Tubing

Electrical Equipment & Systems, Packaging Equipment, Fluid & Gas Flow Equipment

Peelable Heat Shrink aids medical catheter manufacturing.

February 17, 2015

Enabling medical catheter manufacturers method to increase yield, safety, and efficiency while reducing scrap, Class VI-approved FluoroPEELZ™ facilitates and accelerates removal of recovered heat shrink from outer shaft by requiring one linear tear. Optical clarity lets operators visually inspect construction during reflow process, and product produces smooth, void-free exterior finish once removed. Read More

Fluid & Gas Flow Equipment, Electrical Equipment & Systems

Heat Shrinkable Teflon Tubing suits wide array of uses.

November 28, 2014

With temperature range from cryogenic to 400°F, Heat Shrinkable Teflon FEP Tubing is suited for wide spectrum of uses in aerospace, automotive, electrical, and chemical processing. Tubing meets Mil Spec 23053/11 and offers almost 100% chemical resistance in all applications. Read More

Fluid & Gas Flow Equipment, Electrical Equipment & Systems

Heat Shrinkable Teflon Tubing meets Mil Spec 23053/12.

November 28, 2014

With temperature range from cryogenic to 500°F, Heat Shrinkable Teflon PTFE Tubing is suited for wide spectrum of uses in aerospace, automotive, electrical, and chemical processing. Tubing offers low coefficient of friction, long flex life, and almost 100% chemical resistance in all applications. Read More

Food Processing & Preparation, Fluid & Gas Flow Equipment

Polyethylene Tubing suits industrial and food-related uses.

November 13, 2014

Available in linear low density formulation, Zelite™ Tubing resists splitting, making it suitable for air lines, chemical/fluid transfer, wire jacketing, pneumatics, and instrumentation. Lightweight polyethylene tubing is manufactured from 100%, non-toxic, virgin-grade, raw materials that conform to FDA standards. Offered in ¼–1¾ in. OD sizes, chemically inert product forms barrier to gases and moisture, remains flexible at temperatures below 0°F, and offers max operating temperature of 140°F. Read More

Fluid & Gas Flow Equipment

Antimicrobial Polyurethane Tubing resists degradation.

October 24, 2014

Specially formulated with Sanitized®, Series EA resists degradation from mildew, algae, fungi, and biofilm. Product is non-leaching and is 100% treated without using silver additives. Antimicrobial additive is fully compounded into tubing to protect both inner and outer surfaces, benefiting water systems, food and beverage, or any application where microbes can cause problems. Available in ¼, 3/8, and ½ in. sizes, tubing is also BPA- and phthalate-free. Read More

Fluid & Gas Flow Equipment, Mounting & Attaching Products, Materials & Material Processing

Pipes and Connectors enable custom workstation fabrication.

October 22, 2014

Made of aluminum alloy with anodized surfaces, ALUX structural system consists of pipes and connectors that allow companies to build, by themselves, such modular solutions as racks, carts, flowracks, and workstations. This corrosion-resistant, 28 mm tubular system is conductive (ESD) and affords adjustability. Read More

Fluid & Gas Flow Equipment

Formed Tubing offers aesthetic, space, and operational advantages.

October 16, 2014

Offering alternative to injection molded parts, formed tubing and hose parts can be produced for diverse production requirements. Formed shapes can eliminate problems such as space constraints as well as machine downtime due to kinking or improper assembly. Forming can also reduce assembly time and potential cutting errors, while customization can facilitate installation and promote professional aesthetics. For designs requiring tight placement, tubing can be formed into small radius. Read More

Fluid & Gas Flow Equipment, Electrical Equipment & Systems, Green & Clean

Conduit and Fitting System protects wires and cables.

October 15, 2014

HelaGuard Non-Metallic Conduit & Fitting System provides flexible and customized solution for protecting wires and cables from dirt, debris, UV light, and abrasion. Available in solid and slit models, conduits come in various materials, including flame-retardant and UV-resistant nylons. Reinforced spiral and smooth tubing are designed with smooth, inner bore. Offered in snap-on and compression fit options, non-metallic fittings come in straight, elbow, flange, and T-connector styles. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

Radiopaque Compounds target thin wall catheters.

June 13, 2014

Reinforced with nanoparticles for optimized pushability of catheters, LoPro Plus™ Compounds allow for extrusion of single layer tubes with radiopacity and strength properties equivalent to conventional 2 layer tubes, in which each layer provides distinct properties. Compounds use particles that are less than 1 nm thick and up to 1,500 x thickness in length. When added to radiopaque filled compounds in small quantities, nanoparticles optimize rigidity without increasing brittleness. Read More

Fluid & Gas Flow Equipment

Insulated Process Tubing Bundles are steam- and electric-traced.

June 13, 2014

Used to protect viscous materials from freezing, avoid gas condensation, and improve employee safety, jacketed process tubing bundles are available with copper, stainless, high alloy, or fluoropolymer process tubing as well as various insulation and jacket materials. Traced bundles incorporate steam tubing or electric heat trace with choice of self-regulating or constant wattage heating elements. Bundles may include single or multiple process tubes suited for use in heat trace systems. Read More

Fluid & Gas Flow Equipment

Wall Pass-Through System transfers critical fluids.

March 21, 2014

Designed for aseptic transfer of critical fluids during pharmaceutical and biopharmaceutical production, AdvantaPass minimizes cross contamination risks. System combines single-use tubing and isolation chamber assemblies with in-wall, permanent stainless steel components to eliminate cleaning validations associated with clean room protocols. Since system conveys fluids without need to physically move bins and totes, it removes risk of breakage, spillage, and lost pharmaceutical product. Read More

HVAC, Fluid & Gas Flow Equipment, Electrical Equipment & Systems

Pre-Insulated A/C Linesets accommodate pressures to 600 psi.

February 19, 2014

Available in 65 ft rolls of either ¼ and 3/8 in. diameter or ¼ and ½ in. diameter copper liquid/suction line sizes, Paircoil™ Malleable Linesets expedite installation of ductless mini-split and conventional air-conditioning systems. Industrial-grade insulation features UV- and wear-resistant coating with non-frictional surface to facilitate pulling. White insulation reflects solar heat, is water-resistant, and features hardened, but ductile surface that allows bending without kinking. Read More

Fluid & Gas Flow Equipment

Silicone Peristaltic Pump Tubing carries USP Class VI approval.

December 19, 2013

Featuring USP (United States Pharmacopoeia) Class VI endorsement regarding purity for fluid transfer in critical applications, APSPG tubing comes in total of 11 sizes from .031–.500 in. ID, including .313 in. ID x .500 in. OD, and is formulated to withstand repeated compression and release actions of peristaltic pumps. Flexible, 50 Shore A, low-volatile-grade silicone material is platinum cured, operates from -100 to +400°F, and meets FDA 21 CFR 177.2600. Read More

Fluid & Gas Flow Equipment

Coiled Tubing meets pressure/flow needs of CNG fueling stations.

December 18, 2013

Increasing speed of CNG station construction while maximizing safety from compressor to dispenser, CNG Plus™ Coiled Tubing delivers 5500 psi pressures and max flow needed in CNG fuel stations. Seamless coils reduce labor installation expense by eliminating need for welding multiple, shorter lengths of stick tubing. When fittings are required, restricted tolerances provide safe, leak-tight connections. Product meets all required standards, including ASTM A269 and ASTM A213. Read More

Fluid & Gas Flow Equipment

Cylinder Tubes are designed with smooth bore.

October 29, 2013

Smooth bore hydraulic cylinder tubes are standard C-1026 grade, ST 52, extruded to size. While available sizes range up to approximately 5¼ in., walls are available up to slightly greater than 3/8 in. Extruded design negates need for deburring, honing, and stress relieving. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

PVDF Copolymer targets minimally invasive medical catheters.

October 24, 2013

Suitable for catheters that are exposed to bodily fluids for less than 30 days, Kynar Rx® 752 can melt extruded in single or multi-layers for catheter shafts and other medical tubing. Flexible, low-friction fluoropolymer is USP Class VI compliant and resistant to chemicals and temperatures, enabling medical devices to be chemical, autoclave, or irradiation sterilized. Product offers flexural modulus of 50,000 psi and dynamic coefficient of friction of 0.54, according to ASTM test methods. Read More

Fluid & Gas Flow Equipment

Capillary Tubes suit scientific and industrial applications.

October 22, 2013

Suited for specialty applications, glass capillary tubes come in IDs as small as 0.005 mm and such materials as soda lime glass, borosilicate glass, quartz, and sapphire. All materials can be sterilized, are inert, and may be used for precision measuring. Tube shapes can be matched to application and include circular, rectangular, square, heavy wall, double bore, four bore, and multibore versions. Special shapes and sizes of tubes, as well as tubes in other materials, can also be supplied. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

High-Strength Steel Tubing targets automotive applications.

October 17, 2013

Available in sizes such as 1 x 1 in., 1 x 2 in., and 2.5 in. rounds, High Strength Steel Tubing comes in Dual-Phase and Martensitic steel. Dual-phase steel has ferrite and martensitic microstructure, while Martensitic steel has distinctive atomic structure created through Martensitic transformation process. With tensile strengths ranging from 700–1,300 mpa, both low-weight metals are suited for automotive impact beams, bumpers, seats, and structural components. Read More

Fluid & Gas Flow Equipment

Convoluted PTFE Tubing accommodates sharp turns, small bands.

October 4, 2013

Engineered as equivalent of corrugated FEP tubing, Convoluted PTFE Tubing is intended for use where sharp turns and small band diameters are required. High-temperature material, which has non-stick surface, is also electrical insulator and resistant to most corrosive liquids. Properties of PTFE tubing allow for cuffing of ends, fostering smooth transition to fittings and couplings. Uses for this FDA-compliant material include electrical or fluid conduits in semiconductor industry. Read More

Chemical Processing & Waste Management, Fluid & Gas Flow Equipment, Electrical Equipment & Systems

Custom Fluoropolymer Tubing serves multiple industries.

August 13, 2013

Available to be manufactured for custom critical applications, Heat Shrinkable Fluoropolymer FEP, PFA, and PTFE tubing serves as key element in applications for aerospace, medical, chemical processing, electrical, as well as semi-conductor industries. Read More
