Richardson Electronics, Ltd.
La Fox, IL 60147
Sep 17, 2008 Featuring 300 W CW output power, 78% collector efficiency, and -40 dB harmonic suppression, Model FM310-108 pallet amplifier is suited for FM transmitter, transposer, and broadcast exciter designs. Available with MRF6V2300NBR1 LDMOS transistor, rugged unit operates from -10 to +60°C. With 23 dB gain, system designers can use low input power of 1.4 W, eliminating one or more gain stages. Connectorized versions are also available.

AVX Corp.
Myrtle Beach, SC 29578
Sep 17, 2008 Compatible with standard surface mount reflow processes, surface mount chip capacitor is specifically designed for tip and ring telecom applications and is offered with Flexiterm® termination, which prevents PC board flexture cracks. It has X7R dielectric rating from -55 to 125°C with capacitance value of up to 1.2 µF, 250 Vdc TELCO rating, and dielectric withstanding voltage of 625 V. EIA sizes range from 0805-2225 with maximum thickness of 0.080 in.

Calex Mfg. Co., Inc.
Concord, CA 94520
Sep 16, 2008 Designed for complete signal isolation, 8900 Series includes 16 dc powered signal conditioners to offer 8 inputs, including 0-50 and 0-100 mV, 0-5, 0-10, and 0-100 V, and 4-20, 0-20, and 0-50 mA, which can be combined with choice of 2 outputs. It employs 3-way signal isolation topology, where input is isolated from output and both are isolated from supply voltage. UL 508/1604 compliant series comes in 4.3 x 0.89 x 2.9 in. plastic case with built in DIN Rail mounting foot.

Geotest - Marvin Test Systems, Inc.
Irvine, CA 92614-5846
Sep 16, 2008 Providing 100% drop-in replacement solution for HP 8112A pulse generator, Model GP1612H features front panel display that shows individual parameters and their values and selectable complementary pulse and double pulse in continuous, triggered, gated, and counted burst modes. It also offers selectable predefined amplitude and offset for critical stimulus signal generation for testing of semiconductor technologies including TTL, CMOS, and ECL.

Vishay Intertechnology, Inc.
Malvern, PA 19355 2143
Sep 16, 2008 With thermal resistance of 20 k/W, amber VLMK82 and yellow VLMY82 SMD LEDs offer driving currents up to 400 mA. Utilizing AlInGaP technology, VLMK82 features optical power of 7,100-14,000 mcd and typical luminous flux of 28,000 mlm, while VLMY82 provides optical power of 5,600-11,200 mcd and luminous flux of 26,000 mlm. Compatible with IR-reflow solder processes, they deliver optical efficiency of 40 lm/W at 100 mA, and service life of up to 50,000 hr.

International Rectifier Corp.
El Segundo, CA 90245
Sep 15, 2008 Offered in 8-lead SOIC package, high-speed power MOSFET and IGBT drivers AUIRS2123S/AUIRS2124S are qualified to AEC-Q100 standards and offer 10-20 V gate drive supply. High-pulse current buffer stage is designed for minimum driver cross-conduction, while floating channel can drive N-channel power MOSFETs or IGBTs in high-side configuration operating up to 600 V. AUIRS2123S output signals are in phase with input signal, while AUIRS2124S output signals are out of phase with input signal.

National Semiconductor Corp.
Santa Clara, CA 95051-0695
Sep 15, 2008 Available as plug-in module for Xilinx ML571 serial digital video development board, ML571-1982CLK video clock reference design module enables SMPTE-compliant jitter performance for broadcast video applications. It delivers low clock output jitter of 40 psed p-p at 148.5 MHz to drive Virtex-5 LXT FPGA's integrated SerDes without need for additional clock cleaning circuitry. Unit features LMH1982 multi-rate video clock generator and LMH1981 sync separator devices.

National Semiconductor Corp.
Santa Clara, CA 95051-0695
Sep 15, 2008 Model LMH4345 triple-rate (3G/HD/SD) serial digital interface (SDI), dual-channel serializer and deserializer (SerDes) transceiver delivers 30 picosec output alignment jitter and 0.6 units interval minimum input jitter tolerance. It supports 270 Mbps and 1.485 and 2.97 Gbps data rates, enabling transmission of digital video broadcasting-asynchronous serial interface (DVB-ASI), standard-definition (SMPTE 259M-C), high-definition (SMPTE 292M), and 3G-SDI standard (SMPTE 424M).

Linear Technology Corp.
Milpitas, CA 95035-7417
Sep 15, 2008 LT3011 micropower regulator offers up to 50 mA of output current with 300 mV of LDO voltage at full load. It features 1.24-60 V adjustable output voltage range, 46 µA (operating) and 1 µA (in shutdown) quiescent currents, PowerGood flag with programmable delay, and output noise minimized at 100 µVrms over 10 Hz to 100 kHz bandwidth. Suited for noise-sensitive applications, unit has operating temperature range of -40 to +125°C, and is stable with 1 µF ceramic capacitors.

Linear Technology Corp.
Milpitas, CA 95035-7417
Sep 15, 2008 Supplied in 2 x 3 mm DFN package, LT3653 monolithic current mode step-down switching regulator utilizes 1.5 MHz oscillator, internal compensation, and internal boost diode. Input range of 7.5-30 V supports range of sources, input overvoltage lockout protects device from input transients to 60 V, and adjustable output current limit can be set from 400 mA to 1.2 A. Control pin VC is available for external battery tracking, keeping output voltage 300 mV above Li-Ion battery voltage.

Linear Technology Corp.
Milpitas, CA 95035-7417
Sep 15, 2008 Supplied in 4 x 7 mm QFN SMT package, LT6604-xx series is comprised of dual fixed frequency lowpass active filters/amplifiers with 2.5, 5, 10, and 15 MHz cutoff frequencies. Products consist of 2 matched, fully differential amplifiers combined with fourth order filters approximating Chebyshev lowpass response. Differential output stage drives directly into ADCs with minimum distortion/noise, and each amplifier has output swing of 2 Vp-p min as well as adjustable common-mode voltage.

Linear Technology Corp.
Milpitas, CA 95035-7417
Sep 15, 2008 Integrated 2 A Hot Swap(TM) controller, LTC4217, protects low-power boards with 2.9-26.5 V load supply voltages. Reducing external component requirements, power MOSFET and sense resistor in power path limit inrush current. Internal dV/dT circuit eliminates external gate capacitor, and separate ISET pin allows adjustment of 2% accurate current limit threshold. Load current is monitored using voltage sensed across 7.5 mohm sense resistor and adjusting 25 mohm MOSFET gate-to-source voltage.

Linear Technology Corp.
Milpitas, CA 95035-7417
Sep 15, 2008 Supplied in 4 x 6 x 0.75 mm QFN package, LTC3586 integrates switching PowerPath(TM) manager, stand-alone battery charger, always-on LDO, and 4 synchronous switching regulators: 1 buck-boost, 1 boost, and 2 buck. PowerPath control manages power flow between input sources and Lithium battery while preferentially providing power to system load. Switching input stage offers up to 700 mA from 500 mA limited USB supply or up to 1.5 A when wall-powered. Efficiencies reach up to 94%.

austriamicrosystems AG
Premstatten   Austria
Sep 12, 2008 Providing start/play solution for motion control applications as they require no configuration or calibration by host controller after power up or during operation, Models AS5304 and AS5306 can achieve resolutions of 25 and 15 µm, respectively. Immune to dirt, dust, and grime contaminants to meet reliability challenges in harsh environments, linear Hall sensor ICs are available in 20-lead 5 x 5 mm TSSOP and specified to operate at 5 V over temperature range of -40 to 125°C.

Aries Electronics, Inc.
Bristol, PA 19007-6810
Sep 12, 2008 RF test sockets, for use with PCBs, and CSP/BGA test and burn-in sockets, for use with burn-in-boards (BIB), feature solderless, gold over nickel-plated pressure mount compression spring probes that are mounted with 4 SS screws, which allows for height variations in device thickness. Units also include 4-point spring probe crown to insure scrub on solder ball oxides. Signal path during test is 0.977 in. and units operate from -67 to +302°F and accommodate up to 500,000 cycles.

STMicroelectronics
GENEVA   Switzerland
Sep 12, 2008 Connected in parallel with power path, STCC08 offers integrated switch supervision to save board space and meet IEC60335-1/IEC60730-1 safety standards. Integrated Failure Mode Effect Analysis (FEMA) includes descriptions of 52 cases of failure, and supervisor capability meets IEC60335 by detecting short- or open-circuit failures as well as diode-mode failure of solid-state AC switch. Solution also detects true switch status and generates logic signal connected to digital input of MCU.

Cypress Semiconductor Corp.
San Jose, CA 95134
Sep 12, 2008 Based on PSoC® architecture, TrueTouch(TM) Devices can interpret 10 inputs from all areas of screen simultaneously. Other units interpret single touches and gestures such as tap, double-tap, pan, pinch, scroll, and rotate. Supporting projected capacitive touchscreens, devices can also integrate functions such as driving LEDs, backlight control, and I/O expansion. Family includes CY8CTST1xx single-touch devices, CY8CTMG1xx multi-touch gesture devices, and CY8CTMA100 multi-touch all point device.

Bliley Technologies, Inc
Erie, PA 16508-0428
Sep 12, 2008 Suited for radar, communications, and test system applications, NV26AJ OCXO offers design engineers ability to specify exact output frequencies and other variable specifications, allowing unit to be precisely customized for various applications. It features power output up to +15 dBm, low profile packaging, long-term aging, and low power consumption.

Ironwood Electronics, Inc.
St. Paul, MN 55121
Sep 12, 2008 Designed for 11 x 11 mm, 0.65 mm pitch, 15 x 15 array 225 balls, ASE 225 LTFBGA SS-BGA225G-01 is 10 GHz high endurance socket that can be used for hand test and burn-in applications. With 16 g actuation force per ball and -40 to +150°C temperature range, spring pin contactor has self inductance of 1.3 nH, insertion loss of less than 0.25 dB at 4.5 GHz (less than 3dB at 10GHz), capacitance of 0.53 pF, and 2.5 A current capacity.

Atmel Corp.
San Jose, CA 95131
Sep 12, 2008 Sourcing 3-5 V supplies and integrating real-time clock and 2 wire interfaces, Model AT73C224 outputs 4 power supply channels, and supplies required voltages and currents to main sections of generic 32-bit MCU-based applications. One step down dc-dc converter supplies 0.9-3.4 V programmable output voltage and 500 mA output current, while one step up dc-dc converter supplies 5.2 V or higher output voltage, with output current set by external FET up to 1 A.
