Wide-Input DC/DC Power Modules offer broad applicability.

December 22, 2014

Targeting applications in telecom and industrial markets, eight-brick PKB5000W series comprises 2.3 x 0.9 x 0.39 in., open-frame, single-output power modules that provide 2,250 Vdc I/O isolation and deliver 91.5% typ efficiency. Input range is 18–75 Vdc; nominal outputs are 3.3, 5, or 12 Vdc with max outputs up to 30 A and 120 W; and typ efficiency is 91.5% at 12 V full load. Along with multiple protection features, remote sense capability and remote control function are standard. Read More

Electrical Equipment & Systems

Fast-Acting 5 x 20 mm Fuse carries both 420 Vac and Vdc ratings.

December 22, 2014

Offered in cartridge or axial-leaded versions with current ratings to 16 A, 487 Series ensures optimal coordination between PSU and electrical circuit breaker panel during short-circuit and over-current faults to protect telecom and datacenter equipment. Air circuit breaker trips before fuse opens when circuit is exposed to short-circuit condition. Installed in PSU, fuse opens faster than circuit breaker, removes problematic PSU from branch circuit, and keeps branch circuit live without cutoff. Read More

Electrical Equipment & Systems, Electronic Components & Devices

TVS Array provides industrial communications circuit protection.

December 22, 2014

Available in bidirectional configuration and designed for local interconnect network (LIN) BUS protection in industrial applications, PESD1LIN protects one power or I/O port and is rated at 200 W peak pulse power per line for 8/20 secondary lightning surge. Asymmetrical line protection is pin 1–2, 15 V and pin 2–1, 24 V. Supplied in molded JEDEC SOD-323 package, device also provides low clamping voltage; and min breakdown voltage at 15 mA is 17.2 V for pin 1–2 and 25.5 V for pin 2–1. Read More

Electronic Components & Devices, Electrical Equipment & Systems

Opto-Isolated Fast Gate Driver IC works with power MOSFETs, IGBTs.

December 19, 2014

Supplied in 8-lead DIP and 8-lead SOIC package options, IX3180 serves applications requiring isolated drivers for fast switching power MOSFETs and IGBTs. Optocoupler input consists of LED optically coupled to IC containing photodiode and push-pull power output, and output is capable of providing 2.5 A peak drive current. Specified from -40 to +100°C, product has 10–20 V supply range, 100 nS typ propagation delay, and 20 nS typ pulse width distortion. UVLO with hysteresis is also included. Read More

Electrical Equipment & Systems

Programmable LED Driver targets downlight luminaires.

December 19, 2014

Accepting 120–277 Vac universal input, 39 W Model LED39WPR provides selectable output current from 190–700 mA by plugging in appropriate register. No computer workstation or software tools are required for programming. Unit includes 0–10 V dimming and offers flicker-free output. Housed in metal case, constant current driver delivers optimal thermal performance in dry or damp locations. Thermal sensor can be added to roll back output under hot conditions. Read More

Electrical Equipment & Systems

Automatic Transfer Switches offer silent surge protection.

December 19, 2014

Respectively featuring DC coil that eliminates buzzing during operation and standard AC coil, PD52DCS and PD52ACS can protect electronics from damaging power surges, open neutral, and reverse polarity. Both switches incorporate over voltage surge protection of 3,300 J at 103,000 A. While 2 green LEDs indicate generator power or AC power availability, 2 separate red LEDs display need for service regarding shore power section to indicate destructive power surge. Read More

Electrical Equipment & Systems, Test & Measuring Instruments

Continuously Self-Testing GFCI exceeds 2015 UL requirements.

December 19, 2014

Pass & Seymour® Self-Test GFCI tests itself every 3 sec. Upon failure, red light flashes to indicate need for device replacement. SafeLock™ Protection feature automatically disconnects power to receptacle if it detects that critical components are damaged and protection is lost, and automatic shutter system helps prevent improper insertion of foreign objects. Tamper-resistant device is available as 15 A/125 V or 20 A/125 V duplex receptacles, both with dual-direction test and reset buttons. Read More

Electrical Equipment & Systems, Electronic Components & Devices

SMT Transformers suit power-over-HDBaseT applications.

December 19, 2014

Housed in 13.72 x 14.99 x 5.72 mm, 24-pin SMT package, Models HD8004FNL and HD8005FNL provide common mode noise reduction and isolation for power-over-HDBaseT applications. Single-port, RoHS-compliant transformers meet IEEE802.3af standards and operate from 0–70°C. HDBaseT technology enables 5Play™ feature set, which includes ultra HD 4K video, audio, 100BaseT Ethernet, various control signals, and up to 100 W of power on single 328 ft CAT5e/6 Ethernet cable. Read More
