Spool Valves

Fluid & Gas Flow Equipment

Spool Valves come in pipe sizes for optimized flow rates.

July 14, 2016

Brass and 316 Stainless Steel spool valves of 362 and 562 Series come in 3/8 and ½ in. pipe sizes suited for control valve automation in oil and gas markets. While 362 Series consists of 3-way valves for single-acting process valve applications, 562 Series includes 4-way spool valves for double-acting process valves. Both series, which have low-power versions suited for remote applications, offer corrosion resistance for harsh environments and include pneumatic and solenoid models. Read More

Fluid & Gas Flow Equipment

Spool Valves come in ¾ and 1 in. sizes.

April 19, 2016

Available in brass and 316L stainless steel construction for corrosion resistance in harsh environments, 362 and 562 Series Valves offer solutions for control valve automation in upstream, midstream, and downstream oil and gas markets. Units come in 3-way and 4-way versions as well as pneumatic and solenoid models. Options include momentary manual override, low temperature rating of -40°C, and solenoid option with ATEX d and UL hazardous location approvals. Read More

Fluid & Gas Flow Equipment

Stainless Steel Spool Valves deliver mission-critical reliability.

June 23, 2015

Respectively designed for double- and single-acting process valve applications, 4-way 562 Series and 3-way 362 Series are used for control valve automation in upstream, midstream, and downstream oil and gas markets. Both versions are available in ¼ in., 316L stainless steel construction for corrosion resistance in harsh environments and incorporate solenoid technology for mission-critical reliability. Low-power solenoid versions consume as little as 1.4 W.
Read More

Fluid & Gas Flow Equipment

Double Valve combines safety and performance.

May 21, 2014

Available in ¼ and 3/8 port size, CROSSMIRROR® size 0 valve suits shearing, forming, cutting, clamping, pinch-point, 2-hand control (ISO 18351 Type 3 C), and cylinder return-to-home position applications. Dual precision stainless steel spool and sleeve construction eliminates contact wear while accelerating response and extending service life. Able to perform reliably in caustic conditions, valve has self-contained monitoring system and is designed for CAT-4 Performance Level e applications.
Read More

Fluid & Gas Flow Equipment, Green & Clean

Helping You Master the Fields with Compact, Energy-Saving Valves

March 14, 2014

CHARLOTTE, N.C. – HAWE Hydraulics is a leading global manufacturer and supplier of sophisticated hydraulic components and controls for the mobile, industrial, and renewable energy markets. The PSL/PSV valve series is just one of the many components HAWE Hydraulics displayed at the ConExpo/IFPE Tradeshow in Las Vegas, NV. HAWE offers a proportional directional spool valve type, PSL/PSV... Read More

Fluid & Gas Flow Equipment, Material Handling & Storage, Green & Clean

HAWE Valves Assists Off-Road Motorsport Vehicles

January 7, 2014

CHARLOTTE, N.C. – HAWE Hydraulics, a leading global manufacturer and supplier of sophisticated hydraulic components and controls for the mobile, industrial, and renewable energy markets. Dakar 2014, is a legendary sporting event that challenges drivers‘ endurance, racing skills and strategic navigational competencies. This intense off-road race is made up of two marathon stages that... Read More

Fluid & Gas Flow Equipment

Spool-Type Solenoid Valves control flows up to 16 gpm.

July 12, 2012

Comprising 11 models, SV15 High Flow Solenoid Valves provide electro-hydraulic on-off directional flow control. Units feature rated pressure of 3,000 psi, based on NFPA fatigue test standards at 1 million cycles. Using 15 size cartridge cavity, HIC designers can make large passageways in manifolds, minimizing pressure losses in system. Optional features include 300 micron filter to protect actuator from large particles, push-pin manual override, coils with diodes, and AC current. Read More

Fluid & Gas Flow Equipment

Heated Dispense Valve has integrated temperature control.

June 17, 2010

With temperature controller and thermocoupler, Model 775H pneumatically operated spool valve allows accurate heating of material being dispensed from ambient up to 350°F. It can dispense volumes down to 0.01 mL, provide continuous and adjustable flow, and can be used alone or as part of heated system. Supplied with special nozzles or manifolds as required, valve offers adjustable and lockable suck back control, delivering consistent, stringless dispensing of tacky materials. Read More

Fluid & Gas Flow Equipment

Manual Selector Valve is rated to 5,000 psi.

May 10, 2010

Featuring precision ground Iosso plated spool, 6-port Model MS6 come standard with manual handle and 2-position detent that holds spool in either active position. Both ports on top of valve serve as inlet and outlet while ports on either side are plumbed into 2 separate circuits. With O-ring ports to eliminate leakage and standard polypak seals, unit allows up to 45 gpm out of either side ports while other set of side ports are closed. Read More

Fluid & Gas Flow Equipment

Flow Control Valve Package comes in open or closed versions.

May 10, 2010

Combining functionality of Series 36-38 stack valve with flow control of EFC valve, Model 36EFC allows users to proportionally control input flow to stack valve in one complete package. System features precision ground, heat-treated spools; diamond lapped spool bore for consistent spool fit; O-ring ports to eliminate leakage; and pilot cartridges that assure positive force to shift spool. Model 36EFC is adaptable to automated circuits for 4-way directional speed control. Read More

Fluid & Gas Flow Equipment

Hydraulic Loader Valve controls 2 separate functions.

May 7, 2010

Nominally rated for 0-10 gpm and 4,000 psi, LV22 Series is designed primarily for loader market, but is suitable for any application where control of 2 separate functions is required. Unit features adjustable internal relief from 1,000-4,000 psi with standard setting of 2,000 psi. Spool actions include spring centering, detent, friction detent, and fourth position float. Joystick or individual enclosed handle options are available. Read More

Fluid & Gas Flow Equipment

Lever Valves are designed for easy installation and access.

April 15, 2010

Lever Valves are manually-operated, 3- or 4- way spool valves with ¼ in. NPT ports for easy accessibility. Products offered in 0-150 psig pressure ranges and operate in temperatures from 32-140°F. Suited for wide range of application, units are available with either base or panel mount. Read More

Fluid & Gas Flow Equipment

High Flow Spool Valve suits fluid packaging operations.

September 18, 2009

Capable of handling high viscosity fluids, Model 780 is suited for fluid packaging operations, including filling vials, bottles, and other specialty containers, and can be integrated into robotics and automated production processes. Valve offers adjustable material suck-back and flow control to maintain precise accuracy of volume dispensed. Featuring hard-coated aluminum components and Teflon® seals as standard, unit is also available in stainless steel and Teflon® construction. Read More

Fluid & Gas Flow Equipment

Clippard Introduces New Push/Pull Valves

July 23, 2009

Clippard Instrument Laboratory, Inc., introduces a new line of manually-operated Push/Pull Valves.<4444>These new spool valves are available in both 3- and 4- way configurations. Available in detent or momentary versions, these new valves provide the flexibility for unlimited applications. And, with an operating temperature of 32 to 140°F and an operating pressure of 0 to 115 psig, these new... Read More

Fluid & Gas Flow Equipment

Dispensing Valve features suck-back and flow control.

January 16, 2009

Leveraging adjustable and lockable suck-back control, model 775 spool dispensing valve ensures consistent, string-less dispensing of tackier materials while also preventing droplets from remaining on dispense nozzle when using low-viscosity materials. Adjustable and lockable flow control, also included, enables complete control over amount of material dispensed (down to 0.01 ml). Suited for use with various materials, valve can be modified to meet specific requirements. Read More

Fluid & Gas Flow Equipment

Diverter Valve comes in manual and electric versions.

September 11, 2008

Manufactured from iron casting, DDV 60 lm Valve offers manual and direct acting solenoid options in 12 or 24 Vdc. Spool is totally enclosed by universal hand lever in manual version and by solenoid in electric version. Mounted directly on to service ports, Hy-pro V5 PCD pilot check protects against accidental operation when valve is not in use. Valve is suited for applications where 2 or more independent circuits are to be selected from single control valve. Read More

Fluid & Gas Flow Equipment

Mini Spool Valve is designed for low-high viscosity fluids.

November 1, 2006

Model VMS400 dispenses RTV/Silicones, Solder Pastes and Masks, Sealants, and UV Adhesive with up to 700 lb fluid pressure. Suck-back helps adjust fluid cut-off at end of cycle, while UHMW-PE seals separate wetted materials from pneumatic movement. With minimum shot size of 0.1 cc, valve can cycle up to 400/min using 4-way controller. Device suits applications requiring precision and repeatability in shot cycling, bead paths, and gaskets. Read More

Fluid & Gas Flow Equipment

Mini Spool Valve dispenses low- to high-viscosity fuids.

October 24, 2006

Able to handle up to 700 lb of fluid pressure, Model VMS400 has adjustable Suck-Back so that fluid cutoff at end of cycle can be finely adjusted. Unit features minimum shot size of 0.1 cc and can cycle up to 400/min using 4-way valve controller. Wetted materials are separated from pneumatic movement by UHMW-PE seals. Valve is suitable for use with RTV/silicones, solder pastes and masks, sealants, and UV adhesives. Read More

Fluid & Gas Flow Equipment, Material Handling & Storage

Spool Valve dispenses high viscosity materials.

May 12, 2005

High pressure dispensing valve, 790HPNM, dispenses dots and lines and performs potting applications with materials such as silicones, RTV, adhesives, greases, and UV curable materials. Retracting spool design ensures accurate deposit of material, and valve can be adapted for use on robotic or bench-top dispensing systems. Control is via company's standard controller or VC-1195A 4-way valve controller, which maximizes valve suck-back action and closes valve faster. Read More

Fluid & Gas Flow Equipment

Proportional Valve can be programmed via PDA or laptop.

February 4, 2005

Featuring onboard electronics, PowrFlow(TM) VED03M Valves are available in 6 flow rates from 1-9 gpm, 5 flow metering configurations, and 3 spool-centered conditions, resulting in 90 possible combinations. D03 style valves are rated to 5,000 psi, are equipped with 12/24 Vdc solenoids, and use standard 7-pin connectors at system end. Windows-based screen lets user set all programmable functions such as null, gain, ramp-up/ramp down dither, and input signal. Read More
