Trelleborg Sealing Solutions
Fort Wayne, IN 46801
Jun 04, 2007 Designed for large O-Rings and other seal profiles over 20 in., FlexiMold(TM) giant seals eliminate risks associated with spliced O-Rings, and demonstrate full visual and dimensional integrity of molded seal. They can be produced in almost infinite diameters, and allow for zero defect quality policy.

SKF USA Inc.
Kulpsville, PA 19443
May 24, 2007 SKF® Heavy-Duty Mechanical Shaft Seals protect bearings against harmful solid and liquid contaminants and prevent loss of lubricant. SKF® Seals fit into conventional, straight bore housings without boring or polishing and can be installed by hand. Bore diameters range from 70-812 mm, operational temperature range is 54-107°C, and permissible velocity at continuous operation is 1.75 m/sec.

Schreiner Label Tech, Inc.
Southfield, MI 48034
May 14, 2007 Self-adhesive and non-adhesive Pressure Compensation Seals (PCS) are available with air-permeable and waterproof PTFE membrane that enables air molecules to pass through seals while restricting passage of water, oil, and dirt particles. Made from microporous-membrane material that ensures pressure equalization, customizable PCS seals are suited for ventilation of equipment housings. They provide chemical and thermal resistance and can withstand steam cleaning.

Carlton Industries
La Grange, TX 78945
May 14, 2007 Measuring 3 3/8 x ¾ in., High Security Snapper(TM) Bolt Seal is made of steel and has pull strength of 4,000 lb for C-TPAT and ISO 17712 compliance. This 2-piece seal enables both bolt and body to be consecutively numbered to provide optimal security and tamper resistance. Featuring bright yellow plastic coating, seal is suited for container door latches and trailer doors requiring extra security.

Conax Buffalo Technologies LLC
Buffalo, NY 14225 4740
Mar 07, 2007 Suitable for gas or liquid, HL Glands feature Grafoil® sealant and come in ½ and ¾ in. NPT sizes. Units provide temperature range of -4 to 130°F and have pressure rating of 500 psig. With mechanically sealed HL Gland, users do not have to be concerned about cracks in compound sealants that allow explosive gases or liquids to leak in conduit system, or migration of explosive gases through stranded conductors due to pressure differential in conduit system.

Schreiner Label Tech, Inc.
Southfield, MI 48034
Sep 15, 2006 Maintaining manufacturer's exact requirements for airflow, ProTech pressure compensation seal labels are permeable to air but not to water, oil, or dust. Micro-membrane material ensures pressure equalization, without allowing water or contaminants to pass through from outside. Protective laminate is applied over labels to protect membrane. Pre-printed film can be laser-printed during process, enabling information such as serial numbers or barcodes to be added.

Simrit, A Div. Of Freudenberg-NOK
Plymouth, MI 48170
Jul 18, 2006 Utilizing magnetic force to maintain magnetic fluid in specific position around shaft, Magnetic Fluid Vacuum Seals provide liquid sealing barrier to fluids and gases. Low friction hermetic seal allows minimal contamination. Effective in temperatures up to 200°C, seals offer peripheral velocity up to 1.0 m/sec, as well as thermal and high vacuum resistance. Semiconductor applications include deposition, ashing, plasma etch, metallization, and ion implant.

Chromalox
Pittsburgh, PA 15238
May 10, 2006 V Seal, V Seal Plus, A Seal, and RX Seal are able to handle extended storage in high humidity environments. Tubular seals prevent moisture ingress and offer service life over variety of service temperature applications, 300°F max. Products are designed for OEM as well as overseas transport applications.

SKF Motion Technologies
Bethlehem, PA 18017
May 02, 2006 To protect grease-lubricated bearings exposed to contamination, NILOS®-Ring Type LSTO steel-disk seals satisfy key performance requirements by minimizing bearing friction losses and heat build-up as well as preventing lubricant leakage and penetration of dirt. Non-contact, grease-filled labyrinth sealing elements consist of laminated steel-seal disks and steel cores. Seals will not slip when clamped in axial direction of inner and outer periphery of roller-bearing ring.

Flowserve Corp.
Irving, TX 75039
Apr 06, 2006 Built with durable metals to withstand corrosion and harsh chemical conditions, GCX single mechanical cartridge seal features alloy C-276 bellows, 316 SS components, and flexible graphite foil secondary seals. Available in 8 standard inch sizes from 1.125-2.625 in. and 6 standard metric sizes from 33-65 mm, seals operate at 0-200 psig, -40 and 400°F, and up to 15.2 m/s.

Flowserve Corporation
Irving, TX 75039
Mar 28, 2006 Featuring Precision Face Topography(TM) and wavy face seal design, QBQ LZ is suited for pumps in light (0.40-0.60 specific gravity) hydrocarbon service at vapor pressure margins from 5-50 psi. It addresses problem of vaporization by altering temperature and pressure dynamics on seal faces, and satisfies all API 682/ISO 21049 design and qualification test requirements. Bi-directional product may also be used for high-pressure pumps above 300 psi at any vapor margin.

Rogers Corporation
Rogers, CT 06263 0188
Feb 21, 2006 PORON® Soft Seal foam, a formulation of microcellular urethane, is designed for gap filling within sensitive electronic enclosures such as LCDs in cell phones or integrated media players. Product conformability allows LCD panel gaskets to adjust to varying contours and gap thicknesses, while still providing tight seal under harsh conditions. PET supported foam has density of 6.5 pcf and is available in 1 mm thickness.

Bal Seal Engineering Co., Inc.
Foothill Ranch, CA 92610 2610
Jan 13, 2006 Made of formulated, blended PTFE or other engineered polymer compounds, Polymer Seals employ pressure-energized canted-coil spring technology, which enables near-constant contact force over wide range of working deflection. Metal locking ring pressed into housing of each seal minimizes diametrical seal shrinkage. Seals withstand high temperatures, pressures, and velocities as well as abrasive and viscous fluids inherent in hot melt adhesive dispensing applications.

Brooks, E. J., Co.
Livingston, NJ 07039
Nov 01, 2005 Suited for use on marine containers, 3/8 in. Intermodal II Bolt seals are made from all-steel components with plastic-coated locking case, and insert that spins freely to ensure seal integrity. Locking ring ensures proper sealing engagement of bolt and locking case, and plastic cover clearly reveals any tampering attempt. Shoulder design of locking case provides 1/8 in. shroud that prevents insertion of tool or shim to disengage bolt from case.

John Crane Group / Mechanical Seals
Morton Grove, IL 60053
Jul 22, 2005 Mechanically loaded in axial direction by gland follower, one-piece Type LMPC can be installed in new or existing equipment without modifications. Live-loading feature allows for in-service self-adjustment of packing load with aid of Belleville disc springs, eliminating frequent manual gland bolt adjustment. Seal's design features hard-coated shaft sleeve, positive mechanical drive, and internal/external flush and lubrication capabilities.

Bal Seal Engineering Co., Inc.
Foothill Ranch, CA 92610 2610
Jun 07, 2005 BAL™ Seal series U–13X, U–14X, and KS13X ensure down–hole data logging tools remain isolated from harsh, abrasive drilling environments. Sealing technologies U–13X and U–14X withstand 25,000 psi down–hole pressure and 150 psi differential sealing pressure in oil drilling operations, while KS13X suits press–in metal locking ring retention systems. Constructed of filled PTFE seal material, each system incorporates canted–coil spring energizers that provide near–constant force.

EGC Enterprises, Inc.
Chardon, OH 44024
May 11, 2005 Tri-Clad® seals and gaskets combine Thermafoil® and Thermabraid® graphite with range of high-temperature metals. Compressible and resilient graphite elements act as spring to maintain sealing force throughout thermal excursions, while metal provides protection and support. Seals are suited for critical engine joints at temperatures exceeding 1,000°C.

Unisto Electronic Seals
South Wales   United Kingdom
May 05, 2005 Crypta® GateTrak® continuously monitors trailers from the time they are loaded until they are unloaded. Re-usable seals are fitted to vehicles or trailers and generate random seal number each time seal is closed. Seal number remains unchanged until seal is opened, enabling secured status of load to be remotely verified via RF transponder. Vehicle is automatically interrogated by system to determine load, veracity of seal, tractor ID, and driver ID.

Inpro/Seal Co.
Rock Island, IL 61204 7331
May 04, 2005 Custom-engineered Articulating Air Mizer™-PS is suited for containment of powders, abrasives, liquids, and toxic vapors in dry powder and bulk process applications. Able to handle shaft misalignment and deflection, product uses solid wall of air that functions as barrier for contamination and works to retain product in equipment. Non-contact design with air purge accepts radial and angular shaft runout up to 14 in. and shaft diameters from ½–36 in.

Simrit, A Div. Of Freudenberg-NOK
Plymouth, MI 48170
Apr 07, 2005 Fas-N-Seal™ seals feature metal retainers with integrated elastomeric material. Retainer serves as torque limiter to eliminate torque loss during operation, while bonded design prevents displacement under internal pressure. Fas-N-Seals are available in range of Aerospace Material Specification/Military Specification elastomers, including nitrile, fluorocarbon, silicone, and fluorosilicone. Metals include aluminum, stainless steel, and chrome molybdenum steel.
