Fiber Microcable increases capacity in confined areas.

June 30, 2015

Available with 12–144 fibers from full range of OFS application-specific fibers, MiDia® FX Cable features optimized buffer tubes and jacket rifling designed for optimized air-blown installation performance using microducts. Mechanical and environmental protections are in compliance with Telecordia GR-20, and design helps facilitate fiber cable deployment. Increasing capacity and fiber density in space-limited areas as needed, product also provides flexibility for future technology upgrades.
Read More

Electrical Equipment & Systems

Fiber Microcable increases capacity in limited-space areas.

June 29, 2015

Allowing providers to deploy as needed, MiDia® FX Cable accelerates fiber cable deployment and increases capacity and fiber density in space-limited locations. This microcable product, which provides mechanical and environmental protection in compliance with Telecordia GR-20, features optimized buffer tubes and jacket rifling designed for air-blown installation using microducts. Full range of OFS application-specific fibers, in counts from 12–144, are available. Read More

Electrical Equipment & Systems

Cable Assemblies provide Mini DisplayPort connections.

June 16, 2015

Addressing mobile device display, digital signage, and high-end PC monitor applications, DPCAC3MM Series features Mini DisplayPort connectors on each end of assembly, while DPCAC2MM Series features standard DisplayPort connector on one end and Mini DisplayPort connector on other end. VAD010FM Inline Adapter, providing female DisplayPort connector on one end and male Mini DisplayPort connector on other end, allows existing DisplayPort cables to be transitioned to Mini DisplayPort. Read More

Electrical Equipment & Systems

Ethernet Cables increase data capability for civil aerospace.

June 3, 2015

Engineered with fluoropolymers for modern airborne digital networks, GORE® Ethernet Cables handle transmission of up to 10 gigabits over extended distances while maintaining signal integrity with stable performance. Sizes 24 and 26 AWG have nominal ODs of 0.270 and 0.200 in., minimum bend radius of 1.35 and 1.05 in., and nominal weight is 40 and 32 lb/1,000 ft. CAT-6A cables support TIA-568 applications up to 10 gigabits and maintain reliable performance in temperatures from -55 to 200°C. Read More

Electrical Equipment & Systems

SMP Cable Assemblies suit high data rate applications.

May 28, 2015

Offering preconfigured solution for high-frequency applications with 50 Ω impedance requirements, Fixed Length SMP Cable Assemblies provide performance up to 26.5 GHz. Coaxial units feature SMP plug connectors, which accommodate both radial and axial misalignment. Connectors are terminated to industry standard 0.085 conformable and Times Microwave TFlex®-405 cable. Available in lengths from 3–36 in., assemblies are suited for broadband communications, instrumentation, and antennas. Read More

Electrical Equipment & Systems

Continuous Flex Cables feature zero-halogen construction.

May 21, 2015

Constructed with mPPE insulation and polyurethane jacket, EcoFlex® PUR Cables offer 600 V performance. PUR jacket resists oil,  UV, and abrasion and remains flexible at temperatures down to -40°C. Insulation contributes to size and weight savings, and enables cables to meet RoHS and REACH requirements. Available in over 120 shielded and unshielded configurations and up to 36 conductors, EcoFlex PUR cables are suited for industrial machinery, mining equipment, and outdoor applications. Read More

Electrical Equipment & Systems, Welding Equipment & Supplies

Aluminum Welding Wire feeds smoothly, does not produce shavings.

May 12, 2015

Available as standard in 1/16 and 3/64 in. dia, SuperGlaze® HD delivers steady wire feed from payoff to arc and eliminates wire shavings for uniform and uninterrupted weld. Elimination of shavings from feeding process also reduces gun chatter and burnbacks. Suitable areas of use include heavy-duty applications where wire feeding can prove challenging and arc performance is critical. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Flexible VFD Cable features oil-resistant shielded design.

May 8, 2015

Dual rated for 600–2,000 V applications, ÖLFLEX® VFD 2XL combines XLPE (plus) insulation, phthalate-free TPE outer jacket, and conductors made from finely stranded tinned copper. Cross-linked polyethylene insulation provides optimized electrical properties and allows cable to withstand heat generated by overcurrent conditions. Offering test voltage of 6,000 V and minimum bend radius of 7.5 times diameter, cable uses barrier tape, triple layer foil tape, and tinned copper braid for shielding. Read More

Electrical Equipment & Systems

Wind Energy Industry Cables use copper or aluminum as conductor.

May 4, 2015

HELUWIND WK torsion cables — 110-TORSION, 110-TORSION MULTI, MS-SINGLE-TORSION 610, MS SINGLE-310-TORSION — are tested up to 15,000 torsion cycles. Power cable for vertical lifts/elevators in wind turbines, HELUWIND WK LIFT, aids in climbing up tower walls and accessing nacelle. Aluminum-based offering includes 5 single- and multi-conductor power cables: HELUWIND WK POWERLINE ALU MS-SINGLE, HELUWIND WK POWERLINE ALU SINGLE, HELUWIND WK POWERLINE ALU MULTICORE, ALUMINUM MV-90 and MV-105. Read More

Electrical Equipment & Systems, Test & Measuring Instruments

Mini/DisplayPort to HDMI Cables support Ultra HD 4K video.

April 30, 2015

Supporting Ultra HD 4K video and available in various lengths and colors, DisplayPort™ to HDMI® and Mini DisplayPort™ to HDMI cables respectively connect DisplayPort- and Mini DisplayPort-equipped computer to HDMI-enabled display or projector. These adapter cables eliminate need to use separate signal adapter, and included passive signal conversion eliminates need for additional power adapter. Lengths of 3 and 6 ft are available, and color choices include black and white. Read More

Electrical Equipment & Systems, Material Handling & Storage, Welding Equipment & Supplies

Cable Feeding Systems are designed for efficiency, usability.

April 29, 2015

While respectively able to handle up to 330 lb reels with max diameter of 24 in. and up to 880 lb reels with max diameter of 36 in., PreFeeder 3300 and 4300 are based on simplified design that facilitates use, helps increase production rates, and promotes processing efficiency. All axes are electrically driven for facilitated reel handling and accelerated changeovers, and shaftless design aids reel loading/unloading. Read More

Electrical Equipment & Systems, Services

Box Build Assemblies target early-stage companies.

April 29, 2015

Designed for manufacturability, Electro-mechanical Box Build and Cable Assemblies provide compatible, connectorized, and tested solution as one SKU. Assemblies are suitable for NPI and prototype electromechanical applications including instrument and power distribution panels and fan tray assemblies. Aved provides complete engineering support, including process control, 3D modeling, documentation, manufacturing and testing procedures, and consolidation of design and procurement decisions. Read More

Electrical Equipment & Systems

Ethernet Cabling System meets all device connectivity needs.

April 27, 2015

Suited for installations in cramped spaces or junction boxes, Ha-VIS preLink® is based on terminal block that user wires separately, then snaps securely into any one of 7 mating profiles: RJ45, PushPull RJ45, M12 D-coded, M12 X-coded, RJ45 HARTING Industrial Form Factor, RJ45 Keystone, and preLink® extender. Wires are inserted into termination block according to color codes, and special preLink® crimping tool ensures wires are always assembled precisely and correctly. Read More

Electrical Equipment & Systems

Heavy-Duty 5-Outlet Extension Cord has explosionproof design.

April 1, 2015

Resistant to oil, chemicals, and abrasion, 100 ft long EPECX-5X-100 extends reach of explosionproof equipment in hazardous locations by providing power where power receptacles are not in close proximity to work space. There are 5 explosionproof, twist lock receptacles constructed of non-sparking aluminum on one end for connecting equipment, and 20 A explosionproof plug on other end ensures safe and secure connection to power receptacles. Cord can be customized to work on 120 Vac or 250 Vac.
Read More

Electrical Equipment & Systems

Motor Connection Cables have PVC jacketing, XLPE insulation.

March 20, 2015

Offered in 16 AWG to 500 kcmil sizes, TOPFLEX-EMV-UV-3 PLUS 2XSLCYK-J is constructed using 3 conductor plus 3 symmetrical ground configuration. Using 3 conductor plus full-size ground structure, TOPFLEX-EMV-UV-2XSLCYK-J comes in 16 AWG to 350 kcmil sizes. Both models offer conductor temperature resistance of 90°C, which maximizes current load rating. OD aids installation in tight spaces due to cable's max bending radius, and double-shielded cables are jacketed using PVC compound. Read More

Electrical Equipment & Systems

Rugged 75 Ohm Test Cables operate up to 3 GHz.

March 18, 2015

Able to withstand test lab use and applications in 75 Ω communications systems, 75 Ω test cables come in type-N male to type-N male and type-N male to type-F male configurations. F connectors perform up to 3 GHz, which enhances applicability, and are threaded to ensure accurate and secure connection to DUT as well as analyzer. These 75 Ω, flexible, armored test cables, capable of 100,000 bends min, exhibit insertion loss of <0.5 dB @ 3 GHz and typ return loss of 28 dB. Read More

Electrical Equipment & Systems

Explosion Proof Extension Cord provides 4 receptacles.

March 11, 2015

Measuring 25 ft long, Model EPEXC-4X-25 extends reach of equipment in hazardous locations where power receptacles are not in close proximity to work space. Cord is fitted with 4 explosion proof twist lock receptacles constructed of non-sparking aluminum on one end for connection of equipment and 20 A explosion proof plug on other end for safe and secure connection to receptacles. Cord, plug, and receptacles are 3-pole 2-wire design, which works with most common explosion proof equipment. Read More

Electrical Equipment & Systems, Communication Systems & Equipment, Optics & Photonics

All-Dry Fiber Microcable improves safety and productivity.

February 17, 2015

While improving safety and productivity, MiDia® Dry FX microcable helps reduce fiber cable installation expense. Fibers emerge from buffer tubes ready for fusion splicing or optical testing, eliminating need for cleaning products. Available in 3 constructions containing up to 144 fibers, product comes with bend-insensitive AllWave® + fiber. Entirely dry cable technology replaces gel-based filling and flooding compounds traditionally used to prevent spread of water in outside plant cables. Read More

Electrical Equipment & Systems

Heavy-Duty Explosionproof Extension Cord features 3 receptacles.

February 11, 2015

Providing secure connection, EPECX-3X-100 extends reach of explosionproof equipment in hazardous locations where power receptacles are not in close proximity to work space. This 100 ft long cord has 3 explosionproof twist lock receptacles, constructed of non-sparking aluminum, on one end and 20 A explosionproof plug on other end. While cord is resistant to oil, chemicals, and abrasion, receptacles have deep recessed contacts for protection against arcing. Read More

Electrical Equipment & Systems

Structured Cabling System supports migration paths up to 40 G.

February 6, 2015

Supporting shielded applications from Category 8 to 5e and UTP applications from Category 6A to 5e from one unified connectivity platform, Atlas-X1™ seamlessly supports network migration to 40GBASE-T. Solution meets draft 2.0E of TIA-568-C.2-1 Category 8 proposed standard and exceeds Category 5e, 6, and 6A UTP and shielded ANSI/TIA-568-C.2 standards. System includes pre-production Category 8 cable from Berk-Tek and supports 30 m channel. Read More
