Integrated Circuit Enclosures

Electronic Components & Devices, Electrical Equipment & Systems

DIN-Rail Mount Circuit Breakers have 13 mm wide design.

February 6, 2015

Conserving space with high-density housing, DIN-rail mounted circuit breakers are available in 3 varieties. QZ supplemental protection or UL 1077 breakers come in 1-, 2-, and 3-pole versions rated from .5–50 A, while QL branch circuit or UL 489 circuit breakers come in 1- or 2-pole variants with ratings from .5–25 A. For DC applications, QY series is rated from 1–50 A at up to 80 Vdc and carries UL489 listing. Read More

Electronic Components & Devices, Materials & Material Processing

LED Packaging is custom tailored to requirements.

November 24, 2014

Designed to specific customer requirements, LED Substrates and Submounts utilize variety of metallization technologies on alumina, AIN, and BeO ceramics, including PCTF® Plated Copper on Thick and Thin Film with 20–75 µm copper, AgENIG® Electroless Nickel and Immersion Gold over Silver, and DBC Direct Bond Copper with 125–250 µm copper. LED substrates for bond-pad down devices allow narrow gap capability for 50 µm wide gaps. Direct eutectic die-attach eliminates need for wire bonds. Read More

Fluid & Gas Flow Equipment, Plant Furnishings & Accessories, Electronic Components & Devices

Enclosure Vent facilitates heat and moisture dissipation.

September 18, 2014

Suited for outdoor use, IPV Series PC/PC Wide Opening External Vent allows circulation of air while protecting againt rain water and falling debris. Both 2.91 x 2.91 x 1.1 in. and 3.95 x 3.95 x 1.25 in. models, constructed of gray polycarbonate plastic and 10% fiberglass, withstand exposure to UV light and water in accordance with UL 746C. Also able to be used indoors, product features continuous gasket between enclosure and vent and is designed to provide IP32 protection.
Read More

Electronic Components & Devices

Vertical DIN Rail Mount Housing includes terminal blocks.

September 8, 2014

Measuring 22.5 mm wide, CVB-Plus Housing is molded in green self-extinguishing UL94-V0 flame retardant PA66. Unit comes in solid and vented versions, with front and side label recesses, and is supplied with four 4-pole 5 mm pitch pluggable terminal blocks yielding 16 poles. With spring-loaded clips that can be snapped into position, housing can be made chassis/surface mountable. CVB-Plus has 15 A, 300 V rated terminals with 20 mΩ contact resistance and 500 MΩ/500 Vdc insulation resistance. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

NEMA 4X Plastic Enclosures suit indoor/outdoor applications.

July 22, 2014

Available in 4 additional sizes featuring molded on surface mounting flanges, Series WA, WC, and WP are UL listed to UL508-4X specifications. Electrical enclosures include brass inserts for cover on/off convenience, stainless steel screws, and silicone rubber gasket to protect electronics from harsh environmental factors such as dust, dirt, and water. WC and WP Series are molded in flame-retardant UV stabilized Polycarbonate, while WA Series is molded in flame-retardant ABS plastic. Read More

Material Handling & Storage, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

Plastic Push Button Box offers alternative to steel.

May 2, 2014

Offering corrosion resistance in washdown, humid, and outdoor environments, PBB Push Button Box carries NEMA 4X/IP67 rating and meets requirements of UL 746C with respect to UV light and water exposure. Construction combines polycarbonate plastic and 10% fiberglass for combined shatter resistance and molding consistency. Latter results in tight tolerances and seal reliability. Gray PBB Push Button Box suits 22 and 30 mm push buttons and comes in sizes from 0.89 x 1 in. to 1.22 x 4 in. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

NEMA Electrical Junction Boxes offer harsh environment protection.

March 21, 2014

Molded from impact-resistant polycarbonate, YQ Series include 8 sizes from 6 x 4 in. through 16 x 14 in. Products meet NEMA Type 1, 2, 3, 3R, 4, 4X, 5, 6, 6P, 12, and 13 specifications and IP68 of IEC 60529 requirements (UL File No. E352997). Along with corrosion-resistant stainless steel screws, features include waterproofing closed-cell gasket and opaque or clear cover. Boxes are surface mountable, with choice of mounting feet or mounting flange, and customization options are available. Read More

Packaging Equipment, Electronic Components & Devices

Lids and Covers hermetically seal microelectronic devices.

February 10, 2014

Available with screened or affixed getters for moisture or hydrogen absorption, Step Lids, Flat Lids, and Covers can be manufactured from variety of base materials, including Kovar, nickel alloys, stainless steel, cold rolled steel, titanium, and aluminum. Finishing/plating options include gold, electrolytic nickel, and electroless nickel. Selective plating or etching of logos, part numbers, or serialization is also available upon request. Read More

Material Handling & Storage, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

Plastic Utility Enclosure measures 1.00 x 2 x 3.500 in.

January 30, 2014

Molded using ABS plastic, with UL 94VO is available upon request, SATURN Series model 100X235 comes in Black, Ivory, and Dark Grey as standard and features molded top and bottom screwed together with 4 Plastite® screws. Plastic case has lightly textured finish, and additional options offered include EMI/RFI shielding; cut-outs, openings, chamfers, and other assembly requirements; and pad printing. Enclosure is offered with or without mounting tabs. Read More

Material Handling & Storage, Plant Furnishings & Accessories, Electronic Components & Devices, Architectural and Civil Engineering Products

Utility Enclosure features tight fit and compact dimensions.

January 23, 2014

SATURN Series 075X22, measuring .735 x 2 x 2 in., features molded top and bottom that fit together snugly to eliminate need for screws. If needed, 2 halves can be glued or ultrasonically welded together for permanent closure. Halves can also be separated and used as potting boxes by pouring encapsulating liquid over installed electronics to accommodate requirements of wet environments. Featuring lightly textured finish, plastic enclosure may also be machined and pad printed. Read More

Mechanical Components & Assemblies, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

Electrical Enclosures have hinged and waterproof design.

January 14, 2014

Available in 8 sizes from 6 x 4 in. through 16 x 14 in. to protect components in difficult environments, YH Series is molded from impact-resistant polycarbonate and meets NEMA Type 1/2/3/3R/4/4X/5/6/6P/12/13 specifications as well as IP68 of IEC 60529 requirements. Stainless steel hardware, robust hinges, and gasket are standard, and opaque or clear cover can be ordered as screw-down style or latched cover. Enclosures are surface-mountable with choice of mounting feet or mounting flanges. Read More

Mechanical Components & Assemblies, Electrical Equipment & Systems, Electronic Components & Devices

Slide-in Housing features collapsible front panel.

November 5, 2013

Instead of foldaway hinge, 1U Slide-In Housing features front panel that can be folded out so that no design height is lost, optimizing horizontal mounting of circuit boards. To access electrical boards, extruded aluminum panel is pulled out from closed position over slidable conduction unit connected with housing and then folded down with rotatable joint. EMC protection is achieved without any further shielding. In addition, vent openings in side of housing provide heat dissipation. Read More

Plant Furnishings & Accessories, Electronic Components & Devices

Tablet Enclosures meet IP65 rating for waterproofing and dust.

November 4, 2013

Featuring clamshell design that fits together with tongue and groove seal, Bud Tablet Enclosures provide protection for electronics used in industrial automation and control as well as other mission-critical applications that might involve harsh environmental conditions. Sizes range from 5.5 x 3.9 x 1.2 in. to 12.7 x 9.1 x 1.2 in., and high-impact ABS plastic construction is flame retardant to UL94-VO (white) and UL94-HB (black). Recessed area is provided for touchscreen or LCD screen. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Controls & Controllers, Electrical Equipment & Systems, Electronic Components & Devices

PCIe to MIL-STD-1553 BGA Package conserves space, power.

July 31, 2013

Within single BGA device with PCIe host interface, 15 x 20 mm PCIe-Express AceXtreme® (BU-67302B0C0L-202) provides dual MIL-STD-1553 transceivers, protocol, and 64K x 36 of internal memory. Component can serve applications from -40 to +85°C and provides dual redundant MIL-STD-1553 channel with less than 1.1 W power dissipation @ 50% duty cycle. Other features include IEEE 1149.1-compliant JTAG test interface, digital IRIG-B input, and 8 digital discrete I/O lines. Read More

Material Handling & Storage, Electrical Equipment & Systems, Electronic Components & Devices

PCB Component Housings have DIN rail mount design.

July 26, 2013

Intended for printed circuit boards (PCBs) and electronic components, DIN rail mount enclosures come in 12.5, 17.5, 22.5, 35, 45, and 67.5 mm wide housings to accommodate range of application requirements. Ventilating slots promote cooler stable internal temperatures and reduce overheating issues, while cover can be cut to accept various connector interfaces and LEDs. Design also accommodates addition of labels for schematics. Read More

Mechanical Components & Assemblies, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

NEMA 4X Plastic Enclosures support internal mounting panels.

March 20, 2013

Offered in 3 styles and 5 sizes from 5.11 x 3.93 x 2.75 in. to 11.81 x 7.87 x 6.29 in., WH Series supports 0.06 in. thick aluminum mounting panels that attach directly to mounting bosses inside base using included screws. Panels let electrical engineers mount hardware inside enclosure without puncturing exterior, maintaining NEMA 4X rating of box. Hinged cover is standard, and panels can feature cutouts, including threaded holes, per customer specifications. Read More

Plant Furnishings & Accessories, Electronic Components & Devices

Electrical Enclosure features press-fit design.

December 10, 2012

Intended for electrical and electronic applications, 2 x 2 x ¾ in. press-together box has molded top and bottom that fit together snugly as to eliminate need for screws. Top and bottom may be glued or ultrasonically welded together for permanent closure, or halves can also be separated and used as potting boxes by pouring encapsulating liquid over installed component. With exterior lightly textured to resist scratches and scuffing, enclosure comes in ABS plastic or UL-rated materials. Read More

Electronic Components & Devices

MIL-STD-1553 BGAs minimize size, weight, and power (SWaP).

November 28, 2012

Operating from -55 to +125°C, Micro-ACE® TE and Total-ACE® MIL-STD-1553 BGA packages are DO-254 certifiable; support MIL-STD-1553 A/B, MIL-STD-1760, STANAG 3838, and MacAir; and are designed to minimize SWaP (size, weight, and power). Micro-ACE® TE terminals integrate 1553 protocol, memory, and transceivers in plastic BGA package, while Total-ACE® further integrates 1553 transformers to offer complete solution for one dual redundant MIL-STD-1553 channel.
Read More

Electronic Components & Devices

Laminate IC Packages dissipiate heat from high-power devices.

June 28, 2012

Measuring 0.8 x 0.39 in., LL family of leaded laminate copper-moly-copper base packages include model LL802302, with 2 leads and raised lid with epoxy seal, and LL362302 flangeless, fully hermetic version with flat ceramic lid. Packages dissipate heat from compound semiconductor devices such as GaN, GaAs, and SiC. Suitable for applications through 6 GHz, both units can be used in RF radios for communications, radar, and high-power millimeter-wave signals. Read More

Material Handling & Storage, Electrical Equipment & Systems, Electronic Components & Devices

NEMA-Rated Box protects outdoor electrical control wiring.

June 28, 2012

Compliant with NEMA and UL-50 Type 3R rating, NEMA box provides protection against rain, sleet, and damage from formation of external ice. Enclosure is constructed of heavy-duty 16 GA galvanized steel that provides corrosion protection and is coated with ASA-70 gray powder. While internal zinc-plated steel panel facilitates component mounting, external mounting brackets allow installation on vertical surfaces without opening cover and exposing internal components. Read More
