Transceiver Antenna System fosters SBD communication integration.
Hirschmann Car Communication GmbH
Sep 15, 2014
Engineered for tracking and telemetry systems, magnetic and adhesive mount Iridium Transceiver Antenna System (ITAS-m/a) can communicate outside of traditional cellular networks (or terrestrial communication networks) by utilizing Iridium's 66 Low Earth Orbiting satellites to provide global service. Plug-and-play unit, which can accelerate satellite communication market introduction, contains antenna, Iridium 9602 SBD modem, power regulation, and serial communication interface in one housing.
Wireless Charging/NFC Reference Design is automotive ready.
Concord, NH 03301
Sep 03, 2014
Built around MLX90132 NFC Transceiver IC and Freescale MWCT1003AVLH controller IC, WCT-5WTXAUTO initially targets automotive console applications. Solution includes all required hardware and associated software drivers to allow fully autonomous behavior of wireless charging subsystem as controlled via NCI (NFC Controller Interface). Automotive-grade NFC transceiver with Freescale Semiconductor wireless charging technology could eliminate low battery warning.
Rugged Dual 4GSPS Transceiver Card targets C4ISR applications.
Lyndhurst, NJ 07071
Aug 27, 2014
Along with 12-bit ADC configurable with two 4 GSPS channels or four 2 GSPS channels, VPX3-530 dual-channel ADC/DAC engine provides 2 channels of 14-bit DAC data conversion at up to 5.6 GSPS. This SWaP-optimized, 3U OpenVPX™ transceiver card provides user-programmable Xilinx® Virtex®-7 FPGA to couple ADC and DAC channels, which minimizes latency between inputs and outputs. To form array of synchronized analog inputs, card can be scaled for multi-board, multi-channel synchronization.
LIN Transceiver IC targets multi-LIN master systems.
Concord, NH 03301
May 19, 2014
Produced in 0.35 micron HV-CMOS technology, Model MLX80002/4 combines 2 or 4 LIN transceivers, respectively, on one die, enabling development of multi-LIN network master modules. Device features integrated 1 kΩ LIN master termination resistors and decoupling diodes, meets automotive temperature range of -40°C to +125°C, and has on-chip protection against over-temperature, 40 V load dump, and LIN short to ground. For data transmission according SAEJ2602, special low slew mode is available.
Virtex-7 Transceiver Board suits communication, radar systems.
Upper Saddle River, NJ 07458
Apr 30, 2014
As 2-channel, wideband transceiver 3U VPX board based on Xilinx Virtex-7 FPGA, Onyx® Model 52751 is suitable for connection to HF or IF ports of communication or radar systems. Along with built-in data capture and generation features, board includes two 500 MHz 12-bit ADCs followed by 2 DDCs and two 800 MHz, 16-bit DACs with DUC. Programmable decimation and interpolation ranges for each DDC and DUC cover transceiver signal bandwidths from 4 kHz to 200 MHz.
Half-Duplex RS-485 Transceivers support up to 10 Mbps data rates.
Fremont, CA 94538
Apr 15, 2014
Supplied in 8-pin NSOIC packages, XR33032/5/8 are optimized to operate over 2.8–5.5 V supply range and suited for isolated applications where remote devices are powered through cable. Products tolerate voltage drop along cable resistance while maintaining compliant RS-485 output levels and performance. Drawing 300 µA typ when idling with receivers active, transceivers offer ±18 V fault tolerance for direct shorts to DC or AC, ±70 V transient protection, and exceed highest ESD rating of IEC 61000-4-2 Level 4.
Ethernet Transceiver supports 10 Gbps data rates.
Marvell Semiconductor Inc.
Santa Clara, CA 95054
Mar 21, 2014
Housed in 23 x 23 mm package, Alaska® X 88X3240P 4-Port Ethernet PHY brings benefits of IEEE 10GBASE-T standard to equipment ranging from data center and enterprise switches to storage and server equipment. Unit delivers 10 Gbps Ethernet connectivity over unshielded twisted-pair copper cabling, adhering to structured wiring rules and distances in excess of 100 m. Single chip, 28 nm monolithic device features Energy Efficient Ethernet, IEEE 1588 PTP, and MACsec link security encryption support.
SDR Platforms facilitate system prototyping/development.
Analog Devices, Inc.
Norwood, MA 02062-9106
Mar 07, 2014
Able to be software-configured for RF performance in 2,400–2,500 MHz region or for wide tuning over 70 MHz to 6 GHz range, AD-FMCOMMS4-EBZ includes AD9364 RF Transceiver IC in 1 x 1 SDR rapid prototyping FMC module. Built around AD9361 RF transceiver on 2 X 2 SDR rapid prototyping module, AD-FMCOMMS3-EBZ transceiver FMC module is engineered for 70 MHz to 6 GHz wideband tuning applications. Both modules include all HDL code and device drivers needed to get SDR platform up and running.
Vector Signal Transceiver features 200 MHz RF bandwidth.
National Instruments Corp.
Austin, TX 78759-3504
Mar 05, 2014
Combining vector signal analyzer with vector signal generator and user-programmable FPGA, NI PXIe-5646R is suitable for testing wireless standards such as IEEE 802.11ac, 160 MHz WLAN, and LTE Advanced. Engineers can use open software design of transceiver to develop channel emulation systems, radio prototyping, and custom real-time signal processing for spectrum analysis. Built on NI LabVIEW RIO architecture, NI PXIe-5646R offers 200 MHz of complex bandwidth via sample rate of 250 MS/s.
Complete RF Front End is offered for 4G world phones and tablets.
Greensboro, NC 27409
Mar 04, 2014
Integrating all transmit and receive RF functionality, from transceiver to antenna, RF Fusion helps reduce board space within, and accelerate implementation of, global 4G world phones and tablets. PA efficiency (APT- and ET-enabled), cellular switching performance, and filtering and duplexing (BAW and SAW) optimize system-level performance. Model RF7503 supports full global coverage of all major cellular networks, from 2G to 4G, in miniature, integrated package.
Software Defined Radio features MiniPCIe card format.
Schaumburg, IL 60173
Mar 04, 2014
Measuring 31 x 50 x 5 mm, Sidekiq supports operation as 2-channel phase coherent RF receiver or as single-channel RF transceiver providing independently tunable RF transmitter and receiver. Tuning range for RF transmitter and receiver covers 70 MHz to 6 GHz frequency range, supporting RF channel bandwidths up to 50 MHz. On-board Xilinx Spartan® 6 LX45T FPGA provides reconfigurable logic for signal processing tasks, as well as high-speed PCIe interface for performing low latency data transfer.
Wireless Backhaul SoC offers software defined radio platform.
Texas Instruments, Inc. (TI)
Dallas, TX 75243-4136
Mar 03, 2014
Together with AFE7500 analog front end transceiver, Model TCI6631K2L offers 2-chip solution that covers non-line-of-sight spectrum from TV white space to 6 GHz and line-of-sight up to 86 GHz. TCI6631K2L leverages dual ARM® Cortex®-A15 RISC processors and 4 fixed- and floating-point TMS320C66x DSP generation cores as part of KeyStone SoC architecture supporting L1/L2/L3 and transport processing. Interfacing to TCI6631K2L via JESD204B connection, AFE7500 supports wideband 2x3 MIMO configuration.
Multiprotocol Transceiver supports data rates up to 20 Mbps.
Fremont, CA 94538
Feb 19, 2014
Housed in 5 x 5 mm, 32-pin QFN package, Model SP335 supports RS-232, RS-485, and RS-422 serial standards. Programmable end-of-line termination and multiple configuration modes allow all 3 protocols to be used interchangeably over single cable or connector with no additional switching components. Supporting data rates up to 20 Mbps in RS-485/422 modes (1 Mbps in RS-232), transceiver can be slew limited to 250 kbps in any mode by toggling single control pin.
MIMO Radio Transceiver supports military applications.
Doodle Labs LLP
Feb 14, 2014
Consisting of Tri-band, 3 MIMO stream wireless adapter in miniPCI Express form factor, Model ACM-TB-3 features near line-of-sight, self-adapting multi-rate OFDM technology and complies with IEEE 802.11ac standard. Unit can provide up to 1.3 Gbps radio data rate and enables next-generation IP applications to stream video, data, and voice. Operating from -40 to +70°C, COTS transceiver includes integrated LNA and highly linear PA that provides EVM signals for 256 QAM and up to 28 dBm of RF power.
Front-End Subsystems span 100 MHz to 6 GHz frequency range.
Doodle Labs LLP
Jan 14, 2014
Integrating super heterodyne frequency translator technology, Prism FES Series optimizes operating range, receive sensitivity, and interference rejection characteristics of wireless adapters used in wireless communication standards like WLAN. Full-duplex systems provide complete bi-directional transmit and receive paths from wireless adapter to antenna with 50 Ω input/output matched ports. Operating from -40 to +70°C, systems come in low, medium, and high RF power models up to 30 dBm at 16 QAM.
Communications Adapter enabels CFP2 testing on CFP-based modules.
Quebec G1M 2K2 Canada
Dec 12, 2013
CFP-to-CFP2 adapter enables FTB/IQS-88100NGE Power Blazer and FTB/IQS-85100G Packet Blazer to cover 100G testing capabilities — including 100G Ethernet (as per IEEE 802.3ba) and OTN (as per ITU-T G.709) — on second-generation CFP2 high-speed optics. While 100G transport solution supports both CFP and CFP2 interfaces on same hardware, adapter delivers flexibility to support industry's two implementations of 100G transceivers: 4 x 25G and 10 x 10G.
RS-485/RS-422 Transceivers offer ±18 V fault tolerance.
Fremont, CA 94538
Nov 19, 2013
Operating from 3.3 V with 300 µA idle current, XR3070-78X Series includes 9 models that support data rates up to 20 Mbps in either full or half duplex configurations. Analog bus pins can withstand direct shorts up to ±18 V and are protected from ESD events exceeding IEC Level 4. Featuring ruggedized design for harsh industrial environments, transceivers are suited for energy metering, building automation, security systems, process control, and industrial automation applications.
RF Transceiver targets software-defined radio designs.
Analog Devices Inc
Norwood, MA 02062
Oct 29, 2013
Operating from 70 MHz to 6 GHz, AD9361 RF Agile Transceiver integrates RF front end, mixed-signal baseband section, frequency synthesizers, 2 ADCs, and 2 direct conversion receivers. Unit supports channel bandwidth from less than 200 kHz to 56 MHz. Housed in 10 x 10 mm CSPBGA package, device enables programmable radio applications that operate over wide range of modulation schemes and network specifications such as defense electronics, instrumentation equipment, and communications infrastructure.
ISM Band RF Transceiver employs FHSS technology.
Chesterfield, MO 63017
Oct 18, 2013
Supplied in 4.4 x 2.7 x 1.4 in. diecast enclosure, CL024 operates in license-free 2.4 GHz Industrial, Scientific, and Medical (ISM) band. Radio utilizes Server/Client architecture for point-to-point or point-to-multipoint communications with unlimited number of Clients in network, API commands to control packet routing, and communication with serial UART speeds up to 460.8 Kbps. RS232 interface allows integration with legacy data systems, and conducted output power is rated up to 125 mW.
Octal Ultrasound Transceiver features low-noise design.
Maxim Integrated Products
Sunnyvale, CA 94086
Oct 04, 2013
Housed in 10 x 26 mm BGA package, Model MAX2082 replaces thousands of discrete components in any ultrasound system. Device integrates 8 channels of 3-level 200 V pulsers and T/R switches, octal ADC, octal LNA, octal VGA, CW mixers, anti-aliasing filters, and coupling capacitors into single package. Operating from 0–70°C, IC provides ultra-low noise figure of 2.8 dB at RIN = RS= 200 Ω and high dynamic receiver with 76 dBFS SNR at fIN = 5 MHz and 2 MHz bandwidth.
