Scientific Vision Systems
Carlsbad, CA 92008-6581
Jun 06, 2005 Available with 42 or 50 in. diagonal screens, HDTV- and PC-compatible Plasma Displays are .3.5 in. thick and can be wall- or ceiling-mounted. Units meet NTSC standards and are suited for endoscopy, radiology, neurology, and microscopy. Radiology and medical teaching professionals find monitors valuable for consultations and precise visual presentations.

One Stop Displays
Winter Park, FL 32789
Jun 03, 2005 Measuring 10.4 in., Model OSDT104SN01 supports both VGA and SVGA resolution with standard computer analog VGA signals. It provides 640 x 480 resolution with full compliance to VESA VS901101 standard, and when operated in 800 x 600 resolution, display conforms to VESA VG900602 guidelines. With included CCFL inverter, Model OSDT104SN01 provides 350:1 contrast ratio, 10 ms rise and 25 ms fall times, 400 nits brightness, and 60° viewing angle in all directions.

One Stop Displays
Winter Park, FL 32789
Jun 03, 2005 With 128 x 64 pixel resolution, Model OSD2401-04 provides 160° viewing angle and 100:1 contrast ratio. It includes same 8-bit parallel interface and display control instructions as many 128 x 64 LCDs that use S6B0107 and S6B0108 driver ICs.

Cree Inc.
Durham, NC 27703
Jun 03, 2005 Based on XThin® blue and green LEDs mounted to thermally conductive substrate, LED Backlight consumes 40 W, as compared with 100 W for other LED backlighting solutions and 45 W for CCFL-based solutions. It offers peak brightness of 300 NITS at thermal equilibrium. Color and brightness uniformity exceeds ANSII 9-point test for LCD displays. With LED backlighting, large computer and TV screens can be designed that do not require active cooling.

Para Light Corp.
Walnut, CA 91789
Jun 02, 2005 Available in 5 colors and as many viewing angles, LLWB-0001 measures 39.37 x 1.18 in., weighs 59.97 oz, and is made up of 36 LEDs with total flux of 180 lumens. Colors include red (620 nm), orange (590 nm), true green (525 nm), pure green (505 nm), and blue (470 nm), while available viewing angles are 10°, 20°, 30°, 60°, and 100°. With input of 15 or 24 Vac, product is suited for architectural, decorative, and cabinet lighting.

Optrex America, Inc.
Plymouth, MI 48170
May 26, 2005 Available in sizes from 6.5–15.0 in. diagonal in VGA, SVGA, and XGA formats, active matrix digital TFT LCDs offer 90°C-wide operating temperature range. Designed for high-information-content display of images from static to full-motion video, units suit variety of non-PC industrial applications including instrumentation, process control systems, medical diagnostics, office equipment, POS and ATM devices, and high-end appliances/white goods.

Pro-Lite, Inc.
Costa Mesa, CA 92626
May 24, 2005 TruColorXP electronic single-line LED sign displays animated or static messages in 16 color arrangements of red, green, and amber. Programmable over LAN, Internet, IR remote, or satellite, users can schedule and convey messages across room or network anytime of year. With flashing strobe or audible beep, attention-grabbing messages can be displayed with XP's pre-programmed special effects. Display has 160° viewing angle and supports graphics.

Bivar, Inc.
Irvine, CA 92618 2593
May 20, 2005 Featuring metal core PCB assembly, LK Series employs Cree® XLamp™ technology and produces 40–60 lumens for backlighting applications. Lead (Pb)-free, aluminum module has integrated lens and measures only 0.800 in. in hexagon pattern. With viewing angle of 100º, 1 W SMT LED module delivers max If rating of 400 mA and offers full spectrum wavelengths from 465–635 nm as well as white to 8,000 K. Operating temperature ranges from -30 to +100ºC.

PresenterNet
Carlsbad, CA 92008
May 19, 2005 Showrooms provides publicly accessible online areas where companies can display PowerPoint or interactive presentations for review by invited guests or casual visitors. Application also enables companies to create linkages from their Web sites. Viewers independently advance through presentation and can enter onscreen responses to selected interactive slides; resulting responses are captured in database for further processing.

Gateway
Irvine, CA 92618
May 16, 2005 Offered in 15 (FPD1560), 17 (FPD1760), and 19 in. (FPD1960) models, VESA mountable LCDs incorporate EzMenu™ on-screen display technology and support for selectable analog as well as digital DVI-D inputs. Design incorporates clip mechanism for cable routing, attachable/removable base, and optional Ergotron New-Flex LCD Stand with 6 degrees of adjustability. Operating at 40 W, LCDs offer resolutions from 1,024 x 768 and contrast ratios of 400:1 or 450:1.

Rockwell Automation
Milwaukee, WI 53204
May 16, 2005 Visible from up to 25 ft away, panel-mount InView P22R includes firmware with independent line control that lets different information appear on display's 2 message lines simultaneously. Messages can be programmed for each line, allowing multiple employee groups to view pertinent data. Support for alphanumeric variables facilitates scanning and reading of bar codes. Communication options enable unit to connect to legacy, serial, and Ethernet TCP/IP networks.

CI Displays
Holbrook, NY 11741
May 11, 2005 Sunlight-readable LCD displays are offered with passive backlight option, as transflective displays that reflect ambient light out, and as hybrid solution comprised of transflective with passive enhancements. Passive enhancements include optical management films, polarizers, diffusers, and various coatings, all combined to address PCB space, power-consumption, and thermal-management issues. Ruggedized displays are custom designed to meet application requirements.

RGB Spectrum
Alameda, CA 94501
May 05, 2005 Suited for mission critical operations, MediaWall™ 2000 accepts up to 6 graphic and 6 video inputs and displays them simultaneously on up to 4 screens. It supports inputs up to 1920 x 1200 and HDTV with full resolution and real-time performance without dropped frames. Packaged in 2U steel rack enclosure, plug-and-play unit features secure, embedded OS; network-independent operation; and remote, Web browser-accessible control interface.

RGB Spectrum
Alameda, CA 94501
May 05, 2005 Suited for mobile and harsh environments, custom LCDs provide real-time performance and come in 20–55 in. screen sizes with up to 1920 x 1200 pixel resolution. They support Hi-Res RGB, HDTV 1080i/720p, S-Video, component, and composite video, and optional DVI inputs and are offered with resistive, capacitive, surface wave, or IR touch screen integration. Features include web-based control, smooth zoom/pans, and dynamic window sizing and positioning.

NEC Electronics
Santa Clara, CA 95050
May 05, 2005 Models NL160120AC27-05 and NL160120AM27-06/06A are 21.3 in. ultra-extended graphic array (UXGA), amorphous silicon TFT LCDs that utilize SA-SFT technology to offer 170° viewing angle and contrast ratio greater than 10:1. Color model NL160120-AC27-05 features direct, back-light system with 450 cd/m² brightness, while monochrome models NL160120-AM27-06/06A feature 1800 cd/m² brightness. Both incorporate switchable 10-bit internal LUT for customizable gray-scale setting.

NEC Electronics
Santa Clara, CA 95050
May 05, 2005 Touch panel-equipped NL2432HC17-01B provides 2.7 in. quarter video graphic array (QVGA), amorphous silicon TFT LCD with 180 cd/m² brightness, 400:1 contrast ratio, and 25 ms response time. Color display features low power consumption of 220 mW, making it suited for use in GPS-enabled portable terminals as well as smart phones that combine cellular phone and PDA functions.

NEC Electronics
Santa Clara, CA 95050
May 05, 2005 Designed for environments subject to natural outdoor light, 5.5 in. NL3224BC35-22 facilitates viewing of text and graphics with 750 cd/m² luminance, low screen reflectivity, and 500:1 contrast ratio. Quarter video graphics array (QVGA), amorphous silicon TFT LCD utilizes Super-Transmissive Natural Light TFT (ST-NLT) technology. Able to operate in temperatures from -10 to +70°C, product consumes 3.75 W of power.

NEC Electronics
Santa Clara, CA 95050
May 05, 2005 Amorphous silicon SVGA NL8060BC26-27 TFT LCD features 400 cd/m² brightness and 700:1 contrast ratio. Utilizing SA-SFT technology, 10.4-inch display provides viewing angle of 170°. Operating temperature range is -10 to +70°C. With compact design weighing 205 g, 6.5 in. VGA NL6448BC20-18D features 600:1 contrast ratio and 160° horizontal and 140° vertical viewing angles. It consumes 4.4 W of power.

Syntax Groups
City Of Industries, CA 91789
Apr 22, 2005 With black bezel design, Olevia™ LT42HVi incorporates 42 in. widescreen, Super-IPS, LCD panel with 16:9 aspect ratio, 1366 x 768 native resolution, and 1200:1 dynamic contrast ratio. It integrates iDEA digital video processing technology, has HD built-in with de-interlacing up to 1080i, and outputs 800 nit brightness. Along with 178° x 178° wide viewing angle, unit offers choice of horizontal- or vertical-mounted, 25 W surround sound, detachable speakers.

Draper, Inc.
Spiceland, IN 47385 0425
Apr 21, 2005 Available in NTSC, HDTV, and widescreen formats with various viewing surfaces, Salara features extruded elliptical case and unobtrusive, motorized screen. Plug-and-play functionality facilitates installation, requiring user to hang screen and plug it in to standard ac outlet via included 10 ft power cord. Screen can be controlled by wireless wall switch or remote control.
