Operator Consoles & Stations

Controls & Controllers

HMI Mobile Panels feature 7 or 9 in. widescreen display.

December 3, 2014

Featuring 16 million color widescreen display with 16:9 aspect ratio, Simatic HMI Mobile Panels can present highly complex and detailed images. Second-generation wired panels include illuminated emergency stop button for safe automation and compact connection box that can be mounted directly on cabinet. Operating from 0–45°C, IP65-rated units are dust-tight and resistant to chemical action. They offer combined key and touch operation and are integrated into automation solution via Profinet. Read More

Controls & Controllers, Electronic Components & Devices

P-Cap Touch Controller supports large format sensing sensors.

November 21, 2014

With 32-bit ARM® Cortex® M4 processor that can run at 168 MHz, ZXY110 improves speed, accuracy, and EMI stability of self-service touchscreens. Processor is accompanied by 2 ASIC devices that maximize touch detection performance, even through cover glass exceeding 10 mm thick. While 32-input version covers self-capacitive p-cap (PCT™) touch sensors with up to ~19 in. diagonals, 64-input version suits PCT sensors with 19–46 in. diagonals. Controler updates touch event coordinates in <5 msec. Read More

Controls & Controllers

Control Panels allow safe data exchange over bus system.

October 21, 2014

Intended for swing arm systems, openSAFETY Control Panels require only bus and power connection so they can be placed where needed without cable harnesses. Users can choose different display sizes and ratios, as well as various touch technologies. Number and arrangement of buttons, switches, and E-stop buttons are also configurable. Available in housings rated up to IP65, control panels render hard wiring of E-stop, operating mode, and start buttons obsolete. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Controls & Controllers

Interface Panel facilitates capacitance-voltage measurements.

October 13, 2014

Available for Parametric Curve Tracer configurations that incorporate SourceMeter® Source Measure Units, Model 8020 High Power Interface Panel simplifies high-voltage capacitance-voltage measurements of semiconductor devices. Unit also minimizes cable confusion, prevents connection errors, and ensures safety in power device testing. By allowing test engineers to connect all measurement instruments to it at once, Model 8020 simplifies changing from one measurement type to next. Read More

Computer Hardware & Peripherals, Controls & Controllers

Graphic Touchscreen Keypad features wireless design.

October 13, 2014

Equipped with internal proximity device reader for codeless arming/disarming, Model 9862 is available with optional Z-Wave® modules, which enable users to adjust lights, lock exterior doors, and control heating and cooling system. All system features and functions can be accessed via carousel menu on 5 in. full-color touchscreen. With Favorites feature, customers can combine security and multiple home automation functions, and program multiple devices to respond to single command. Read More

Controls & Controllers, Electrical Equipment & Systems, Display & Presentation Equipment

Large LED Light Panels come in back and diffuse ring variants.

July 29, 2014

For industrial lighting applications requiring edge-lit product definition, Large Light Panel (LLP) Series features 4-edge lighting and clear anodized profile frame. SMART driver provides constant reliable power to LEDs with NPN-PNP strobe trigger compatibility and 0–10 Vdc remote analog intensity. Back lights (LLP) and large diffuse ring lights (LLP-H) can be operated in continuous on or strobe mode. Standard as well as custom sizes from 200 x 200 mm to 1,800 x 1,200 mm are available. Read More

Controls & Controllers, Architectural and Civil Engineering Products

Anti-Slip Flooring Solutions withstand traffic, harsh conditions.

July 29, 2014

Intended for installations in industrial, marine, transportation, and off-shore industries, Grit-Coated Fiber Glass Step Covers and Walkway Panels exceed OSHA and ADA slip resistance recommendations. Construction consists of 0.125 in. thick fire retardant fiberglass (FRP) coated with blend of mineral abrasive epoxy grit. Step covers come in 3, 9, and 11.75 in. depths. While 3 and 9 in. covers have 1 in. nose, 11.75 in. version has 2 in. nose. Several grit-coating options are available. Read More

Retail & Sales Equipment, Controls & Controllers

Touch Panel Control System delivers versatile connectivity.

July 9, 2014

Able to surface mount onto any surface with 2-gang, low-voltage box, QXT-700 Quad Core IP Touch Panel Control System features 1200 x 800 HD display with 2D/3D accelerator and supports connectivity via 2 RS232, 2 IR/Serial, 2 relay, 2 DIO, and 10/100/1Gbps PoE LAN interfaces. Proximity and light sensor, with stereo speakers, are also included. Platform-agnostic Web-server control platform allows tablet integration without any apps or license fees. Read More

Computer Hardware & Peripherals, Controls & Controllers, Plant Furnishings & Accessories

Tabletop Control System turns any room into conference room.

July 3, 2014

Integrating connectivity, cable management, and control in one tabletop package, PoE-enabled FlipTop™ Touch Screen Control System (FT-TSC600) provides hidden solution for accessing cables, connectors, power outlets, and room control. Features include 3-Series® control processor, 5 in. TSW touchscreen, Ethernet and Cresnet® ports, and Rava™ SIP Intercom technology. TSW touch screen, with HD graphics, capacitive display, and edge-to-edge glass, works with Crestron Smart Graphics™. Read More

Computer Hardware & Peripherals, Controls & Controllers

Portable Touchscreen Controller lessens or negates need for Wi-Fi.

July 2, 2014

Supporting voice command recognition, streaming video (H.264 and MJPEG), and Web browsing, TST-902 is powered by rechargeable Li-ion battery and features widescreen display, capacitive touchscreen, and edge-to-edge glass. Smart Graphics™ enable gestures navigation, swiping, and kinetic effects, while 4 rear-mounted pushbuttons afford quick access to programmable functions. To reduce or eliminate need for Wi-Fi®, touchscreen functionality is supported via Crestron ER wireless communications. Read More

Controls & Controllers

HD Touch Panel Control features platform-agnostic design.

June 24, 2014

Backed by quad-core processor with PoE-enabled 1 Gbps LAN port, multiple on-board RS232/IR/relays, and DIO, Model QXT-700 HD is suited for conference rooms, classrooms, and hospitality A/V control applications. Fully autonomous touch panel with integrated control system provides 1280 x 800 resolution HD screen and 2D/3D graphic accelerator. MPEG2/H.264 high definition decoder allows for clean video streaming without affecting performance of main processor. Read More

Controls & Controllers, Software

Plant Control Console meets mobile plant operator needs.

June 11, 2014

Built upon Experion Process Knowledge System control platform, Experion® Orion Console offers ergonomic design that reduces operator fatigue as well as displays that simplify control system management and improve situational awareness. Flexible, ultra-high definition display provides clear status assessments of process operations in one glance, and operators can customize displays for context-specific process issues. Alarm management and pan and zoom capabilities are also standard. Read More

Computer Hardware & Peripherals, Controls & Controllers

PCAP Touch Panel features thin, durable construction.

June 6, 2014

Available in sizes up to 4.8 in., Crystal Touch EDGE single-layer, all-glass, projected capacitive (PCAP) touch panel features single FPC and Chip on Flex (COF) assembly. Product is available with or without optically bonded cover glass and is built for maximum optical clarity and multi-touch functionality. Operated via stylus or finger(s), panel has scratch-resistant surface that will not deform with frequent use. Thickness is 1.1 mm (up to 1.5 mm if cover glass is required).
Read More

Controls & Controllers

HMI Panels feature single-surface screen.

April 2, 2014

Housed in rugged aluminum chassis with IP65 rating, Kollmorgen Automation Suite™ features widescreen format and integrated Ethernet, as well as data logging and trending software. Touchscreen HMI panels use 16:9 format and are programmed with Kollmorgen Visualization Builder™ graphical tool. In addition to packaging, food processing, and printing machinery, HMIs are suitable for material forming, laboratory automation, and test and measurement applications. Read More

Computer Hardware & Peripherals, Controls & Controllers, Display & Presentation Equipment

Flat Panel Touchscreen PC has waterproof IP65 design, Atom CPU.

March 13, 2014

Powered by 1.6 GHz Intel® Atom™ N2600 dual core processor and NM10 express chipset, PC9150 comes standard with onboard DDR3 SO-DIMM socket with 2 GB max system memory and 2.5 in. SATA HDD. Multiple I/O options – 2 Ethernet, 2 COM, 2 USB, half size mini PCIe slot, audio (Line-out), optional HDMI – meet diverse connectivity requirements. Industrial panel PC also features 15 in. flat panel LCD that offers 1024 x 768 resolution and optional resistive or capacitive type touchscreen. Read More

Safety & Security Equipment, Health, Medical and Dental Supplies & Equipment, Controls & Controllers, Communication Systems & Equipment

Intercom, Nurse Call Alert Systems increase healthcare efficiency.

March 10, 2014

Pro-Alert™ 480 Area of Rescue System helps meet code requirements and satisfy communication needs of U.S. healthcare facilities. Fully supervised solution is always immediately alerted by central station of any system faults/issues to ensure system is kept fully operational. Available intercom system offers optional interface to allow offsite calls. Providing instant communication between occupants and staff, Pro-Alert 610 Nurse Call system lets facilities customize alerts and displays. Read More

Test & Measuring Instruments, Controls & Controllers, Communication Systems & Equipment, Green & Clean

Industrial Control Panel monitors solar systems.

March 4, 2014

Providing data acquisition for commercial and utility-scale solar PV installations, LGate 360 combines revenue-grade power meter and Modbus-enabled datalogger pre-wired in outdoor-rated metal enclosure. Unit includes integrated RS-485 surge suppression and power supply that accommodates all 3-phase configurations. Together with web-based SolarOS™ monitoring platform, LGate 360 enables plants to gather data for troubleshooting, asset optimization, and performance guarantee/billing functions. Read More

Computer Hardware & Peripherals, Controls & Controllers, Display & Presentation Equipment

Industrial PC has touchscreen interface, 21.5 in. HD display.

February 21, 2014

Accelerating workflow operations via visualization of production processes, ruggedized C21 offers several interfaces for connection to peripherals as well as slots for plug-in cards or additional ports for PCI, PCIe, and mini-PCIe. Secured USB port on front for uses such as transferring software updates; NSetup tool lets administrators dictate who has authorized access. Connectivity is also fostered by 2 Ethernet ports, integrated WLAN antennas and Bluetooth, and mobile wireless capability. Read More

Computer Hardware & Peripherals, Controls & Controllers, Green & Clean, Architectural and Civil Engineering Products

HMI Panels enhance intelligent building automation systems.

February 14, 2014

Comprised of Wide Temperature Touch Panel PCs, HMI Operator Interface Terminals, HMI Compact Thin Clients, and HMI PoE Touch Panel PCs, standard and custom HMI panels deliver scalable and flexible solutions for HMI integration and visualization of automation systems for smart buildings. Building control and monitoring solutions, simplifying operator interaction and engagement, help commercial and industrial facility owners and operators manage their BMS, EMS, and BAS more effectively. Read More

HVAC, Computer Hardware & Peripherals, Controls & Controllers

Touchscreen Controller monitors dust collection equipment.

January 29, 2014

Used with Farr Gold Series® dust collectors, or other types of collectors if integrated with motor starter or VFD package, Touchscreen Controller features built-in differential pressure sensor that monitors primary filter pressure drop. Four analog inputs monitor secondary filter as well as other devices, while 6 digital inputs monitor hopper level, smoke detection, remote cleaning and other functions. To signal faults from any input or from internal device faults, unit provides 4 relay outputs. Read More
