Graphics & Video Cards

Test & Measuring Instruments, Computer Hardware & Peripherals

Differential Frame Grabber works with legacy equipment.

July 8, 2015

Leveraging PCIe technologies and camera link front end featuring 32-bit differential interface (circa 1997), Neon™-DIF provides upgrade path that lets differential users keep existing LVDS and RS-422 cameras, cables, and code while benefiting from FlowThru™ architecture. Product can control, acquire, reformat, and transfer video data directly into user's application at camera speeds with zero CPU usage and near-zero latency. Solution also handles porting of applications to 64-bit Windows®. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Cable STB Reference Design offers data speeds to 5 Gbps.

June 12, 2015

Equipped with dual-core Brahma15 12000 DMIPs ARMv7 processor, Model BCM93390VMS52 combines multi-Gigabit broadband data speeds, Ultra HD video decoding, and dual concurrent 4x4 Wi-Fi in single design. Device provides 4kp60 or Quad HD decode and dual transcode capabilities as well as support for up to 16 concurrent DVB-C video channels. Integrated DOCSIS 3.1 cable modem and router with Broadcom's BCM4366 5G Wi-Fi offers speeds up to 2.2 Gbps at 5 GHz and 1 Gbps at 2.4 GHz. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Application Processors target Internet of Things.

April 21, 2015

Based on ARM® Cortex®-A9 dual-core CPU, ApP Lite™ TZ5010XBG and TZ5011XBG incorporate built-in baseband for high-speed Wi-Fi® 802.11ac, graphics, and video engine. ApP Lite™ TZ5021XB and TZ5023XBG support LP-DDR2/3 memory, specialized low-power mode for mobile devices, and small package size for IoT applications. Additionally, TZ5023XBG includes Cadence® Tensilica® HiFi Mini DSP, which executes voice, audio, and sensor processing. All models feature Imagination PowerVR SGX540 GPU. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

VME Interface Board supports radar video applications.

April 20, 2015

Combining Intel® Core™ i7-based single board computer and radar video processing capabilities on single-slot 6U VME module, Cougar 2 accepts both analog and digital radar signals. Dual-channel unit supports wide range of radar interfaces including radar video, triggers, and azimuth turning data. Module eases integration of radar video capture, conversion, and mixing into deployed vessel tracking, airborne target tracking, and airport ground movement applications. Read More

Computer Hardware & Peripherals, Controls & Controllers

Rugged XMC Graphics Module combines low power, high performance.

April 20, 2015

Based on 3U VPX VPX3-716 Graphics Engine (AMD Radeon™ E8860 GPU-based display card), XMC-725 delivers multiple independent channels (up to 4 heads) of graphics output: DVI/LVDS/RGB-HV/DisplayPort™. Performance is optimized over -40 to +85°C basecard edge temperature, and 2 GB dedicated onboard memory supports demanding applications. Requiring <17 W, SWaP-optimized design eliminates need to throttle performance and unwanted shutdowns. Applications may only require as little as 10 W draw. Read More

Electronic Components & Devices, Computer Hardware & Peripherals, Mechanical Components & Assemblies

Hardware Core manages HD video production and storage.

April 17, 2015

Specifically designed for low complexity and low latency, Model VC-2 LD combines light compression with lossless video. Intra-frame wavelet codec is patent-free and gives video equipment OEMs option to make their tools HD/UHD-proof. Thin solution may be integrated in existing designs and low-end Altera and Xilinx FPGAs. Read More

Communication Systems & Equipment, Computer Hardware & Peripherals, Electronic Components & Devices

Video-over-IP Reference Design supports JPEG 2000 streams.

April 14, 2015

Built around Xilinx FPGA platform, 4-channel Video-over-IP Reference Design allows interoperable transport of JPEG 2000 streams over IP networks. Transmitter is able to take up to 4 SDI high-definition streams (1080p30), optionally compress them with JPEG 2000, and send them over 1 Gbps (with compression) or 10 Gbps (uncompressed) Ethernet according to VSF TR-01 standard. Receiver platform, conversely, can receive IP stream, de-encapsulate and decompress it, and put it on 4 SDI HD links. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

HD STB SoC targets China's free-to-air satellite market.

April 6, 2015

Featuring 750+ DMIPS application CPU and 300+ million pixel/sec graphics engine for 2D graphic acceleration, BCM7228 lets satellite TV operators roll out advanced services and HD satellite broadcast transmissions via integration of Audio Video Coding Standard (AVS+) decompression. Chip also provides Conditional Access and Digital Rights Management security. Along with 1080p AVS+ decode and display capabilities, features include 16-bit DDR3 support and support for China DTH tuner/demodulator.
Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Mobile SoCs optimize LTE broadcast capabilities.

March 11, 2015

Equipped to support eMBMS evolved Multimedia Broadcast and Multicast Service technology, ARMADA® PXA1802, PXA1920, PXA1928, PXA1908, and PXA1936 enable smartphones, mobile hotspots, and home gateways to play multicast video streams starting with Android L operating system support. eMBMS provides effective and efficient way to multicast streams on single frequency LTE networks to satisfy growing convergence of linear TV and on-demand content over mobile networks. Read More

Electronic Components & Devices, Computer Hardware & Peripherals

Ultra HD SoC Devices integrate MoCA 2.0 IP interface.

March 9, 2015

Designed for connected home gateways and IP clients, Models BCM7448S and BCM7449S support multiple Ultra HD video compression standards for operators and manufacturers to deliver variety of 4K content to home subscribers. Chips feature dual core ARMv7 32-bit CPUs, Ultra HD HEVC and VP9 p60 decoding, and mobile applications compatible OpenGL ES 3.1 3D GPU. In addition, SoCs provide advanced content security technology, including watermarking and DCAS cardless security. Read More

Computer Hardware & Peripherals

Imaging IP enables human-like intelligent vision processing.

March 3, 2015

Supporting real-time 3D depth map and point cloud processing for 3D scanning, CEVA-XM4 aids implementation of energy-efficient, human-like vision and visual perception capabilities in embedded systems. Programmable wide-vector architecture features fixed- and floating-point processing, multiple simultaneous scalar units, and vision-oriented instruction set. Parallel random memory access and 2D data processing scheme enable 4,096-bit processing in single cycle with memory bandwidth <512 bits. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

HMI Embedded Video Engines offer 800 x 600 pixel resolution.

March 3, 2015

With optimized algorithms for smooth video playback, FT81xQ Series provides up to 1 MB memory capacity and quad SPI interface that accelerates data transfer rates. Multiple palettes are supported, covering 16-bit and 32-bit colors with transparency. Screen rotation through 90° permits both landscape and portrait orientations. Offering resistive/capacitive touch functionality, Models FT810Q/FT811Q have 18-bit RGB interfacing while Models FT812Q/FT813Q have 24-bit RGB interfacing. Read More

Computer Hardware & Peripherals

Low Power Audio/Voice DSPs supports EVS codec.

February 26, 2015

CEVA-TeakLite DSPs support Enhanced Voice Services (EVS) codec, which is backwards-compatible with AMR Wideband (AMR-WB) and Narrowband (AMR-NB) standards and delivers optimized voice and audio quality on any cellular network. For existing licensees of CEVA-TeakLite DSPs, including CEVA-Teaklite-III and CEVA-TeakLite-4 DSPs, EVS can be quickly added to baseband processors to upgrade voice experience. Read More

Computer Hardware & Peripherals

PCIe Video Card supports multi-display digital signage.

February 13, 2015

With quad outputs, Model C420 drives up to 4 displays or projectors at resolutions up to 2560 x 1600 per output. Two cards together can drive 8 displays from single system. Secure Mini DisplayPort connectivity prevents loose cabling, while 2 GB of on-board memory ensures smooth video playback and graphics performance. Featuring fanless, low-profile design, C420 is suited for SFF systems and digital signage PCs used for public information displays, video walls, and multi-display workstations. Read More

Vision Systems, Robotics, Computer Hardware & Peripherals

Vision Processor enhances fixed industrial robot functionality.

February 9, 2015

Optimized for continuous use in factory environments,, Adept SmartVision MX can add vision guidance and inspection to industrial robot applications. Unit features Intel® Core® i7 CPU, SSD, fanless architecture, and operating temperature range suited for industrial use. Compatible with machine vision cameras offering diverse resolution options in color or monochrome, device is equipped with Gigabit Ethernet ports with PoE and USB 3.0 ports to concurrently accommodate up to 8 cameras. Read More

Computer Hardware & Peripherals

Blade Workstations integrate PCoIP technology.

February 4, 2015

Based on Dell® M630 and supporting up to 2 Intel® Xeon™ E5-2600 v3 processors, DXM630 PCoIP® Blade Workstation delivers true 64-bit workstation OS on server-grade hardware with as many as 36 cores. System supports 768 GB of DDR4 memory and integrated solid state drives. Up to 16 workstation blades can be installed in only 10U of rack space. For virtualized environments, DXM-A variant provides PCoIP hardware offload processing power to optimize frames per second delivered to end point. Read More

Computer Hardware & Peripherals

Embedded XMC features AMD 6-head GPU.

January 30, 2015

Based on AMD's Radeon E8860 GPU, featuring 2 GB of GDDR5, Model M596 is capable of routing simultaneous digital and analog streams in multiple output formats. XMC integrates graphics language acceleration, parallel processing engines as well as video and audio decompression units. It also supports advanced graphics and video standards including DirectX, OpenGL, and Shader. With rugged design, XMC is suitable for harsh environments that have versatile video overlay and capture requirements. Read More

Computer Hardware & Peripherals

Ethernet Accelerator helps transition to 10 and 100G networks.

January 23, 2015

Providing 100 Gbps capture with zero packet loss, PCI-SIG®-compliant NT100E3-1-PTP assists network appliance manufacturers as they make transition from 1 to 10 and 10 to 100 Gbps networks. One-port unit helps users understand and identify specific data by enabling analysis in real-time for applications that require 100 Gbps connectivity. Accelerator offers time-stamping of every Ethernet frame with nanosecond resolution, plus flexible support of multiple time synchronization schemes. Read More

Computer Hardware & Peripherals

Wi-Fi Processor supports 160 MHz bandwidth.

January 8, 2015

Combining 802.11ac Wave-2 4x4 processor with beamforming and MU-MIMO support, Avastar® 88W8964 achieves 2.6 Gbps peak data rate for high speed and secure access points and smart gateways. MU-MIMO allows simultaneous and concurrent sessions from one access point to several client devices, while beamforming enables seamless streaming of HD video in locations where devices could previously maintain only minimal connection to network. In addition, 802.11mc provides precision location capability. Read More

Computer Hardware & Peripherals, Electronic Components & Devices

HEVC Set-top Box SoCs feature integrated 4x4 5G Wi-Fi.

January 8, 2015

With integrated MHL 2.0, Models BCM7250 and BCM72502 bring full-featured set-top box functionality to OTT streaming media player and HDMI stick formats, respectively. Units provide 2x2 and 4x4 5G WiFi connectivity options via high-speed PCIe interface. Chips' 4x4 5G WiFi option is powered by BCM4366 4x4 MU-MIMO device, which enables broadcast-quality video delivery over Wi-Fi. SoCs also integrate 6000 DMIPS B15 ARMv7-A CPU, 1.0 Gpix/s OpenGL ES 3.0 3D GPU, and HEVC decoder. Read More
