Transmitters & Transducers
Targeting telemetry, remote control, and industrial applications, Circuit Design STD-601 offers 6 selectable RF power output levels from 1–50 mW, 5 selectable data rates from 1,200–19,200 bps, and 4 selectable frequency bands: 429, 434, 447, and 458 MHz. Narrowband, blocking, and sensitivity features suit rugged, noisy industrial environments where good channel selectivity is required. Consuming 35 mA typ (TX 10 mW, 3 V), 20 x 32 x 5 mm SMD unit offers 600 m LOS communication range at 10 mW.
Offering deployment flexibility and sustainability, PTP 700 covers 4 GHz NTIA/NATO bands and 5 GHz unlicensed spectrum for federal, industrial, and public safety deployments. This point-to-point wireless broadband solution is available as Connectorized Radio or Connectorized+Integrated Radio. Latter allows for antenna selection at time of deployment. Capable of line of sight and non-line of sight operation, radio offers up to 450 Mbps throughput and has 124 mile max range. Read More
Featuring programmable frequency bands and channels, STD-601 comes in SMD, 20 x 32 x 5 mm package and offers communication range of 600 m (LOS) at 10 mW. Frequency bands – 429, 434, 447, and 458 MHz – conform to various ISM bands to allow frequencies to be set within wide range, and transparent user data input allows use of proprietary protocol. Module also offers selectable RF power levels – 1, 5, 10, 20, 25, 50 mW – and data rates: 1,200, 2,400, 4,800, 9,600, and 19,200 bps. Read More
Measuring different sensor inputs such as thermocouple, RTD, relative humidity, and pH, UWBT Series transmits data to smartphone or tablet via wireless Bluetooth communication. App running on iOS or Android™ phone/tablet monitors and logs sensor data and displays data in digital, graph, or gauge format. It can be configured in 9 languages and can be paired with multiple transmitters simultaneously. Logging up to 10 samples/sec, UWBT Series can send data files to email address or Cloud. Read More
Used where multiple devices concurrently stream HD and Ultra HD content, 8-Stream 5G WiFi XStream MU-MIMO platform features pentacore architecture that realizes max speeds over 3.8 GHz. MU-MIMO support improves wireless networking efficiency, while 1024 NitroQAM™ technology promotes performance, reach, and rate through high-power RF on 5 and 2.4 GHz bands. Router supports 8 streams at 5 GHz and 4 streams at 2.4 GHz; extended 5 GHz support adds three 80 MHz channels and two 160 MHz channels. Read More
Allowing channel switching according to preset channel plan, 1.6 x 1.15 x 0.22 in. STD-503 facilitates embedding of wireless capabilities in industrial remote control equipment. Radio communication reliability in 2.4 GHz ISM band is ensured via use of noise-resistant direct-sequence spread spectrum (DSSS) modulation as well as true diversity receiver design employing 2 antennas. Transmitting data at up to 19.2 kps, module achieves low power operation of 10 mW using 3.3 V 65 mA supply.
Employing quad-core ARM®Cortex®-A9 (Freescale i.MX6) processor running Linux, 4.4 x 1.6 x 1.1 in. Matchstiq™ S10 supports connectivity via GigE (PoE capable), USB 2.0 OTG, and HDMI and features integrated GPS with 1PPS. Platform is based on Sidekiq MiniPCIe SDR card, with RF transceiver providing independently tunable RF transmitter and receiver covering 70 MHz to 6 GHz as well as RF channel bandwidths up to 50 MHz and Xilinx® Spartan®6 LX45T FPGA. RTC with battery backup is also standard.
Fully managed from central location, HT1300 enables satellite operators worldwide to leverage JUPITER™ System over conventional satellite capacity while positioning them for seamless migration to future high-throughput (HTS) satellites. Router operates over conventional C-band and Ku-band while also supporting Ka-band satellite capacity. High availability and flexibility via L-band interface enable operation with outdoor units, including high-power amplifiers. Read More
Featuring IR interface, PolyTrans® P 32000 automatically recognizes signal outputs of any 2-, 3-, and 4-wire temperature, force, and strain sensors; resistors; potentiometers; resistive sensors; and similar sensing technologies. Transmitters can also recognize standard thermocouple signals, with either internal or external reference junction compensation, and without further adjustments. DIP and rotary encoder switches or IrDA® interface enable adaption to individual measurement tasks. Read More
Featuring 2-part modular design with electronic housing and mechanical probe, Model CS02 measures liquid level in oil and gas industry. Unit can be mounted fully submerged within process tank or through threaded opening. Electronics platform features adjustable high/low resolution sensor and controlled linearity scale of measurement. Custom-designed in accordance with user specifications, transmitter is available with 4–20 mA, 0–5 Vdc, and 1–5 Vc outputs with indication lengths from 4–180 in. Read More
Intended for installation on new or existing turbine meters or pulse devices, Rosemount® 705 wirelessly provides average flow rate and totalization in operator-configurable k-factor. Unit also delivers predictive diagnostics data to indicate instrument health and support proactive maintenance. Along with 1 sec updates, features include mounting capability up to 1 km away and ability to be configured to reset at unit or remotely via MODBUS, EtherNet/IP, or OPC from host system. Read More
Supporting use anywhere in 3G coverage area, Mobile Base Station RTR-500MBS-A supports all Remote Units in RTR-500 Series and transmits data via mobile networks to T&D WebStorage Service. This enables data collection and monitoring without LAN or PCs and also allows data access, without necessitating server preparation, via smartphone/tablet browser. Along with GPS function for location info, solution also supports sending of warnings and alert notifications to mobile devices. Read More
Suitable for laminar flow control and other clean room applications, Model EE660 utilizes thin film sensor that operates on hot film anemometer principle for long-term stability and low sensitivity to dirt. Large, flush-mounted LCD with backlight is 180° rotatable, ensuring optimal readability. Available for wall or duct mounting as well as with remote probe, transmitter has current and voltage output, whereby both signals are available on terminal. Read More
Available in 7 ranges from 0–10,000 psi, Model 3800 Series Pressure Transmitters offer 5 ms response times with choice of loop-powered 4–20 mA or low-power 1–5 Vdc output. Units have NEMA4X/IP66 housings, stainless steel wetted parts, and hermetically sealed enclosures without O-rings. Providing 4–20 mA standard output and optional 1–5 Vdc output, all stainless steel Model 3820 Series OEM Pressure Switch-Transmitters add 30 V, 120 mA normally open solid state relay switch with ±2% URL accuracy. Read More
Integrating with Yokogawa or any other ISA100 wireless system, ISA100 Microcor Wireless Transmitter (MWT-3905) employs high-resolution metal loss measurement that provides 18-bit resolution and supports operation in any process environment. Multiple units can be combined with wireless extenders to form network of up to 500 devices, and functionality enables users to choose star or mesh network topologies. Device can be deployed in hazardous area locations (Class 1, Zone 1). Read More
CSI 9420 comes with AMS Suite: Machinery Health Manager v5.61 asset management software, which integrates data from route-based, online, and wireless vibration solutions, as well as third-party oil and IR analysis data, to provide complete picture of machinery health. Spectral resolution options help reduce bandwidth requirements and improve power module life, while data log and configuration capabilities streamline user interaction with multiple transmitters on single gateway. Read More
Meeting requirements of CIA 443 (SIIS Level 2 device), PAINE 226-30-0020 Series provides intelligent CANopen® digital networking solution for bi-directional full-line differential pressure and temperature measurements of subsea media. Fully submersible transmitter, constructed of all welded Inconel®, is designed for universal mounting and offered with micro Subconn® MCBH4F subsea connector to facilitate network integration and installation. Read More
Used to measure moisture, hydrogen, and temperature directly in transformer oil, MHT410 provides real-time measurements and trend data to facilitate reliable decision-making and foster predictive maintenance planning. Features include adjustable probe installation depth; non-membrane technology-based hydrogen measurement; and maintenance-free design that does not require post-installation calibration/adjustment. Product does not employ pumps, hoses, batteries, or other consumable parts. Read More
CE-compliant UWBT Series measures different sensor inputs, such as thermocouple, RTD, relative humidity, and pH, and transmits data to iOS- or Android™-based smartphone or tablet via wireless Bluetooth® communication from UWBT app. Among other features, app can be configured in 9 different languages, pair with multiple transmitters simultaneously, monitor and log sensor data on device, and display sensor data in digital, graph, or gauge format. Data can also be emailed or sent to cloud. Read More
Digi XLR PRO™ radios, intended for wireless data transmission in various industries with remote assets, Ethernet, and serial devices, overcome noisy RF environments via Punch2™ Technology, which leverages Chirp Spread Spectrum (CSS) modulation. With line of sight range of >100 miles, 1 W unlicensed 900 MHz wide-band radio supports data rates >3 Mbps. Radio does not require any programming and can be configured using XCTU configuration platform and managed/maintained via Device Cloud Manager. Read More
