New Controls & Controllers Products

Central Control Module handles heavy-equipment functions.

Model CL-100 HED Central Control Module, for CANLink(TM) family of control components, is placed along CAN systems for trafficking communications to areas that must be isolated. It includes 32-bit microprocessor and RS232 connection. Incorporated J1708 port enables CL-100 to talk to other parts of machinery that operate on that protocol. Field-rugged, CL-100 is not affected by EMI/RFI, extreme...

Monitoring/Control Systems detect temperature and humidity.

Model LTM-8201C and LTM-8203C provide standalone solutions with up to 32 input points connected on 1 to 3 data lines (Number and configuration of points vary per model). They leverage I-WireÃ-® Network technology to provide multi-drop systems that can be configured without programming. Basic systems consist of panel-mount controller with push-button interface and LED display. They offer...

Redundant System provides backup for process automation systems.

ControlWave Hot-Standby Control Redundancy System prevents single point of failure from shutting down system. In event of primary CPU failure, system will automatically switch to Hot Standby backup CPU. All process control and communication functions are automatically switched to backup. Standby CPU is automatically updated via Ethernet link to on-line unit. ControlWave also provides backup of...

Pneumatic Positioner includes onboard electronics.

AccuMaster(TM) linear positioner uses pneumatic closed-loop servo valve, which is electronically controlled, continuous action type with 5/3 directional control. ISO size 2 valve is mounted directly onto cap of positioner. Feedback signals are 0 to Ã-

Automation Streamlines Medical Kit Assembly

Automation technology is key to streamlining medical kit assembly operations. Our eBook delves into the benefits of automation, the industries it serves, and its role in COVID-19 response.

Digital Servo Drive offers true axis synchronization.

Model HNC 100 freely programmable, bus-capable NC control is designed for electromechanical and electrohydraulic drives. User can program sequence via PC using WIN-PED software. Local CAN-bus can be used to link individual drives for general data exchange or for implementing synchronization controls. HNC 100 can communicate with higher level controls via Profibus-DP, INTERBUS-S, and CANopen...

Intelligent Control Units reduce installation costs.

DURADRIVE decentralized drive system offers servo motors and servo drives with IP65 protection and allows decentralized use directly at the machine. Standardized bus systems reduce necessary installation outlay and allow connection to different servo drives while facilitating simpler project planning, more cost-effective installation, and faster commissioning.

I/O Module features IP67 rating and enhanced diagnostics.

FieldLine I/O fixture-mounted I/O module is offered with 8 digital inputs, 8 digital outputs/2 A capacity, or 4 digital inputs/4 digital outputs/2 A capacity. It offers detachable mounting subplate and horizontal/vertical DIN rail mounting. Fieldbus connections support Profibus, Interbus, and DeviceNet networks. Diagnostic capabilities include monitoring of low sensor supply voltage, sensor...

Digital Input Module increases speed in frame grabbers.

Digital Input Module acquires images at resolutions up to 2048 x 1024 pixels from single or dual tap area scan cameras, 8-bits/pixel wide at 60 MHz, or 10-bit/pixel wide at 30 MHz in dual channel mode. LVDS and RS-422 compatible module offers four 256 x 8-bit and one 1024 x 8-bit programmable input lookup tables (LUTs). It is used with Bandit-II RGB (AGP) and Bandit-II MV frame grabbers.

I/O Modules provide control for embedded products.

IndustryPackÃ-® and PMC mezzanine modules are applicable to systems with high I/O density and mixed analog, digital, fieldbus, motion control, and serial requirements. They include 8 analog, 8 digital, 4 communication, and 2 memory modules. Model TVME200, 6U VMEbus carrier, holds up to 4 (single-size) or 2 (double-size) IndustryPack modules. It offers rotary switches, selection of IRQ levels,...

Automation Platform can control up to 96 axes of motion.

Q-Series Automation Platform employs multi-CPU architecture that allows designers to select and scale CPU types. Motion control is addressed by adding one Motion CPU, which is linked to company's servos via SSCNET motion control network. Motion control instructions are processed at rates to 888 Ã-µS. Development tools include programming environment in Sequential Function Chart format. Cam...
