Liquid Silicone Seals exhibit lotus effect (superhydrophobicity).

April 24, 2015

With surface-located protrusions measured in microns and modeled after surface of lotus flower, Liquid Silicone Seals feature structure resistant to water as well as viscous substances. Friction-reducing microstructure of sealing surface can help ease assembly in dry state without need for lubrication, and lightweight construction promotes application versatility. Also, liquid silicone seals possessing lotus effect help eliminate concerns over stick-slip effect. Read More

Fluid & Gas Flow Equipment

Air Nozzle suits cooling, drying, and blow-off applications.

April 24, 2015

Made of tough ABS material and rated at 150°F, Airwisk™ Nozzle produces quiet, concentrated flat-fan pattern of air. High-impact air is discharged through recessed orifices with pinpoint accuracy. Nozzle is designed with several mounting holes to ensure accurate alignment and can be mounted individually or side by side for maximum coverage. With ¼ in. thread size, nozzle’s capacity ranges from 9.5 scfm at 20 psi to 32.1 scfm at 100 psi. Read More

Fluid & Gas Flow Equipment

High Pressure Piston Pumps produce minimal pulsation.

April 24, 2015

Designed with automatic pressure compensation and pulse dampener, LS Class single-headed, positive displacement piston pumps employ micro-stepping motor technology. Standard fluid path materials are stainless steel and PEEK (titanium optional); jacketed heads are available for temperature-controlled processes. Available in 5, 10, and 40 mL/min versions, products offer pressure capability up to 6,000 psi, chemically resistant drip tray, leak sensor, and RS-232 and Micro USB 2.0 ports. Read More

Fluid & Gas Flow Equipment, HVAC

Fume Extraction Filters provide 31 sq-ft of filter media.

April 23, 2015

Available for FILTAIR® 130 portable fume extractors, FILTEK™ XL Filters double lifecycle compared to previous filter styles and feature MERV rating of 15, ensuring capture of smallest weld fume particles ranging from .3 to 1 micron in size. FR-treated replacement filters can be cleaned manually with dry, compressed air. Filter service indicator light on fume extractor indicates when this routine maintenance should be performed. Read More

Fluid & Gas Flow Equipment, Lubricants

Automatic Lubrication Pumps suit in-plant applications.

April 22, 2015

Designed to operate without priming, LubePro™ Series comprises Models A900 and A1900 for oil applications and Model A2600 for grease applications. Injector-based pumps feature factory-installed low level detection system, and integrated vent valve that automatically relieves pressure on return stroke to provide trouble-free performance. Typical applications include food and beverage processing and packaging, glass manufacturing, tire production, injection molding, and paper production. Read More

Fluid & Gas Flow Equipment, Health, Medical and Dental Supplies & Equipment, Mounting & Attaching Products

Single-Use Sterile Manifold Adapters create closed systems.

April 22, 2015

Offered in gamma and high-temperature versions, AseptiQuik® Tee and Cross Manifold Adapters provide flexibility for biopharmaceutical manufacturers by enabling onsite connection of standard sub-assemblies to create wide array of customized single-use systems. Units mate with genderless AseptiQuik G series connectors without need for clamps or fixtures. Adapters are suited for transferring valuable media in single-use bag and tubing assemblies, cell banking systems, bioreactors, and mixers. Read More

Fluid & Gas Flow Equipment

PEEK Tubing comes in several color-coded versions.

April 21, 2015

PEEK Tubing comes in varieties of natural PEEK®: solid color-coded, dual-layer color-coded, striped, and dash-stripe coded. Dual Layer Color-Coded type eliminates concern that sample stream could be contaminated by pigments used to color code tubing. Available with ODs of 360 micron, 1/32 in., 1/16 in., and 1/8 in. and IDs down to .002 in., tubing uses RoHS-compliant colorants. Tolerance is ±.0005 in. for IDs up to .010 in. and ±.001 in. for larger IDs. Read More

Fluid & Gas Flow Equipment

Needleless One-Way Valve suits liquid sampling procedures.

April 21, 2015

Featuring swabbable design, Model 90403 is constructed with ABS red male luer lock body, polycarbonate female luer lock body, and silicone valves. When valve is accessed by male luer lock or male luer slip syringe, internal duckbill check valve allows fluid samples to be taken. One-way duckbill prevents accidental injection through connector. Upon disconnection of syringe, needleless valve will seal against any back pressure. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

Microcellular Polyurethane Foam meets dynamic design needs.

April 20, 2015

Able to be custom fabricated as needed, with or without pressure sensitive adhesive, PORON® AquaPro™ provides soft (41) to very soft (37) water sealing solutions. Both formulations, which exhibit resistance to stress relaxation and compression set, deliver long-term performance needed to maintain seal. While performing reliably from -40 to +90°C (constant), chemical-resistant and flame-retardant foams also support intermittent use up to 120°C. Read More

Fluid & Gas Flow Equipment

Back Pressure Regulator withstands aggressive chemicals.

April 16, 2015

Available with ½–2 in. port sizes, Equilibar© Back Pressure Regulator utilizes flexible diaphragm as only moving part. Body is CNC-machined from PVDF bar stock, while diaphragm is manufactured from glass matrix reinforced PTFE material. Diaphragm acts to directly seal against valve seat, eliminating need for friction-causing dynamic seals. With response time measured in milliseconds, pilot operated regulator controls media pressure on inlet port in precise 1:1 relationship to pilot pressure. Read More

Fluid & Gas Flow Equipment, Materials & Material Processing

Mini Tank-Mixing Eductors utilize venturi design.

April 16, 2015

Available with orifice diameters from 0.59–1.18 in., Mini Tank-Mixing Eductor Spray Nozzles enable small pumps to circulate large volumes of tank solution. Color-coded units are constructed of polypropylene and PVDF and can circulate 4–5 times inlet flow. Nozzle flow ranges from 0.31 gpm with circulation rate of 1.9 gpm at 10 psi to 2.9 gpm flow rate with 10.7 circulation rate at 50 psi. Applications include tanks used for plating, cleaning, phosphating, sludge, paint, and anodizing. Read More

Fluid & Gas Flow Equipment

Intelligent Metering Pump features pulsation-free design.

April 16, 2015

By incorporating Electronic Programming Module memory chip on which parameters can be pre-configured, Intelligent Metering Pump makes replacement of drive quick and accurate. Users can insert EPM chip from previous drive into new one for no downtime between stop and startups. Each unit has keypad on controller lid equipped with operator elements for H-O-A selection, manual speed control, display of pump speed/RPM or flow, fault indication, and ability to change factory settings. Read More

Fluid & Gas Flow Equipment

Double Acting Piston Seal promotes quality and capability.

April 16, 2015

Employing profiled nitrile rubber energizer, 714 high-pressure compact double acting piston seal meets needs of medium- to heavy-duty industrial applications. Reinforced, heat stabilized, thermoplastic sealing face with precision, no gap, step-cut joint facilitates installation and allows seal to pass over ports (suited for double-acting telescopic cylinders). Also, rugged and extrusion-resistant design performs in high-pressure, off-highway applications with extrusion gap. Read More

Fluid & Gas Flow Equipment

Eccentric Disc Pump handles both thin and viscous liquids.

April 15, 2015

Featuring ductile iron construction and ability to handle differential pressures up to 145 psi, Model A6 provides safe transfer of viscous, non-lubricating, volatile, or delicate fluids. ATEX-certified, positive displacement pump utilizes eccentric disc technology, which enables self-priming and run-dry capabilities while maintaining constant flow rate regardless of changes in viscosity and pressure. Equipped with 1 ½ in. suction and discharge ports, Model A6 has max flow rate of 25 gpm. Read More

Fluid & Gas Flow Equipment

Chemical Injection System monitors and controls operations.

April 15, 2015

Designed to automatically calibrate and monitor pump operation, Chemical Injection System maintains specified injection rate that may be slaved to production rates. Diagnostic system provides operational visibility into monitoring conditions at injection site and verifies and records that chemical injection is working to specifications. From local RTU/SCADA system or through central service such as Wonderware or CygNet, users can remotely monitor and control parameters and conditions. Read More

Fluid & Gas Flow Equipment, Electrical Equipment & Systems

Cable Tray Fittings target confined area applications.

April 15, 2015

Offered in left or right configurations, T&B® Cable Tray Helix™ Fittings ease transitions between horizontal and vertical cable tray runs, especially in confined areas and near walls. Units come in aluminum, pre-galvanized steel, and stainless steel in 12 and 24 in. widths with 6 in. side rails. Available pre-assembled, fittings enable installers to secure and organize cable runs without needing to position cable tray assembly to make room for transitional fittings. Read More

Controls & Controllers, Fluid & Gas Flow Equipment

Miniature Pressure Regulators come in multiple configurations.

April 14, 2015

MAR-1 Series includes relieving designs, which maintain constant pressure output even when downstream conditions change, as well as non-relieving designs, which do not automatically compensate for changes in downstream flow or pressure. Supporting flows to 5 scfm, series does not vent to atmosphere. Output pressure can increase due to downstream event, and multiple adjustment options are available. Configurations include #10–32, M5, 1/8 in. NPT, R1/8, G1/8, and cartridge mount. Read More

Fluid & Gas Flow Equipment

Single Handle Faucets are lead-free compliant.

April 13, 2015

Available with stainless steel and chrome finishes, respectively, 8 in. Models BL-140 SS and BL-140C include metal lever handle and ceramic cartridge plus side spray if desired. Units have max flow rate of 1.5 gpm at 60 psi. With less than 0.25% weighted average lead content on wetted surfaces, BL-140 faucets are compliant with federal Safe Drinking Water Act. They also meet or exceed applicable ANSI/ASME/NSF and IAPMO/UPC standards. Read More

Fluid & Gas Flow Equipment, Machinery & Machining Tools, Green & Clean

Water Jet Pump Units minimize emissions.

April 10, 2015

Available on convertible high-pressure pump units, UltraGreen™ Packages feature environmentally friendly Tier 4F engines that comply with EPA emissions regulations, which limit NOx emissions to 10% of the level allowable 20 years ago, and particulate matter to 5% of old level. Systems are trailer-mounted for towing to job sites, and offer fast conversion to variety of operating pressures, often up to 40,000 psi. Read More

Chemical Processing & Waste Management, Material Handling & Storage, Fluid & Gas Flow Equipment

Suction Cups and Vacuum Ejectors suit basic applications.

April 9, 2015

Comprising 21 suction cups and 2 small vacuum ejectors, Value Line is suitable for applications where machine speeds and surfaces to be gripped are less challenging. Suction cups, made of TPE-U material for wear resistance, come in flat-concave, bellows, and long bellows shapes with diameters from 0.79–2.95 in. Inline vacuum ejectors can be installed directly on hose very close to point of vacuum and are suitable for applications with vacuum levels of 20–50%. Read More
