TE Connectivity Ltd.    Berwyn, PA 19312
Dec 13, 2002 Product senses rotor positions, serves as revolution counter, and detects speed and rotation. Contactless sensor requires no external power to operate. Permanent-magnet design generates output voltages from 3.5-4 Vdc and requires no voltage amplification for switching electronics. Adaptable to custom applications, sensor is suitable for applications with drive frequencies of 0-10 kHz.

Renishaw, Inc.    Hoffman Estates, IL 60192
Dec 13, 2002 Model SP25M uses Renscan(TM) technology to provide scanning on coordinate measuring machines and vision systems. Measuring only 1 in. in diameter, probe can be mounted to motorized articulating heads, or fitted to extension bars to allow access to deep part features. Interchangeable scanning probe modules are available, each optimized to suit range of stylus lengths from 0.8-8 in. Model SP25M includes kinematic stylus changing and bump-stop crash protection.

Paul N. Gardner Co., Inc.    Pompano Beach, FL 33060 6608
Dec 13, 2002 LAB-CRIER Model LCVA plays audible warning message when approaching individuals pass in front of unit's infrared sensor. Messages up to 20 seconds in length can be recorded on permanent, non-volatile memory chip via one-button operation; new announcements may be recorded as often as necessary. With 4 included AMA batteries, up to 13,680 messages may be recorded without loss of clarity. Warning light indicates low battery power.

Flexicon Corporation    Bethlehem, PA 18020 8006
Dec 13, 2002 Series BFF Combi-Hood allows automatic discharging from bulk bags as well as manual emptying from sacks, drums, and other containers. FLOW FLEXERâ„¢ bag activators raise and lower opposite bottom edges of bag at timed intervals, promoting material flow. POP-TOPâ„¢ bag extension devices stretch bag into cone shape, promoting discharge of material into hopper. Series BFC has cantilevered I-beam with electric hoist and trolley to raise and position bulk bags without forklift.

Flexicon Corporation    Bethlehem, PA 18020 8006
Dec 13, 2002 Twin-centerpost(TM) unit provides product contact surfaces that are constructed and finished in compliance with 3-A standards. Available with primary bag filling components and material delivery system, filler is constructed of 304 stainless steel. It is equipped with manual fill-head height adjustment, pneumatically retractable bag hooks, inflatable cuff, and feed-chute outlet port. Unit is offered with flexible screw conveyor delivery system.

Flexicon Corporation    Bethlehem, PA 18020 8006
Dec 13, 2002 Discharger eliminates dust during untying, discharging, retying, collapse, and removal of bulk bags. Promoting complete discharge from bag, design incorporates bulk bag/hopper interface consisting of manual SPOUT-LOCKâ„¢ clamp ring, positioned atop pneumatically actuated TELE-TUBEâ„¢ telescoping tube. Offerings include Power-Cincherâ„¢ pneumatically actuated flow-control valve, Bag-Vacâ„¢ dust collector, and FLOW-FLEXERâ„¢ bag activators.

Drum-Mates, Inc., Drum Mixer & Pump Div.    Lumberton, NJ 08048
Dec 13, 2002 Hand Dispensing Nozzle, Series DM-85HFR, transfers liquids or chemicals from pumps and process equipment. It provides 0–40 gpm flow rate at up to 150 psi, with choice of ½, ¾, or 1 in. hose-barb connections. Two models offer chemical resistance with polypropylene body, Viton and either Hastelloy or stainless steel components. Nozzle is suitable for gravity-feed transferring and dispensing of drums, day tanks, and reservoirs.

Liebert Corp.    Columbus, OH 43229
Dec 13, 2002 UPStation® GXT5000R-208 208 V, 5 kVA UPS delivers scalable power protection in 3U electronics and 3U-battery modules. Double-conversion, on-line technology provides sine-wave output and zero transfer time, ensuring load is supported by seamless flow of power from UPS if utility power is interrupted. MicroPODâ„¢ allows users to manually transfer connected equipment to utility power via maintenance bypass switch, eliminating critical load shutdown during routine maintenance or replacement of UPS.

Flowline Inc.    Los Alamitos, CA 90720
Dec 13, 2002 General-purpose, 2-wire LU05 MicroSpanâ„¢, with miniature deadband, optimizes filling capacity of small, atmospheric process vessels. Product includes fail-safe intelligence with diagnostic feedback and digital infinity surface mapping. Accuracy is ±0.15% of span. Enclosure is rated NEMA 6X/IP67 and unit includes Kynar® transducer. Transmitter is spanned using calibration wire, dc power supply, and flat, reflective target. Applications include IBC totes, drums, and waste sumps.

Gould Instrument Inc.    Cleveland, OH 44125 6100
Dec 13, 2002 Upon trigger, Ultima 500 automatically transfers data to Excel, ProView, or imPRESSion and displays it in dual-video mode: analysis results on external monitor and acquired data on internal display. DataSentryâ„¢ provides remote monitoring and unattended operation, while IntelliProbeâ„¢ interface offers differential and current probes. Ultima offers up to 2 GS/s sampling rate, 12-bit high-resolution mode, 1 million points of data storage per channel, and 500 MHz bandwidth.

Gould Instrument Inc.    Cleveland, OH 44125 6100
Dec 13, 2002 ViewGraf features removable 11 in. real-time thermal array writer, 12.1 in. real-time display panel, and variety of signal conditioners for any type of signal. It provides 16-bit resolution, up to 500 kS/s sample rate and up to 32 channels, with Gigabytes of memory and PC connectivity. Portable unit prints on 11 in. chart paper at 100 mm/sec. It can print real-time and recorded data, or archive data on hard disk, network, paper, or 250 Mbyte Zip disk.

Gould Instrument Inc.    Cleveland, OH 44125 6100
Dec 13, 2002 DAstarNET XE combines full range of signal conditioning, writer output, real-time display and continous storage in compact rack, 13-slot mainframe. Amplifiers cover full range of sensors with programmable inputs from 50 µV to 2,500 V including bridge, thermocouple, accelerometer, and frequency inputs. Summit Software begins displaying signals at start up and up to 4 simultaneous screens show numerics, stripcharts, trends, and X/Y displays.

Multiton MIC Corp.    Richmond, VA 23223
Dec 13, 2002 Model SM15/20 is available with 1 mast for 62 in. lift or telescopic mast for lifts up to 130 in. Walk behind stacker provides hydraulic lifting/lowering via pressure pump with 1.5 kW motor. Offerings include built-in 10 A automatic battery charger, floor locking foot brake, and adjustable straddle legs and forks. Measuring 67½ in. long, unit has maximum load capacity of 1,500 and 2,000 lb for SM15 and SM20, respectively.

Electronic Development Laboratories, Inc.    Danville, VA 24540
Dec 13, 2002 Suited for use with type K and J thermocouple sensors, instrument records temperature readings and downloads directly to PC via RS-232 computer interface. Sensors plug into back of instrument as to not interfere with front panel visibility. Unit simultaneously shows temperature output from sensors on 2 different and independent displays in 1/2 in. tall digits. Temperature ranges include -280 to +1,100°F ±1°F (J) and -280 to +2,000°F ±1°F (K).

Manchester Tool Co.    Akron, OH 44319 3998
Dec 13, 2002 MTC-PT deep-grooving tool incorporates double-V design for stability and positive-rake geometry for low cutting force, suitable for soft materials. Product cuts in axial and radial directions and delivers chip control over entire range of depth of cut when turning. Double-ended inserts are available in 3 grades: M40 (-36), M45 (-33) and M93 (-34).

Thermal Care Inc.    Niles, IL 60714
Dec 13, 2002 Oiltherm Hot Oil Temperature Control Unit circulates oil through process and automatically maintains oil temperature at selected setpoint. With vacuum option, venturi in Oiltherm allows oil to be sucked from mold, in preparation for mold changes or removal of unit. Positive/negative mode allows mold to run with leak. Unit includes stainless steel heat exchanger and can run continuously. It is suited for city water supply, water for chillers, and cooling towers.

Electronic Development Laboratories, Inc.    Danville, VA 24540
Dec 13, 2002 Accutherm® allows recording of temperature readings and direct download to any PC for analysis. Data can be imported into Excel or other programs for use in charts, graphs, or tables. Standard model monitors 10 zones with measurement range of -280 to +2,000°F. It includes ½ in. display with lighting for low-light areas, and is protected by water resistant case. Thermocouple type J or K may be used. Accutherm is NIST traceable.

Intertest Inc.    Columbia, NJ 07832
Dec 12, 2002 Handheld XtendaCam(TM) Series cameras, with 380-470 HTVL resolution, illuminate and view inaccessible areas, delivering crisp video to any monitor or recorder. Carbon-fiber, collapsible pole telescopes from 2 ft 10 in. to 11 ft 6 in. Interior cabling ensures quick deployment and snag-free operation. Locking swivel mechanism lets user aim head manually. Cameras submerge to depth equaling their length and collapse to less than 3 ft long, stowing away in transit case.

Sealevel Systems Inc.    Liberty, SC 29657
Dec 12, 2002 Model SIO.104+2 dual port, serial communications adapter provides two RS-232/422/485 ports, allowing field-selectable connection to real-world devices. Each port can be individually configured and offers automatic control of RTS signal when using RS-485 mode. Adapter uses XR16C850 UART, which supports standard PC data rates with top speed of 460.8 Kbps. It provides 128 byte FIFO, allowing error-free operation. SeaCOMâ„¢ Windows 95/98/ME/NT/2000/XP drivers are included.

Textron Automotive Co    Farmington, NH 03835
Dec 12, 2002 Metal Extrusion System consists of 2,000 ton stamping press equipped with computerized controls that adjust instantly to 100 different component designs. It combines stamping, deep drawing, and cold forming to produce fully integrated automotive components. Fasteners become part of single component, eliminating need for weld nuts, stamp-in nuts, and self-piercing nuts. Applications include suspension systems, drive trains, seat belt anchors, and transmission mounts.
