Jumper Connectors

Electrical Equipment & Systems, Electronic Components & Devices

SMD Jumper Cables come in 0.5 mm pitch version.

December 11, 2015

Available from 8–50 poles, SMD Jumpers enable any number of PCBs to be populated, connected, and reflow soldered while they remain flat and next to each other. This allows circuit and functional test of application during production process. Connected PCBs can then be folded to any angle and inserted into housing/enclosure. SMD Jumpers offer optimal connectivity solution for SMD boards in both 90° and 180° applications. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Ultra-Miniature Cable Assemblies offer operation up to 6 GHz.

October 9, 2015

Respectively compatible with Hirose® U.FL™ and W.FL™ connectors, UMCX and WMCX cable assemblies feature miniature snap-on connectors with mated connection heights from 1.2–2.5 mm. There are 40 unique configurations with multiple coax options, including 0.81 mm, 1.13 mm, 1.37 mm, RG178, and double shielded RG178 (RG178-DS). In-series and between-series cable assemblies are available. UMCX, WMCX, and HMCX32 flexible micro-coax jumpers come in standard lengths of 6, 9, and 12 in. Read More

Electrical Equipment & Systems, Electronic Components & Devices

New EZ-Removable Jumper Links from Harwin Cut the Cost of LED Array Assembly, Simplify Rework and Reduce Production Time

October 1, 2015

Harwin Presents TTI’s John Sandy with Prestigious Chairman’s Award Hi-rel and SMD hardware manufacturer recognizes outstanding contribution to success Salem NH, USA – Harwin, the leading hi-rel connector and SMT board hardware manufacturer, has presented John Sandy, Supplier Marketing Manager with TTI, Inc. in the U.S. with its prestigious Chairman’s Award. This is an occasional... Read More

Electrical Equipment & Systems, Electronic Components & Devices, Green & Clean

Solar Grounding Products are certified to UL 2703.

September 15, 2015

Available in lengths from 6–72 in., Type SBJ solar bonding jumpers are approved for use with anodized aluminum, mill finished aluminum, and galvanized steel rack mounting systems. Conical contact points penetrate mounting surface to create solid bond. Expanding ground wire range to 250 kcmil –14, Type SGB lay-in solar grounding and bonding lugs are suited for use with copper or aluminum conductors. Both utilize Viritium® green plating process which prolongs life by minimizing galvanic corrosion. Read More

Electrical Equipment & Systems, Electronic Components & Devices

High-Temperature Headers and Jumpers foster design flexibility.

April 7, 2015

Offered in single- and dual-row versions, 0.100 in. pitch contact spacing male headers and jumpers support continuous operation to 150°C, 200°C, and 250°C. Headers come in straight, right angle, and SMT configurations, and current rating is 3 A per contact. Provided with 1–36 contacts per row and 10–30 µin. of overall gold plating, products feature PA9T, PPS, or PEEK insulator materials and beryllium copper, phosphor bronze, spinodal, or beryllium nickel alloy contacts materials. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Mounting & Attaching Products

High Current SMT Jumpers replace true zero ohm resistors.

January 13, 2015

Manufactured from copper with silver plating, true Zero ohm high current SMT Jumpers come in 3 resistor chip sizes – 0603 chip size (Cat #5110), 0805 chip size (Cat #5106), and 1206 chip size (Cat #5108) – to simplify designs and footprint template compatibility. These connectivity devices provide low impedance and circuit linkage with footprint identical to zero ohm resistor. Areas of use include high-density, high-current PCB applications. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Electronic Components & Devices

Coaxial Cable suits repeated bending applications.

September 26, 2014

Offered in 1,000 ft bulk reels, CA195FLEX Coaxial Cable is constructed with stranded center conductors and black or white thermoplastic elastomer jacket. Antenna cable assemblies, jumpers, and pigtails with thousands of length and connectors options are available. Read More

Communication Systems & Equipment, Computer Hardware & Peripherals, Electrical Equipment & Systems, Electronic Components & Devices, Mechanical Power Transmission, Mounting & Attaching Products

KGP Logistics Adding Value to Wireless Market with CommScope

September 12, 2014

FARIBAULT, Minn. -- KGP Logistics is committed to providing enhanced, value-add solutions to the North American wireless industry via increased focus on delivering wireless solutions with an emphasis on customer support and reliable supply chain services.  As a North American channel partner for CommScope, KGP Logistics has developed a robust stocking position of CommScope wireless product... Read More

Electronic Components & Devices

Long Jumpers feature thick copper construction.

July 9, 2014

Included within Keystone 510x Series, 5100 consists of 0.025 in 0.64 mm thick copper (silver finish) 0.27 in 6.85 mm long jumper that has 6.86 mm pitch. Also available 5104 is 0.02 in 0.5 mm thick copper (silver plated) 0.484 in 12.3 mm long jumper with 12.3 mm pitch. As 0.02 in 0.5 mm thick copper (silver plated) 0.27 in 6.85 mm long jumper, 5102 has 2 mm pitch. All products come in standard packaging quantity of 100. Read More

Electrical Equipment & Systems, Electronic Components & Devices

SMT Jumper DIP Switches feature bifurcated contact design.

June 11, 2014

Sealed with removable top tape, TDD Series can be used in reflow soldering and washable assembly processes. These RoHS-compliant SPDT jumpers, designed for surface mount PCB soldering, have bifurcated contact design that promotes electrical reliability. Contacts are constructed from copper alloy with gold plate over nickel plate and are rated for 25 mA @ 24 Vdc (switching) and 100 mA @ 50 Vdc (steady state). Operating force is 4.9 N (max), and operational life of 200 cycles. Read More

Electronic Components & Devices

Jumper System operates in demanding environments.

April 15, 2014

Available in 5, 10, or 30 pole lengths, PTP Easy Bridge Plus is designed for terminal block wiring and circuit configuration safety following ATEX and IEC Ex Directives. Flexible metal conducts high currents while minimizing vibration and oxidative gases. Red and blue insulated tops protect from accidental contact with high voltages and are marked for easy circuit configuration identification. Read More

Electronic Components & Devices

Surface Mount Jumpers link circuit board traces/tracks.

March 17, 2014

Offering alternative where through-hole jumper use is not feasible, SMT PC Board Jumpers provide low-profile circuit linkage for high-density, high current PCB packages on power and aluminum backplanes. Manufactured from copper with silver plating, units come in 3 styles: Compact, Micro-Miniature, and Miniature, each in bulk or tape and reel. All tape and reel parts are packaged per ANSI/EIA-481 standard for compatibility with most vacuum and mechanical pick and place assembly systems. Read More

Communication Systems & Equipment, Electronic Components & Devices, Optics & Photonics

Ruggedized Fiber Jumpers ensure reliable wireless performance.

December 3, 2013

Featuring IP66/67 ratings, LC-LC Duplex Fiber Jumpers are manufactured with Corning FREEDM® One cable and terminated with harsh environment connectors with strain reliefs that exceed 56 lb of pull. Operating from -40 to +70°C, assemblies are suited for wireless systems with remote radio head designs that are installed outside and require ruggedized fiber-to-the-antenna cabling. Read More

Electronic Components & Devices

Wire, Vertical Jumpers extend terminal block functionality.

June 28, 2013

Available for Double-Deck TOPJOB®S 2000 Series and X-COM®S MINI 2020 Series DIN-rail terminal blocks, jumpers provide horizontal and vertical potential commoning. Users can vertically common both levels of double-deck terminal block or multiply potential over several adjacent DIN-rail terminal blocks. While Vertical Jumper carries 13.5 A/500 V rating, Push-in Wire Jumpers feature 9 A/800 V rating (AWG 18) and come in 60, 110, and 250 mm lengths. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

Low PIM Coaxial Cable Jumpers support RF communications.

July 20, 2012

Available in ½ in. flexible and superflexible versions, Corrugated Coaxial Cable Jumpers can be ordered in standard and custom lengths with 7/16 DIN and Type N connectors to meet requirements. Assemblies have injection molded boot on each connector, which provides added strain relief and weather sealing. Providing years of optimal PIM and VSWR performance, assemblies are suited for tower top jumpers, shelter/cabinet jumpers, antenna feed lines, and 2-way land mobile radio installations. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Passenger Vehicle Jump Starter offers 900 A starting power.

August 9, 2010

Powerful enough to jump start most passenger vehicles, Jump-N-Carry's JNC300XL weighs 9 lb and can deliver 900 peak amps. It can be stored and used anywhere and features Clore PROFORMER battery technology, which is designed to deliver optimal cranking power, sustained cranking, and extended service life. Unit comes with high-intensity work light and 56 in. cable span as well as full size clamps, heavy-duty cables, and Grip-Lock(TM) clamp storage system. Read More

Electrical Equipment & Systems, Electronic Components & Devices

LED Screw-Down Jumper Assembly serves solid state lighting market.

January 8, 2010

With 5 A current rating and 250 Vac/dc voltage rating, board-to-board screw-down jumper assembly provides electrical connection between adjacent PCBs arranged in string of LED PCBs. Screw fastens to threaded holes in aluminum clad PCB base or into separate aluminum heat sink used with FR4 boards, while RoHS-compliant 2-position jumper fits onto 16.50 mm wide PCB, maintaining 7.0 mm spacing between adjacent boards. ETL recognized board-to-board connector meets UL 1977 standards. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

Bend-Tolerant Jumpers suit enterprise applications.

May 1, 2009

Pretium® Low-Loss OM3 Jumpers with ultra-bend performance are high-bandwidth, laser-optimized cable assemblies featuring Corning® ClearCurve® multimode fiber, which confine modes of light to within fiber's core. Products are able to accommodate minimum bend radius of 8-10 mm, on 1.6-2.0 mm cable, with minimal bend-induced attenuation loss. They are suited for enterprise LAN and datacenter applications. Read More

Electronic Components & Devices

Jumpers are for mating Micro Edge card connectors.

September 26, 2008

HSF8 Series Rugged High Speed Flex Jumpers offer choice of mating HSEC8 Series Micro Edge Card connectors in vertical, horizontal, or edge mount designs on .8 mm pitch. They include 14 and 32 differential pairs (7 and 16 signal pairs/side) and 20 and 50 signal single-ended pins (10 and 25 signal pins/side). Jumpers are offered in standard lengths of 5 and 10 in. Read More

Communication Systems & Equipment, Electronic Components & Devices

Circuit Jumpers are suited for mid-speed applications.

July 16, 2008

Delivering 1.1 GHz at -3 dB insertion loss depending on signal type, RoHS compliant TCDL2 and FFDL2 Series standard flex data links offer choice of .050 and .0787 in. pitch, single-ended or differential pair signal routing, and variety of end assembly options. They allow end solutions of sockets or terminals on both ends or socket terminal combination transfer end assembly. Units can be modified for custom pin counts, cable lengths, guide posts, or connector heights. Read More
