Spirax Sarco, Inc.    Blythewood, SC 29016
May 23, 2012 Pressure rated to ASME standards, Model BTS7.1 removes condensate from clean steam systems. Self-draining trap operates close to steam saturation temperatures, minimizing condensate back up and effectively venting air to ensure full sterilization. Safeguarding free draining surface, smooth surface finish minimizes risk of bacterial growth and product blockage. Trap is available with tri-clamp option, which is suitable for both ½ and ¾ in. connections.

Emhart Glass    Elmira, NY 14901
May 23, 2012 Using light barrier consisting of transmitter and photoelectric sensor, WHS Ware Handling Supervision automatically detects substandard glass containers at hot end of production line. Pneumatic air-reject system removes unwanted ware from conveyor before it can cause jams in subsequent stages. Completely integrated into FlexIS control system, WHS enables users to enter nominal bottle width, tolerance bottle width, reject duration, and minimum bottle distance.

ITTIA - Mobile and Embedded Database Solutions    Bellevue, WA 98004
May 23, 2012 Compatible with wide range OS range and OS-free environments, ITTIA DB SQL v5.4 lets embedded and mobile applications distribute data with Oracle, SQL Server, or other back-end enterprise databases. API for Dynamic Scripting Languages supports Python, while query engine is optimized with support for clustered indexes, scrollable cursor positioning, and support for Unicode in SQL query strings. Optional client/server feature enables multiprocess and remote network access to database files.

Aitech Defense Systems Inc.    Chatsworth, CA 91311
May 23, 2012 Developed specifically for avionics, C925 cPCI PowerPC-based SBC helps reduce engineering resources typically diverted to RTCA design requirements. Solution is fully-certifiable to DO-178 (software) and DO-254 (hardware) for safety- and mission-critical applications. PowerQUICC III 8548E processor can be hardware configured to 1.2 GHz with CPU core complex bus speed of 400 MHz. Along with range of memory features, SBC offers range of integrated I/O and expansion options.

UV III Systems, Inc.    Alburg, VT 05440
May 23, 2012 Customizable to suit specific needs, 3D UV Curing Units include UV-4XL Heavy Duty, UV Cure Buddy with slightly smaller footprint, and UV Multicure starter unit. Hand-held systems have cure footprints ranging from 12-36 in.², but there is no limit to size that can be scanned. Available in dual voltage models for U.S. or Europe, units are suited for hard-to-reach areas and have power needed to cure specialized coatings in both production and jobsite environments.

Rousseau Metal    St. Jean-Port-Joli, QC G0R 3G0  Canada
May 23, 2012 Featuring versatile and modular design that facilitates integration within work space, smart compact mobile L cabinet offers 100 lb of capacity per drawer and employs precision ball slides to ensure drawers open consistently and with minimal effort. Configurations are available with single, double, or triple cabinets, all of which feature casters. Available dimensions include 24, 28, 34, or 40 in. heights; 18 in. width; and 21 or 27 in. depths.

Rohrback Cosasco Systems    Santa Fe Springs, CA 90670
May 23, 2012 Offered in 3 types, CUI Corrosion Monitoring Sensors may be customized to meet requirements. Continuous Insulated Braid Wire Sensor, using insulated carbon steel wire as corrosion fuse, detects corrosion over large area. Inserted Probe Array Sensor acts as corrosion fuse detector that provides indication of corrosion occurring at pipe surface. Consisting of individual electrical resistance probe, CUI Corrosometer® Probe measures corrosion rate near pipe surface and helps determine underlying cause.

NEC Display Solutions of America, Inc    Itasca, IL 60143
May 23, 2012 With factory DICOM calibration and uniformity control, 21 in. MultiSync® MD211G3 provides accurate imaging across screen and monitors for any inconsistencies. Three megapixel grayscale model is equipped with ergonomic stand that provides 150 mm height-adjust, tilt, pivot, and swivel. Integrated front sensor constantly monitors and adjusts brightness, while GammaCompMD(TM) QA software performs routine display configuration and ensures consistent image quality.

ON Semiconductor, LLC    Phoenix, AZ 85008
May 22, 2012 Intended for high-power inductive heating and inverter applications, 1,200 V-rated NGTB15N120, NGTB20N120, and NGTB25N120 are targeted for industrial motor control and consumer products. Deep trench technology as well as wafer thinning and processing techniques enable minimal turn-off losses while maintaining low ON state voltage during turn-on. Supplied in TO-247 package with low forward drop and soft-recovery fast rectifier, IGBTs are offered with 15, 20, and 25 A current ratings.

Ironwood Electronics, Inc.    St. Paul, MN 55121
May 22, 2012 Designed to JEDEC STD, Model SBT-QFN-4015 features contact design with outside spring and flat stamped plungers for burn-in and test applications. Contactor provides current capacity of 4 A, self inductance of 0.88 nH, insertion loss of less than 1 dB at 15.7 GHz, and 0.097 pF capacitance. Operating from -55 to +180°C, socket includes IC guide for precise QFD edge alignment, and swivel lid with shoulder screw to facilitate IC change out.

Qosmedix Div., Qosina Corp.    Edgewood, NY 11717 8329
May 22, 2012 Available in black, white, and natural, Hinged Polypropylene Jars come in 1, 3, 5, and 10 g sizes and are suitable for trial samples of creams, lotions, serums, or powder-based formulas. Containers snap shut to secure contents inside, helping to prevent product from spilling during travel. Jars can be customized to any color or size, and can be personalized with company logo to promote individual brand.

Pixus Technologies    Waterloo, ON N2V 1C5
May 22, 2012 Offered in high-power, pluggable, and standard versions, VME64x (VME64 extensions) backplanes come in 6U (typ) height and offer various slot sizes with power bugs above and below slots. To meet VITA 1.7 Increased Current specification or high-power VME applications, 6.5U high backplanes feature extra power bugs on bottom of board. Another power option for VME-based systems is to use pluggable 47-pin connector, which can be implemented in vertical-mount backplanes parallel to signal slots.

Allegro MicroSystems Inc.    Worcester, MA 01615
May 22, 2012 Supplied in 28-pin TSSOP with exposed pad, A4979 has built-in translator and operates bipolar stepper motors in full-, half-, quarter-, and sixteenth-step modes at up to 50 V and 1.5 A. IC can be controlled by step and direction inputs or SPI-compatible serial interface. Also, current regulator can be programmed to operate in fixed off-time or fixed frequency PWM. Several decay modes are available, and phase current tables can be programmed to create unique microstep current profiles.

Hayward Industrial Products Inc., Hayward Flow Control Systems    Clemmons, NC 27012
May 22, 2012 Available in sizes from ½-2 in., GF-PP TB Series feature full port design, with true union threaded or flanged end connections, reversible seats, adjustable seat retainer, and double O-Ring stem seals. Units have max pressure rating of 250 psi, 150 psi with threaded or flanged ends, and max service temperature of 240°F. Providing impact resistance, platinum glass filled polypropylene material is suited for chemical services, abrasive applications, and water distribution.

Honeywell International, Inc.    Morristown, NJ 07960
May 22, 2012 To help companies in process industries optimize operation, Intuition(TM) Executive delivers enterprise-wide information management, decision support, and collaboration tools. Data processing and analytics capabilities enable software to anticipate problems and identify opportunities, while collaboration tools highlight and capture expert knowledge, share information, as well as help users make decisions and take action in order to drive intelligent operations and solve key challenges.

Joining Technologies    East Granby, CT 06026
May 22, 2012 Incorporating laser cutting and welding with single head, Infinite Web® enables splicing of titanium coils as well as splicing on 15° bias. Latter increases effective splice strength by increasing material at weld joint, and coaxial optics verify proper positioning. Able to service multiple converting lines, mobile and stand-alone system handles material thicknesses from 0.002-0.040 in. and features industrial PC-based control with touchscreen interface.

Electro Industries/Gaugetech    Westbury, NY 11590
May 22, 2012 Supplied in NEMA 12 enclosure, Shark® meter assembly comes pre-wired and configured in either 120 or 277 V (for 277/480 V systems) configuration and is suited for use as retrofit solution in environments where there is no available metering compartment. Assembly can be mounted and wired next to existing switchgear and is available with Shark 100 power and energy meter; Shark 100B, with native BACnet/IP protocol; or Shark 200, with data-logging and I/O.

Cherwell Laboratories Ltd    BICESTER OX26 4XB  United Kingdom
May 22, 2012 For use in critical manufacturing and validation applications with DataTrace wireless dataloggers, DataTrace® Pro promotes insight and productivity by creating process reports that promote analysis and comprehension of data while complying with regulatory requirements. Integrated solution maximizes efficiency with batch functions, shortcuts, and intuitive navigation. Also, field calibrations, battery changes, and data logging events are automatically incorporated into audit trail.

OSRAM Opto Semiconductor    San Jose, CA 95134
May 22, 2012 Able to help simplify laser system design, SPL BKxx-40WFT series has bar width of 10 mm and cavity length of 4 mm and produces IR radiation in wavelengths from 915-1,020 nm. Efficiency of up to 65% at 200 W optical output power promotes extended operating lifetime of greater than 30,000 hr typ. These direct diode lasers are efficient laser light sources for fiber-coupled systems and are efficient alternative to carbon dioxide lasers.

Stratasys, Inc.    Minneapolis, MN 55344 2020
May 22, 2012 Mojo 3D Printer comes in complete system (3D Print Pack) that contains everything needed to produce models, including material and support-removal system. Measuring 25 x 21 x 18 in., this Fused Deposition Modeling (FDM®) system features ABS material spool and print head integrated within one package. Settings for professional-grade 3D printing system are selected at host computer, and modeling operations are facilitated via included preprocessing software.
