Differential Pulse Generators are suited for high-speed testing.

November 19, 2015

PicoSource PG900 Series can test transmission paths with fast pulse, instantly simulating wide-spectrum signal. Capable of creating pulses with less than <40 psec rise-times for 200 mV pulses or <60 psec for 2.5–6 V pulses, these USB-connected products offer differential outputs with programmable de-skew in 1 psec steps. Each output can also function in single-ended mode, and generators offer 2 triggered step-generation technologies to suit different applications. Read More

Electronic Components & Devices

Digital Delay/Pulse Generator offers 250 psec resolution.

September 1, 2015

With 250 psec width and delay resolution and <200 psec internal jitter, 4- or 8-channel Model 577 enables precise timing up to 1,000 sec. Each output is individually configurable with its own trigger, gate, delay, and width settings. Optical and electrical outputs and inputs (or combination thereof) are optionally available, and LED output stage can be configured for 2, 4, or 8 outputs at 820 or 1,300 nm. Other features include pulse picking and selectable external clocks. Read More

Electronic Components & Devices

Digital Delay Pulse Generators have compact, wireless design.

June 24, 2014

Along with Bluetooth® wireless technology, plug-and-play Emerald 9250 Digital Delay Pulse Generators feature 5 psec timing resolution, 15 psec channel to channel jitter, and low Period Jitter of <40 psec RMS. Custom software application, included, lets users program instrument using GUI on PC. With full functionality offering range of complex pulse trains, these reusable products serve such applications as LIDAR, LIBS, PIV, and university physics/chemistry labs. Read More

Electronic Components & Devices

Automatic Changeover Units complement sync pulse generator.

September 12, 2013

Designed to be deployed with SPG8000 Master Sync and Master Clock Reference Generator, Models ECO8000 and ECO8020 feature hot-swappable redundant dual power supply system to eliminate risk of sync loss due to power supply failure. SNMP support and Web UI enables units to be seamlessly integrated into facility control systems, while scalable architecture allows customers to configure sync generator systems to fit application needs. Both changeover units are fully 3G-SDI capable. Read More

Electronic Components & Devices

Pulse/Delay Generator offers Bluetooth wireless capabilities.

June 25, 2013

Field-upgradeable 9200 Sapphire Plus Series pulse/digital delay generator provides solutions to generate and synchronize multiple pulses and triggers for range of applications. With 5 ns delay and width resolution accuracy, <50 ps RMS jitter, <2 ns rise time, and 1 ppm oscillator, product provides precisely defined pulses at repetition rates up to 20 MHz. Other features include period counter, virtual channels, synchronous update mode, and external trigger/gate inputs. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Rotary Pulse Generators target robotics industry.

May 14, 2013

Featuring 0.25 in. shaft diameter, ZSD Series is suited for applications requiring miniature, high-precision encoders. Units feature NPN open collector output and quadrature outputs with indexing, available in 100 or 1,000 pulses per shaft revolution. Designed with all metal construction for years of trouble-free operation, shaft servo mount generators operate from supply voltage of 4.75–28 Vdc with max frequency of 200 KHz and accuracy within 0.017°. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Rotary Pulse Generators feature NPN open collector output.

January 28, 2013

Featuring 0.375 in. shaft diameter, ZDH Series is available in 100 or 1,000 pulses/revolution and provides quadrature output with indexing. Heavy-duty flange mount sensors have NEMA 4/IP66 environmental rating to withstand harsh factory and plant floor environments. Typical applications include motion control feedback, machine control, process control, robotics, and food processing. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Rotary Encoders offer single channel or quadrature output.

December 19, 2012

With supply voltage of 4.75–28 Vdc, ZB Series Rotary Pulse Generators deliver 1,000 PPR for precision counting or speed measurement. AU-ZBG models have single channel for counting, unidirectional measuring, or speed applications, while AU-ZBH models are for quadrature applications, allowing for counting up and down as well as speed and direction measurements. Using conversion bracket, industrial duty shaft encoders can be converted into length measuring sensors. Read More

Laboratory and Research Supplies & Equipment, Electronic Components & Devices

Pulse Generator supports classic and modern testing standards.

November 30, 2012

Used by EMC test laboratories and design engineers, FT 5531 helps simulate real world disturbances that occur in electrical systems of cars, buses, and trucks, and facilitates weak-spot analysis and QA during development. Product features pulse width of 150 ns and tolerance of 100 ns pulses; complies with ISO 7637-2 and OEM standards; and is designed using ferrites, which allow DUT to experience minimal supply voltage drop due to heavy in-rush current, switching event, or load change. Read More

Electronic Components & Devices

Single-Channel Pulse Generator drives E/O modulators.

August 1, 2012

Designed for driving electrical/optical modulators, T240 single-channel, externally triggered, complementary-output pulse generator offers programmable delay/pulse width in 2 ranges, from 100 psec FWHM up to 25 nsec, and programmable trigger threshold. Product is controlled via USB, RS232, or trimpots, with optional SPI, and powered by USB or standard 5 V micro-USB connection. Generator can further drive seed lasers in pumped fiber systems and also suits RF applications. Read More

Electronic Components & Devices

Four-Channel Pulse Generator IC integrates fast RTZ damping FETS.

March 13, 2012

Suited for use in portable medical diagnostic ultrasound devices and NDT testing applications, 4-channel HV7331 brings together controller logic interface circuitry, level translators, MOSFET gate drive buffers, as well as high-voltage and high-current P- and N-channel MOSFETs as output stage for each channel. Other features include ±2.5 ns matched delay, guaranteed output of over 2.0 A for each channel with ±70 V pulse swing, and up to 20 MHz operating frequency. Read More

Controls & Controllers, Electronic Components & Devices

Pulse Generator Chip drives stepper and servo motors.

June 1, 2011

Providing 18 operating modes, Model PCL6045BL controls up to 4 axes as well as linear interpolation of 2-4 axes and circular interpolation between any 2 axes. Chip also offers operation correction, backlash correction, programmed soft limit, and ability to override pulse rate during operation. With max output of 6.5 Mpps and 19.6608 MHz standard reference clock, chip is suited for biotechnological and scientific instruments, medical analysis machines, and inspection systems. Read More

Test & Measuring Instruments, Laboratory and Research Supplies & Equipment, Electronic Components & Devices

Pulse Generation Kit integrates with Ti:sapphire amplifier system.

March 23, 2011

Terahertz pulse generation kit utilizes Newport optics, opto-mechanics, manual stages, and CONEX(TM)-based motorized solutions. Generated 800 nm Ti:sapphire laser pulse is focused into ambient air to generate air plasma, which produces pulse, and has oscillation that spans 1 psec and estimated pulse energy of 0.1-0.3 nJ/pulse. Kit can be integrated with Ti:sapphire amplifier to generate terahertz pulses which can used in linear, nonlinear, and time-resolved spectroscopy applications. Read More

Electronic Components & Devices

Pulse Generator controls differential pumping system.

January 27, 2011

Model 725 Multi-Trigger Pulse Generator includes TimerPro software for visual control of 8 inputs, 8 outputs, and 8 triggers, and which controls delays and gates to valves, transfer coils, and deflector plates. Measuring 20.8 x 24.2 cm, product features timing unit that routes light pulses into chamber for storage, transfers it to second chamber, and then emits it from that chamber. Generator has 8 timing processors capable of less than 1 µs timing, and each timer can run in one of eight modes. Read More

Electronic Components & Devices

Programmable Pulse Generators operate from 0.1 Hz to 50 MHz.

October 11, 2010

Delivering clean and accurate pulses for testing digital circuits and systems based on TTL, CMOS, or ECL logic families, Models 4033/4034 provide flexible control over pulse timing, level thresholds, and transition edges. They also support multiple trigger modes and offer closed case calibration as well as SCPI-compatible programmability via GPIB or RS-232. Functioning as 2 units in one, Model 4034 provides dual-channel outputs that can operate independently or in sync. Read More

Test & Measuring Instruments, Electronic Components & Devices

EMC Emission/Immunity Tester is offered with telecom surge module.

July 28, 2010

Model TSM 3751 generates open circuit voltage test pulse of 10/700 µs and tests ports intended for connection to symmetrical communications lines. Designed for NSG 3060 Test System, it lets users select source impedance from 15 or 40 W using button on generator's touchscreen. Voltage range is 200-7,700 V in 1 V steps and minimum repetition time for voltages up to 4,400 V is 20 sec and 30 sec in 4,401-7,700 V range. Maximum repetition time is 600 sec. Read More

Electronic Components & Devices

High Voltage Pulse Drivers deliver low jitter outputs.

April 5, 2010

Powered by external 12 V plugin supply, model T750 features 4 channels, each with logic-level input and isolated HV pulse output, while model T760 has 2 channels, each with fiberoptic inputs and isolated HV electrical outputs. They provide transformer-isolated pulse outputs, which are user adjustable from 5-100 V into 50 W load, with rise and fall times of 2 nsec. Both units are packaged in compact extruded aluminum cases and include test points to assist in setup. Read More

Electronic Components & Devices

Ultrasound Pulse Controller uses BCD mixed-signal technology.

January 27, 2010

Housed in QFN64 9.0 x 9.0 x 1.0 mm package, Model STHV748 provides 4 independent channels, each generating high-voltage pulses to drive piezoelectric crystals or other transducers. Device integrates CMOS digital control logic, analog level translators, MOSFET gate drivers, and N- and P-channel MOSFET output stages in self-biasing architecture. Controller features ±90 V dual independent supplies, ±2 A source and sink current in pulse mode and CW mode, and up to 20 MHz frequency. Read More

Electronic Components & Devices

Programmable Pulse Generator delivers 5 ppb stability.

October 12, 2009

Model PB-5 NIM Pulser offers 5 ppb stability over temperature changes, allowing end users to test the linearity and stability of demanding circuits. Included front end software utility, PB-5 WinControl, expands functionality and test options for laboratory users, allowing them to concurrently control up to 8 pulse generators to synchronize outputs or test multiple systems. Also, numerous settings may be stored and recalled in computer to accelerate test process. Read More

Electronic Components & Devices

Pulse Generator offers multi-channel operation.

July 23, 2009

Model 9520 provides up to 8 independent digitally controlled channels with width, delay, rate, and amplitude control on each output and permits differing rates for all channels using clock-divider functions. Output modules selection array includes both TTL/CMOS with adjustable amplitude, 35 V high voltage electrical, and optical at either 820 or 1,310 nm. Unit offers dual inputs, functioning as dual triggers or trigger/gating through BNC or optical connections. Read More
