IKey Ltd.    Austin, TX 78754
May 05, 2011 Suited for use in harsh environments, Model PMD-W-SK-97-TP features ergonomic 10° pullout that fits into rackmount computer systems and enclosures. Magnetic, auto-lock feature prevents drawer from falling open, while 6.5 in. depth allows for storage behind drawer. Constructed of CRS steel with scratch-resistant epoxy paint finish, 10 lb drawer has operating temperature of -40 to +70°C. Model PMD-W-SK-97-TP pairs with SK-97-TP keyboard, which meets NEMA 4X specifications.

LeCroy Corp.    Chestnut Ridge, NY 10977
May 05, 2011 Consisting of Master and Slave Acquisition Modules and server-class CPU using Intel Xeon(TM) X5660 processor with 24 GB RAM, LabMaster 9 Zi-A offers bandwidth ratings up to 45 GHz, sample rate of 120 GS/s, and analysis memory up to 768 Mpts/ch. System architecture separates oscilloscope signal acquisition function from display, control, and processing functions. By using ChannelSync(TM) technology, Master Acquisition Module can synchronize Slave Acquisition Modules.

LeCroy Corp.    Chestnut Ridge, NY 10977
May 05, 2011 Available in 400 and 600 MHz models with 12-bit ADC, WaveRunner HRO(TM) 6 Zi provides 55 dB signal-to-noise ratio and ±0.5% DC vertical gain accuracy. Deep memory capability of 256 Mpts/ch permits long acquisitions to capture 30 seconds of data sampled at 10 MS/s, or shorter capture times with highest resolution at 2 GS/s. Unit also provides advanced triggering to isolate events and pivoting display that permits viewing signals vertically as well as horizontally.

Lumencor, Inc.    Beaverton, OR 97006
May 05, 2011 CORE illumination and imaging system(TM) offers equipment manufacturers optical block, based on solid-state excitation subsystems, that includes all illumination and imaging optics needed in fluorescence scanner. Functionality enables efficient light delivery within customizable unit that functions as heart of fluorescence reader. Product illuminates fluorescent samples and images the resulting emissions, streamlining engineering and development time for new instruments.

Epson America, Inc.    Torrance, CA 90509
May 05, 2011 Equipped with MicroPiezo® AMC(TM) print head that produces 5,670 x 1,440 dpi resolution, 13 in. Epson Stylus® Photo R2000 utilizes Epson UltraChrome Hi-Gloss® 2 eight-color ink set for prints that are water, smudge, and fade-resistant. Gloss optimizer delivers uniform finish, while AccuPhoto(TM) HG screening technology ensures precise placement of each ink droplet for grain-free images. For connectivity, printer provides 100 Mbit Ethernet, 802.11n wireless, and Hi-Speed USB 2.0.

ADLINK Technology Inc.    Irvine, CA 92618
May 05, 2011 Designed to meet needs of critical applications in severe environments, ASD Series provides SATA 6 Gbps interface to match data transfer capabilities of 2nd generation Intel® Core(TM) processor-based platforms. Industrial-grade units deliver low latency with less than 1 msec access time and power consumption as low as 2 W. Available in 2.5 in., 1.8 in., and JEDEC MO-297 Half-Slim form factors, drives operate from -40 to 85°C and implement both wear-leveling and hardware ECC.

Boca Bearing Company    Boynton Beach, FL 33426
May 05, 2011 Available in inch and metric sizes, One Way Bearings transmit torque between shaft and housing in one direction and allow free motion in opposite direction. HF, FC, and RC versions come without bearing assemblies, while HFL, FCB, and RCB models include assemblies. Featuring 2 integral radial bearings arranged on both sides of needle roller clutch, HFL Series can support radial forces in tight areas. Plastic springs and partially mounted knurled outer rings are available.

Parker Hannifin Corp.    Oxford, MI 48371
May 05, 2011 To keep refrigerated air dryers operating at full capacity, Finite series removes up to 99.995% of oil, water, and solids from compressed air and other gases. This protects complex internal components of dryer by removing compressor oil carryover. Element threads into top of housing, facilitating replacement even in space-constrained environments. Design also eliminates need to disconnect drain connections before removing bowl to access spent element.

Detex Corp.    New Braunfels, TX 78130
May 05, 2011 Built for maximum strength, 230X Door Lock features heavy-duty, 3-bolt construction for resistance against attempted intrusion. Design puts more deadbolt deeper into frame than typical products, and connecting rods are made of continuous solid metal. Suited for back doors requiring both panic hardware and high-level protection from break-ins, multi-point lock accommodates needs of commercial properties and complies with life safety and code requirements.

Ophir-Spiricon Inc.    Logan, UT 84321
May 05, 2011 Supporting USB L11058 Large Format Beam Profiling Camera, BeamGage® v5.5 is based on UltraCal(TM) baseline correction algorithm and guarantees data baseline is accurate to 1/8th of digital count on pixel-by-pixel basis. Standard version features BeamMaker® beam simulator, automatic camera control, and beam analysis algorithms, while Professional version adds partitioning of camera output for separate analysis of multiple laser beams, .NET interface for full remote control, and camera sharing.

Schneider Packaging Equipment Co., Inc.    Brewerton, NY 13029 0890
May 05, 2011 Designed to stabilize load for safe internal transport, String Tie Load Containment Option is suited for empty blow molded bottles in cases and other lightweight products that require additional handling and transport for filling or further processing. String tie arm can be programmed to automatically tie all layers or selected layers of cases as they are being loaded onto pallet. Once load reaches next processing/handling station, tie can be removed or remain intact for secondary stabilization.

Lyrtech    Quebec City, QC G1P 2J7
May 05, 2011 Offered in SISO and 2x2 MIMO configurations, Radio420X multimode SDR RF transceiver module is designed around multi-standard, multi-band RF transceiver and can be used with any FMC carrier. Front end design and RF coverage, combined with multiple references and synchronization modes, make unit suitable for narrowband and broadband applications. Clock management facility offers low phase noise clock distribution, PLL core, dividers, dual VCOs, and jitter cleaner feature.

Larson Electronics, LLC    Kemp, TX 75143
May 05, 2011 Available in 2 and 4 ft lengths, 30 W Model EPL-24-2L-LED Explosionproof light carries UL Class 1, Div 1 and Class 2, Div 1 ratings. Unit offers 5.5 year bulb life and is available in surface and pendant mounting options. Models EPLC-48-4L-LED and EPLCD-48-2L-LED, supplied with explosion proof dolly cart, enable operators to move lights in and around hazardous location area. UL certified for both flammable vapors and dusts, lights are suitable for manufacturing, refineries, and tank storage.

Mitsubishi Digital Electronics America    Irvine, CA 92618
May 05, 2011 Model WD380U-EST wide-format projectors produce 2,800 lumens brightness, while XD380U-EST XGA-resolution models produce 2,500 lumens. Weighing 9 lb, devices feature USB A and B inputs, LAN display, and 10 W speaker, as well as RS232 connector and RJ45 input. They operate at 28 dB and offer lamp life of up to 6,000 hr, along with 3,000:1 contrast ratio. Wall- or ceiling-mounted products have lens that can project 70 in. diagonal WXGA image from less than 23 in.

Aramsco    Thorofare, NJ 08086
May 05, 2011 Syclone centrifugal air mover has stackable design and dual-GFCI-receptacle outlet, allowing user to daisy-chain up to 4 units in single room. Providing air flow of 2,900 ft/min, device enables effective drying for restoration contractors, and has multiple drying angles and 3 speed settings. Low-power machine also includes carpet clamp as well as front-mounted control panel.

Fieldbus Foundation    Austin, TX 78731
May 05, 2011 FOUNDATION fieldbus Flow Transducer Block Final Specification includes standardized flow transducer block with high-performance totalizer function. Specification provides standard definitions, schematic of blocks, parameter access, and details for handling status of input parameters. In addition to greater consistency in fieldbus device setup, configuration, and maintenance, specification will make it easier for end users to utilize instruments from wide range of automation equipment suppliers.

Cybernet Manufacturing, Inc.    Irvine, CA 92618
May 05, 2011 Designed to meet needs of hospital and medical facilities, CyberMed integrates scanners for barcodes, RFID, and fingerprints as well as readers for smart cards and magnetic stripe cards. Medically certified all-in-one PC, featuring waterproof front bezel and antimicrobial coating, also supports communications via Skype VoIP and webcam for telemedicine and collaboration between medical professionals in different facilities.

Hobart Brothers Co.    Troy, OH 45373-2900
May 05, 2011 Tri-Mark® TM-811N1 and TM-811N2 are gas-shielded, flux-cored welding wires designed to improve weldability and productivity on out-of-position welding applications. To promote good CVN (Charpy V-notch) impact values at low temperature, TM-811N1 and TM-811N2 offer respective weld deposits of 1% and 2% nickel. Both offer stable arc and flat bead profile that provide consistent weld quality and minimize rework, while spatter, freezing, and slag characteristics reduce post-weld cleanup.

Miller Service Co., Inc.    Wakefield, MA 01880
May 05, 2011 OmniShield(TM) Gloves utilize Anti-Microbial Technology from Anti-Microbial Solutions LLC, which has been developed using all EPA Registered ingredients and has been shown to be 99% effective against certain harmful bacteria. Technology capitalizes on effects of non-carcinogenic, non-allergenic, and anti-fungal agents. Since anti-microbial qualities are built into gloves, they cannot be rubbed off and remain 99% effective for life of product.

Robert Bosch GmbH    Waiblingen D-71332  Germany
May 05, 2011 Intended for primary and secondary packaging of free-flowing products, 10-lane Sigpack RAx Stick Pack system can handle range of granules, powders, pellets, and piece goods. Turnkey solution can form, fill, and seal up to 1,000 stick packs/min and pack as many as 120 cartons/min. Dosing and sealing technology ensures precise filling and seal integrity. While auger fillers are available for poorly flowing powders to direct product, tipping fillers can be integrated for easy-flow products.
