Servo Drives target OEM market.

February 23, 2015

Designed to drive servomotors rated up to 1,000 W, Luminary Series Servo Drives are suited for applications such as x-y tables, actuators, roll feeders, and any requirement where true position, velocity, and torque control are desired. Units can operate as single-axis analog drives or can be connected to Luminary Series Motion Controller for full multi-axis configurability. Read More

Electronic Components & Devices, Controls & Controllers

Motor Control Pre-Driver IC enables quiet low-power fan operation.

February 18, 2015

Accommodating 3.5–30 V input, TC78B006 series comprises single-phase brushless DC (BLDC) motor control pre-driver ICs available in 5.5 x 6.4 mm SSOP16 or 3 x 3 mm QFN16 package. PWM voltage and pseudo sine-wave current driving functions promote efficient and quiet cooling fan operation in data servers and home appliances, while automatic standby function reduces power consumption when fan is not in use. Additionally, IC can drive 2 external high-side Pch and 2 low-side Nch MOSFETs. Read More

Mechanical Power Transmission, Controls & Controllers, Green & Clean

Compact AC Drive conserves energy in elevator applications.

February 16, 2015

Suited for new elevator drive installations and modernization projects, Quattro® AC Cube is all-in-one, regenerative, clean power elevator drive that maintains minimal harmonics and meets building power requirements. All drive- and regeneration-related power control components, including line and motor contactors, harmonic filters, and fusing, are integrated into space-constrained package. Voltage boost feature supplies additional voltage for operation. Read More

Electronic Components & Devices, Computer Hardware & Peripherals, Controls & Controllers

Microcontrollers suit home appliances and factory automation.

February 4, 2015

Based on ARM® Cortex®-M4F processor, Models TMPM470FDFG and TMPM475FDFG can operate at up to 120 MHz. Both MCUs incorporate 2 modules, each containing programmable motor driver, 12-bit AD converter, and Vector Engine technology, which consists of hardware-based vector control processor for motor control applications. In addition, TMPM475FDFG incorporates CAN controller. Housed in 14 x 14 mm LQFP100 package with 0.5 mm pitch, both devices operate at 4.5–5.5 V. Read More

Controls & Controllers

Motor/Motion Controller offers high resolution, smooth operation.

January 16, 2015

Featuring full motion controller and GeckoMotion software compatibility, UL-Recognized GM215 runs up to 4 axes of coordinated motion off of onboard flash memory. Unit operates step and direction input step motor drive and offers 10 microstep native resolution. Each full step angle is divided into 10 equally spaced microsteps. Motor morphs from sine-cosine motor currents at low speeds (from 240 rpm) to square-wave currents at high speeds (ending at 360 rpm). Read More

Controls & Controllers

AC Motor Speed Control drives motors rated up to 1 hp.

December 31, 2014

Housed in NEMA-4X/IP65 aluminum die-cast enclosure, Model 2999 Pacesetter™ is suited for stand-alone AC gearmotor applications that require variable speed, controlled acceleration, and reversing. Unit drives 230 Vac, 50/60 Hz, inverter-duty 3-phase gearmotors and motors rated up to 1 hp/746 W. Allowing for up to 200% starting torque, control ensures startup of high frictional loads. Slip compensation with static auto-tune and boost circuitry provides load regulation over wide speed range. Read More

Controls & Controllers

12 V Motor Drivers eliminate stepper and brushed DC motor tuning.

December 16, 2014

Respectively available in 24-pin, 4 x 4 mm QFN package and 16-pin, 5 x 6.4 mm HTSSOP, DRV8846 and DRV8848 reduce spin-up time to seconds. DRV8846 incorporates adaptive current control technology and 1/32 micro-stepping indexer to automatically tune motor performance for precise, smooth, and quiet motion. DRV8848 can operate without current sense resistors and simplifies designs by using PWM control interface and minimal external components. Both models are fully fault protected. Read More

Controls & Controllers, Mechanical Power Transmission

Digital Motor Drive features sensorless, brushless design.

November 18, 2014

Designed to drive delta- or wye-connected brushless motors at up to 150,000 rpm, DPFlex™ II provides sensorless control, minimizing wiring complexity. Unit outputs up to 48 V and 30 A peak with 1,200 W of power to drive wide range of motors. Offering 20:1 speed control range, drive features full protection against most faults, including thermal overload. Patented technology enables detection of motor rotor position at standstill for reliable starting without rotor movement and while under load. Read More

Controls & Controllers, Mechanical Power Transmission

Variable Speed Pump Drive provides high dynamics.

November 11, 2014

Covering wide performance range up to 120 kW, Sytronix SVP 7010 offers comprehensive selection of hydraulic-specific functions and can be used in both open and closed loop hydraulic circuits. Control can eliminate pressure overshoot and position linear axes to high degree of accuracy, without instability. Algorithms allow for reduction of pressure ripple inherent in certain pump designs. To save energy, drive reduces pump speed during idle and partial load operation. Read More

Controls & Controllers, Electronic Components & Devices

Power Hybrid IC drives motors in appliance applications.

October 28, 2014

As 10 A, 600 V power hybrid IC with open emitter pins, IRAM256-1067A is suited for use in air conditioners and washing machines. This compact AC motor driver, supplied in fully isolated and thermally enhanced package to simplify design, combines low VCE(on) Trench IGBT technology and 3-phase high voltage, high speed driver (3.3 V compatible). Features include built-in temperature monitor, over-current protection, short-circuit rated IGBTs, and integrated UVLO function. Read More

Controls & Controllers, Mechanical Power Transmission

High-Speed Drives target vertical lathes.

October 24, 2014

Using planetary reducers, high-speed versions of DRP, KRP, and KRPX Drives simplify design of mechanical transmission systems of both large rotary tables used on vertical lathes over 2,000 m and smaller tables used on milling machines. When meshed with drive gear, reducers on TwinDrive and DualDrive solutions cancel 100% of backlash. Reducers have been hardened to allow continuous operating cycles and can achieve rotational speeds up to 28 rpm-1. Read More

Controls & Controllers, Electronic Components & Devices

BLDC Motor Driver reduces fan/small pump application noise.

October 22, 2014

Supplied in 24-pin, 8 x 6 mm HTSSOP, DRV10983 enables users to tune motors for reliable start-up and optimal performance using configurable, 3 A driver with integrated control logic. This 24 V brushless DC (BLDC) motor driver features 180° pure sinusoidal, sensorless operation and start-up algorithms that minimize operational noise and eliminate startup clicks/pops. Along with code-free configurability, features include integrated on-chip protections, power FETs, and sensorless control logic. Read More

Fluid & Gas Flow Equipment, Controls & Controllers

Electric Submersible Pumps utilize variable speed drive.

October 14, 2014

Available for electric submersible pumps, Vector Plus™ VSD surface control system allows operator to gradually increase motor speed and remotely adjust pump speed from surface with optimized intelligent control capabilities. Drive can be used with ESP applications ranging from 100–1,000 hp and is designed to work with all worldwide power systems rated 380–480 V, 50/60 Hz. Featuring NEMA 4 outdoor rating, enclosure is sealed against dust, dirt, and moisture. Read More

Controls & Controllers

AC Drive offers multi-pump control solution.

October 8, 2014

Covering power range of 0.75–250 hp and voltage range of 230–500 V, VACON® 100 FLOW AC Drive offers 3 multi-pump control solutions: single drive multi-pump, multi-drive multi-master, and multi-drive multi-follower. Unit offers control of flow and pressure for up to 8 pumps or fan without need for external controller—communication between drives is provided by integrated RS-485. Available with UL Type 1 or UL Type 12 approved enclosures, drive is equipped with built-in Ethernet as standard. Read More

Controls & Controllers, Electronic Components & Devices

Servo Drive combines compact size and high power.

October 3, 2014

Gold Twitter features power density that delivers up to 4,000 qualitative W in package size of 18 g and volume of <13 cm³ with up to 99% efficiency. EMI is negligible, enabled via integrated FASST (Fast and Soft Switching) Technology, and voltage/current ratings range up to 50 A/100 V. Along with advanced servo capability and CANopen networking, miniature drive features internal breaking shunt resistor, multi extended I/O interface, and optional support for EtherCAT fieldbus networking. Read More

Controls & Controllers

AC Digital Drive offers intuitive operation.

October 1, 2014

Supplied in NEMA 1 enclosure, KBWK-23D operates with 115 or 230 Vac line and is rated for 3-phase induction motors to ½ hp. Common Sense Programming (CSP™) organizes parameters into understandable, intuitive groups, while UL-approved proprietary current limit software provides motor overload protection, prevents motor burnout, and eliminates nuisance tripping. Digital display features LED status indicators, and drive helps conserve energy by only using power required by application. Read More

Controls & Controllers, Mechanical Power Transmission

Stepper Motor/Driver Packages achieve optimal application results.

September 26, 2014

CVK Series includes 24 Vdc input driver combined with 2 stepper types featuring 1.8°, 0.72°, and 0.36° step angles. While 1.8° motor type offers highest torque in low-speed range, 0.72° motor type maximizes mid- to upper-speed range, and 0.36° motor type provides optimal positional. Offering 5 frame sizes from 0.79–2.36 in., series has common driver size, mounting, and wiring to facilitate testing and standardization. Fully digital standard full time microstepping driver minimizes vibration. Read More

Controls & Controllers, Mechanical Power Transmission

Motor Protection Platform incorporates control and management.

September 16, 2014

Multilin™ 869 is used for protection, control, and management of medium and large induction and synchronous motors. Along with high-speed protection and control features and tools for accelerated motor configuration and startup, solution also generates motor functioning reports that facilitate identification of potential motor issues and necessary corrective action. Motor failure-mode analysis is also provided via broken rotor bar detection and stator turn-turn fault. Read More

Controls & Controllers, Mechanical Power Transmission

Digital Servo Drives deliver up to 1,000 W of motor power.

September 8, 2014

Panel- or DIN-rail mounted, Series SXD 15 can drive DC brush, DC brushless, or AC brushless motor requiring 1 kW of power. Standard ratings are 12–80 Vdc bus, 15 A continuous, and 30 A peak current. In addition to torque, velocity, and position control modes, drives provide 4 digital inputs, 1 digital output, 2 analog inputs, and 1 analog output. Series SXD 15 communicates via RS232, RS485, or CAN and offers full protection against short circuits, voltage excursions, and temperature extremes. Read More

Controls & Controllers, Mechanical Power Transmission, Green & Clean

Decentralized AC Drive targets outdoor installations.

September 8, 2014

Supporting both induction and permanent magnet motors up to 50 hp, VACON® 100 X features UL Type 4X die cast metal enclosure, breathable pressure equalizer vent to protect gasket seals, and heat sink cooling system that is not dependent on motor airflow. Drive is rated for 0–100% relative humidity, 3 g vibration, 25 g shock for 6 ms, and operating temperatures from 10–40°C. For safety, drive features integrated Safe Torque Off mode, which provides immediate removal of power to motor. Read More
