Hayward Industrial Products Inc., Hayward Flow Control Systems    Clemmons, NC 27012
May 22, 2012 Available in sizes from ½-2 in., GF-PP TB Series feature full port design, with true union threaded or flanged end connections, reversible seats, adjustable seat retainer, and double O-Ring stem seals. Units have max pressure rating of 250 psi, 150 psi with threaded or flanged ends, and max service temperature of 240°F. Providing impact resistance, platinum glass filled polypropylene material is suited for chemical services, abrasive applications, and water distribution.

Assured Automation    Clark, NJ 07066
Apr 30, 2012 Available in ½-4 in. sizes, P2 Series 2-Way True Union Ball Valves include DUAL BLOCK® system, which locks union nuts, preventing back-off due to vibration or thermal cycling. Deep grooves, thick O-rings, and cushioned PFA seats contribute to optimized seals at pressures up to 232 psi, while integral mounting flange and support bracketing combine to facilitate actuation and anchoring. Offered in PVC or CPVC with NPT or glue socket connections, valves use electric, pneumatic, or manual actuators.

Viega    Wichita, KS 67202
Feb 23, 2012 Available for use with Viega ProPress® stainless steel systems, ball valve features 3-piece construction from 316-grade stainless steel, comes in ½-2 in. sizes, and has machined ISO 5211 mounting pad for actuators or operators. Ball within valve is full port ball, and handle locks in 2 positions. Able to be maintained without being removed, valve features Smart Connect® feature and press ends that include FKM sealing element for elevated temperature tolerance.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Feb 10, 2012 Featuring PFTE stem packing and ball seat and -40 to +365°F temperature limit, Series UBV Uni-Flange Ball Valve handles working pressures up to 600 psi for gases and liquids. Forged brass construction lends to reliability in residential and industrial applications, while full port design minimizes flow resistance. Sizes, which range from ½-2 in., promote application versatility. Body, cap, stem, gland, and stem nut are of brass, and ball is of chrome-plated brass.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Jan 23, 2012 Available in ¼-3 in. sizes for commercial and general industrial use, Series DBV is constructed with brass body, body cap, and ball. Seats and blowout-proof stem are made of TFE for maximum safety in event of overpressure. Operating from -40 to 365°F, hand lever ball valve has full port design and is suited for manual shut off of gases and liquids compatible with wetted materials.

Habonim USA    South Hackensack, NJ 07606
Dec 29, 2011 Available in 3-, 4-, and 5-way models ranging from ¾-3 in., A61X/A62X Series provides diverse selection of flow patterns, rotation angles, and end configurations, making it suited for demanding mixing and diverting applications. Units are made of Hastelloy C22 and stainless steel with pressure range from vacuum to 100 bar and temperature range to 500°F. Offering manual or actuated operation, valves are suited for water, gas, chemicals, and solvents.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Dec 23, 2011 With working pressure of up to 450 psi, Series MVB comes in 4 sizes with choice of tee, wedge, and lever handles. Pure PFTE ball seats promote tight shutoff, while double seal design allows valve use in both directions. Availability of female x female and male x female configurations enables application flexibility. Wetted materials include chrome-plated brass valve body and ball as well as fluoroelastomer O-ring stem seal.

Top Line Process Equipment Co.    Bradford, PA 16701
Nov 10, 2011 Meeting 3A/FDA/USDA requirements, Top-Flo® 3-Way Ball Valves feature fully encapsulated PTFE cavity filler, locking vinyl handle, and and are available in sizes from ½-4 in. ISO-5211 direct mounting pad, standard on all valves, eliminates need for brackets and couplers. Suited for applications requiring tight shut off, valves maintain and regulate high-volume, high-pressure, and high-temperature flow. Tri-clamp ends are standard, but other ends are available.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Jun 07, 2011 Suited for commercial and general use, Series 3ABVH Digital Temperature Switch features PTFE seats and seals as well as blowout-proof stem. Valve body, end caps, ball, and stem are all made of brass, and ISO 5211 mounting pad allows for direct mounting of pneumatic and electric actuators. Suited for manual valve shut off in hot and cold water systems, series has Female NPT end connection and accommodates line sizes from ¼-3 in., pressures to 400 psi and temperatures to 320°F.

Hayward Industrial Products Inc., Hayward Flow Control Systems    Clemmons, NC 27012
May 25, 2011 Available in 2½-6 in. sizes with full port design, TB Series incorporates actuation mounting pad per ISO5211 and integral panel mount foot pad. Units feature FPM or EPDM seals, reversible PTFE seats, and double O-ring stem seals. Pressure rated at 235 psi non-shock, ball valves have heavy wall thermoplastic construction that stands up to most aggressive applications, including waste and water treatment, chemical processing, food and beverage, pharmaceutical, and marine environments.

Dwyer Instruments, Inc.    Michigan City, IN 46361
May 05, 2011 Featuring heavy-duty construction with full port design and female NPT end connection, Series 3BV3H has ball and stem of 316 Stainless Steel as well as 4-seat design suited for high cycle applications. Pneumatic and electric actuators can be mounted using ISO 5211 mounting pad, and available line size from ½-2 in. optimizes flow rates while minimizing pressure loss. Respectively, pressure and temperature limits are 1,000 psi and 450°F.

Dwyer Instruments, Inc.    Michigan City, IN 46361
May 04, 2011 Compatible with liquids and gases, Series 3BV3SH 3-Way Stainless Steel Ball Valve is available in line sizes from ½-3 in. with sanitary clamp ends that facilitate removal. ISO 5211 mounting pad is provided for automation when attached with electric or pneumatic actuator. Featuring full port design that provides consistent flow characteristics, valve is suited for use in pharmaceutical, food and beverage, and chemical processing systems.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Apr 14, 2011 Available in ½-4 in. sizes optimized for flow with minimal pressure drop, Series 3BV2FH is designed to meet ANSI B16.34 flange standards and features ANSI 150 lb flanged ends that facilitate installation. This full port valve, suited for mixing applications, has 4-seat design as well as 316 SS ball and stem construction. Also, ISO 5211 mounting pad accepts direct mounting of pneumatic and electric actuators.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Apr 14, 2011 Designed to meet ANSI B16.34 flange standards, Series BV2FH features ANSI 150 lb flanged ends to facilitate installation, blowout-proof stem that promotes safety, as well as RTFE seats and seals for extended operational life. All available sizes, optimized for flow with minimal pressure drop, feature 316 SS bodies, ends, and balls. Also included, ISO 5211 mounting pad accepts direct mounting of pneumatic and electric actuators.

Asahi/America    Malden, MA 02148
Apr 01, 2011 Intended for gas, sewer, and water pipeline applications, PE100 features corrosion-resistant internal and external parts. Sizes range from 1-6 in., and each employs 2-step planetary gear system that ensures smooth opening and closing of valve and eliminates water hammer. Suitable for below-ground service, valves come in both metric and IPS pipe sizes with NBR seals for air/gas and EPDM seals for fluids. Valves larger than 2 in. are available with integrated gear box.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Mar 30, 2011 Suited for commercial and general industrial use, Series BV2IB incorporates Buna-N stem O-rings and PTFE seats and seals that extend product life and lend to leak-free operation. Blowout-proof stem adds additional safety in event of over pressure, and full port is designed for minimal pressure drops with consistent flow rates. Accommodating ½-2 in. line sizes, series has 600 psi and 320°F limits. ISO 5211 mounting pad accepts direct mounting of pneumatic and electric actuators.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Mar 30, 2011 Series BV2IM Ball Valve with ISO Mounting Pad is compact valve with body, end, ball, and stem manufactured of 316 stainless steel. Its ISO 5211 mounting pad accepts direct mounting of pneumatic and electric actuators. Blowout-proof stem provides safety in event of overpressure, while full port design of product allows for maximum flow rates with minimal drops.

A-T Controls, Inc.    Cincinnati, OH 45242
Jan 31, 2011 M-series employs coated matched balls and seats of stainless steel, stellite welded, and hard chrome-plated steel that withstand abrasive materials, temperatures from -20 to +661°F, and ANSI class 600 pressures. Oversized stem prevents deformation, ball design prevents leakage, and Inconel® seat spring maintains positive contact between ball and seat during operation. Available in 0.5-8.0 in. nominal pipe sizes, valves offer flanged, threaded, socket weld, and butt weld connection options.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Aug 23, 2010 Constructed with wetted materials compatible with gases and liquids, Series 3MSV is suited for directional control of fluid in instrumentation and process systems. Micro finished ball and PTFE seats ensure quality seal and facilitate operation, while blow-out-proof ball and stem promote durability and safety in case of over pressure conditions. Valve body is available in brass or 316 stainless steel, and straight through flow path minimizes pressure drop.

Dwyer Instruments, Inc.    Michigan City, IN 46361
Aug 11, 2010 Suited for use with gases, steam, and liquids that are compatible with wetted materials, Series HBV features pressure limit of 2,000 psi and temperature range of -20 to 425°F. ISO 5211 mounting pad facilitates direct mounting of pneumatic and electric actuators. With blow out-proof stem, lockout capability, and live-loaded stem packing system, valves are suitable for variety of automation applications.
