New Controls & Controllers Products

Positioning Controller provides quick machine changeover.

Model IB IL POS 200 Multi-Axis Positioning Controller Module offers intermediate solution between manual changeover and total servo control. It allows user to do automatic machine set up using existing controls. Communication of parameters and motion commands is done over device level network. Up to 10 axes of motion can be controlled in modular system. Additional function modules can be added.

Step Motor Controller is IC-based.

Available in single-, 2-, and 4-axis configurations, Series MC2502 consists of 132-pin processor and 100-pin logic device. Both components are surface-mount CMOS technology and powered by 5 V. Processor is driven by host microprocessor via 8- or 16-bit bus interface or through asynchronous bi-directional serial port. Controller offers programmable pulse and direction output at up to 1.0...

I/O Modules do not degrade Wavebook measurement bandwidth.

Models WBK40(TM) and WBK41(TM) provide measurement capabilities for Ethernet-based 1 MHz WaveBook/516E(TM) by adding up to 224 thermocouple inputs. WBK40, 14-channel thermocouple modules have on-board, 16-bit, 200 kHz A/D converters that measure TC inputs synchronously with WaveBook's 1 MHz measurements. Multifunction WBK41 modules, similar to WBK40 modules, include 14 thermocouple inputs, but...

Lighting Controller does not require hard wiring to fixtures.

Advanced Lighting System with PulseBloc-® utilizes digital pulse technology to provide 4 levels of remote stepped dimming. System consists of 3 components: Sportlite fixture, PulseBloc receiver, and PulseBloc wall controller. PulseBloc digital pulse technology is unaffected by noise on line, allowing signals to get through 99.97% reliability. Using existing wiring as communication medium, system...

7 Steps to Optimize Your Spring Design for Your Next Project

This white paper provides an in-depth overview into how to optimize a compression spring design in seven steps.

Flow Restrictors provide safe control of anesthesia.

Sintered metal flow restrictors are used in anesthesia delivery systems, maintaining minimum oxygen flow and non-hazardous gas mixtures of nitrous oxide, helium, and/or carbon dioxide. They have no moving parts and provide repeatable, close tolerance flow rates. Units are constructed of non-shedding compatible materials and are resistant to plugging and fouling. They are custom manufactured and...

Embedded Controller includes 320 x 240 pixel display.

Model QVGA Controller(TM) consists of C-programmable embedded computer with touchscreen-controlled GUI on 1/4 VGA display. It commands eight 12-bit analog input channels, eight 8-bit analog inputs, eight 8-bit D/A lines, 24 digital I/O, 4 high current drivers, and two RS232/485 ports. Unit features real-time multitasking operating system, hundreds of pre-coded device drivers, 512 K Flash and 512...

Sludge Level Monitor operates in hostile environments.

Model MSL600 sludge measurement system consists of transducer unit suspended in supernatant that transmits ultrasonic pulses. Time of flight of echo determines height of blanket to accuracy of Ã-

Servo Drive facilitates soft motion implementation.

Series DC201 digital drive allows users to implement multi-axis coordinated motion control system without need for dedicated motion controller. With built-in third-order interpolation and 5 kHz position loop, series has position set points sent from host via network. Able to be synchronized, drives are offered in encoder and resolver feedback models. Series include units with supply range of 80...

AC and DC Drives are offered in various styles.

VersaFlex(TM) drives, with protected chassis enclosures, provide selectable feedback with option boards and auto-tune. Design offerings include 30 sec peak overload capacity @ 150% (1 sec @ 200%) and assignable analog I/O. Products include AC inverter drives, encoderless vector drives in open-loop vector configurations, and vector drives in closed-loop configurations. Features include output...

Drivers/Stepping Motors include built-in resolver.

AlphaStep PLUS programmable systems are offered with motors in 1.65, 2.36, and 3.35 in. sq frames sizes for round shaft models or 3.54 in. sq for geared models. Holding torque range is 41.5 oz-in. to 327 lb-in. Driver-controller platform can be programmed in positioning, mechanical home seeking, continuous motion and electrical home seeking modes. Software allows user to control and link up to 14...
