Bus Interface Adapters & Expansion Boards

Electrical Equipment & Systems, Computer Hardware & Peripherals

USB Wall Plug Adapters meet Level VI standards.

August 13, 2015

Featuring 2.56 x 1.42 x 0.89 in. footprint, 5 Watt Models SWI5-5-N-I38 and SWI5-5-E-I38 deliver 5 Vdc single regulated outputs with universal input voltage from 90~264 Vac. Both feature no load power consumption of <0.075 W and provide over voltage, over current, and short circuit protections. SWI5-5-N-I38 has input blades for North American and Japanese applications, while SWI5-5-E-I38 has European input blades. Applications include media players, e-readers, GPS, and other mobile devices. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Computer Hardware & Peripherals

Ruggedized mPCIe CAN Bus Adapter IoT-enables embedded systems.

July 28, 2015

By providing dual channel CAN Bus 2.0A/B functionality, EMUC-B201 extends embedded systems and industrial PCs with capability for Internet of Things (IoT). Embedded peripheral module can interface 2 CAN Bus channels through mPCIe connector or direct pin header connection for USB 2.0 communication with main system. CAN 2.0B and CAN 2.0A are supported, and module lets embedded systems tap directly into vehicle or factory sensors and subsystems for real-time data access and control.
Read More

Electrical Equipment & Systems, Computer Hardware & Peripherals

Snap-In Panel Mount Cables accelerate secure installation.

July 22, 2015

Reducing installation time for system builders and system integrators, Snap-In Cables are designed so that they can snap into properly sized bulkhead opening without requiring any nuts, screws, or tools while producing secure fit and clean look. This panel mount cable line includes single and dual USB cables and Ethernet cables. Read More

Computer Hardware & Peripherals

USB Flash Module enables in-field panel upgrades without computer.

April 13, 2015

Used in field, Model 400 USB Flash Module lets installers update firmware for panels that would otherwise require computer and Model 399 Programming Harness. USB 2.0 connector is provided to plug USB flash drive into Model 400, and 4-pin header connects directly to panel. As new firmware is released from DMP, it can be downloaded and stored on USB flash drive and then connected to Model 400 to be used for panel firmware updates. LED on USB indicates successful programming. Read More

Computer Hardware & Peripherals

Fault Insertion Card features PCI form factor.

April 8, 2015

Available as either 1- or 2-slot short PCI card, Model 50-190 provides 75, 64, or 36 channels of fault insertion as well as 1 or 2 fault insertion busses, each of which can select from 3 fault sources. Card includes ability to introduce open circuit paths, shorts between paths, or shorts to fault connections such as battery or ground. Suited for use on Can and FlexRay bus systems, unit features 2 A hot switch capacity for powers up to 60 W and voltages to 165 Vdc/115 Vac. Read More

Electrical Equipment & Systems, Computer Hardware & Peripherals

PCIe Gen3 Expansion Solution works with MicroTCA, other systems.

March 2, 2015

PCIe-compliant module, PCI123, routes x16 PCIe Gen 3 out of front panel ports. Utilizing SFF-8644 connectors, signals can be partitioned as single x16, dual x8, or quad x4 as required. Module supports aggregate raw data rate up to 128 Gbps and can be cabled to UTC006 MicroTCA Carrier Hub (MCH) for PCIe Expansion. Offering quad SFF-8644 ports for PCIe Gen3 expansion (x16, x8, or x4) and PCIe switch, MCH routes PCIe x16 to Rear Transition Module (RTM). Read More

Computer Hardware & Peripherals, Controls & Controllers

USB 3.0 Hub Controller comes in 6 x 6 mm BGA package.

December 29, 2014

Intended for mobile and consumer devices, EZ-USB® HX3™ offers full configurability via I²C EEPROM, I²C Slave, and GPIO options. Ghost Charging allows device charging without host, and Accessory Charger Adaptor Dock enables upstream charging for portable devices with USB OTG host. Other features include Shared Link, which enables up to 8 downstream ports; support for USB-IF Battery Charging v1.2 specification and charging of Apple devices; as well as configurable USB 2.0 and SuperSpeed PHYs. Read More

Safety & Security Equipment, Computer Hardware & Peripherals, Electrical Equipment & Systems

Panel Mount USB Cables feature ground wires.

November 24, 2014

Offered in 0.3, 0.5, 0.75, 1, 2, and 3 m lengths and suited for use inside box or enclosure, USB 2.0 panel mount cables are available with ground wire for option of electrically grounding USB female connector to panel or enclosure. Molded, panel-mountable construction features 20 AWG power conductors and 28 AWG twisted pair data conductors all under double shield for maximum EMI resistance. Cable is light gray, and each assembly includes two 4-40 x 3/8 in. Phillips pan head mounting screws. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

USB 3.0 Interface ICs come in low-pin count packages.

November 20, 2014

Respectively, FT600Q and FT601Q come in 56- and 76-pin QFN packages and feature 16- and 32-bit wide FIFO bus interface. Both chips, which function as SuperSpeed USB 3.0 to FIFO bridges, support up to 8 endpoints (other than management endpoints) linked to configurable buffers of 16 KB length for in and 16 KB for out. Providing data bursting rates up to 3.2 Gbps, USB 3.0 products support 2 interfacing modes: 245 FIFO mode and multi-channel FIFO mode. Read More

Computer Hardware & Peripherals

USB Adapter Kit extends wireless coverage.

October 31, 2014

Supplied in FCC/IC certified kit, 2.4 GHz 802.11b/g/n Model ARK-2404U-3 comprises WLAN-LCUSB2415 wireless USB Adapter and Hyperlink's 4 dBi omni-directional antenna. Adapter supports data rates of 150 Mbps and features IP67-rated waterproof enclosure for outdoor applications. Included 5 m cable is terminated with USB 2.0 plug for direct connection to desktop or notebook PC. Additional features include 100 mW to 1 W adjustable RF power, Windows OS drivers, and WPA/WPA2 data security. Read More

Computer Hardware & Peripherals

Video Adapters provide 4K HD video through USB 3.0 connection.

October 13, 2014

USB 3.0 to HDMI® (USB32HD4K) and USB 3.0 to DisplayPort® 1.2 (USB32DP4K) enable users to connect USB 3.0-equipped laptop or desktop PC to Ultra HD 4K television, display, or projector, even if computer does not natively support 4K video. Integrated chipset enables plug-and-play functionality, where drivers are automatically installed and updated, and USB-powered performance eliminates need for additional power supply. Areas of use include graphics-intensive applications. Read More

Computer Hardware & Peripherals

USB to Serial Bridges offer 12 Mbps USB data transfer rate.

September 29, 2014

Available with 1, 2, or 4 UART channels, XR21B142x Series provides way to interface with RS-232 or RS-485 serial networks through USB using minimal PCB space. Large 512 Byte transmit and receive FIFOs enable max data throughput of 9 Mbps across up to 4 UART channels. Offering ±15 kV ESD protection on USB pins, devices eliminate need for additional protection components, making them suitable for smart grid data collection, data aggregators/concentrators, and security/access control systems. Read More

Computer Hardware & Peripherals, Controls & Controllers, Green & Clean

Fieldbus Gateway enables device communications switching.

September 22, 2014

Used for PLC programming and process visualization, PFC200 acts as fieldbus gateway to switch field devices between MODBUS TCP/UD/RTU, CAN, PROFIBUS, Smart Grid, and Serial RS-232/RS-485. System uses 600 MHz ARM Cortex A8 processor that offers high-speed processing and support of 64 bit-variables. Other features include 256 MB memory; compatibility with NTP, SNMP, HTTPS, and FTPS protocols; and 2 switched Ethernet ports. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems

Right-Angled USB Cable Line serve confined-space applications.

July 24, 2014

Suited for tight-fit and confined-space applications, black 90° angled USB cable assemblies come in all 4 mold options for type A and B connections and feature USB 2.0-compliant, 24 AWG power leads. Areas of use, along with specific OEM applications, include PC peripheral interconnects, test and measurement, DAQ, portable data storage, and printer interface. There are 14 connector angle combinations available as stock cables; additional connector angle combinations can be custom produced. Read More

Computer Hardware & Peripherals, Communication Systems & Equipment

USB Fieldbus Adapter extends connectivity to fieldbus networks.

July 1, 2014

USB Fieldbus Interface v3 facilitates in-field or instrument shop-based FOUNDATION fieldbus device configuration, monitoring, and troubleshooting. Multiple options are provided for commissioning and configuring FOUNDATION fieldbus devices. Functionality allows Fieldbus devices to be commissioned, decommissioned, and assigned device tags. Communication DTM, included, enables device configuration using third-party FDT Frame Applications and library of Emerson Device DTMs. Read More

Computer Hardware & Peripherals

USB-to-RS422/RS485 Adapters offer 10 kV ESD protection.

June 25, 2014

Offering plug-and-play installation, single-port Model ES-U-2001-S incorporates automatic transmit and receive control for 2-wire RS485 half-duplex mode. Model ES-U-2001-STB has same features and functionality, but with 5-pin terminal block connector included which facilitates wiring process. Suitable for connection with either USB 1.1 or 2.0 hosts, adapters' high-speed serial ports are capable of data rates from 300–921.6 kbps. Both have built-in termination and biasing mechanisms. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems

USB Charging Station accommodates up to 4 devices.

June 12, 2014

FUEL Station mini 4-Port USB Charge Base enables simultaneous charging of up to 4 USB-powered devices – tablets, smartphones, Bluetooth™ speakers, cameras, and others – from one wall outlet. Along with built-in power supply, portable solution features integrated over voltage, over current, over temperature, leakage, and short circuit protection to ensure mobile device is safe while charging.
Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems

Mini-USB Cable Assembly is sealed to IP67/68/NEMA 250 (6P).

June 10, 2014

Sealed to IP67 and IP68/NEMA 250 (6P) when mated, Data-Con-X® sealed mini-USB cable assembly features quick connect bayonet style interface. RoHS-compliant and pre-assembled cable, offered with 3 standard cable assembly options, mates with field installable Mini-USB panel connectors. In addition to military or industrial GPS location devices, uses include instrumentation, medical data cart, DAQ unit, and general industrial electronic applications. Read More

Computer Hardware & Peripherals, Services

USB3.0 Connectors accommodate height-restrictive applications.

June 2, 2014

USB3.0 mid reverse connectors are designed for inclusion in such devices as tablets, notepads, and other handheld devices. Mid bottom mount USB3.0 connectors are available for low-profile applications where height above and below PCB is critical. Allow mounting on bottom of PCB, reverse connectors sit in cut out on PCB to minimize height. With cutaway face, USB1115 has .212 in. body height and suits angled panels. While USB1110 is mounted below PCB, bulk sits above PCB. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Mounting & Attaching Products

Extension Cables target USB 2.0 micro B enabled peripherals.

May 28, 2014

Offered in lengths of 0.3, 0.5, 0.75, 1, 2, and 3 m, USB 2.0 Micro B Extension Cables are male-to-female cables used to extend phone charger cables and other USB 2.0 micro B enabled peripherals. They can also be used to extend plug-in wall chargers that have short, fixed length cords.  To provide protection against EMI/RFI, each cable incorporates foil plus braid shielding. All 5 connector positions are integrated to ensure proper functionality in every application. Read More
