Batching & Mixing Controls & Controllers

Controls & Controllers

Batch Processing Controller automates dosing and dispensing.

August 22, 2014

By automating batch-out processing, Model 1020-B™ eliminates need for operator to visually monitor dosing and dispensing processes. Controller monitors single channel using loop-powered, programmable output of 4-20 mA. Overall system accuracy is 0.1–0.25% FS capacity. Recommended for use with drum, tank, platform, and stainless steel platform scale bases, controller operates using 6-button panel with indicator lights and provides accurate readings to 5 digits on 2-line, backlit, alphanumeric LCD. Read More

Test & Measuring Instruments, Controls & Controllers, Electrical Equipment & Systems, Sensors, Monitors & Transducers, Optics & Photonics

Transmitter supports batch controller capabilities.

April 2, 2013

Signet 9900 Transmitter (Generation II) supports multiple parameters, including flow, pH/ORP, conductivity/resistivity, salinity, temperature, pressure, level, and 4–20 mA signals, and batch systems. In addition to saving up to 10 batch sizes, capabilities include customizable batch names, entry of K-factors for each batch, confirmation for preventing accidental batch starts, manual batch feature for topping off, override batch size function, and batch count indicator. Read More

Controls & Controllers

Batch Controller minimizes waste while improving quality.

December 20, 2012

Eliminating rework and maximizing efficiency, IND780batch is intended to serve small- to mid-sized batching operations. Rugged unit can execute recipes that utilize up to 4 scales at once, and each controller can store up to 1,000 recipes with up to 999 hand-added materials in each. To eliminate errors, interface guides operators through each recipe. Also, automatic batch recordkeeping throughout production process facilitates tracking and tracing. Read More

Controls & Controllers

Batch Controller ensures exact dispensing.

May 17, 2011

Designed to provide precise sensing and dispensing of liquids into container or process vessel, Model RA33 monitors flow, temperature, and density; controls valves and pumps; and dispenses exact amount requested by programmed recipe. Unit can work with single valve and pump in automatic or manual mode, or with 2 valves for 2-stage batching. Error diagnostics detect leakage, fill deviation, and no-flow conditions. Suited for wall, panel, or DIN rail mounting, controller operates from -4 to 140°F. Read More

Controls & Controllers

Automatic Sampler Controller consolidates plant operations.

June 9, 2010

Consolidating 50+ controller designs, Model SBC can control every automatic sampler in Sentry's product line. Stand-alone sampler controller offers intuitive operator interface as well as local and remote operating modes. This dedicated logic control system, designed for use with Sentry samplers in general-purpose environment, installs with few connections and offer Quick Start screen to guide operator through setup. Customization is possible via various sampling options. Read More

Controls & Controllers

Batch Controller uses multifunctional system architecture.

July 29, 2004

Nova-Flow Batch Controller provides local display and transmits flow data for control capability. Plug-n-flow computer also provides for single and dual stage batching processes for use on liquids and gases requiring temperature, pressure, and compressibility compensation. Unit features LED backlit display, capable of showing 4 parameters simultaneously, and 8 expansion slots that accommodate electronic modules for I/O and communications options. Read More

Controls & Controllers, Sensors, Monitors & Transducers

Flow Monitor/Batch Controllers work with flow meters.

January 30, 2004

Model HPD-FEM provides flow rate, total, or ratios. Outputs can be programmed to perform limit, warning, or alarm functions. Model HPD-FEMA has 4-20 mA output to track data remotely, while Model HPD FEM A2 has 2 channels to monitor dual flows. Model HPD-BAC features 9 programmable batch amounts, batch counter and totalizer, and batch error compensator. Two relays for solenoid VA control are provided, as is 4-20 mA batch fill indicator. Model HPD-BAC-E is 110 Vac-powered with NEMA 12/13 enclosure. Read More

Controls & Controllers

Formula Batch Controller does not require use of PLC.

July 21, 2002

Model F805-F runs multiple formulas with multiple ingredients. Each of 200 stored formulas can have 30-step sequences to control 5 ingredient supply bins. Two-speed filling with jog feature controls each ingredient. Ingredients and formulas are identified alpha-numerically. Data acquisition features A/D conversion with rolling average calculations for 200 weighing results per second. Color touch screen display or RS-232 port provides for set-up and operation. Read More

Test & Measuring Instruments, Controls & Controllers

Flow Instruments can work without external power.

May 29, 2002

Compact Access® Series includes BA200 rate totalizer, BA212 heat calculator, and intrinsically safe BA214 batch controller. Suitable for remote locations, models include battery, loop, and dc powered versions. All models interface with turbine, positive-displacement, and paddlewheel flowmeters, making them suitable for pipeline and irrigation applications. Each has large LCD, front panel controls, and menu-driven programming for quick and easy setup. Read More

Material Handling & Storage, Controls & Controllers

Batching Controller has fieldbus interface capabilities.

May 6, 2002

AD-4402 can be used as stand-alone batching unit or part of multi-function system. RS-485 interface allows up to 32 controllers to be networked to PLC, PC, or equipment supporting Modbus. Eleven outputs and 11 inputs can be set up using one of 50 pre-programmed function codes. Controller has internal resolution of 1,000,000 counts, maximum display resolution of 16,000 counts, and A/D conversion rate of 100 times per second. Read More

Controls & Controllers

Batch Controller works with pulse-producing flow meters.

May 1, 2002

Ecobatch IP66 operates with PD, turbine, mass, and magnetic style flow meters. Ac/dc-powered controller can be field or panel mounted. Two control relays provide staged control of batch, PIN protection, missing pulse detection, multi-controller networking, logging of accumulative total, and totalization of number of batches. Scrolling prompts display operation, alarm, and error conditions. Programming prompts guide user through set-up routine directly through front panel. Read More

Controls & Controllers

Batch Controller handles liquids and gases.

April 10, 2002

Nova-Flow provides local display, transmits flow data for control, and provides for both single and dual stage batching processes on liquids and gases requiring temperature, pressure, and compressibility compensation. Batching methods available include manual, auto, auto-continue and remote batching using standard Modbus protocol. Manual, timed, compensated, and auto prewarn methods are available for dual stage batching processes. Read More

Test & Measuring Instruments, Controls & Controllers

Mass Flow Meters offer integral batch control.

February 5, 2002

FlexCOR(TM) CMF Series features ASIC design and processes multi-parameter information including mass flow, volumetric flow, density, temperature and fraction-flow. Series comes in 5 flow sizes ranging from 1/16 to 2 in. Measuring range can be as low as 0.1 lbs/min with CMF-A to over 1900 lbs/min with CMF-F. Designed with continuous, seamless tube, CMF units withstand pressure loads up to 6760 psig. All sensors are intrinsically safe to Ex ia IIC. Read More

Controls & Controllers

Weigh Batch Controller has up to 100 groups of set points.

January 28, 2002

F805 Weigh Batch Controller with 100 gate control outputs is offered with full color touch screen displays to allow setup, calibration, and clear messaging. Displays have adjustable contrast and backlight settings. F805 provides speeds of 200 updates per second and selectable resolution to 40,000. Power supply can excite/power up to four 350 ohm load cells (or eight 1000 ohm). There are two (5.0 and 10.0 V) selectable excitation voltages. Read More
