Dec 07, 2004 Suited for OEM applications, Locating Pins are made with hardened A2 tool steel for common industrial usage or in corrosion-resistant 304 stainless steel for machines found in food processing, medical, and pharmaceutical industries. Design engineers can specify all critical dimensions in metric and inch sizes, including head heights, lengths, shanks, and diameters in very fine increments, as well as OD tolerances.

J. W. Winco, Inc.
New Berlin, WI 53151
Nov 26, 2004 By pressing pin body into proper bore size and depth, Side Thrust Pins hold, position, or clamp workpieces. Four versions are available: single sided with stainless steel ball and stainless steel spring, single sided with plastic ball and stainless steel spring, single sided with black oxide finish steel ball and elasticized plastic spring, and double sided with black oxide finish steel ball and elasticized plastic spring.

Logansport Matsumoto Co.
Logansport, IN 46947
Nov 09, 2004 Designed to facilitate hard turning, Neidlein hard-coated drive pins mount around face driver to reduce or eliminate part slippage and scrapped parts. If slippage occurs, pins can be used again. Given proper parameters, products achieve circular run outs of less than 0.002 mm in long production runs. They work with proprietary SB/FSB and FFB face drivers as well as special application face drivers for hard turning. Pins also work with other brands.

J. W. Winco, Inc.
New Berlin, WI 53151
Nov 09, 2004 Suitable for holding, positioning, and clamping of workpieces, Side Thrust Pins feature knurled aluminum body that requires hole tolerance of H8. Available in light, standard, or heavy-duty end pressures, pins are zinc-plated hardened steel or Delrin plastic. Versions with NBR/perbunan rubber seal are gold-passivated and those without seal are silver-passivated. Made of steel with black oxide finish, Eccentric Bushings facilitate adjustment of side thrust pins.

J. W. Winco, Inc.
New Berlin, WI 53151
Oct 29, 2004 Used in holding, positioning, and clamping of workpieces, Press Fit Side Thrust Assemblies have knurled body with aluminum, gold passivated finish. They require bore of H8 tolerance. While various sized assemblies are available in light-, standard-, or heavy-duty end pressures, all incorporate steel thrust plate hardened with black oxide finish and seals of NBR/perbunan rubber. User can design thrust pin, which can be screwed into thrust plate.

Zierick Manufacturing Corp.
Mount Kisco, NY 10549
Oct 22, 2004 Intended for automation using existing pick and place equipment with special feeder, SMT Z-Axis Compliant Pins help compensate for thermal expansion and contraction. They can be placed on .100 x .120 in. on-center applications, making them suitable for parallel PCB stacking. Pins come in 0.025 x 0.025 x 0.375 in. high copper and feature 95/5 matt tin/lead over copper finish.

Jergens, Inc.
Cleveland, OH 44110
Oct 01, 2004 Kwik-Lok™ Heavy Duty T & L Handle Pins have solid stainless steel handle and button for corrosion resistance. Standard sizes range from 3/16–1 in. nominal pin diameters. Metric sizes are available from 5–25 mm nominal pin diameters. Welded handle provides impact resistance and ring is included for attachment of optional lanyard. Pins meet or exceed NASM 23460 specifications.

J. W. Winco, Inc.
New Berlin, WI 53151
Sep 20, 2004 Spring-loaded Side Thrust Pin has elements for holding, positioning, and clamping of workpieces. Protruding height can be adjusted with threaded body. Made of steel, thrust pin is zinc-plated and hardened. Version with seal has yellow finish, while unit without seal has blue passivated finish.

Jergens, Inc.
Cleveland, OH 44110
Sep 16, 2004 Kwik-Lok™ Heavy Duty Detent Pins are shoulder-style alignment pins for applications that do not require positive locking ball. Heavy-duty spring and 2 spring-loaded stainless steel balls provide high pullout force. Available in stainless steel and alloy steel, units range from 3/16–1 in. and 5–25 mm. Ring is included for attachment of optional lanyard.

Logansport Matsumoto Co.
Logansport, IN 46947
Sep 15, 2004 Micro-serrated, hard-coated Neidlein face driver drive pins reduce or eliminate part slippage, reduce scrapped parts, and increase turning productivity. If part slips, it will not remove serrations or coating, and pins can be used again. Products achieve circular run outs of less than 0.0007 in. in long production runs. Drive pins can be used with SB/FSB and FFB face drivers and all special application face drivers for hard turning.

Jergens, Inc.
Cleveland, OH 44110
Sep 08, 2004 Activated by push or pull motion, Kwik-Lok™ Double Acting Pins feature corrosion-resistant, solid stainless steel construction and are suited for quick insertion and removal. Products are offered with ring, L, and T handles, and 4 ball configurations are available upon request. Ring is included for attachment of optional lanyard. Standard sizes range from 3/16–1 in. for nominal pin diameters, and metric sizes are available from 5–25 mm for nominal pin diameters.

Spirol International Corp.
Danielson, CT 06239 1434
Jul 19, 2004 Type 316 Stainless Steel Coiled Pin handles marine and petrochemical applications, resists pitting and crevice corrosion, and maintains mechanical integrity at high and sub-zero temperatures. It can be installed using hammer, arbor press, or any other standard pin insertion equipment. Pin has uniform strength and flexibility after insertion.

Micro Plastics, Inc.
Flippin, AR 72634
Jun 02, 2004 Molded in Nylon 6/6, Shutter Pins feature chemical resistance and low coefficient of friction. They come in translucent, off-white color and are used in assembly of shutters.

Jergens, Inc.
Cleveland, OH 44110
May 14, 2004 Available in 2- and 4-ball version, Kwik-Lokâ„¢ Heavy Duty Button Handle Pins feature solid stainless steel handle for impact-resistance. Ring is included for attachment of optional lanyard. Nominal pin diameters range in size from 3/16–1 in. with ½â€“6 in. grip lengths. Metric pin diameters are available from 5–25 mm with 10–100 mm grip lengths. All pins meet or exceed NASM 23460 specifications.

J. W. Winco, Inc.
New Berlin, WI 53151
May 11, 2004 Metric Quick Release Pins provide quick fixing, connecting, and locking of various jig and fixture systems. Shaft, ball, and spring components are stainless steel. Heat-resistant to 175°F, knob is black nylon plastic with matte finish. Balls are spring-loaded and not rigidly locked, resulting in low axial holding strength. Split rings with various lengths are available to prevent loss or misplacement of ball lock pins.

Spirol International Corp.
Danielson, CT 06239 1434
Apr 02, 2004 Helical grooved solid pins utilize unique groove configuration that makes them suitable for installation in harder host materials. Wide, low-profiled peaks spiral about body of pin, allowing pin to maintain integrity when installed into hardened hole. Available in Full Length Groove, Half Length Centered Groove, and Half Length Offset Groove configurations, pins are made of carbon steel and 300 Series austenitic stainless steel.

Cooper B-Line
Highland, IL 62249-1331
Apr 01, 2004 Pre-loaded Drive Pin Fasteners aid in installing cable hooks, strap hangers, wire or rod hangers, and conduit. Products come with 1¼ Ramset® PowerPoint drive pin pre-installed on bracket, hanger, or hook. Pins are rated for concrete up to 4,000 psi and steel up to ¼ thick. Fasteners are suited for use with most powder actuated guns, including Ramset® and Hilti®.

Royal Diversified Products
Warren, RI 02885
Mar 26, 2004 Medical Core Pins can be custom-made with multiple steps from 0.010–0.750 in., tapers, points, spherical radii, and flats, in 0.250–36 in. lengths. Featuring tolerances to 0.0002 in. on length and 0.00005 in. on diameters, pins can be made from all common tool, stainless, and exotic steels. They can be nitrided, TiN coated, and hard chrome plated to meet wear requirements. Units are suited for molds in luer taper components, catheters, syringes, and valve assemblies.

Flexible Steel Lacing Co.
Downers Grove, IL 60515-4200
Oct 28, 2003 Clipper® Duralinkâ„¢ and DuraStainlessâ„¢, for wire-hook splices, feature nylon coating that provides 10x more abrasion resistance compared to nylon-covered pins. Coating lubricity reduces wear on inner radius of fastener loops. Duralink pins, with coating extruded over braided stainless steel cable, provide flexibility to accommodate troughing conveyors or crowned pulleys. DuraStainless pins, built on solid stainless wire core, help prevent ripple. Diameters range from .065–.125 in.

J. W. Winco, Inc.
New Berlin, WI 53151
Jun 25, 2003 Plastic, 3-Prong self-locking products connect and secure components or work pieces. Pins feature nylon plastic grip handle with heat tolerance up to 808°C and stainless steel pin, ball, and spring. Split rings with various lengths of chain are available to prevent loss or misplacement of ball lock pin. Depressing spring-loaded push button frees 2 balls and releasing push button locks balls. Typical application includes bearing shafts that have to be regularly mounted and unmounted.
