PC Board & Card Accessories
(Showing headlines 1 - 20) more ....
Carrier Board enables creation of custom industrial SBCs.
6048 Horw Switzerland
Jul 08, 2014
Viola 4-layer Open Source carrier board can be combined with Colibri VF50 COM, Freescale® Vybrid™-based Computer-on-Module, as well as any module in pin-compatible Toradex Colibri family. Inserting Colibri VF50 or any other Colibri module into Viola carrier board allows for creation of custom-specific, industrial-quality SBC. In addition to supporting LCD panels and touch interfaces, this 74 x 74 mm board supports such interfaces as USB 2.0 host, 100 Mbit Ethernet, I˛C, SPI, UART, and GPIO.
OpenVPX Dual XMC Carrier Card has rugged ,6U design.
Lyndhurst, NJ 07071
Jul 01, 2014
Supporting 8 lanes of PCIe Gen2, VPX6-218 enables system designers to add up to 2 XMC (VITA 42.3) mezzanine module cards to OpenVPX-based embedded systems for defense and aerospace applications. PCIe interface communicates with host processor over VPX backplane. This fully OpenVPX®-compliant card can host two 25 W XMCs and support such high-performance mezzanine modules as Curtiss-Wrights XF07 FPGA XMC.
AMC Module serves HPC and general multi-processor systems.
Poway, CA 92064
Jun 26, 2014
From 1U MicroTCA™ platform with 6 AdvancedMC™ slots to 13U ATCA® platform with up to 12 ATCA® slots, AM4024 acts as integral component for supporting streaming, live, and off-line video transcoding. This AdvancedMC™ (AMC) module supports choice of 4th generation Intel® Core™ i5 or i7 CPUs along with Intel Iris™ Pro Graphics 5200 engine and Intel HD Graphics hardware acceleration. Along with connectivity options, features include up to 16 GB ECC Memory DDR3 1600 MHz and up to 64 GB NAND Flash.
AdvancedTCA Carrier Board holds 4 AMC modules.
Henderson, NV 89052
Jun 24, 2014
In addition to 10G managed Layer 2 switch with Xilinx® Virtex-7 FPGA, ATC133 10GbE Carrier features crossbar Switch (CBS) that allows any combination of backplane ports to be routed to FPGA. There are dual XAUI ports and dual GbE ports to each AMC slot. On-board PowerPC runs Linux OS, managing switch, loading FPGA image, and CBS. Also, carrier also routes up to 280 W to 4 full-size single or 2 double Advanced Mezzanine Cards (AMC) modules.
Embedded System Board supports industrial temperature range.
American Portwell Technology
Fremont, CA 94538
Jun 12, 2014
Measuring 70 x 70 mm, PQ7-M106IL Qseven Module Board supports Intel® Atom™ processor E3815/E3825/E3826/E3827/E3845 System-on-Chip and processor speeds from 1.46–1.91 GHz. Product features 8 GB system memory, dual independent displays by LVDS/DisplayPort, one industrial-grade Gigabit Ethernet, 4 USB ports, two SATA ports, HD audio, 3 PCI-E x1, and 1 UART interface. Supporting extended temperature range of -40 to +85°C, board is suitable for transportation and traffic management systems.
Mezzanine-Based Shelf Manager works with ATCA, MicroTCA systems.
Henderson, NV 89052
Jun 04, 2014
Fully backwards compatible with previous VadaTech product generations, VT003 provides quad-core, 1 GHz per core processor; 1 GB DDR3 memory; 32 GB Flash; and 8 GB NAND Flash. Mezzanine approach facilitates deployment on choice of carrier, while F-RAM for log messages promotes accelerated write performance, increased write/erase cycles, and minimized power consumption. Other features include dual 10/100 Ethernet ports, 3 RS-232 ports, and I˛C RTC with battery back-up.
Pico-ITX SBC suits graphic-intensive applications.
AXIOMTEK Co., Ltd.
May 27, 2014
Based on AMD G-Series Embedded SoC GX-210JA dual core 1.0 GHz processor, Model PICO121 provides one DDR3/L 1066/1333 SO-DIMM slot up to 8 GB. Fanless unit supports DirectX 11, Open GL4.2, and Open CL1.2 for optimal graphics performance, and features dual-view compatibility through VGA and LVDS with AMD Radeon™ HD8180 graphics controller. Operating from -4 to +158°F, PICO121 provides 4 high-speed USB 2.0 ports, 2 COM ports, 1 SATA port up to 6 GBps, 1 Gb Ethernet, and HD audio.
Fanless Embedded SBC includes PC/104 for ISA bus expansion.
AXIOMTEK Co., Ltd.
City of Industry, CA 91748
May 23, 2014
Powered by AMD Embedded G-Series APU dual core T40E at 1.0 GHz or single core T16R at 615 MHz, 3.5 in. Model CAPA112 features A55E FCH chipset and one DDR3-1066 SO-DIMM that supports 4 GB memory. Radeon™ HD 6250 graphics controller offers DirectX 11 support, while 18/24-bit single/dual channel LVDS and VGA interface offers dual view compatibility. Measuring 146 x 104 mm, CAPA112 provides 6 USB 2.0 ports, 1 SATA-600 port, 1 CFast™ socket, 4 COM ports, 8 DIO ports, and dual Gigabit LANs.
Mini-ITX Motherboards feature AMD embedded G-Series SOCs.
May 21, 2014
Suited for visualization and control applications, conga-IGX Mini ITX Boards include 9 W TDP 1.0 GHz dual-core processor GX-210HA SOC with AMD Radeon™ HD 8210E graphics; dual-core 18 W TDP GX-217GA SOC processor model with AMD Radeon™ HD 8280E graphics; and 2.0 GHz quad-core AMD Embedded GX-420CA SOC with AMD Radeon™ HD 8400E graphics. In addition to 1x PCIe x4 connector and Mini-PCI Express, boards offer dual GbE LAN, 2x Serial ATA III, 7x USB 2.0, and 2x USB 3.0 ports.
DAQ Boards are designed for OEM and embedded applications.
Measurement Computing Corp.
Norton, MA 02766
May 19, 2014
Featuring header connectors for facilitated integration into OEM applications, multifunction USB DAQ boards come in 6 models that offer up to 500 kS/s sampling, 8 or 16 DIO, and up to 2 analog outputs. Software support includes out-of-the-box DAQami and TracerDAQ® for data logging and display along with support for Visual Studio® and Visual Studio® .NET, DASYLab®, NI LabVIEW™, and MATLAB®. With UL for Android™ support, users can develop DAQ applications that run on tablets and smartphones.
Virtualization-Ready SFF NUC Platforms are rugged, configurable.
Laguna Hills, CA 92653
May 06, 2014
Designed around Intel®'s Next Unit of Computing (NUC), RoughNUC-Max accommodates full range of NUC chipsets and processors. Expansion bay areas allow peripheral or customer I/P expansion (SATA, GPS, 3G/4G, CAN, Serial, I˛C, SPI, PoE, DAQ). Designed to serve Intelligent Systems solutions™ with Microsoft® embedded and cloud platforms for connectivity, security, usability, and scalability, each ultra-SFF system is application-ready with range of OSs.
Eight-Channel 8-bit PCIe Gen2 Digitizer occupies one slot.
Agilent Technologies, Inc.
Santa Clara, CA 95051
Apr 28, 2014
Featuring on-board processing, U5309A immediately provides 8 channels of simultaneous acquisition with rates to 1 GS/s once plugged directly into computer PCIe® slot. Channels can be interleaved to reach 2 GS/s sampling rate, and applications benefit from data throughput provided by Gen2 eight-lane PCIe bus as well as possibility to implement real-time signal processing algorithms into on-board FPGA.
PICMG 1.3 Half-Size SBC suits network-intensive applications.
AXIOMTEK Co., Ltd.
Apr 18, 2014
Based on Intel® Q87 PCH, Model SHB230 supports 4th Generation Intel® Core™ i7/i5/i3 and Celeron® processors in LGA1150 socket. Slot CPU card is equipped with two DDR3-1333/1600 SO-DIMM sockets for up to 16 GB memory capacity. In addition to 4 PCIe x1 or 1 PCIe x4, and 1 PCIe x16 routed to backplane, single board computer provides 2 SATA interfaces that support RAID 0/1 functions, 1 CFast™ socket, 2 RS-232/422/485 ports, 4 USB 2.0 ports, 2 USB 3.0 ports, and 2 Gigabit Ethernet ports.
COM Express Mini Module features quad-core processor.
San Jose, CA 95125-1039
Apr 08, 2014
Measuring 55 x 84 mm, EmNANO-i2300 Type 10 Module comes in 4 Intel Atom-based versions, ranging from 1.33 GHz dual core E3825 with 6 W power consumption, up to 1.91 GHz quad-core E3845 with 10 W max power consumption. Module can support TMDS (HDMI/DVI) or DisplayPort at DDI interface as well as 24-bit LVDS channel. Providing up to 4 GB of fast DDR3L onboard memory, module includes 8 USB 2.0 ports, 1 USB 3.0 SuperSpeed port, three 5 Gbps PCI Express 2.0 lanes, and two 3 Gbps SATA interfaces.
OpenVPX and XMC Modules feature Freescale processors.
Extreme Engineering Solutions (X-ES)
Middleton, WI 53562
Apr 02, 2014
Consisting of 3U OpenVPX™ REDI module based on Freescale QorIQ T2080 processor, XPedite5970 supports up to 8 GB of DDR3 SDRAM and provides variety of I/O options to backplane, including 10 Gigabit Ethernet, Gen3 PCIe, and Gen2 SRIO. Conduction-cooled XPedite6101 XMC/PrPMC module is based on Freescale QorIQ T2081, T1042, or T1022 processor. It provides up to 8 GB of DDR3 ECC SDRAM, Gen2 PCI Express interface to P15, as well as dual Gigabit Ethernet, USB 2.0, and SATA 3.0 Gb/s interfaces to P16.
COM Express CPU Module incorporates AMD G-Series SoC.
ARBOR Technology Corp.
New Taipei City 235 Taiwan
Mar 17, 2014
Based on 1.0 GHz AMD GX-210HA dual core SoC with 9 W TDP, EmNANO-a56M0 Mini Type 10 CPU Module is suited for medical equipment, security and surveillance, gaming, digital signage, and 3D display. Board includes Radeon HD 8210 GPU and 2 GB DDR3L SDRAM as well as single channel 18-bit LVDS and DDI interfaces. Measuring 55 x 84 mm, module also incorporates Gigabit Ethernet controller, plus 8 USB 2.0 ports, 3 PCIe x1 lanes, and 2 SATA ports.
Compact Computer-on-Modules leverage x86 processor.
Poway, CA 92064
Mar 07, 2014
Powered by Intel® Atom™ processor E3800 series, Kontron SMARC-sXBTi Computer-on-Modules consume 5–10 W, operate from -40 to +85°C, comply with SGET specification, and suit compact portable handheld devices. Edge card connectors enable low-profile design, and space accommodates 64 GB on-board SSD for storage of OS and application data. Along with up to 8 GB RAM (ECC optional), features include mobile feature set with 3 UARTs, Intel® Gen 7 Graphics, and various I/O and extension options.
Pico-ITX SBC enhances graphic-intensive embedded Android devices.
VIA Technologies, Inc.
Taipei 231 Taiwan
Mar 03, 2014
Powered by 1.0 GHz dual core VIA Elite E1000 Cortex-A9 SoC with Unified Shader Architecture featuring 64 stream processors, VIA VAB-1000 supports dual independent displays, smooth 3D/2D graphics acceleration, and full HD playback support for resolutions up to 1080p. Available I/O encompasses HDMI, mini-USB 2.0, MicroSD, Gigabit Ethernet, GPIO, I˛C, and COM ports as well as A/V interfaces. Measuring 10 x 7.2 cm, Pico-ITX board comes with 4 GB eMMC Flash memory and 2 GB DDR3 SDRAM.
CompactPCI Board features Intel Atom E3800 processors.
Kontron Modular Computers GmbH
Dec 10, 2013
Available with up to quad core 1.9 GHz Intel Atom processor and 8 GB DDR3L memory, EN50155-compliant Model CP3010-SA integrates Intel Gen7 graphics, delivering 2D, 3D, and video capabilities to up to 2 independent displays connected via 2x DisplayPort and VGA. Board includes 3x Gbit Ethernet, 1x USB 3.0, and 3x USB 2.0 plus CAN bus and 2x COM ports. For data and software storage, Model CP3010-SA provides 2x SATA interfaces used for onboard CFAST socket.
Mini-ITX Embedded Motherboard withstands harsh environments.
Poway, CA 92064
Dec 09, 2013
Powered by dual- or quad-core 4th generation Intel® Core™ i3/i5/i7 processor up to 3.4 GHz, vibration- and shock-proof KTQM87/mITX is based on Intel® QM87 chipset and supports up to 16 GB DDR3 RAM with ECC support. ATX-compatible motherboard, supporting performance-intensive applications in 0 to +60°C environments, offers diverse selection of interfaces. Customer-specific functions can be integrated via PCIe and Mini PCIe extension slots as well as embedded Feature Connector.
(Showing headlines 1 - 20) more ....
