PMC Interface Cards

Computer Hardware & Peripherals, Test & Measuring Instruments

PCIe Card can connect PC to any industrial Ethernet network.

April 1, 2015

Based on Anybus and proprietary technologies, IXXAT INpact comes in standard and low-profile formats and lets users connect their PC-based slave application to EtherCAT, EtherNet/IP, Modbus TCP, PROFINET IRT/RT, Powerlink, and standard TCP/IP. Uniform driver concept allows user to switch between protocols without extensive programming as well as utilize future protocol extensions and developments. Two-port Ethernet interface (10/100 Mbit, RJ45s) supports protocol-specific switch functions. Read More

Electrical Equipment & Systems, Computer Hardware & Peripherals

PCIe Gen3 Expansion Solution works with MicroTCA, other systems.

March 2, 2015

PCIe-compliant module, PCI123, routes x16 PCIe Gen 3 out of front panel ports. Utilizing SFF-8644 connectors, signals can be partitioned as single x16, dual x8, or quad x4 as required. Module supports aggregate raw data rate up to 128 Gbps and can be cabled to UTC006 MicroTCA Carrier Hub (MCH) for PCIe Expansion. Offering quad SFF-8644 ports for PCIe Gen3 expansion (x16, x8, or x4) and PCIe switch, MCH routes PCIe x16 to Rear Transition Module (RTM). Read More

Controls & Controllers, Test & Measuring Instruments, Computer Hardware & Peripherals

Configurable XMC Modules feature Xilinx Kintex-7 FPGA.

February 25, 2015

XMC-7K series feature reconfigurable Xilinx® Kintex™-7 FPGA and 128M x 64-bit DDR3 SDRAM. Eight-lane, high-speed serial interface on rear P15 connector for PCIe Gen 1/2 (standard), Serial Rapid I/O, 10 GbE, and Xilinx Aurora implementations are supported. While rear I/O provides 4- or 8-lane, high-speed serial interface on P16 XMC port, select I/O or LVDS pairs plus global clock pairs direct to FPGA via rear P4 or P16 port. Read More

Computer Hardware & Peripherals

Deployable Half-Size PCIe FMC Carrier offers optical interface.

February 24, 2015

Along with Virtex-7 FPGA, Flexor™ Model 7070 PCIe FMC (FPGA Mezzanine Card) carrier features VITA 57.1 FMC site; 4 GB DDR3 SDRAM; PCIe (Gen 1, 2, and 3) interface up to x8; optional 12x user-configurable gigabit serial I/O; and optional LVDS connections to FPGA for custom I/O. Gigabit serial interface, with optional optical transceivers, makes 12 full duplex optical lanes available to MTP connector. Built-in IP functions cover data capture, synchronization, time-tagging, and formatting. Read More

Computer Hardware & Peripherals

Mini PCIe Card withstands harsh and rugged environments. .

February 11, 2015

Comprising mini PCI Express (mPCIe) multi-port serial communication cards, 50.95 x 30 mm mPCIe-COM Series offers 4 or 2 ports of software-selectable RS-232, RS-422, and RS-485 asynchronous serial protocols on port by port basis. Each RS-232 port is capable of supporting data communication rates up to 921.6 kbps, while RS-422 and RS-485 modes support data communication speeds up to 3 Mbps. Existing serial peripherals can connect directly to DB9M connectors on optional accessory kits. Read More

Computer Hardware & Peripherals

AdvancedTCA Carrier is designed for PCIe Gen 3 cards.

December 9, 2014

Along with Intel® Xeon® E3-1268L V3 processor (quad-core @ 2.3 GHz or turbo frequency @ 3.3 GHz), ATC121 features x16 PCIe Gen 3 slot that accepts any PCIe edge-type module. Dual RJ-45, USB, and RS-232 ports are standard, and graphics ports include dual Display Port input as well as DVI-D and Display Port outputs. Customized versions afford different I/O front panel options. Also available are optional mSATA sockets (for expanded storage) and on-board VT003 shelf manager. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

CAN Cards for PCI Bus support up to 4 high-/low-speed channels.

November 7, 2014

Modularly expandable CAN-IB300/PCI and CAN-IB400/PCI let users connect computer to CAN-system for control applications and perform analysis, configuration, and troubleshooting. While CAN-IB300/PCI is passive card, active CAN-IB400/PCI has 32-bit MCU system that enables intelligent handling and active filtering of messages sent and received on card. Interfaces can be equipped with up to 4 LIN or K-Line interfaces as well as customer-specific interfaces upon request. Read More

Computer Hardware & Peripherals

PCI-Express 3.0 Card accelerates Hadoop applications.

October 21, 2014

By offloading computationally intensive compression and security algorithms from host CPU, Model DX2040 minimizes I/O bottlenecks while optimizing storage efficiency. Half-length 8-lane PCI-Express 3.0 card leverages XR9240 compression and security co-processor to deliver 40 Gbps of simultaneous compression, encryption, and hashing while providing compression ratios comparable to level 9 gzip. In addition, public key engine delivers 40,000 operations/sec of RSA with 2048 bit keys. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

PCIe Analysis/Emulation Boards monitor T1 E1 line conditions.

October 14, 2014

With PCIe (x1) bus interface and GUI for Windows® 7/8, Dual T1 E1 Express (PCIe) Analysis and Emulation Boards support basic and special T1 E1 applications as well as VF drop and insert with software selectable VF Tx and Rx impedances, Pulse Mask Compliance, Jitter Generation, and Measurement testing applications. FXO FXS and Datacom functionality is not covered. Cross-port Through and Cross-port Transmit modes facilitate cabling with drop/insert and fail-safe inline monitoring. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

AMC Module serves HPC and general multi-processor systems.

June 26, 2014

From 1U MicroTCA™ platform with 6 AdvancedMC™ slots to 13U ATCA® platform with up to 12 ATCA® slots, AM4024 acts as integral component for supporting streaming, live, and off-line video transcoding. This AdvancedMC™ (AMC) module supports choice of 4th generation Intel® Core™ i5 or i7 CPUs along with Intel Iris™ Pro Graphics 5200 engine and Intel HD Graphics hardware acceleration. Along with connectivity options, features include up to 16 GB ECC Memory DDR3 1600 MHz and up to 64 GB NAND Flash. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Hardware-Accelerated Compression works with Apache Hadoop.

November 1, 2013

AltraHD enables all applications in Apache™ Hadoop® stack to be transparently compressed using hardware acceleration, removing I/O bottlenecks and optimizing storage capacity. Leveraging software technology and hardware compression accelerators, solution integrates seamlessly into stack and transparently compresses all files that are using Hadoop Distributed File System (HDFS). Features include application-transparent file system filter and up to 3.2 GBps compression throughput. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

PCIe Digitizer delivers multi-gigahertz, real-time processing.

July 3, 2013

Intended for systems in commercial, industrial, aerospace, and defense applications, U5303A features 8-lane PCIe 2.0 interface and delivers 12-bit resolution, sampling up to 3.2 GSPS, and on-board processing. Dual-channel PCIe digitizer gives users ability to integrate real-time signal processing within embedded Xilinx Virtex-6 FPGA and facilitates integration into PC via included set of drivers. Other performance features include DC-1.8 GHz bandwidth, 9.1 ENOB at 100 MHz, and 58 dB SNR. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

VPX Processor Board supports hypervisor technologies.

June 3, 2013

Based on Freescale P2041 QorIQ quad-core processor, 3U Model VX3240 has four 1.2 GHz Power Architecture e500mc cores, which helps engineers meet SWaP-C requirements for constrained environments in military, aerospace, and transportation markets. Board provides up to 8 GB soldered DDR-3 SDRAM and optional XMC/PMC slot that enables application specific customization. For networking and peripherals, there are 2 Gigabit Ethernet ports, 2 USB 2.0, 2 serial interfaces, and 6 GPIOs. Read More

Computer Hardware & Peripherals

PCI-104 Serial Communication Boards offer selectable protocols.

March 15, 2013

PCI-104 boards of 104I-COM-8SM Series offer selection of 8, 4, or 2 ports of field-selectable RS-232, RS-422, and RS-485 asynchronous serial protocols on port-by-port basis. Allowing connection of multiple serial devices, ports are accessed via two 40-pin IDC-type right angle header connectors. Each RS-232 port supports data communication rates up to 921.6 kbps and implements full modem control signals. RS-422 and RS-485 modes support data communication speeds up to 1.8432 Mbps. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

PCIe Gigabit Ethernet Card suits SFF computing applications.

February 18, 2013

With ultra low profile 1U slim PCIe add-on card form factor, Model 1uPCIe-1000 is suitable for systems with 1U or 1.75 in. of system height and can be installed without additional riser card. Card features onboard Intel PCIe 82574L Gigabit Ethernet controller and support for auto-switching 10/100/1000BASE Ethernet networking connection as well as Wake-on-LAN functions. Based on standard PCI Express bus interface, 1uPCIe is supported by motherboards with x1 PCI Express expansion slot. Read More

Computer Hardware & Peripherals

PCI/104-Express Boards are available for CAN and LIN interfaces.

August 8, 2012

PCI/104-Express boards, based on modular architectural concept, are designed for compact industrial computers and mobile systems. In addition to passive version, active version with 32-bit MCU is offered. Latter suits applications with high demands for data preprocessing. Depending on version, boards are available with up to 4 CAN interfaces as well as optional switchable high-/low-speed CAN interface and LIN interface. All interfaces are galvanic isolated by default. Read More

Computer Hardware & Peripherals

PCI Express Board synchronizes up to 256 channels.

July 9, 2012

Supporting up to 8 Pentek Virtex-6 Cobalt® and Pentek Virtex-7 Onyx(TM) boards at sample clock rates up to 800 MHz, Model 7893 single-slot system synchronization and distribution amplifier supports multi-channel, phase-coherent applications. Up to eight 7893 boards can be linked in cascade mode to allow 64 Onyx or Cobalt boards to receive common clock along with timing signals for synchronizing, triggering and gating functions. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Sensors, Monitors & Transducers, Communication Systems & Equipment

PCI-Express Card encodes/decodes real-time MPEG2/4/1 video.

July 6, 2012

With multiple video I/O and MPEG codec ICs and application/SDK software, MPEGIO2 encodes/decodes multichannel, full D1 video and always synchronized audio in real-time. Functions include color text/graphics overlay, picture-in-picture encoding, multi-pin DIO control, PAL and NTSC conversion, live video preview, low-latency video streaming, and seamless recording file splitting. Product encodes/compresses MPEG4/2/1 video, without involving PC CPU, at bit rates from 15 Mbps to 128 Kbps. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Multifunction DAQ Board is designed for PCIe bus.

June 13, 2012

Connector- and software-compatible with MCC PCIM-DAS1602/16 for those who need to migrate to PCIe, 16-bit PCIe-DAS1602/16 offers 16 analog inputs, 100 KSPS sample rate, 32 DIO, 2 analog outputs, and 3 counter inputs. Board includes software options to meet any skill level or application requirement. Support includes out-of-the-box TracerDAQ® along with comprehensive drivers for Visual Studio® and Visual Studio® .NET, DASYLab®, and NI LabVIEW(TM). Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

PXI Express Remote Control Modules foster system expansion.

November 23, 2011

Used for creating multichassis PXI Express (PXIe) systems, PXIe-8364 and NI PXIe-8374 enable engineers to directly interface multiple PXIe chassis to one host computer using any expansion topology without complex custom solutions. Modules PXIe-8364 and -8374, respectively, use x1 and x4 MXI-Express links to connect downstream and upstream PXI Express chassis and provide max data bandwidth of 250 MBps and 1 GBps. Cabled PCIe is used as underlying communication technology. Read More
