Thomas Scientific    Swedesboro, NJ 08085
Apr 28, 2005 Requiring less than 6 in. of bench space, Mini Centrifuge provides users with compact size unit for microfiltration and spin downs from walls and caps of microcentrifuge tubes. Interchangeable microtube and strip rotors and adapters accommodate 0.4, 0.5, and 1.5 mL tubes as well as 0.2 mL strips and individual tubes. Translucent lid, which opens with stainless steel hinge pin, turns unit off if opened during use and restarts unit after closing.

Sanborn Technologies, North American Filtration of Massachusetts, Inc.    Walpole, MA 02081
Dec 22, 2004 Turbo-Separator T18-2 automatic solids discharging centrifuge recycles grinding and polishing fluids by removing 1–10 micron particles entrained in fluids. With process rate of up to 40 gpm, system has solids removal rate of up to 20 gal of sludge or swarf per shift and works with single CNC or in-line with central manufacturing cell. Features include automatic controls, digital interface, and sensors for monitoring operating parameters.

Labnet International    Woodbridge, NJ 07095
Nov 22, 2004 Offered with 10 rotor options, non-refrigerated Z 233 M-2 and refrigerated Z 233 MK-2 utilize microprocessor that controls all run parameters, including accel/decel rate. Hybrid control panel provides knobs for setting parameters and digital displays for viewing values. Speed can be set in rpm or g-force, and conversion program allows both to be viewed during run. Systems use brushless motors capable of attaining speeds to 14,000 rpm/18,620 x g.

Labnet International    Woodbridge, NJ 07095
Nov 22, 2004 High-speed Spectrafuge 16M offers acceleration and deceleration rates of 10 seconds or less, and continuously variable speed control to max of 14,000 rpm/16,000 x g. Unit is supplied with rotor for 18 x 1.5/2.0 mL tubes that can be removed for cleaning and autoclaving. Brushless motor is quiet, even at maximum speed.

Westfalia Separator, Inc.    Northvale, NJ 07647
Aug 04, 2004 Suited for use in vegetable oil refining and biodiesel production, RSC 30 Centrifuge offers self-cleaning, gas-tight operation. Output capability is 50 tons/day or 5,000 lb/hr.

Sanborn Technologies, North American Filtration of Massachusetts, Inc.    Walpole, MA 02081
Apr 19, 2004 Model T10-3AQ Centrifuge System removes solids, such as iron phosphate and dirt, as well as oil from parts washers baths. Producing separation force of over 1,100 g, stainless steel components operate within pH range of 2–12 and temperatures to 180°F. Unit features heavy-duty, removable liner designed to produce dry solids cake for ease of disposal. Product ships complete with transfer pumps and oil holding tank.

Sanborn Technologies, North American Filtration of Massachusetts, Inc.    Walpole, MA 02081
Sep 02, 2003 Turbo-Separator Model T6 centrifuge separates solids from oil, coolant, or water and includes centrate removal system that reduces misting and foaming associated with metalworking fluids. Unit also offers hinged lid that provides ease of access for cleanouts. In operation, contaminated liquid flows by gravity or is pumped into center feed of rotor and is accelerated to speeds of 3,450 rpm. Product processes oil at flow rates to 8 gpm and water-based fluids to 13 gpm.

Magstar Technologies    Hopkins, MN 55343
Mar 06, 2003 ROC 5 Envi-ro-fuge System utilizes centrifugal force of over 2,000 G to remove contaminants as small as 0.5 microns. When oil change is required, cleanliness of used oil makes it recyclable. Product takes out abrasive grit, soot, and dirt, and spins them into solid cake that is removed without shutting down operation. By-pass system allows for retrofit installation for engines, generators, pumps, and compressors with 100 gal and larger oil sump reservoirs.

National Conveyors Co., Inc.    East Granby, CT 06026
Dec 17, 2002 Vari-Screen centrifuge provides adjustable exposure of wedgewire dewatering screen area, resulting in desired product dryness for all types/configurations of metal chips. Available with motors rated from 10–25 hp, product offers capacities from 15–160 ft³/hr for cast iron, 20–200 ft³/hr for aluminum, and 25–240 ft³/hr for steel. Unit provides 550 gravities of centrifugal force and uniform feed distribution. Design offers self-cleaning, horizontal bowl.

Heinkel Filtering Systems, Inc.    Swedesboro, NJ 08085-1731
May 20, 2002 Beaker Centrifuge contains 2 beakers with maximum volume of 1.18 l each to filter and separate. It allows for testing at same G-forces using various filter cloths and wash ratios, as well as simulation of pressurization and drying. Unit is gas tight and totally enclosed. Variable frequency drive allows for high G-forces to be attained. Small cakes and pressure added centrifugation are possible.

Mars Tech    New City, NY 10956
Mar 26, 2002 Alfa Laval Alfie 400 disc-bowl centrifuge filters and recycles coolants and other water-based industrial fluids. 2 GPM module with high-speed, 7500 RPM, centrifuge offers feed and discharge pumps, inlet strainer, inlet and outlet hoses with quick disconnects, floating suction device, and collection tank for tramp oil and electrical control. It operates on single-phase 110V power.
