Littelfuse, Inc.    Des Plaines, IL 60016
Oct 31, 2008 Available in DO-214 or QFN SMT package, PLED® 6 Series provides switching electronic shunt path when single LED in LED array fails as open circuit. This ensures entire array of LEDs will continue to function, even if one LED in array does not. In addition to built-in surge immunity, protector has 4-layered thyristor structure that automatically resets if LED heals itself or is replaced. Featuring current range of 300 mA to 1.0 A, RoHS compliant unit has on-state voltage of 1.5 V.

Densitron Corp.    Santa Fe Springs, CA 90670
Oct 29, 2008 Utilizing ITO metal film technology, DTS413 series features Projected Capacitive (PCT) sensor component behind glass front cover lens for protection against physical, mechanical, and chemical abuse. Light transmission up to 90% promotes readability, and no recalibration is required since there is no drift. Able to work with gloved or ungloved finger, sensors require activation force approaching 0 g on glass cover lens. Standard sizes include 3.2, 3.5, 4.3, and 5.7 in.

Apple Computer, Inc.    Cupertino, CA 95014-2084
Oct 24, 2008 Designed for MacBook® family, LED Cinema Display incorporates iSight® video camera, mic, and speakers into its aluminum and glass enclosure. Glossy, widescreen display offers 1,920 x 1,200 pixel resolution, and notebook/peripheral connectivity is fostered via integrated MagSafe® charger, 3 USB 2.0 ports, and Mini DisplayPort. Suitable for video conferencing, display meets Energy Star 4.0 requirements and achieves EPEAT Gold status.

Datalux Corp.    Winchester, VA 22602
Oct 22, 2008 Featuring die cast aluminum enclosure, XGA resolution, and locking power connector, 12.1 in. XG12 Series offers choice of serial or USB resistive touch screen. Model XG12 features 380 cd/m² display, while daylight-viewable Model XG12i has 1,000 cd/m² display. Designed to minimum IP54 rating, monitors prevent penetration of dust or other contaminants. Units accept input voltage from 8-18 V and provide power conditioning to allow use of 12 Vdc vehicular power.

AmbientNAV    Lynnwood, WA 98036
Oct 22, 2008 With electronic components isolated in separate compartment for protection from corrosive water, humidity, and sea air, Alpha Sunlight Display's LED-backlighting offers brightness level of 1,200-0.5 nits. Unit comes in 15 and 17 in. sizes, while on-screen display and user interface help improve setup and operation with third-party marine electronics products. Utilizing SeaEye technology, monitor is suited for use in boats, yachts and ships.

Electronic Display Applications, Inc.    Southampton, PA 18966
Oct 21, 2008 Designed for film production, movie production, and mobile broadcast, 2.4 GHz StarGate SL-1550-TXX Transmitters include digital controls and display of frequency and power setting, as well as user-programmable channel frequencies. FCC-approved units are housed in extruded aluminum case with built-in ¼-20 camera mount. Featuring 10-40 V power input range, wireless transmitters have BNC video input, RCA audio input, and locking power connectors.

Siemens Energy & Automation, Inc.    Alpharetta, GA 30005
Oct 17, 2008 Suited for migrating basic hardwired control design to programmable controller, LOGO! TD consists of backlit LCD with 128 x 64 pixel resolution capable of displaying 4 lines of text with up to 12 characters per line. Bar graph can be configured to represent any numeric value, and text ticker allows up to 24-character text message to scroll horizontally across screen. There are 6 buttons for screen navigation/data entry and 4 configurable user function buttons.

Arista Corp.    Fremont, CA 94538
Oct 15, 2008 Suited for high demand control environments, ARP 1700 Series combines Arista ADM 1500 Series industrial monitors with industrial BoxPC computer series to form modular panel computing systems. Units are available with BoxPC 108A, which includes 1.5 GHz VIA C7 with 1 PCI expansion slot; BoxPC 108K, which offers 3.0 GHz P4 with 1 PCI expansion slot; BoxPC 304A providing 1.5 GHz VIA C7 with 3 PCI expansion slots; or BoxPC 304K offering 3.0 GHz P4 with 3 PCI expansion slots.

LaCie USA    Hillsboro, OR 97124
Oct 13, 2008 Available in 20, 24, and 30 in. models, LaCie 700 Series offers close match between captured, displayed, and printed colors. Units include blue eye pro Proof Edition calibration software, which allows user to calibrate and profile displays, verify profile accuracy, and maintain display uniformity. With ultra-wide gamuts up to 123% of Adobe RGB, need for gamut mapping is minimized. ColorKeeper technology constantly analyzes brightness and chromaticity of backlight, and adjusts it in real-time.

Viewsonic Corp.    Walnut, CA 91789
Oct 13, 2008 In addition to offering respective brightness ratings of 2,300, 2,700, and 3,200 lumens, PJD6220/PJD6230/PJD6240 satisfy large-screen requirements of enterprise users with 1,024 x 768 native resolution and 2,000:1 contrast ratio. Built-in RJ-45 jack enables network connectivity as well as remote diagnosis/management support. Additional connectivity is fostered via RGB, composite, and S-Video input capabilities, and closed captioning function accommodates needs of hearing impaired.

Beijer Electronics, Inc.    Schaumburg, IL 60173
Oct 03, 2008 Featuring brightness of 550 Cd/m², Exter Sun-Readable Display combines standard display, enhancement film applied on internal screen to optimize brightness and contrast, and polarizing film applied on both sides of touch screen to minimize reflection. Anti-reflective coated protection glass minimizes mirror image and maximizes transmittance, while anti-glare coated protection glass scatters light directed on surface and softens image of direct light sources.

Chassis Plans Inc.    San Diego, CA 92123
Oct 02, 2008 Featuring anti-glare hard coating to minimize reflections, CPPM-9U24 Series provides 400 nit brightness, 700:1 contrast, 178° viewing angle, and 16.7 million colors. Unit offers fixed Mount-On-Rack(TM) technology for fixed installation and swivel extension mount that allows display to be pulled out from rack and pivoted left or right up to 90° or up and down. Video input connections include aRGB, DVI-D, NTSC, Pal S-Video, and Composite Video with optional HD/SD-DDI.

Densitron Corp.    Santa Fe Springs, CA 90670
Sep 30, 2008 Measuring 85 x 55 mm with 2.9 in. diagonal active area, Negative Mode LCDs with Tri Color LED Backlights deliver touch capability in form factor of many handheld and rack size applications. Units offer optimal cell gap control making them suited for audio, instrumentation, medical equipment, and industrial indoor meters. LCDs are also available in single colors with and without touchscreen.

Cayin Technology Co., Ltd    Taipei   Taiwan
Sep 29, 2008 Used in public display networks, SMP-WEBPLUS-T and SMP-WEBPLUS (LB-500) support HTML, Flash, JPG, HD video, and streaming video playback in landscape and portrait presentations. Designed to meet demands of interactive digital signage, SMP-WEBPLUS-T supports HID-compliant touch panel devices, while SMP-WEBPLUS (LB-500) features DVI support to maximize visual quality. Players can be deployed as networked standalone solutions and controlled through Internet or in server-client structure.

Sanyo E & E Corp.    San Diego, CA 92173
Sep 29, 2008 Along with 5:5 pull down for frame-accurate delivery of all source material, PLV-Z3000 Full HD 1080p LCD Projector incorporates TopazReal HD 3D color management system featuring 14-bit digital processing and 216 billion color reproduction. Pull-down mode also features Dynamic Predictive Frame Interpolation Technology, which utilizes speeds of 120 Hz to increase smoothness in video reproduction. Rated at 1,200 ANSI lumens, product can project 100 in. diagonal image from 10-20 ft away.

Amplicon Liveline Ltd    Brighton East Susse BN2 4AW  United Kingdom
Sep 29, 2008 With operating temperature of 0-50°C and IP65 rated front panels, Pro-Lite II series LCD monitors suit industrial applications where waterproof and dustproof capabilities are required. They feature 4:3 display aspect ratio, contrast ratios 1,000:1, brightness up to 400 cd/m², viewing angles up to 160°, and 3 mm protective glass. Available in wall, rack, panel, and VESA mount orientations, units are offered with capacitive and resistive touch screen options.

Heidenhain Corp.    Schaumburg, IL 60173-5337
Sep 26, 2008 Able to be integrated into machine data transfer network, ND 200 Series single-axis position displays host multiple inputs, offer flexible configuration, and are suitable for future absolute length gauges. Model ND 280 has monochrome flat screen and standard functions to fulfill measuring tasks, while modular ND 287 has color flat screen and allows up to 4 inputs. Statistical Process Control is also available on ND 287, and both models come with card for gauge hookup.

Toshiba Teli America, Inc.    Irvine, CA 92618
Sep 19, 2008 Housed in sealed chassis, 24 in. widescreen Model T24MSA001-MD connects via DVI-I, DVI-D, composite, Y/C, or RGB video outputs, and supports both NTSC and PAL. Unit complies with variety of video display formats ranging from VGA to WUXGA resolution, and is pole- or wall-mountable using standard VESA brackets. With 800:1 contrast ratio, 500 cd/m² brightness, and 178° viewing angle, monitor is suited for EKGs, EEGs, x-ray, and other dynamic medical images.

TE Connectivity Ltd.    Berwyn, PA 19312
Sep 04, 2008 Combining Acoustic Pulse Recognition (APR) touch technology with seamless screen, Elo TouchSystems 1900L and 2200L LCD monitors with seamless glass surface that provides optimal optical quality and dragging properties. Users can interact with touchscreen using any kind of stylus, from fingertip to edge of credit card. Featuring integrated VGA and DVI video-input ports, touch-interface USB (APR), and serial jacks, units offer zero-drift performance and never require recalibration.

Advantech Automation Corp.    Cincinnati, OH 45240
Sep 03, 2008 Powered by 1.66 GHz Intel® Core(TM) Duo processor with memory expansion for up to 4 GB DDR2 SDRAM, Model POC-S196 features 19 in. LCD touchscreen with 1,300:1 contrast ratio, suited for storage and retrieval of patient information. Unit is certified with IPX1 rating for water resistant enclosure, IP65 rating for dust-tight panel, and medical certifications UL60601-1 and EN60601-1. It is also CE and FCC Class B certified to meet medical safety approval standards.
