North Atlantic Industries, Inc.    Bohemia, NY 11716
Jun 29, 2009 Capable of performing Synchro/Resolver evaluation, calibration, and test functions on components, assemblies, and systems, Model 8810A automatically accepts and displays input voltages from 1.0-90 VL-L and reference voltages from 2-115 Vrms over frequency range of 47 Hz to 20 KHz. Unit provides fully independent dual inputs, touch screen controls, 0.001° resolution, and 0.004° accuracy. It offers front panel analog and digital display modes and adjustable resolution from 1/10,000° to 1°.

Hach Co.    Loveland, CO 80539-0389
Jun 29, 2009 Designed for HQd line of meters, IntelliCAL(TM) Probes provide portable measurement of ORP, sodium, and pH for low-ionic strength samples for analysis in lab or field. When switching between parameters, operator plugs IntelliCAL probe into HQd meter. System automatically recognizes testing parameter from probe and recalls calibration history. It uses intuitive menu structure along with guided measurement and calibration methods. Conductivity, DO, and LBOD probes are also available.

Linear Technology Corp.    Milpitas, CA 95035
Jun 29, 2009 Supplied in 7 x 8 mm QFN package, LTC2754-16 incorporates 4 DACs that can each be software-programmed or pin-strapped for 1 of 6 unipolar or bipolar output ranges via 4-wire serial interface. SoftSpan output voltage ranges include 2 unipolar ranges (0-5 V, 0-10 V) and 4 bipolar ranges (±10/±5/±2.5/-2.5 to +7.5 V). Along with 2 MHz multiplying bandwidth, features include voltage controlled offset and gain adjustment pins, settling time of 2 µsec, and glitch impulse of 0.26 or 1.25 nV/s.

Key Technology, Inc.    Walla Walla, WA 99362
Jun 29, 2009 Manta® uses Vis/IR cameras, Raptor laser technology, and LED lighting to recognize object size, shape, and color differences to detect foreign material. Locating Manta at end of processing line helps assure quality of final product; it can tally specific product characteristics and trigger alarm or process adjustment if out-of-tolerance conditions are detected. Featuring 2 m wide scan area, Manta handles up to 50,700 lb of frozen potato strips per hour, based on 7 mm wide cuts.

Flexicon Corporation    Bethlehem, PA 18020 8006
Jun 29, 2009 As fully mobile unit, Recirculating Spreader-Feeder evenly distributes powder and bulk coatings onto food products as they pass between its longitudinal discharge hopper and lower collection hopper. Horizontal conveyor, which has multiple discharge ports to apportion material across length of discharge hopper, automatically starts and stops to maintain preset fill level in hopper. Also, rotating agitator along bottom of hopper promotes uniform discharge through adjustable screen.

Sealed Air Corp.    Saddle Brook, NJ 07663-5291
Jun 29, 2009 Custom-designed to accommodate exact size and shape of product, Instapak® TempGuard(TM) coolers use polyurethane foam to keep temperature-sensitive products safe during shipment. Cavities can be customized to fit right amount of gel refrigerant or dry ice, lending to weight reduction, while ability to keep products colder for extended periods lets companies choose more cost-effective shipping options. Cooler is reusable, since foam is not fused to corrugated shipping container.

Edmund Optics    Barrington, NJ 08007
Jun 29, 2009 Zoom Beam Expanders are designed for Nd: YAG laser sources, providing variable magnification of 1-3x and 2-8x with adjustable focus to correct for laser beam divergence. Antireflective coating can be customized for various wavelengths. Devices are available for 1,064 nm lasers in both 1-3x and 2-8x models, with Output Clear Apertures of 20, 30, 38, and 60 mm; and in 532 nm models with magnification of 1-3x with aperture of 20 mm and, as with 355 nm models, 2-8x with apertures of 30 and 60 mm.

ITW Vortec    Cincinnati, OH 45242-4719
Jun 29, 2009 Vortex A/C NEMA 12 delivers Total Enclosure Protection to ensure reliable operation in extreme environments. Along with 62 dBA operation, features include maintenance-free design, capacities from 900-5,000 BTU/H, and integral mechanical thermostat that maintains 80 to 90°F temperatures. Enclosure cooling product operates in environments up to 175°F and offers slight pressurization of enclosure in all operating modes. Top- or side-mount installation requires no wiring.

FANUC Robotics America, Inc.    Rochester Hills, MI 48309 3253
Jun 29, 2009 Model M-2000iA/1200 can support standard payload of 1,200 kg, and up to 1,350 kg, with 0.6 m offset from faceplate and fully articulated motion at wrist. Vertical lifting stroke is 6.2 m and wrist is IP67 protected for harsh environments. System includes vision and force sensing as well as FANUC iRVision system with 2D robot guidance tool for operations such as part location and error proofing. Integrated software uses robot itself for some safety functions.

FANUC Robotics America, Inc.    Rochester Hills, MI 48309 3253
Jun 29, 2009 Model M-1iA intelligent assembly robot is 17 kg, compact 6-axis robot suited for small part handling, high-speed picking, and assembly applications. Parallel-link structure maximizes speed and accuracy and robot includes 3-axis wrist. Unit operates via R-30iA controller with integrated functions such as iRVision®, Robot Link, and Collision Guard. It is also available as 4-axis model, for part picking and kitting, with single-axis wrist offering speeds up to 3,000°/sec.

Advantapure, Div. Of NewAge Industries    Southampton, PA 18966
Jun 29, 2009 Capable of withstanding minimum of 500 kGy cumulative exposure to gamma radiation, GammaTag 500 is suited for use in pharmaceutical, biotech, medical device, gowning, and cleanroom supply industries. It handles typical doses of 25 kGy and is designed for repeated exposure to gamma radiation. Measuring only 4 x 52 mm, read-only tag uses 2.45 GHz radio frequency and is available as bare inlay or converted into various finished tag constructions.

Schneider Electric    Palatine, IL 60067-7399
Jun 29, 2009 With 2 digital inputs and 2 digital outputs, Square D® PowerLogic E5600 socket-based power and energy meter can integrate readings from electric, gas or water meters, or pair with facility's existing energy management system. It is suited for wide variety of commercial enterprises, including office buildings, malls, and transportation hubs. When used with PowerLogic Tenant Metering Commercial Edition Software, meter forms end-to-end automated sub-billing solution.

RF Micro Devices, Inc.    Greensboro, NC 27409-9421
Jun 29, 2009 Utilizing Gallium Arsenide (GaAs) pseudomorphic high electron mobility transistor (pHEMT) technology, symmetric SPDT switches operate in multiple market segments, including cellular infrastructure, WiFi, WiMAX, and antenna tuning applications for mobile devices. Models RF3021 and RF3025 are housed in 16-pin 3 x 3 mm QFN package and feature high isolation and single-bit control. Offered in 6-lead SC70 package, RF3023 and RF3024 feature low insertion loss and moderate isolation.

Seco-Larm    Irvine, CA 92606-5012
Jun 29, 2009 Suited for distributing video signals to multiple locations, ENFORCER VA-1000 Series are compatible with both color and black and white signals and can be installed at monitor or DVR side of cable run. VA-1102B-WQ 1-in 2-out unit features power pass-through circuit, allowing for excess current and voltage not used by included 12 Vdc power adapter to be used to power other nearby 12 Vdc devices. Dual voltage, 12/24 Vac/dc unit VA-1104B-WQ has 1-in 4-out configuration.

Eurotherm Controls    Leesburg, VA 20175
Jun 29, 2009 Based on MACO® Compact System platform, EM-3c control system can be used for extruder temperature and pressure control or complete line control. It utilizes CE.net operating system and offers preconfigured screens and sequence login to simplify installation. System's temperature card is designed for single-screw, twin screw, co-extrusion, or blown film applications and features fully automatic adaptive tuning as well as conventional tuning.

RF Micro Devices, Inc.    Greensboro, NC 27409-9421
Jun 29, 2009 Suited for use in cellular handsets, personal navigation devices (PNDs), digital cameras and MP3 players, RF5500, RF5501, RF5510, and RF5511 contain single-pole, three-throw (SP3T) switch designed to enable multi-path operation in embedded segment of WiFi or WLAN, consumer electronics markets. Models RF5501 and RF5511 also integrate low noise amplifier (LNA), providing for reduced footprint area with low insertion loss for RF architectures requiring additional Rx gain.

Extech Instruments Corp.    Nashua, NH 03063
Jun 29, 2009 Offering 5 automatic measurements (Frequency, Cycle, Average, Peak to Peak, and RMS), 20 MHz dual-channel Model MS420 features auto-set function that optimizes position, range, timebase, and triggering to assure stable display of any waveform. It utilizes Peak Detect function for 50 nsec glitch capture XY mode, Average Mode for smoothing waveforms, and Persistence Mode for observing dynamic signals. Unit can store and recall up to 4 waveform screens and setups.

Epson America, Inc.    Carson, CA 90746
Jun 29, 2009 PowerLite Pro Z8000WUNL multimedia projector provides 1,920 x 1,200 resolution and 6,000 lumens color light and 6,000 lumens white light output. It includes high-aperture 3-chip 3LCD technology for maximized image intensity/sharpness, liquid cooling system, and lamps/filters with simplified access. It can be installed ±30° off-axis horizontally and ±10° off-axis vertically. Monitored/controlled via included software, it also has LAN connectivity and closed captioning decoder.

Intergraph Corp.    Huntsville, AL 35824
Jun 29, 2009 Supplied as data-centric and rule-driven solution, SmartPlant® 3D Materials Handling Edition automates design and modeling of bulk materials handling systems, such as conveyors and transfer chutes, for mining, port, power, pulp, and paper industries. Functionality allows accelerates completion of changes with detailed, fabrication-level deliverables. Also, system sections may be designed and modeled once and then saved for future reuse.

Intergraph Corp.    Huntsville, AL 35824
Jun 29, 2009 SmartPlant® Enterprise Power Solution enables designers and operators of power generating plants to optimize design and construction, operation, and life cycle management of engineering design for regulatory compliance. It provides preconfigured KKS asset naming convention and plant classification structure as well as application integration. Integrated solutions suite also provides 3D design, materials, and engineering data management capabilities.
