Arbitrary/Function Generators are available in 150 MHz models.

August 20, 2015

Available with 1 or 2 channels, AFG3151C and AFG3152C feature intuitive UI that shows at-a-glance information to promote productivity. Display size and 25 shortcut keys foster usability, while included 12 standard waveforms, arbitrary waveform capability, and signal impairment options support diverse application requirements. Also included, ArbExpress software lets waveforms be created from any Tektronix oscilloscope or defined by standard functions, equation editor, and waveform math. Read More

Electronic Components & Devices

Arbitrary/Function Generator targets education labs.

April 8, 2015

Integrating with TekSmartLab™ wireless lab management solution, dual-channel Model AFG1022 features 25 MHz bandwidth with 1 mVpp to 10 Vpp output, 14-bit vertical resolution, and 1 µHz frequency resolution. Unit provides 125 MS/s sampling rate along with 64 MB of built-in non-volatile memory and USB memory expansion for user-defined waveforms. On functionality side, instrument offers 50 built-in standard function and arbitrary waveforms with continuous, modulation, sweep, and burst modes. Read More

Electronic Components & Devices

Function/Arbitrary Waveform Generator has 2 independent channels.

June 24, 2014

Dual-channel models 4063, 4064, and 4065 respectively generate sine waveforms up to 80, 120, and 160 MHz. Featuring pulse generator and 512k-point arbitrary waveform generator on one channel, these instruments can generate pulses with <100 ps jitter and output 12 nsec width pulses at frequencies as low as 0.1 Hz. Other features include adjustable rise and fall times, rotary control knob, numeric keypad, function keys, built-in counter, Sync output, and trigger I/O terminal. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Electronic Components & Devices

All-in-One Instrument suits circuit debugging and validation.

June 24, 2014

Featuring 10 x 7.5 x 2.9 in. benchtop design, VirtualBench integrates mixed-signal oscilloscope, function generator, digital multimeter, programmable DC power supply, and digital I/O. Users interact with VirtualBench through software applications that run on PCs or iPads. In addition to wireless connectivity, system offers consolidated view of multiple instruments, visualization on large multitouch display, and quick functionality to save data and screenshots. Read More

Test & Measuring Instruments, Software, Electronic Components & Devices, Optics & Photonics

Mixed Domain Oscilloscopes integrate 6 instruments in one.

March 4, 2014

Integrating spectrum analyzer, logic analyzer, protocol analyzer, arbitrary function generator, and digital voltmeter, MDO3000 Series can test and debug virtually any embedded design. Customizable units feature 2 or 4 analog input channels with bandwidth from 100 MHz to 1 GHz, 16 digital channels, and 1 RF input channel. With FastAcq™ feature, oscilloscopes provide capture rate of 280,000 waveforms/sec. Units offer automated serial/parallel bus analysis and more than 125 trigger combinations. Read More

Electronic Components & Devices

Function/Waveform Generators offer bandwidths up to 160 MHz.

November 19, 2013

Featuring 4.3 in. color display, 2 output channels, and PC waveform editing software, WaveStation 3000 function/arbitrary waveform generators include 3 models that offer respective bandwidths of 80, 120, and 160 MHz. Each offers 500 MS/sec sampling rate, 14-bit resolution, and 16 kpts memory per channel; applications requiring greater memory may access 512 kpts of memory on channel 2. Front panel facilitates access to basic waveforms and various operating mode. Read More

Electronic Components & Devices

Function Generator ranges from 0.001 Hz to 20 MHz.

August 27, 2012

With Direct Digital Synthesis and frequency accuracy of ±20 ppm, Model GX320 can be used to generate precise, varied signals, including waveforms, sine, triangle, square, and LOGIC TTL output. Unit provides internal and external AM FM modulation, as well as linear and logarithmic sweep functions. With BURST function, users can choose number of cycles per time period. Equipped with 125 x 45 mm LCD, Model GX320 also includes external frequency meter ranging from 5 Hz to 100 MHz. Read More

Electronic Components & Devices

Bench-Top Waveform Generators feature dual-channel design.

March 30, 2012

WaveStation(TM) series features intuitive front panel, 2 output channels, and PC waveform editing software. Models are available with bandwidths of 10, 25, and 50 MHz, each with 125 MS/sec sampling rate, 14-bit resolution, and 16 kpts memory/channel. Basic functions include sine, square, ramp, pulse and noise, and more than 40 built in arbitrary waveforms are also included. Waveform shape, along with various parameters, such as frequency, amplitude, and offset can be previewed on 3.5 in. display. Read More

Electronic Components & Devices

Signal Generators feature Direct Digital Synthesis technology.

September 21, 2011

Housed in 11 x 9 x 4 in. case, Models SDG1005 and SDG1050 provide 125 MS/sec sample rate, 14-bit resolution, and 16 Kpts waveform record length. Dual-channel units feature built-in AM, FM, PM, PWM, and FSK modulation, without requiring external modulating source, and both also function as 200 MHz frequency counter. In addition to sine waves, generators provide square waves, pulse and ramp waveforms, white noise, and arbitrary waveforms. USB Device/Host I/O allows for storage of waveforms/setups. Read More

Electronic Components & Devices

Arbitrary Function Generators meet needs of design and test engineers.

September 16, 2011

Delivering arbitrary waveform, function, and pulse generation, Tabor Wave Standard series models WS8351 and WS8352 Arbitrary Function Generators (AFGs) offer up to 350 MHz in single and dual differential channels configurable as separate or synchronized. Inherent 2 GSps clock with 512k memory and up to 4 Vpp output into 50 ohms speeds generation of complex waveforms. Utilizing PulseComposer(TM) software, AFGs can generate pulses for up to 350 Mbps device tests. Read More

Electronic Components & Devices

Digital Function Generator supports INT/EXT AM/FM modulation.

June 16, 2011

Operating from 0.3 Hz to 3 MHz or 0.5 Hz to 5 MHz, Model 8219A is suited for audio response testing, vibration testing, servo system evaluation, and ultra sound applications. Unit can automatically and repetitively sweep frequency of output waveform between 2 operator-determined limits. Instrument features variable DC offset control, LIN/LOG sweep mode, and GCV output for synchronization, as well as external VCF function and built-in 6-digit counter with INT/EXT function up to 100 MHz. Read More

Electronic Components & Devices

Digital Function Generator produces electrical waveforms.

March 4, 2011

Operating from 0.3 Hz to 3 MHz or 0.5 Hz to 5 MHz, model 8219A provides external VCF function and duty cycle control with signal inversion capacity. Available waveforms - Sine, Triangle, Square, Ramp, TTL, and COMS output - can be either repetitive or single-shot. Unit contains 2-step and variable attenuator, offers output waveform modulation, and can automatically and repetitively sweep frequency of output waveform between 2 operator-determined limits. Read More

Electronic Components & Devices

Waveform Generators feature less than 40 psec jitter.

August 11, 2010

Featuring 30 MHz sine, square, and pulse waveform bandwidth, 1-channel Model 33521A and 2-channel Model 33522A deliver true point-by-point arbitrary waveforms for accurate representation of user-defined signals. Units offer 250 MS/sec, 16-bit sampling rate and total harmonic distortion of .04%. Both function/arbitrary waveform generators are fully compliant with LXI Class C Specification and include USB 2.0 and 10/100 Base-T Ethernet for connectivity to PC or network. Read More

Test & Measuring Instruments, Electronic Components & Devices, Optics & Photonics

PC Oscilloscope offers real-time sampling rate of 250 MS/s.

June 21, 2010

Powered from PC's USB port, Model PS4227 includes integrated spectrum analyzer, function generator, and arbitrary waveform generator. Unit has 32 Megasample buffer memory, which can hold up to 10,000 waveforms, viewable in pop-up navigator window. USB 2.0 port allows high-speed data to be delivered to host PC. With two 12-bit input channels and bandwidth of 100 MHz, detailed waveforms can be captured for production testing, scientific analysis, electronic design and debug tasks. Read More

Electronic Components & Devices

Waveform/Function Generators offer 125 MS/sec sampling rate.

September 2, 2009

Able to produce nearly any possible waveform, single-channel Model 4076 and dual-channel Model 4079 provide frequency range from 1 µHz to 50 MHz for sine and square waveforms and up to 62.5 MHz in arbitrary mode. With 14-bit amplitude resolution and up to 4 million points of length, waveforms can be output in continuous, triggered, gated, or burst modes. Both arbitrary waveform/function generators include front panel keypad, graphical digital display, and GPIB or RS232 interface capability. Read More

Electronic Components & Devices

Waveform Generators include single- and dual-channel models.

March 10, 2009

Single-channel Model 4075 and dual-channel 4078 arbitrary waveform/function generators utilize Direct Digital Synthesis architecture to generate sine and square waveforms up to 25 MHz. Both produce waveforms with 14-bit amplitude resolution, 100 MSa/s sample rate, and up to 400,000 points length, which can be output in continuous, triggered, gated, or burst modes. Products include internal or external AM, FM, and FSK modulation and can be remotely controlled via RS-232 interface. Read More

Electronic Components & Devices

Programmable SIgnal Generator performs 6 key functions.

October 27, 2008

With 50 MHz max sine wave frequency, Model 3390 can perform function, pulse, arbitrary waveform, pattern, and noise generation as well as AM/FM/PM/FSK/PWM modulation. Features include 25 MHz pulse frequency with 10 ns min width; 256,000-point, 14-bit resolution function generator; and precision pulses and square waves with rise/fall times under 10 ns. Product also comes with LXI Class C-compliant Ethernet, TMC-compliant USB, and standard GPIB interfaces. Read More

Electronic Components & Devices

Function Generator replaces obsolete HP 8112A pulse generator.

September 16, 2008

Providing 100% drop-in replacement solution for HP 8112A pulse generator, Model GP1612H features front panel display that shows individual parameters and their values and selectable complementary pulse and double pulse in continuous, triggered, gated, and counted burst modes. It also offers selectable predefined amplitude and offset for critical stimulus signal generation for testing of semiconductor technologies including TTL, CMOS, and ECL. Read More

Electronic Components & Devices

Function/Waveform Generator meets LXI Class C specification.

September 11, 2008

Model 33210A is 10 MHz Function/Arbitrary Waveform Generator that provides stable, accurate, and low-distortion signals with up to 10 built-in waveforms needed for bench and system applications. It includes USB 2.0, 10/100 Base-T Ethernet (LAN) and GPIB interfaces as standard features, enabling quick connectivity to PC or network. High frequency unit can also be remotely operated from any browser by connecting to its built-in web page. Read More

Electronic Components & Devices

Sweep Function Generator utilizes direct digital systhesis.

January 24, 2008

Equipped with 4-digit counter for accurately determining output frequency, model 4040DDS provides 0.1 Hz to 20 MHz sine/square waveforms and 0.1 Hz to 2 MHz triangle waveforms. Adjustable features include dc offset (±4.5 V), coarse and fine tuning controls for output frequency, and linear or logarithmic sweep with variable sweep rate and adjustable sweep time. Adjustable symmetry lets generator produce various pulse waveforms, ramp or saw tooth waves, and slewed sine waves. Read More
