power failure. Switch can be controlled via front panel pushbutton or remotely through DB9 RS232 serial port utilizing ASCII commands.

OSRAM Opto Semiconductor    San Jose, CA 95134
Jun 03, 2009 Suited for applications in spotlights, desk lights, and ceiling floodlights, OSLON SSL LED features thermal resistance of 7 K/W, 100 lm/W efficiency, and beam angle of 80°. Ultra-white unit is offered with color temperature ranging from 5,700-6,500 K, while warm white has color temperature ranging from 2,700-4,500 K. With operating current of 350 mA, light source can achieve typical brightness of 110 lm in ultra-white, and maximum possible luminous flux of 130 lm.

NAPCO Security Systems, Inc.    Amityville, NY 11701-2800
Jun 03, 2009 Able to scan and monitor area of 50 x 50 ft in both commercial and residential settings, C100STEAM auto-adjusts to its environment 24/7 to counteract false alarms. It automatically changes its sensitivity modes to widen gap between detected signal and its alarm threshold. Built-in anti-mask/block supervision detects intentional or accidental masks or blocks and sends trouble signal, while look down feature prevents people from crawling under sensor unnoticed.

Trek, Inc.    Medina, NY 14103 9710
Jun 03, 2009 Suited for piezoelectrics, electro-optics, and MEMS applications, Model PZD350A provides large signal bandwidth of 250 kHz and small signal bandwidth greater than 350 kHz. It offers high speed and precise control of DC or peak AC output voltages in programmable ranges of 0 to ±350 V with output current range of 0 to ±200 mA (bipolar model) and 0 to ±700 V with ±100 mA (unipolar model). CE marked unit provides full four-quadrant, class AB, all-solid-state output stages.

AICSYS, INC (Advanced Industrial Computer Systems)    Taipei Hsien   Taiwan
Jun 03, 2009 Built with two 12 cm fans with replaceable air filter for optimum cooling, RCK-403 4U Rackmount Chassis supports up to two 3.5 in. HDD drives with mobile rack and slim optical drive. Retaining bar is included to hold expansion cards in place in high vibration environments. Featuring changeable rear I/O shield, and front panel with lockable door to protect drives, unit supports both AT and ATX PS/2 size power supplies and mini-redundant power supply.

Phihong USA    Fremont, CA 94539
Jun 03, 2009 Enabling remote monitoring and reset without onsite service personnel, POE75U-1UPN is suited for applications such as wireless network access points, LCD displays, kiosks, and security cameras. Gigabit compatible midspan meets Ultra PoE requirements and has AC input voltage range of 90-264 VA. Operating in temperature range of 0-40°C, unit has total output power of 75 W, and meets IEEE 802.3af standards, including detection, disconnect, and overload control.

Phihong USA    Fremont, CA 94539
Jun 03, 2009 Accepting power from IEEE802.3at Layer 1 classification or other pre-standard POE Plus midspans, Gigabit single-port extender POE16S-1AF boosts PoE voltage back up to 56 V with full IEEE802.3af detection and disconnect. Designed for use within temperature range of 0-55°C, 10/100/1000 base T switch extends reach of data and PoE to 200 m, doubling cabling distance offered for remotely powering security cameras, wireless network, and access controllers.
