Sherex Fastening Solutions    Tonawanda, NY 14150
May 16, 2012 Facilitating accurate attachment of components in off center applications, RIV-FLOAT®-SHORT rivet nuts allow manufacturers to account for tolerance stack up and resolve alignment issues during product assembly. Knurls increase spin out resistance in soft materials, and design allows installation from front side of work piece. Fastening technology is designed for post installation in applications where cage nuts, clinch nuts, floating nut plates, or weld nuts are typically used.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Apr 05, 2012 Offered in 1/8, 5/32, and 3/16 in. diameters, Grip Tite® Rivets come in range of steel bodies and steel mandrels with domed and large flange head configurations. Units have extended secondary side footprint for high-strength applications, with shear strengths from 326-696 lb, depending on rivet diameter, and tensile strengths from 382-764 lb. With anti-rattle properties, rivets are appropriate for fastening thick to thin material stack-ups and composite-to-metal material combinations.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Jan 31, 2012 Characterized by wide grip range, POP® LS Rivet is designed to set in tri-fold configuration, which separates into 3 legged sections to ensure secure joint. Mandrel head is contained within rivet body, eliminating rattling joints. Set creates large secondary head formation that will evenly distribute load, which is key in preventing material damage, pull-through, or rivet failure.

Micro Plastics, Inc.    Flippin, AR 72634
Aug 17, 2010 Available to fit hole sizes ranging from 0.156-0.260 in. and metric hole sizes of 4-6.6 mm, Blind Rivets are used to fasten plastic to plastic, plastic to metal, and plastic to fiberglass. They feature molded black impact modified nylon 6/6 body and black acetal pin, and 3-leg design that securely locks panels in place and prevents pullout. Offering insertion from either side of assembly, all 14 models can handle grip ranges of .028-.413 in. and metric grip ranges from 7-10.5 mm.

EFC International    St. Louis, MO 63146
Apr 14, 2010 Orlock(TM) rivets feature double locking system and high shear and tensile strengths to accommodate heavy-duty structural applications. They provide water/vibration resistance to joints and offer large blind side bearing area that spreads clamp load over large area. Suitable for thin, brittle, and soft sheet materials, units have grip ranges up to 39.5 mm and support various head types, including P, L, X, and K. Optional decorative caps are available.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Sep 14, 2009 With no loose mandrel heads present in final assembly, 3 mm steel counter-sunk rivets suit electronics applications. Manufactured to ISO, QS, and TS requirements, they can handle applications with no protrusion as well as those requiring installation from either side of application. RoHS and DFAR compliant units have been color coded for quick visual identification on production floor.

Richco, Inc.    Morton Grove, IL 60053
Apr 13, 2009 Designed for flush surfaces, RoHS-compliant SRCS Series substitutes normal countersunk screws and bolts and is installed by hand. Tamper-resistant design allows access from back of panel only, while locking feature holds pin flush in body after installation.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Jan 02, 2009 POP® brand HS (High Strength) blind rivets provide positive mandrel head retention and maximized rattle and vibration resistance. Offering consistent clamp force, high-strength rivets also accommodate oversized holes and are compliant with ISO, QS, TS, and RoHS. Product line is available in range of ¼ in. dia domed head steel and aluminum materials.

Flexco    Downers Grove, IL 60515-4200
Dec 30, 2008 Colored blue and made of FDA-accepted material, Alligator® Plastic Rivet fasteners are available to match conveyor belts used in food industry applications from -20 to +180°F. Non-magnetic product can be mechanically applied with portable installation tool, is non-scratching, and provides quiet splice as it operates over conveyor components. Removable hinge pin facilitates belt cleaning and installation with minimal dismantling.

Sherex Fastening Solutions    Tonawanda, NY 14150
Dec 08, 2008 With design that promotes thread strength, Dejond TUBTARA® 304 Stainless Steel M10 fully cold formed rivet nuts come in 4 different types. Available sizes include SPO (Flat Head, Round Shank, Open End), SPX (Flat Head, Round Shank, Closed End), SFO (Countersunk Head, Round Shank, Open End), and SKO (Low Profile Head, Round Shank, Open End).

Sherex Fastening Solutions    Tonawanda, NY 14150
Sep 12, 2008 Facilitating attachment of components in off center applications, RIV-FLOAT(TM) can accommodate for tolerance stack up in manufacturing process. Floating nut with .020 in. radial float aligns to drive angle of screw and eliminates cross threading and spin out. Product is suited for post installation in applications where cage nuts, clinch nuts, floating nut plates, or weld nuts are typically used.

Alcoa Fastening Systems (Formally Huck International)    Waco, TX 76714
Oct 26, 2006 Available in 3/16 and ¼ in. sizes, HuckLok(TM) offers ¼ in. grip range, allowing it to join assemblies from 1/8-7/8 in. thick. After maximum clamp has been achieved from minimum to maximum grip, shear ring breaks free from pin and settles into appropriate catch groove. High-shear, structural steel HuckLok features double-locking design, installs within seconds, and is suited for use with variety of air-actuated tooling.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Jul 05, 2006 Suited for applications where same rivet body size is specified but multiple grip ranges are required, POP® Steel Multi-Grip(TM) Rivets automatically adjust grip range during setting to accommodate range of variation in material thicknesses. Elliptical impressions in rivet body ensure consistent compression of rivet body during setting, and rivet body expands to completely fill irregular or oversized holes. Products come in 1/8-3/16 in. dia in domed head and large flange configurations.

Richco, Inc.    Morton Grove, IL 60680
Apr 14, 2006 Suited for applications where secured components may need to be removed, RRR Series comes in 2 sizes to accommodate panel thicknesses from .059-.217 in. and works in round holes as well as non-rotating square holes. RoHS-compliant product is manufactured of black nylon material. For installation, users place rivet in hole and press head; legs of rivet expand to firmly lock components into place. Design allows for removal of pin and rivet by pulling on side tabs.

Micro Plastics, Inc.    Flippin, AR 72634
Jan 10, 2006 Available in beige and grey, all-plastic ¼ in. Truss Head Anchor Rivets are blind fasteners for solid or hollow materials. Nylon body provides thermal, electrical, corrosion, and vibration resistance. Mushroom, Round, and Flat Head Anchor Rivets are also available.

Emhart Teknologies    Shelton, CT 06484
Aug 05, 2005 Suited for automotive, electronic assembly, and transportation industries, High Retention rivets employ rib design that counters deformation and stress fracture pressures. They are available with steel and stainless steel bodies and mandrels as well as domed, large-flange, and 120° countersunk head configurations. Offered in 1/8, 5/32, 3/16, and ¼ in. dia sizes, rattle-resistant rivets exhibit shear strengths from 213–1,056 lb and tensile strengths from 269–1,174 lb.

Richco, Inc.    Chicago, IL 60680
Jul 12, 2005 Manufactured in black Nylon 6/6 material, RBF Series Barbed Fasteners feature ribs that deflect when pushed into hole, then spring back for a secure, non-removable lock. Fastener push mounts into panel or board and is quickly installed by hand. Barbed fasteners are also available by special order in natural color or flame retardant material and in other combinations of head, barbed end, and body length.

Richco, Inc.    Chicago, IL 60680
Dec 23, 2004 Series FM elastomeric rivets connect small cooling fans to fan components and mounting hardware. High elongation rubber allows for assembly by hand and eliminates need for screws and nuts. Two styles are available: one with low profile end for single-direction, short protrusion on mounting panel side, and another for 2-direction mounting of fan components to leading fan flange. Both are black EPDM rubber available in 2 different durometers.

aDP Rivet    Hartford, CT 06114
Oct 18, 2004 Suited for long grip applications, 2-piece Rivet-Mates fasten multiple components up to 2 in. thick without marring of application's surface. They are suitable for steel fences, highway signs, metal furniture, construction signs, aluminum buildings, wood and metal assemblies, transportation vehicles, and steel storage containers. Standard, handheld blind rivet tools are used for fastening.

Flexible Steel Lacing Co.    Downers Grove, IL 60515-4200
Jul 15, 2004 Flexco® Rapid Loaderâ„¢ Collated Rivet Strips facilitate installation of Flexco SRâ„¢ Rivet-Hinged and BRâ„¢ Butt-Rivet conveyor belt fasteners. Plastic strips hold 4 sets of 5 rivets in pattern required for SR/BR installation. Each block of 20 rivets, which installs 4 adjacent fasteners, loads in approximately 7 seconds. Strips are color-coded to assure correct rivet size selection for belt thickness and for consistency across splice.
