Motherboards & Backplanes

Computer Hardware & Peripherals

Mini-ITX Boards suit factory automation applications.

February 4, 2015

Powered by Intel® Atom™ E3800 series processors, Models EMB-BT2 and EMB-BT4 support dual LAN and mSATA for factory automation applications. Units also provide 2 LVDS sockets for electronic kiosk and POS applications, 6 COM ports, and up to 8 USB ports. Fanless design negates problems such as vibration and mechanical breakdown from moving or changing of parts. With utilization of ATX power specifications, requiring only 12 V, energy consumption is minimized. Read More

Computer Hardware & Peripherals

Embedded Computers use 5th Generation Intel® Core(TM) processor.

January 8, 2015

With 5th generation Intel® Core™ processor consuming 15 W TDP, COM Express Computer-on-Modules and Thin Mini-ITX Motherboards are suited for IoT applications. Intel® HD Graphics 5500 and 6000 deliver responsive visuals, including Ultra HD 4k display and additional codec support. Both conga-TC97 COM Express Type 6 Module and conga-IC97 Thin Mini-ITX Motherboard allow connection of up to 3 display interfaces via HDMI 1.4, LVDS, and eDP. Two SODIMM sockets support up to 16 GB DDR3L memory. Read More

Computer Hardware & Peripherals

Mini-ITX Motherboard leverages Intel Q87 chipset.

January 5, 2015

Targeting industrial control, factory automation, and communications industries, MI981 supports up to 4 GHz, 4th Generation Intel® Core™ i7/i5/i3 CPUs manufactured on 22 nm process technology with 3D tri-gate transistors. TPM v1.2 helps ensure computer platform integrity and iAMT 9.1, used with software management application, allows remote system monitoring, upgrades, and repair. Along with I/O, expansion, and display interfaces, features include 2 DDR3-1600 SO-DIMM memory slots (16 GB max). Read More

Computer Hardware & Peripherals, Display & Presentation Equipment

Embedded Motherboards serve digital signage applications.

January 5, 2015

Along with one HDMI, EMB-Q87B features 3 DisplayPort interfaces that are programmed to be used simultaneously or independently to accommodate those wishing to enlarge signage or show signage in sequence. Other features include USB ports, onboard Intel® Active Management Technology (AMT) with remote management capabilities, full size and half size MiniCard slots, and 12–24 V operating range. With exception of AMT, EMB-H81B can perform same functions as EMB-Q87B. Read More

Computer Hardware & Peripherals

Mini ITX Motherboard features Intel® quad-core SoC.

November 19, 2014

Based on quad-core Intel® Celeron® J1900 processor with Intel® HD Graphics engine, MANO840 utilizes high bandwidth DDR3L-1333 SO-DIMM with memory up to 8 GB. Embedded board provides 6 USB ports, 6 COM ports, 2 Gigabit Ethernet ports, and digital I/O. Various display interfaces support dual-view via VGA, HDMI, and 18/24-bit dual-channel LVDS. With 12 V single voltage DC power jack, MANO840 can be applied to medical/healthcare, in-vehicle infotainment, kiosk, digital signage, and POS uses. Read More

Computer Hardware & Peripherals

Thin Mini-ITX Motherboard consumes just 15 W TDP.

November 19, 2014

Based on 4th generation Intel® Core™ single-chip processors, conga-IC87 measures 25 mm in height with I/O-Shield, enabling flat housings such as those for panel PCs. Processors support up to 3 independent displays, while 2 SODIMM sockets support 16 GB DDR3L memory. In addition to 4 USB 3.0 SuperSpeed ports available on I/O shield, board supports 4 USB 2.0 ports via internal interface. Two Intel I210 Gigabit Ethernet controllers each provide one Gigabit Ethernet LAN access via 2 RJ45 sockets. Read More

Computer Hardware & Peripherals

Mini-ITX Motherboard suits digital signage and control.

November 19, 2014

Based on Intel® Atom™ E3800 series, conga-IA3 measures 25 mm in height with I/O shield, allowing installation in display and panel PCs. Two SODIMM sockets support up to 8 GB DDR3L memory, while Intel® Gen7 graphics support DirectX 11, OpenGL 3.2, OpenCL 1.2 plus flexible hardware decoding. In addition to 3 USB 3.0 SuperSpeed ports and 4 USB 2.0 ports, board includes 2 Intel I211 Gigabit Ethernet controllers that each provide Gigabit Ethernet LAN access via 2 RJ45 sockets. Read More

Computer Hardware & Peripherals

OpenVPX Backplanes offer central-switched, pass-through profiles.

November 14, 2014

Hybricon® Fabric40™ central-switched and pass-through OpenVPX backplanes enable end-to-end transmission of high-speed data required for ground and airborne C4ISR and EW deployed applications. With 3U form factor, products support full-speed, bottleneck-free distribution of data over Gen3 PCIe, 40 Gbps Ethernet, or Infiniband® fabrics as well as such high-speed FPGA I/O as Xilinx® RocketIO and Aurora architectures. Air-cooled or conduction-cooled versions are available. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Micro-Overlays automate OpenVPX backplane topology optimization.

October 16, 2014

Tuned for high-speed signal transmission, connector-less Fabric Mapping Modules (FMMs) simplify and automate optimization of backplane topologies in compliance with OpenVPX profiles. FMMs interface PCB-based differential pair matrix with compatible Dawn backplanes. Using BGA substrate technology as micro-overlay, FMMs can be used on VPX backplanes and reduce transmission line impedance variations and stubs by connecting directly to main backplane via solder interface. Read More

Computer Hardware & Peripherals

EPIC 4 in. Motherboards combine low power and high performance.

October 14, 2014

Powered by 4th Generation Intel® Core™ i7/i5/i3 CPUs, SBC-7110 offers 4GB DDR3L 1,600 MHz onboard memory. Powered by 1.91 GHz Intel Atom E3845/1.83 GHz Celeron® N2930 CPU, SBC-7111 provides 2 GB DDR3 1,600 MHz onboard memory. Both motherboards feature 18/24bit Dual Channel LVDS, accept 9–36 Vdc input, and operate from -20 C to +70°C. I/O for both models includes USB3.0/2.0, HDMI, and SATA III ports. Depending on model, other interfaces are available as well.
Read More

Computer Hardware & Peripherals

Industrial Motherboard supports IoT applications.

October 13, 2014

Featuring 4.4 x 4.6 in. UTX form factor, Model UTX-110 is equipped with fourth generation Intel® Atom™ E3800 processor that supports optimized stereoscopic 3D capabilities and high-resolution graphics. Board provides 4/8 G DDR3L dual channel memory at 1066/1333 MHz, VGA/LVDS/HDMI dual display support, 2 x Intel 210 Gigabit LAN, 2 COM ports, and 3 USB ports. For Wi-Fi modules and mSATA storage, UTX-110 includes built-in full size/half size PCIe x1 expansion slot. Read More

Computer Hardware & Peripherals

OpenVPX Backplanes support full-speed distribution of data.

September 17, 2014

Featuring patent-pending signal integrity technology, Hybricon® Central-Switched Fabric40™ OpenVPX Backplanes and Gen3 OpenVPX-optimized Fabric40 OpenVPX Pass-through Backplanes enable end-to-end transmission of high-speed data required for demanding ground and airborne C4ISR and EW deployed applications. Available in air-cooled or conduction-cooled development chassis, units support bottleneck-free data distribution over Gen3 PCI-Express, 40 Gbps Ethernet, or Infiniband® fabrics. Read More

Computer Hardware & Peripherals, Green & Clean

Mini-ITX SBC offers choice of three 2nd Gen AMD SoC processors.

September 3, 2014

Able to be powered by onboard AMD® G-series quad- or dual-core SoCs integrated with GPUs based on AMD's Graphics Core Next technology, MB-73360 offers up to 8 GB DDR3 and operates from 8–32 Vdc input. Connectivity is covered by 2x Intel® GbE LAN, 6 COM , 9 USB, and 2 SATA ports, while display interfaces include 2 HDMI (4k resolution) and VGA. Other I/O options include HD audio and expansion interfaces: mini-PCIe socket, PCIe X16 slot, and PCIe slot. Read More

Computer Hardware & Peripherals

Mini ITX Motherboard combines processing power, I/O flexibility.

August 6, 2014

Along with Intel® H81 Express chipset, MANO881 offers socket H3-LGA1150 that supports 4th generation Intel® Core™ i7/i5/i3 and Celeron® (Haswell) CPUs. Integrated Intel® HD 5000 graphics supports graphic processing and dual-display capability through HDMI, VGA, and dual-channel 24-bit LVDS. Along with 2 sockets for up to 16 GB DDR3 system memory, features include one PCIe x16 slot and one mSATA slot for expansion, diverse I/O options, HD audio, and support for watchdog timer and SMART FAN. Read More

Computer Hardware & Peripherals

Mini-ITX Motherboards feature AMD embedded G-Series SOCs.

May 21, 2014

Suited for visualization and control applications, conga-IGX Mini ITX Boards include 9 W TDP 1.0 GHz dual-core processor GX-210HA SOC with AMD Radeon™ HD 8210E graphics; dual-core 18 W TDP GX-217GA SOC processor model with AMD Radeon™ HD 8280E graphics; and 2.0 GHz quad-core AMD Embedded GX-420CA SOC with AMD Radeon™ HD 8400E graphics. In addition to 1x PCIe x4 connector and Mini-PCI Express, boards offer dual GbE LAN, 2x Serial ATA III, 7x USB 2.0, and 2x USB 3.0 ports. Read More

Computer Hardware & Peripherals

Embedded Motherboards leverage Intel Atom E3800 Series CPU.

March 7, 2014

Respectively featuring Pico-ITX and Mini-ITX form factors, Kontron pITX-E38 and Kontron mITX-E38 are powered by Intel® Atom™ E3800 series processor and can be deployed in extended temperature ranges up to -25 to +75°C. Both embedded motherboards feature hardware-integrated security features for IoT applications and support KEAPI implementation. Latter consists of platform-independent middleware which allows standardization of access routines to hardware resources. Read More

Computer Hardware & Peripherals

Industrial Motherboards come in ATX and Micro-ATX form factors.

January 24, 2014

Along with choice of 4th Generation Intel® Core™ i-Series processors and Intel Q87 Express chipset, IMBA-Q87A (ATX) and IMBM-Q87A (micro-ATX) support up to 32 GB via 4 DDR3 DIMMs and up to 3 independent displays through various interfaces. Hardware decoder and Intel® Clear Video HD technology optimize performance. Each motherboard can process high-resolution videos, live broadcasts, and digital content and feature diverse range of I/O and expansion options. Read More

Computer Hardware & Peripherals

Server Motherboard offers 12 Gbps SAS-3 connectors.

January 9, 2014

In addition to offering 6 SATA ports, E3C224D4M-16RE adopts LSI™ SAS 3008 controller and 3X24R expander to support 16 SAS-3 (12 Gbps) ports directly onboard with 4 SAS HD connectors. Mezzanine slot enables upgrades to 10GLAN, while ECC memory lends to stability. Solution enables businesses to create solutions for intractable data bottlenecks in big data/network storage, ERP/MRP, network/security, and Web farm/hosting environments. Read More

Computer Hardware & Peripherals

Mini-ITX Motherboard withstands harsh environments.

December 9, 2013

Based on soldered dual- or quad-core, 3.4 GHz 4th Gen Intel Core i3/i5/i7 processor and Intel QM87 chipset, KTQM87/mITX is vibration- and shockproof with temperature range of 0–60°C. Unit supports up to 16 GB DDR3 RAM with ECC and provides both PCI Express Gen 3.0 as well as 2 Mini PCIe slots. Further peripherals connect via 4 USB 3.0 ports, 8 USB 2.0 ports, or Feature Connector capable of executing 160 GPIOs. Up to 3 independent displays or one 4K monitor are supported via DisplayPort 1.2. Read More

Computer Hardware & Peripherals

Mini-ITX Embedded Motherboard withstands harsh environments.

December 9, 2013

Powered by dual- or quad-core 4th generation Intel® Core™ i3/i5/i7 processor up to 3.4 GHz, vibration- and shock-proof KTQM87/mITX is based on Intel® QM87 chipset and supports up to 16 GB DDR3 RAM with ECC support. ATX-compatible motherboard, supporting performance-intensive applications in 0 to +60°C environments, offers diverse selection of interfaces. Customer-specific functions can be integrated via PCIe and Mini PCIe extension slots as well as embedded Feature Connector. Read More
