Electronic Components & Devices

Electrical Equipment & Systems, Electronic Components & Devices

TPL-2516 Series Transformers feature split primary design.

Dec 12, 2016

Optimized for PFC derived switchmode power supplies and full-bridge / half-bridge converters, TPL-2516 Series Transformers are rated to 22.0 A current and 3 W of power dissipation. Operating at -55°C to +130°C, units are operated in 100 kHz to 500 kHz frequency range and provide leakage reactance of 1.30 µH. Featuring low 16.51 mm maximum profile, transformers meet MIL-PRF-27 standards and... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Triple Row Connectors are available in 9 − 96 position configurations.

Dec 10, 2016

Available in 804 and 805 series, Triple Row Spring-Pin Connector series are suitable for wave and reflow soldering processes. With concave face for making contact with our standard 1.07 mm dia. spring pin plungers. 804 series provide 1.14 mm of stroke at working travel and 2.29 mm maximum stroke. Including current rating of 2 amps continuous and 3 amps peak, 805 series is designed for through... Read More

Electronic Components & Devices, Services

NREL works on PV cells for military areas.

Dec 09, 2016

NREL finds solution for powering military bases with Photovoltaic cells. Thin-film solar cells, grown on substrates such as stainless steel, titanium foils, and polyimide, produce flexible products that are ideal for solar blankets and tarps and are portable. NREL team was making lightweight CdTe solar cells on flexible glass.

Read More

Electronic Components & Devices

Multi-Mode Crystal Oscillators Combine Wide Frequency Range with Low Jitter

Dec 08, 2016

Single, Dual or Quad Frequency Output with Five Output Level Types

NDK’s NP5032S and NP7050S oscillators combine small size with low jitter performance. The two oscillators have similar performance and capabilities, but offer different package size options for more flexibility. The wide frequency range of 15 MHz to 2.1 GHz and low jitter makes them suitable for high-speed serial... Read More

Electronic Components & Devices

Mounting Capacitors feature low temperature coefficients.

Dec 08, 2016

Available in 20 x 40 mils to 127 x 145 mils standard chip sizes with six capacitances ranging from 45 pF to 1000 pF, Mounting Capacitors have 50 VDC to 200 VDC withstanding voltage. Accommodating any FET and MMIC device, units feature gold contacts on both sides. Suitable for applications requiring DC protection, RF bypassing, oscillators and filters, capacitors are developed using MNOS... Read More

Controls & Controllers, Electronic Components & Devices

P-Series PLC on Chip features SD card and display interface.

Dec 08, 2016

Using EZ ladder programming software and drag-and-drop widgets in the cloud portal, P-Series PLC on a Chip™ allows monitoring, data logging via Ethernet, Wi-Fi, cellular or satellite. With temperature range of -40 to 85°C, chip feature Ethernet communications, SPI ports, 2 CAN ports and Modbus TCP. Communicating serially using Modbus master and slave, counter/timer functionality, device... Read More

Electronic Components & Devices, Mechanical Power Transmission

NuPowerTM 06C09A C-band PA uses GaN-on-SiC MMIC technology.

Dec 08, 2016

Measuring 2.5 x 2.0 x 0.65 inch compact size, NuPowerTM 06C09A C-band Power Amplifier provides 40 dB RF gain and module efficiency of greater than 35%. Suitable for electronic warfare systems for airborne electronic attack and unmanned aircraft systems, unit offers 15 Watts saturated RF power in C-band of 4.5 GHz to 6.25 GHz frequency coverage and is ideal for integration into wide variety of... Read More

Electronic Components & Devices

T59 Series Chip Capacitor offers overvoltage ratings up to 75 V.

Dec 07, 2016

Available in molded EE (7343-43) case code, T59 series surface mount chip capacitors are suitable for computing, telecom, and industrial applications. With ESR range from 25 mΩ to 150 mΩ at +25 °C and 100 kHz, T59 features ripple current from 1.3 A to 3.1 A. Operating at temperature range from -55 °C to +105 °C, device offers capacitance from 15 µF to 470 µF with capacitance tolerance... Read More

Electrical Equipment & Systems, Electronic Components & Devices, Vision Systems

MaxLite JA8-Certified LED Lamps Now Available for Title 24 Compliance

Dec 03, 2016

WEST CALDWELL, N.J. (December 1, 2016) – MaxLite, a manufacturer of energy-efficient lighting, has immediate availability of omnidirectional LED A-lamps that meet Joint Appendix 8 (JA8) requirements of the California Title 24 2016 building code, which takes effect January 1, 2017.

MaxLite’s initial offering of JA8-certified lamps includes 60-watt incandescent equivalent A19 lamps in... Read More

Electronic Components & Devices

Stackpole Adds High Power 0201 Size Chip Resistor

Dec 03, 2016

RALEIGH, NC (December 1, 2016) – The RMCP Series from Stackpole is a thick film chip resistor series with high power ratings for a given chip size. Stackpole recently added an 0201 size chip resistor with a power rating of 0.063W while the usual power rating for this size is 0.050W. This high power capability allows the RMCP0201 to be used in a wider range of applications requiring small... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Vishay Intertechnology to Highlight Latest Grid and Ribwound Resistors at POWER-GEN International® 2016

Dec 03, 2016

MALVERN, Pa. - Dec. 1, 2016 - Vishay Intertechnology, Inc. (NYSE: VSH) today announced that the company will be exhibiting its latest grid and ribwound resistors for oil and gas, industrial, and renewable energy power systems at POWER-GEN International® 2016, the world's largest power generation event. Taking place Dec. 13-15 at the Orange County Convention Center, in Orlando, Florida,... Read More

Display & Presentation Equipment, Electronic Components & Devices

Pick2Pallet LED Light System maximizes operator productivity.

Dec 03, 2016

Designed to improve customer productivity and reduce picking errors, Pick2Pallet LED Light System provides end-to-end warehouse solutions by helping better A-B picking. Product directs operators correct spot to place picked product using visual, colored light cues that works together with voice picking solutions.

Read More

Electronic Components & Devices

C3M0065100K MOSFETS provide notch between drain and source pins.

Dec 02, 2016

With minimal gate circuit ringing due to Kelvin gate connection, C3M0065100K Power MOSFET includes maximum junction temperature as 150 °C. Optimized for electric-vehicle charging systems and three-phase industrial power supplies, device offers output capacitance of 60 pF, output capacitance and reverse-recover time of 24 ns. As Ideal blend for conduction losses, unit features current rates at... Read More

Electronic Components & Devices

Flatpack and Slimpack Capacitors with 5,000 hours operating life.

Dec 02, 2016

Applied in compact power supplies like military and aerospace systems, MLSG Flatpack and Slimpack Capacitors measure 0.5” thick and 1.75” wide and 0.5 in thick by 1 in wide respectively. Flatpack welded seals capacitors can withstand up to 50g vibrations and altitudes greater than 80,000 ft. Flatpack capacitors are offered in values 220µF to 24,000µF and Slimpack from 120µF to 3,200µF,... Read More

Electronic Components & Devices

High-Power SMT Attenuators have impedance at 50 ohms.

Dec 01, 2016

Sutable for applications requiring low noise, inductance and parasitic capacitance like military and aerospace fields, High-Power SMT Attenuators offer virtual flat loss over broad frequency spectrum. Product is stable over temperature and time with balanced Pi design for even current distribution and accurate attenuation from DC to 20GHz. Features Tantalum nitride resistors, attenuation of... Read More

Electronic Components & Devices

Up to 40 GHz Schottky Barrier Diodes with Low Junction Capacitances for Low, Medium, and High Barrier Applications

Dec 01, 2016

Manchester, NH November 29, 2016 – SemiGen, Inc. (www.semigen.net), an ISO and ITAR registered RF/Microwave assembly, automated PCB manufacturing, and RF Supply Center, has added a series of new Schottky Diodes to its expanding product offerings.

SemiGen Silicon-based Schottky Diodes utilize various metal schemes to provide excellent performance... Read More

Electronic Components & Devices

High-Current Inductors feature lead free shielded construction.

Dec 01, 2016

Eliminating separate Faraday shielding, High-Current Inductors at 36.0A provides up to -20dB of electric field reduction at 1cm from center of inductor. Unit works at high-temperatures up to +155°C and has coplanarity of 4 terminals at ≤100µm. Featuring high-vibration for on-engine and chassis-mounted circuits, IHLE-2525CD-5A, IHLE-3232DD-5A, and IHLE-4040DD-5A vishay models offers high... Read More

Electronic Components & Devices, Services

SANS DIGITAL announces partnership with high-performance all-flash array, AccelStor, Inc.

Dec 01, 2016

City of Industry, CA - November 22, 2016 - SANS DIGITAL, a leading provider of high performance storage subsystems, is proud to announce its partnership with high performance software-defined all-flash array company, AccelStor, Inc. who is committed to accelerating the world's information access with innovative software technology and solid-state storage. The new SANS DIGITAL line-up of... Read More

Electronic Components & Devices

N-channel MOSFETs for electric power switching applications.

Dec 01, 2016

Used as load switches in smartphones and tablets, N-channel MOSFETs: 30V SSM6K513NU and 40V SSM6K514NU uses trench process for efficiency. Unit reduces output charge and on-resistance to 6.5mOhm and 8.9mOhm respectively and reduces heat dissipation by 40%. Unit meets USB Type-C and USB Power Delivery standards. Unit is compact and consumes low power.

Read More

Electronic Components & Devices

Vishay Intertechnology to Exhibit Leading Passive, Diode, and Thyristor Technologies at InnoRail India 2016

Dec 01, 2016

MALVERN, Pa. - Nov. 29, 2016 - Vishay Intertechnology, Inc. (NYSE: VSH) today announced its technology lineup for InnoRail India 2016, taking place Dec. 1-3 in Lucknow, India. In Hangar B, booth 39, Vishay will be exhibiting its latest industry-leading passive components, diodes, and thyristor modules for a wide range of applications.

Passive components from Vishay at InnoRail India... Read More
