Electrical Boxes

Electrical Equipment & Systems, Optics & Photonics, Green & Clean, Electronic Components & Devices

Combiner Box suits photovoltaic installations.

June 23, 2015

Housed in NEMA4X fiberglass enclosure, 1500 V SlimLine Combiner Box features 100% load break UL98B rated disconnects and surge suppression. Busbars utilized are C1100 oxygen-free and are precision milled to ensure optimum contact and long- term reliability. Multiple off-the-rack and custom options are available up to 400 A and 32 strings. Read More

Electrical Equipment & Systems

Ceiling Fan Boxes accelerate and ease installation.

May 22, 2015

Available in pan, shallow, deep, and integral mounting bracket styles, Steel City® Ceiling Fan Boxes have gold-finished No. 10 screws for identification as UL and NEC® compliant for ceiling fan support. New-work bar hangers feature locating tabs to facilitate installation and arched profile for higher load ratings. Old-work bar hangers, designed for use in existing ceilings, are installed through 4 in. hole and expanded to secure box to ceiling joists. Both accommodate joists spaced from 16–24 in. Read More

Electrical Equipment & Systems

Floor Box eliminates hazard of outdoor outlets.

May 4, 2015

Intended for raised-deck applications, Red•Dot® Deck Grommet™ Pro Floor Box keeps power outlet recessed below deck’s surface, eliminating safety hazard of cords plugged into outdoor post or wall-mounted outlets. When outlet is not in use, hardwired box remains concealed beneath deck board, with only non-metallic cover showing. Product is suited for residential outdoor living spaces and light-commercial applications, such as outdoor restaurants and hospitality recreation areas. Read More

Electrical Equipment & Systems

Square Open Back Boxes allow access to back of installed devices.

January 26, 2015

Conserving time as well as expenses on jobsite, Steel City® 4 in. Square Open Back Box allows wiring of pre-installed device from back without removal of mud ring from front of box to make connections. Installers can, after making connections, close box with blank cover. Boxes are available in shallow (1 ½ in. deep) or deep (2 1/8 in. deep) models, and mounting screws on both sides accommodate mud ring on front and blank cover on back. Ground wire clips are also available. Read More

Electrical Equipment & Systems, Electronic Components & Devices

IP Rated Electronic Enclosures support custom design options.

December 8, 2014

Intended for instances where PCB/application has already been designed, IP65 Sealed enclosures range in size from 80 x 80 x 60 mm to 360 x 360 x 158 mm. Other feature-based considerations include availability of hinged lid for regular access to electronics, optional transparent lid, cable gland knock outs, captive screws, and separate terminal wiring compartment. All electronic enclosures can be custom machined and/or printed to meet specific demands. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems, Mechanical Power Transmission

Customizable Terminal Enclosure is offered in unsealed version.

November 24, 2014

While designed for desktop use, UNIDESK unsealed sloping front terminal enclosures can also be wall mounted. Ergonomic aluminum instrument enclosures, supplied pre-assembled, feature recessed front panel for membrane keypad, pre-punched PCB fixing points in base, and flat rear wall for installing switches, connectors, power inlets, and cable glands. In addition to light gray and black colors, 3 sizes are available: 7.87 x 7.87 x 4.02 in., 11.81 x 7.87 x 4.02 in., and 15.74 x 7.87 x 4.02 in. Read More

Electrical Equipment & Systems, Mechanical Power Transmission, Electronic Components & Devices

DIN Rail Mounting Enclosure houses Raspberry Pi B+.

November 20, 2014

Produced in UL94V-0 self-extinguishing material, Modulbox 4M RMB fosters use of Raspberry Pi B+ within industrial and process control applications. Enclosure features transparent top panel, body enclosure, and base, and DIN rail hook allows enclosure to be mounted on DIN Rail. Manufactured with openings for specific input and output requirements of Raspberry Pi B+ platform, enclosure can also be machined/printed to custom specifications for volumes from 50–100 minimum. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems

Hinged Cover protects electrical units from damage.

November 6, 2014

Comprising cover, mounting frame, and piano style hinge, STI-6519 Single-Gang Protective Cover is molded of clear polycarbonate, protecting pushbuttons, electrical switches, digital keypads, electrical outlets, pull stations, biometrics, and volume/lighting controls against vandalism and accidental damage. Frame mounts directly through product mounting plate to electrical box, eliminating need to drill additional holes in wall. Read More

Electrical Equipment & Systems

Pop-Up Floor Boxes make receptacles disappear.

September 25, 2014

Available in more than 20 models, as complete assemblies or cover-only plates, Pop-Up Floor Boxes mount flush with floor and receptacles disappear when retracted, providing clean appearance and preventing tripping hazards. One-gang pop-ups include round or square shapes, duplex or RJ45, while 2-gang pop-ups are available in duplex, RJ45, or combination of both. ETL-listed and offered in brass or stainless steel finish, boxes can be installed in wood or concrete flooring. Read More

Electrical Equipment & Systems, Electronic Components & Devices

Open Face Wall Box is designed for facilitated access.

September 5, 2014

Along with rugged 16 gauge steel back box, PWB-353 Wall Box unit features open face design that facilitates access to cables and connectors without requiring cover removal. White interior and white extended trim ring provide clean appearance, and latter also covers rough cuts in drywall created during installation. Designed for use in 3 or 4 in. stud walls, 3 in. deep enclosure features multiple knockouts for power as well as openings for up to 6 single IPS connector plates.
Read More

Electrical Equipment & Systems, Electronic Components & Devices

NEMA 4X Enclosures include data-ready light.

August 20, 2014

Corrosion-resistant and IP66-rated, VibraLink® Enclosures feature LED that indicates when sensor bias output voltage levels have stabilized and data can be collected. Switchboxes provide termination for up to 48 cables and include RFI filtering, differential switching, and grounding lug. MIL-C-5015 and BNC output connectors provide quick connectivity to portable data collectors. For route-based or online monitoring, online connectivity output is available. Read More

Electrical Equipment & Systems

Power Supplies accept wide range of AC/DC inputs.

August 7, 2014

Available in single- and 3-phase units, PROeco Power Supplies provide outputs of 12, 24, or 48 Vdc for loads up to 40 A. Auto-detect feature on each module makes switching between ranges unnecessary. Tri-colored LED delivers local output status, while integral relay contacts provide remote status monitoring for detection and diagnosis of power issues. Featuring 100 mm housing depth for use in small enclosures, power supplies operate from -25 to +50°C with efficiency up to 93%. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems

Polycarbonate Cover protects small electrical units.

August 6, 2014

With cover, mounting frame, and piano-style hinge molded of clear polycarbonate material, STI-6519 Single-Gang Cover can protect pushbuttons, electrical switches, digital keypads, electrical outlets, pull stations, biometrics, and volume/lighting controls against vandalism and accidental damage. Frame eliminates need to use appliance mounting plate and mounts directly through product mounting plate to electrical box. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

NEMA 4X Plastic Enclosures suit indoor/outdoor applications.

July 22, 2014

Available in 4 additional sizes featuring molded on surface mounting flanges, Series WA, WC, and WP are UL listed to UL508-4X specifications. Electrical enclosures include brass inserts for cover on/off convenience, stainless steel screws, and silicone rubber gasket to protect electronics from harsh environmental factors such as dust, dirt, and water. WC and WP Series are molded in flame-retardant UV stabilized Polycarbonate, while WA Series is molded in flame-retardant ABS plastic. Read More

Computer Hardware & Peripherals, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

Modular Data Center scales to suit requirements.

July 14, 2014

Using components that can be manually assembled on-site without crane, T4 Granular Modular Data Center helps overcome site access and logistical challenges. Sizes can range from few racks to few hundred, while thick insulated walls surrounded by weatherproof, galvanized, powder-coated steel protect against adverse environmental conditions. Along with built-in control, features include non-combustible materials, Tier 1 to Tier 4 resilience, secure construction, cooling, and other options. Read More

Electrical Equipment & Systems

Intelligent Breakout Boxes simplify NVH testing.

June 17, 2014

When incorporated into test solution with EMX-425X series modular dynamic signal analyzers, 8-chanel EMX-4008 and 16-channel EMX-4016 provide external trigger connector and external calibration input connector to facilitate and simplify triggering and calibration of EMX-425X cards. Both replaceable breakout boxes (BOBs) provide BNC interfaces and support full range of capability of EMX-4250 series, including sampling rates to 204.8 kSa/s/channel and deterministic multi-channel phase response. Read More

Material Handling & Storage, HVAC, Electrical Equipment & Systems, Electronic Components & Devices

Filter Fans cool electrical and electronic enclosures.

May 27, 2014

Designed to remove unwanted heat from enclosures and cabinets, VFF Series provides forced convection cooling for computers, power distribution equipment, industrial automation controls, and food/beverage process controls. Fans draw filtered ambient air into cabinet while simultaneously blowing heated air out exhaust. Featuring injection molded, thermoplastic construction, fans provide 11–368 cfm of airflow and will maintain NEMA ratings of 12, 3R, or 4, depending on model. Read More

Material Handling & Storage, Plant Furnishings & Accessories, Electrical Equipment & Systems

Wall-Mount Utility Box is molded of ABS plastic.

May 5, 2014

Available in black, ivory, and dark grey, SATURN Series 160X13 wall mount plastic enclosure measures 1.600 x 1.800 x 2.815 in. and features molded top and bottom that secure together via 4 Plastite® screws. Utility box, molded using ABS plastic with UL 94VO rating available upon request, has lightly textured finish and is offered with or without mounting tabs. Other options offered include EMI/RFI shielding; cut-outs, openings, chamfers, and other machining variations; and pad printing.
Read More

Material Handling & Storage, Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

Plastic Push Button Box offers alternative to steel.

May 2, 2014

Offering corrosion resistance in washdown, humid, and outdoor environments, PBB Push Button Box carries NEMA 4X/IP67 rating and meets requirements of UL 746C with respect to UV light and water exposure. Construction combines polycarbonate plastic and 10% fiberglass for combined shatter resistance and molding consistency. Latter results in tight tolerances and seal reliability. Gray PBB Push Button Box suits 22 and 30 mm push buttons and comes in sizes from 0.89 x 1 in. to 1.22 x 4 in. Read More

Plant Furnishings & Accessories, Electrical Equipment & Systems, Electronic Components & Devices

NEMA Electrical Junction Boxes offer harsh environment protection.

March 21, 2014

Molded from impact-resistant polycarbonate, YQ Series include 8 sizes from 6 x 4 in. through 16 x 14 in. Products meet NEMA Type 1, 2, 3, 3R, 4, 4X, 5, 6, 6P, 12, and 13 specifications and IP68 of IEC 60529 requirements (UL File No. E352997). Along with corrosion-resistant stainless steel screws, features include waterproofing closed-cell gasket and opaque or clear cover. Boxes are surface mountable, with choice of mounting feet or mounting flange, and customization options are available. Read More
