Electronic Components & Devices

Electrical Equipment & Systems, Electronic Components & Devices

Field-Installable PV Connector features IP68 rating.

August 4, 2016

Certified for UL 1500 Vdc system voltage, T4 Field-Installable PV Connector has IP68 rating for protection against water/humidity ingress. NEC-compliant locking mechanism secures against vandalism and against unplugging under load for maximum safety and protection. Supporting broad operating temperature of -40 to +90°C, connector can be used in very hot climates such as Middle East and Central... Read More

Electronic Components & Devices, Optics & Photonics

Linear 2.2 Micron Wavelength Photodiodes are rated up to 5 GHz.

August 3, 2016

Targeting applications at 1.2–2.2 micron wavelengths, 50 mA and higher current handling, extended InGaAs photodiodes can help realize full potential of high-power fiber laser and frequency comb technology at 1,550 as well as 2,050 nm. Available formats include K or SMA coax fiber optic module, SMT fiber optic module, and benchtop O/E instrument Lab Buddy, and multimode fiber options... Read More

Electronic Components & Devices

Thick Film Chip Resistors provide anti-surge characteristics.

August 3, 2016

Available in 0402, 0603, and 0805 case sizes to save space on densely packed PCBs, RCS e3 Series features power ratings up to 0.4 W, voltage range of 50–150 V, and resistance from 1 Ω to 10 MΩ with tolerances of ±0.5%, ±1%, and ±5%. AEC-Q200-qualified devices offer optimized pulse load performance and ESD surge characteristics for automotive and industrial applications. Resistors... Read More

Electronic Components & Devices, Optics & Photonics

Precision Crystals have low-profile, surface mount enclosure.

August 1, 2016

Assembled in vacuum for maximized Q values and phase noise, SMP-8 (8–130 MHz) and SMX (6–220 MHz) measure 8.0 x 7.2 x 2.3 mm, utilize braze seal, and can be made with custom specifications for precision SC cut, AT cut, and IT cut crystals. Heat transfer properties of 4-point mount make these products suited for OCXO designs. Additionally, thermal transfer properties and Q of SMX-8 can... Read More

Electronic Components & Devices

RF Power Amplifier supports electronic warfare applications.

August 1, 2016

When driven with 0 dBm RF input signal, NuPower™ Model 12A03A delivers minimum of 5 W RF power from 1.0–2.5 GHz. Unit is also available in 30 dBm (1 Watt) input power level version, allowing plug-and-play use with various data transceivers, such as L-3 Communications Bandit radio. Housed in 1.8 x 1.8 x 0.5 in. rugged aluminum chassis, amplifier features low current draw of 0.85 A at +28 Vdc,... Read More

Electronic Components & Devices

Voltage Variable Attenuators provide 60 dB attenuation.

July 29, 2016

Available in 6 models covering octave broadband frequencies from 400 MHz to 18 GHz, Voltage Variable Attenuators are suited for use with variable gain amplifiers, power level controls, and feed-forward amplifiers. PIN diode-based devices provide broadband flatness where output level can be adjusted continuously by varying analog voltage on input control line. With CW input power rated up to +23... Read More

Electronic Components & Devices

Surface Mount High Current HEW Inductors

July 29, 2016

Gardena, CA - MPS Industries' HWIA2918S Series offers a High Current HEW Inductor in a surface mount, low-profile, compact form.  Maximum height for these inductors is 18mm and the package includes a dummy 3rd pin for extra mounting stability.  The HWIA2918S series is constructed using wire with true 30 Amp handling capacity.  The standard series inductance ranges from 3.3... Read More

Electronic Components & Devices

High Density Inductors for 1U Power Supplies

July 29, 2016

Gardena, CA - MPS Industries' HWI4427 and HWI4434 series of Helical Edge Wound (HEW) inductors is the lowest profile and highest current density package size in the industry, making them perfect for very high density 1U power supplies above 2kW.  These inductors are available with height as low as 27mm and in a variety of mounting options, including horizontal, vertical, and with... Read More

Computer Hardware & Peripherals, Electronic Components & Devices

Four Gigabit DDR4 DRAM supports long-term requirements.

July 29, 2016

Organized as 256 Mb x 16, IS43QR16256A and automotive-grade IS46QR16256A come in 96-ball BGA package and operate at 1.2 V with speeds of 2,400, 2,100, 1,866, and 1,600. Power, bandwidth, performance, and reliability address networking, automotive, and industrial system needs. Along with bidirectional differential data strobe, features include data masking per byte on write commands, per DRAM... Read More

Electronic Components & Devices, Portable Tools

Thick Film Chip Resistor Design Kits target specific value ranges.

July 28, 2016

Thick film chip resistor engineering design kit, which includes 0201 case size, includes 30 pcs of all 96 standard 1% values within respective value range. There are 5 kits available, and respective value ranges are 10–97.6 Ω (SEI Part KIT-RMCF0201FT-02), 100–976 Ω (SEI Part KIT-RMCF0201FT-03), 1–9.76 KΩ (SEI Part KIT-RMCF0201FT-04), 10–97.6 KΩ (SEI Part KIT-RMCF0201FT-05),... Read More

Electronic Components & Devices

SMD LED features ultra-miniature 0201 footprint.

July 28, 2016

Engineered with AlGalnP and InGaN chips, HELI-UltraMiniature measures 0.65 x 0.35 x 0.20 mm, making it suitable for wearable consumer products as well as disposable healthcare applications and portable devices with limited space. RoHS-compliant product is compatible with automatic placement equipment and features Level 2 moisture sensitivity. Read More

Electrical Equipment & Systems, Electronic Components & Devices, Optics & Photonics

WPC v1.2, Qi-Certified Transmitter wirelessly delivers up to 15 W.

July 28, 2016

Supplied in 9 x 9 mm VQFN package, bq501210 enables connectorless models of industrial and medical equipment. Fixed-frequency solution, which enables 84% system efficiency with minimal thermal dissipation and EMI, supports multiple fast-charging protocols and can reduce end-application size by eliminate need for bulky wiring. Rail control output provides power to deliver full 15 W... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Automotive LED Driver enhances headlight system efficacy.

July 28, 2016

Offered in 16-pin TSSOP, S6BL112A one-channel, 2 A output, buck LED driver has 4.5–42 V input range and can drive LEDs at 2.1 MHz switching frequency. This enables headlight designs with small inductors, which allows physical size and BOM reductions. Synchronous control helps promotes conversion efficiency, which enables stable lighting system performance, while analog and PWM... Read More

Computer Hardware & Peripherals, Electronic Components & Devices

Multi-Purpose DSP targets compute-intensive SoC designs.

July 28, 2016

With Xtensa instruction-set architecture, quad 32-bit integer MACs, and quad single-precision 32-bit floating-point MACs, Cadence® Tensilica® Fusion G3 Digital Signal Processor supports compute-intensive applications including radar, imaging, and mid- to high-end audio pre/post-processing. Unit offers comprehensive data-type support with auto-vectorization. DSP provides real-time control... Read More

Electronic Components & Devices

HexaTech Demonstrates UVSure(TM) High-Performance UV-C LED

July 28, 2016

First Generation Aluminum Nitride-Based Device Achieves Market-Leading Performance MORRISVILLE, N.C. - HexaTech Inc. announced today the demonstration of its first generation UVSure™ UV-C LED, based on HexaTech's proprietary and world-leading aluminum nitride (AlN) substrate material. The 263 nm wavelength device achieves 6 mW in a 0.15 mm2 active area die. When scaled to our... Read More

Electronic Components & Devices

Compact, Mid-Power UV LED (365 nm) delivers extended lifetime.

July 27, 2016

Able to replace mercury lamps in medical, industrial, and printing applications, shock-resistant VLMU1610-365-135 is built on InGaN technology and comes in 1.6 x 1.6 x 1.4 mm SMT package. Typical radiant power is 18 mW at 20 mA and 50 mW at 60 mA in 362.5–370 nm wavelength range. Along with silicone lens that enables lifetimes up to 25,000 hr, features include 135° emission angle,... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Low-Profile Single 2-Piece Contacts feature locking plug.

July 27, 2016

Intended for linear LED lighting and other commercial and industrial coplanar and extended card applications, 70-9159 Series STRIPT™ insulator-less, single 2-piece contacts with locking plug have 1.2 mm profile. Positive latching mechanism replaces thermal adhesives, hand soldering, and light-blocking connectors. Based on 9159 Series gold-plated BeCu spring contact system, SMT contacts... Read More

Electrical Equipment & Systems, Electronic Components & Devices, Mounting & Attaching Products

Machined Brass MCX Interconnects come in multiple configurations.

July 27, 2016

Straight, right-angle, or edge-mount PCB jacks offer surface or through-hole mounting options. Cable plugs 919-382J-51P, 919-383J-51A, 919-384-51P, and 919-385J-51S, designed for RG-178 (RG-196) and RG-174 (RG-188, RG-316) type cables, come in straight and right-angle versions. Performing at up to 6 GHz with VSWR of 1.10 (max) at 2.5 GHz for right-angle configurations, 50Â Ω MCX connectors... Read More

Electronic Components & Devices

Surface Mount MLCCs feature U2J ceramic dielectric material.

July 27, 2016

Available in case sizes from 0402–1812, Class-I Multilayer Ceramic Capacitors feature max available capacitance from 2.2–470 nF at 25 Vdc. Commercial-grade U2J capacitors are extremely stable with linear capacitance change with temperature, and also retain over 99% of nominal capacitance at full rated voltage. Pb-free as well as RoHS and REACH compliant, non-polar devices are suited for... Read More

Communication Systems & Equipment, Electrical Equipment & Systems, Electronic Components & Devices

SDR Receivers support analog audio and digital I&Q outputs.

July 26, 2016

Offered in 8.75 x 6.50 x 2.02 in. module or 1U, 19 in. rack version, MtRF-2100 Series includes 6 models that cover 100 kHz to 550 MHz range. These complete, stand-alone, black box receivers, which use 16-bit, 130 MHz ADC and Altera Cyclone III FPGA to achieve optimal sensitivity and dynamic range, do not require supporting PC. Supporting communication via RS-232 serial, USB, and... Read More
