Linear Technology Corp.    Milpitas, CA 95035
Oct 06, 2004 True RMS-DC converter ICs LTC1967 and LTC1968 measure energy of AC signal regardless of waveform shape. With 0.02% linearity, there is no need for in-system calibration, and delta-sigma computational technique is inherently immune from changes vs. temperature, time, and PCB stress. Rail-to-rail inputs can be driven single-ended or differentially, and rail-to-rail outputs feature separate output reference pin for flexible level shifting.

Linear Technology Corp.    Milpitas, CA 95035
Oct 06, 2004 Standalone switch-mode battery charger controller LTC4002-8.4 charges 2-cell, 8.4 V Li-Ion batteries. For safety and autonomous charge control, product features automatic shutdown, battery preconditioning and temperature sensing, end-of-charge indicator, and 3 hr charge termination timer. Offered in 3 x 3 mm DFN and 8-lead SO packages, current mode PWM controller has 500 kHz switching frequency and drives external P-channel MOSFET.

Zettler Magnetics, Inc.    Aliso Viejo, CA 92656
Oct 06, 2004 AHI series transformers offer dual bobbin non-concentric design that reduces inter-winding capacitance and eliminates need for electrostatic shield. Shroud and bobbin meet UL 94V-0 flammability requirements. Other features include specially designed bobbin wall slots that eliminate wire crossovers, and insulating shroud that provides 4,200 Vrms hi-pot dielectric strength. Units are available in 2.5 VA, 5 VA, and 10 VA output configurations.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Oct 05, 2004 Featuring SOD523 package and measuring 0.8 x 1.6 x 0.6 mm, Series VESDxx-02V provides data line protection in portable electronics. Units offer one-line transient protection of 15 kV (air) and 8 kV (contact) as per IEC 61000-4-2. Devices are packaged in plastic case with UL 94 V-0 flammability rating and are specified for operating temperature range of -40 to +125°C. Maximum clamping voltage is 9–25 V, and low leakage current helps prolong battery life.

Fox Electronics    Fort Myers, FL 33905 5022
Oct 05, 2004 Available with HCMOS output, Series AH OCXOs suit telecom and switching applications. Series AS offers sine wave output for wireless, satellite communications. Both are available in Euro package measuring 1.0 x 1.42 in. with various heights. Frequency range of all models is 5-50 MHz, and supply voltage is +5 Vdc. Depending on model, frequency stability is ±7, ±10, or ±15 ppb; and operating temperatures are available as wide as -40 to +167°F.

Prem Magnetics Inc.    McHenry, IL 60050
Oct 05, 2004 Printed circuit mount linearity coils SDL-3006 through SDL-3009 are electronically adjustable via control winding that is biased with positive or negative dc current. Measuring 1.8 x 1.0 x 0.8 in., products are designed for applications with yoke current requirements from 14.0 A (SDL-3006 and SDL-3008) to 18.0 A (SDL-3007 and SDL-3009) peak to peak. Products also offer extended operation for multi-scan rate monitors utilizing frequencies up to 90 and 150 KHz.

American Bright Optoelectronics Corp.    Chino, CA 91710
Oct 04, 2004 Available in high-brightness White and Blue, Super NovaLeds come in PLCC2 package with quality assured by JEDEC Moisture Sensitivity Level 2. Driven at 350 mA, intensity can reach up to 14,000 mcd. Viewing angle is 40° with lens and 120° without lens. Super NovaLeds are suited for backlighting, signage, and automotive applications.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Oct 01, 2004 Housed in SOD523 package, measuring 0.8 x 1.6 x 0.6 mm, Series VESDxx02V offers one-line transient protection of 15 kV air and 8 kV contact as per IEC 61000-4-2. Five devices provide working voltage from 1–12 V and max clamping voltage from 9–25 V. Specified for operating temperature of -40 to +125°C, units deliver ESD protection for data lines in mobile phone handsets, cordless phones, laptop computers, PDAs, digital cameras, and modems.

American Bright Optoelectronics Corp.    Chino, CA 91710
Oct 01, 2004 Featuring 32 pieces of surface-mount LEDs on 0.4 x 17.5 in. strip, product is available in color selections from 470–625 nm, which includes blue, green, red, white, and yellow. Strip is driven at 30 or 50 mA, depending on color, and has 10 Vdc input voltage, 120° viewing angle, and 25,000–50,000 hr life span. Suited for decorative lighting applications, product aids in channel lettering, highlighting, accenting, and direct lighting.

American Bright Optoelectronics Corp.    Chino, CA 91710
Oct 01, 2004 Available to fit E27, GU10, and MR16 bases, Lamp Replacement Series delivers red, blue, green, yellow, and white LED light. Lamps feature 100,000+ hr lifespan and tolerate shock, vibration, frequent switching, and extreme temperatures. Screw base E27, rated 120 Vac, has 16 LEDs, while GU10 has same number and rating with 30° viewing angle and up to 342 cd. Base MR16, rated 12 or 24 Vac, uses 15 LEDs with 30° viewing angle and up to 342 cd.

PTI - Piezo Technology, Inc.    Orlando, FL 32804 2780
Oct 01, 2004 Featuring noise floor of -170 dBc, Model XO5051 provides frequency stability of ±.5 ppm and yearly aging of ±1 ppm along with 20 dBm sinewave output. It has 12 V supply and draws steady state current of 150 mA in 2 x 2 x .75 in. enclosure.

Phoenix Contact    Harrisburg, PA 17111 0100
Sep 30, 2004 Quick Locking SPEEDCON Connection System requires only ½ turn to make secure, watertight, and vibration-proof connection between cordsets and devices. Connectors fulfill same requirements for electrical and mechanical properties as classic M12 plug connector systems. Product range includes IP65 and IP67 cordsets, sensor-actuated boxes, and field wireable, panel-mount connectors. SPEEDCON technology is also integrated in Fieldline modular I/O system.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Sep 30, 2004 Available in 0402, 0603, and 0502 cases, E/H MIL-PRF-55342 Qualified Resistor Chips offer ratings from 100 ohms to 160 kilohms. Units feature high-purity alumina substrate and electroplated nickel barrier layer, which enables operation at temperatures up to +150°C. In addition to low noise of less than -25 dB and low voltage coefficient of ±0.5 ppm/V, non-inductive devices feature absolute TCR down to ±25 ppm/°C and tolerances down to 0.1%.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Sep 30, 2004 Available in sizes down to 0402, Thin Film Series FC offers resistance values from 10–1,000 ohms, depending on case size, with precision tolerances down to 0.1%. Featuring alumina substrate and passivated nichrome resistive layer, units are rated for stability of 500 ppm/°C over 2,000 hr at 70°C and for operating temperature of -55 to +125°C. They are intended for low-noise amplifiers, precision voltage dividers, and attenuation circuitry.

Linear Technology Corp.    Milpitas, CA 95035
Sep 30, 2004 Offering programmable charge current from 0.4-2 A with ±5% accuracy, autonomous Model LTC4060 charges 1-4 cell NiMH and NiCd batteries. Available in 16-lead TSSOP or 5 x 3 mm DFN package with operating voltage from 4.5-10 V, unit uses external PNP transistor to supply current to battery or battery pack. Charger offers 3 options for terminating charge cycle: negative deltaV, max voltage, or max time. Battery drain current is less than 1 µA during sleep mode.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Sep 30, 2004 Measuring 5.0 x 3.2 x 1.3 mm, surface-mount oscillator models XOSM-531, XOSM-532, and XOSM-533 are suited for use in portable computing and telecommunications devices. Efficiency is enhanced via tri-state enable/disable function. Rated for frequency range of 1.544–100.000 MHz, lead-free, HCMOS-compatible oscillators are compatible with IR re-flow processes and offer frequency stability options of ±25, ±50, and ±100 ppm.

Vishay Intertechnology, Inc.    Malvern, PA 19355 2143
Sep 30, 2004 Offered in super red, orange, yellow, green, pure green, and blue, each device in SMD 0603-LED series measures 1.6 x 0.8 x 0.6 mm and is built on AllnGaP and GaN technology. Angle of half intensity is 80°, providing 160° viewing angle. Each LED, packaged in lead frame base and embedded in clear epoxy, ensures even lighting with luminous intensity ratio of 1.6 or less per packing unit over operating temperature range of -40 to +100°C.

Deva Electronic Controls Ltd    Wirral CH41 1EL  United Kingdom
Sep 30, 2004 Designed for use with Brown and Sharpe reader heads, Deva 023-1SIN-BS1 reader-head preamp performs necessary signal conditioning required for use with Deva 018 Sine Wave Interpolator. It has 15-way D-type connector at one end, which is pin-compatible with existing reader head. Other end of module has high-density, 15-way D-type connector that mates directly with 018 interpolator without custom cabling. Four trim pots scale and offset sine wave signals.

Marktech Optoelectronics    Latham, NY 12110
Sep 29, 2004 With luminous intensities up to 1,800 mcd, Cotco LM1-xxx-11 Power LED series is built on InGaAlP and InGaN technologies. They handle forward currents from 30-50 mA depending on wavelength and come in PLCC-4 package that measures 3.0 x 2.8 mm. Integrated reflector offers viewing angle of 120°, and operating temperature range is -40 to +100°F. Available colors include White, Blue, Blue-Green, Green, Yellow, Red-Orange, and Red.

EM Microelectronic-US    Colorado Springs, CO 80918
Sep 29, 2004 Featuring programmable voltage reset monitoring and watchdog timer with programmable time window, 615x/625x family of integrated microprocessor supervisory ICs have system-enable output and power saving function compatible with CAN-bus sleep mode. V series includes V6150 and V6155 windowed watchdog ICs, while A series includes A6150, A6155, and A6250 windowed watchdog ICs with built-in 5 V LDO voltage regulator. All products are TTL/CMOS compatible.
