Cable Testers

Computer Hardware & Peripherals, Optics & Photonics, Test & Measuring Instruments

Tier 2 Fiber Optic Cable Tester simplifies troubleshooting.

July 15, 2016

In addition to accurate test data, OTDR II offers automated fault-finding capabilities that help minimize network downtime. With touch of button, intelligent Optical Link Mapper turns complicated graphs into easy-to-read diagram displaying all events along link with pass/fail results. System’s advanced algorithms also prevent common OTDR testing challenges, such as wrong OTDR traces. Handheld and lightweight, rugged tablet-style tester offers outdoor-enhanced touchscreen. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

TDR Cable Analyzer measures frequency domain S-parameters.

June 23, 2016

Featuring portable design, CT100B TDR Cable Analyzer provides step TDR impedance waveforms with resolution sufficient to show connector detail (~1 cm). Unit is also capable of making calibrated frequency domain S-parameter measurements, including return loss (S11) and cable loss/insertion loss (S21). Fully re-engineered sampling engine allows for waveforms up to 1.5 million points long, while subpixel sampling ensures that every detectable cable fault is visible at every horizontal scale. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Test & Measuring Instruments

W. L. Gore & Associates, Inc. Introducing High-Frequency Solutions at IMS 2016

May 23, 2016

New cable assembly products solve 70 GHz challenges. LANDENBERG, Pa. - W. L. Gore and Associates (Gore) has continuously expanded the company's microwave/RF solutions at higher frequencies by designing cable assemblies that are reliable and will perform over time, and Gore is now addressing industry requirements for enhanced performance in the 60-70 GHz range.At the 60-70 GHz range, there... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Micro-Hardness Testers suit quality control applications.

May 13, 2016

Featuring adjustable 7 in. color touchscreen, Wilson® VH1102 and VH1202 offer deadweight loads from 10 g to 2 kg and 9 automatically selectable loading stages. VH1102 is equipped with turret providing 4 positions, including indenter for Knoop or Vickers and 2 standard objectives for 10x and 50x magnification at normal working distance. VH1202 features 6-position turret, including 2 indenters for both Knoop and Vickers, and additional objective with 5x magnification at long working distance. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

CableEye Upgrade Program Announced - Upgrade Original Serial Port Testers to USB Interface

November 11, 2015

CAMI Research Inc. (Acton, MA) is offering a comprehensive upgrade program to owners of its original (serial port) M2 and M3 testers that will help expand test capabilities and productivity. These systems were manufactured between 1997 and 2010, and this program is typical of the company's dedication to delivering excellent and sustained customer service. Serial port to USB upgrade orders... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

CableEye® Testers offer Asymmetric, Absolute, and Percentage Tolerancing for Resistance Measurements

November 9, 2015

CAMI Research Inc. (Acton, MA) offers a comprehensive tolerancing option to its standard CableEye cable and harness testing system Graphical User Interface (GUI). The intuitive, graphic-rich GUI provides a clear simple operator interface and, for resistance measurements, may be user-set asymmetrically in either absolute or percentage parameters. Comprehensive Tolerancing A leader in... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Test Kit combines network testing and cable verification.

October 2, 2015

Featuring handheld design with full-color display, Net Prowler™ Pro Test Kit combines network testing, IP device address mapping, cable troubleshooting, and PoE voltage testing — all with capability of saving and printing results from PC. Tester measures cable length using TDR technology and generates tone levels for signal tracing and cable identification. Unit enables quick identification of network drops link capability and current link status as well as presence of PoE on network drop. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

U.S. Navy Chooses MOHR TDR for Cable Testing Applications

June 12, 2015

RICHLAND, Wash. – MOHR Test and Measurement LLC (MOHR), a supplier of precision time-domain reflectometry (TDR) instrumentation, announced it has won a 5-year contract award from the U.S. Navy to supply high-resolution portable TDR cable testers. The contract is worth an estimated USD$5.3 million at commercial pricing. The Naval Supply Systems Command (NAVSUP) selected MOHR's new... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Cable and Harness Tester offers Japanese language option.

June 12, 2015

CableEye® Testing System is available with graphic-rich GUI, which may be user-set to any of 7 global languages, including ENG, ESP, DEU, FRA, TUR, CHN, and JPN. Translated by native speakers to ensure clarity, all language options are provided in CableEye’s standard software as well as PinMap™, Connector Designer™, Autobuild™, and Exporter. Language setting affects anything presented on screen, such as standard comprehensive reports, color-coded net lists, scripting, and cable database entries. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Connector Board trains new users on cable testing system.

May 28, 2015

Populated with common connectors, Model CB-T1 allows trainees to methodically experience how CableEye cable and harness testing system responds to opens, shorts, miswires, diodes, resistance, and intermittent connections while simultaneously learning to operate tester. Board comes with identification LEDs for each connector that may be used to show trainee operator which connector she/he must connect. Rated to 250 Vdc/200 Vac, CB-T1 may be used on all CableEye Testers. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Test Kit combines network, cable, and voltage testing.

May 20, 2015

Combining network testing (physical layer and link), IP device address mapping, cable troubleshooting, and PoE voltage testing in handheld tester with full-color display, Net Prowler™ Pro Test Kit can save and print test results from PC. System will display wire map, numbered ID remotes, and any faults. Using TDR technology, Net Prowler™ measures cable length and generates tone levels for signal tracing and cable identification on all pairs, selected pair, or selected pin. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Cable Testers support snap-on video test modules.

April 13, 2015

Intended for video installation and maintenance professionals, LVPro20, LVPro30, and LVPro30SR have backlit screens and re-designed back panel, software, and electronics that enable snap-on adapter module. Video Test Module snaps on to back of testers, hijacking user interface to run host of tests on BNC, RG6, RG59, or HDMI cable, including signal level and loss, transmitter mapping, and cable length and quality. It will also generate color-bar test pattern for HDMI display testing. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

IP Camera/Ethernet Port Testers facilitate field work.

April 10, 2015

IP Answer Stick™ enables IP camera installers to align and focus IP camera from any terminus along data cable. Unit passes IP power through to camera and has port to connect notebook computer for monitoring and control. Solution additionally allows configuration of router or other access point from its location. Testing RJ45 Ethernet ports for presence of end- or mid-span DC power, PoE-Bug™ enables installers and repairmen to preempt potential PoE-related damage to equipment. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Handheld Tester combines multiple functions.

March 9, 2015

Equipped with full-color display, Net Prowler™ Pro Test Kit combines physical layer and link network testing, IP device address mapping, cable verification and troubleshooting, and PoE voltage testing. Unit provides full cable testing on any category network, coax, or telephone cable. Capable of saving and printing test results from personal computer, tester will display wire map, numbered ID remotes, and any faults, including shorts, opens, miswires, split pairs, and reverses. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Multifunctional Cable Tester incorporates full-color display.

February 16, 2015

Within one handheld unit, Net Prowler™ Pro Test Kit combines network testing (physical layer and link), IP device address mapping, cable troubleshooting, and PoE voltage testing. Functionality supports full cable testing on any category network, coax, or telephone cable, and display shows wire map, numbered ID remotes, and any faults. Network tests can also be saved for record keeping and printing using companion software application. Read More

Automatic ID, Computer Hardware & Peripherals, Test & Measuring Instruments

Handheld Analyzers offer 2 cable test options.

February 9, 2015

With Time Domain Reflectometry option, FieldFox Handheld Analyzers become suitable tool for any cable system test. Option measures impedance changes along cable and helps identify specific faults. FieldFox Extended Range Transmission Analysis option enables users to measure in-situ, long lossy microwave cables. With this option, 2 FieldFox instruments are deployed at each end of measured cable. One analyzer acts as source, while other acts as receiver. Read More

Computer Hardware & Peripherals, Electrical Equipment & Systems, Electronic Components & Devices, Portable Tools, Test & Measuring Instruments

Southwire Launches 42 New Voice-Data-Video Tools

September 9, 2014

New VDV Tools Meet Key Installer Needs and Expand Southwire Tools & Equipment Line CARROLLTON, Ga. -- Southwire will unveil a new line of over 40 voice-data-video (VDV) tools at CEDIA Expo 2014, a showcase for new audio, video, control, networking and lighting products taking place in Denver from Sept. 10-13. The new VDV tools complement Southwire's full line of Low-Voltage cable... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Cable Test Kit measures length and identifies link status.

September 2, 2014

Featuring full color graphical display, Cable Prowler™ Pro Test Kit provides full cable testing, displaying wire map, numbered ID remotes, and determining faults. Tester also measures cable length, generates tone levels, and identifies network drops, link capability, and current link status. Users can save results as well as export to computer via micro USB cable for record keeping and printing. For security and powered networking applications, Cable Prowler detects presence of PoE. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

GOEPEL Electronic Establishes Boundary Scan Technology in Asia

August 26, 2014

GOEPEL electronic announces another strategic partnership in the Asian region, by the inclusion of the Chinese technology company Pansino Solutions, into the GATE Alliance Program (GOEPEL Associated Technical Experts). The main focus of the cooperation is special application development and practical implementation of new JTAG/Boundary Scan solutions as well as their integration into existing... Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Multifunctional Cable Tester serves voice/data/video projects.

July 28, 2014

While able to test continuity on voice (RJ11/12), data (RJ45), and video (F-connector) connections, Scout® Pro 2 Series also locates cable runs with location ID remotes, supports multiple tones to decipher wires, and can measure cable length to fault, on reel, or in box. LT models can measure cable length in feet or meters, and all models work with Test-n-Map™ remotes, which test, map, and identify location in one step. Read More
