ICL1200 Battery Charger comes with customizable cable design.

March 30, 2017

Operated on single-phase electrical grid, ICL1200 Battery Charger can be used as on-board or off-board charger. Featuring vibration, shock and temperature resistant mechanical design, units use Controller Area Network communications. Meeting IP66 and touch-safe requirements, charger is suitable for charging electric vehicles.

Read More

Electrical Equipment & Systems

SEL-T400L Time-Domain Line Relay is based on traveling-wave microprocessor.

March 29, 2017

Capable of detecting power system faults, SEL-T400L Time-Domain Line Relay sends trip signal to circuit breakers at 4 to 10 times faster than phasor-based relays. Relay uses combination of traveling wave and incremental quantity protection technologies. Unit trips at a speed of millisecond for improved system stability and power quality.

Read More

Electrical Equipment & Systems, Electronic Components & Devices

Series KA Industrial Control Transformers come with finger safe fuse terminals.

March 29, 2017

Available in 25-5000 VA rating, Series KA Industrial Control Transformers are used in control panels, factory automation, process control and motors. Impregnated in high grade class varnish, Series KA transformers offer 120/240VAC primary and 12/24 VAC secondary voltage. Meeting NEMA, ANSI, NMBTA and NFPA standards, units are operated in -20°C to 40°C temperature range. Unit’s primary and... Read More

Electrical Equipment & Systems

NSB2-0 Rotary Switch comes with black powder coated enclosure.

March 29, 2017

Suitable for both outdoor and indoor applications such as in-plant process control, mining vehicles and lift systems, NSB2-0 Rotary Switch features strong steel operating shaft. Offering more than 10 million cycles of mechanical life, unit is controlled using step control method with up to 7-0-7 individually detented steps. Unit is designed with custom contact sequences, detents, spring... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Series KA Control Transformers feature CC fusing options.

March 29, 2017

Suitable for factory automation, process control, material handling and motors, Series KA Industrial Control Transformers are available in 25 to 5000 VA rating. Offering 120/240VAC primary voltage and 12/24VAC secondary voltage, transformers come with rugged construction. Operating in -20°C to 40°C temperature range, units come with IEC “Touch proof” and finger safe fuse terminal.... Read More

Electrical Equipment & Systems, Test & Measuring Instruments

Regulated Bus Converter features 45-56 VDC input / 10.4 VDC at 96.2 A output.

March 29, 2017

Rated Class 2 and Category 2, 0RQB-X0S10BG Regulated Bus Converter offers up to 1000 W in Quarter Brick footprint. Combining digital control, efficient secondary side synchronous rectifiers and thermal management system for effective power dissipation removal, device includes protection features such as under voltage lockout, overtemperature protection, OCP, SCP and OVP. Converter comes with... Read More

Electrical Equipment & Systems

Key Pad Dome Switches feature four legged shape.

March 29, 2017

Available in Mini, Compact and Maxi with diameters 0.331 in., 0.394 in. and .480 in. respectively, Key Pad Dome Switches provide forces from 7.8oz. to 14.8oz. Used for single or double-sided PCB, flex circuits and membrane switch panels, units are made from nickel plated stainless steel and are designed for harsh environments like microwaves or vending machines.

Read More

Electrical Equipment & Systems

PHR Series AC-DC Power Supplies feature opto-less design.

March 29, 2017

Available with 120W, 150W, 200W or 250W output power levels, PHR Series AC-DC Power Supplies are designed to provide 30 years of operating life. Featuring low component count and full electronic protection, units convert universal ac-input voltage of 95V to 264Vac to 12V, 24V, 48V or 125Vdc for 120W, 150W and 200W units and to 24V, 48 V. Operating in -20°C to +70°C temperature range, units... Read More

Communication Systems & Equipment, Electrical Equipment & Systems, Optics & Photonics

Wurth Electronic Wireless Transmitter and Receiver Coils Featured in Semtech’s Wireless Charging System

March 29, 2017

Watertown (USA), 27 March 2017 – Created for charging high-power applications, Wurth Electronics wireless charging coils are now featured in Semtech’s LinkCharge™ 20. LinkCharge™ 20 is the only available inductive wireless charging system beyond 15 watts that is backwards compatible. It uses a proprietary protocol for transmitter/receiver communication up to 20 watts, and is also fully... Read More

Electrical Equipment & Systems

ITZ Series DC-DC Converters feature remote on/off function.

March 28, 2017

Available with +3.3, +5, +9, +12, +15, or +24 VDC single output or ±5, ±12 or ±15 VDC dual output model, ITZ Series DC-DC Converters are rated to 1.5k VDC input to output isolation. Operated in –40 to +85°C temperature, units come with +9 to +36 VDC or +18 to +75 VDC of input range options. Meeting EN55032 level A standards, converters are housed in 21.9 x 11.2 x 9.6 mm SIP-8 package and... Read More

Electrical Equipment & Systems, Electronic Components & Devices

TXtreme™ Distribution Transformer comes with corrosion resistant coating.

March 28, 2017

Designed for harsh operating conditions containing salt, moisture or chemicals, TXtreme™ Distribution Transformer comes with ABB's new coating formula which reduces the cost of repainting and increases service life of transformer. TXtreme™ transformer enhances grid reliability. Using ABB's new innovation, transformers can be protected from corrosive substances.

Read More

Electrical Equipment & Systems

Hazardous Location Area Lights come with die cast aluminum housing.

March 27, 2017

Ceiling or wall mounted, Hazardous Location Area Lights feature tempered glass lens. Marine grade and certified for use in Class I, Division 2, and Class II, Division 2 spaces, LEDs can operate in temperatures up to 140°F on 120-277V and 347-480V inputs. With lifespan exceeding 100,000 hours at L70 standards, LEDs output 9,000 and 18,000 lumens respectively. Luminaires are placed on rugged... Read More

Electrical Equipment & Systems

Quick-Fit Surface Mount Terminals ensure easy reflow soldering.

March 27, 2017

Designed for use with vacuum pick-and-place equipment, Quick-Fit Surface Mount Male Tab Terminals feature three-legged design. Made from brass with tin-plate, units are housed in 13 in. tape and reel package with high temperature nylon pick pads.

Read More

Electrical Equipment & Systems, Mounting & Attaching Products

Pre-leading Contacts Protect Sensitive Electronics in New HARTING Har-flex® Variant

March 25, 2017

Elgin, IL, March 2017 – Angled male versions of HARTING’s miniaturized har-flex® SMT connectors now can be ordered with pre-leading contacts, an option for manufacturers to protect sensitive electronics from damage during operational plugging and unplugging. This special-order variant addresses a particular risk associated with modifying modular electronic systems. End users often enhance... Read More

Electrical Equipment & Systems

EVC- 42-84 Charger is compliant with EN55014-1 Class B emissions.

March 25, 2017

Used as on-board or off-board charger for electrical vehicles or bicycles, EVC- 42-84 Lithium Ion Battery Charger offers constant 2 A current output with ±5% accuracy. Operated in -20 to +45°C temperature range with 90 to 264VAC input supply, unit provides 25 to 41.8 V charging voltage range with ±0.6% output voltage accuracy. Featuring 3750VAC of input to output isolation, charger comes in... Read More

Electrical Equipment & Systems

High Current Converters Support Many Applications

March 25, 2017

Get your designs to market faster with TI's next-generation SWIFT™ mid VIN, high IOUT buck DC/DC converters with integrated FETs. The high-performance, synchronous buck DC/DC converters range from 1.5V to 17V input and 8A to 40A. They are ideal for designs that require high power density and high efficiency such as telecom, servers, storage, switches, routers, FPGAs, ASICs, test and... Read More

Electrical Equipment & Systems

Design Improvements for AutomationDirect’s Line of Bryant Watertight Wiring Devices

March 25, 2017

New design improvements have been made to AutomationDirect’s offering of Bryant watertight products to provide additional water ingress protection.

Newly offered are ten plugs ranging from 125VAC/15A to 480VAC/30A, 2-pole / 3-wire and 3-pole / 4-wire; ten corresponding connectors for plugs; and a portable outlet box and two covers. These new products are a one for one replacement of... Read More

Electrical Equipment & Systems, Electronic Components & Devices

Wurth Electronics IEEE802.3.bt LAN Transformer Featured in the Texas Instruments’ (TI) High Power IEEE802.3bt PoE Smart Lighting Power Supply System

March 25, 2017

Watertown (USA), 23 March 2017 – Wurth Electronics is proud to have its transformer featured in Texas Instrument’s new high power IEEE802.3bt power over Ethernet connected lighting power supply system.

Expecting publication in 2018, the IEEE802.3bt standard, also known as four-Pair PoE, will enable systems capable of delivering power at ~70W and broaden PoE's technology reach... Read More

Electrical Equipment & Systems

Military Cable Assemblies for Drones, Missiles & Telecom Systems

March 24, 2017

If you need custom manufactured military cable assemblies and wire harnesses, check with Aved Electronics, Inc. of North Billerica, MA.

They are an ITAR registered SBVO (Small Business Veteran Owned) company.

Aved Military Cable Assemblies are custom manufactured using MIL-Spec wire, cable, boots, transitions, tubing, contacts, terminals, connectors back-shells, and adapters.... Read More

Controls & Controllers, Electrical Equipment & Systems

Minnesota Twins Install Eaton’s Advanced LED Lighting and Controls System at Target Field for the 2017 Season

March 24, 2017

SYRACUSE, N.Y. - Power management company Eaton today announced that its advanced Ephesus sports lighting light-emitting diode (LED) and controls system is being installed at Target Field, home of the Minnesota Twins, for the 2017 season. Featuring industry-leading control functions, the LED system enhances the viewing experience for spectators while reducing energy use by as much as 75... Read More
