Compact Directional Coupler operates over 12.4-18.0 GHz range.

September 30, 2014

With stripline design, Model 181206 delivers 6 dB (±0.5 dB) of nominal coupling, with respect to output, and frequency sensitivity of ±0.30 dB. Directivity is >15 dB; and insertion loss is <1.9 dB across full frequency range, including coupled power; max VSWR at any port is 1.35; and input power rating is 20 W average and 3 KW peak. Measuring 1.40 x 0.40 x 0.66 in., directional coupler comes standard with SMA female connectors but supports various connector options. Read More

Communication Systems & Equipment

HEVC Decoder targets programmable SoC devices.

September 30, 2014

Partitioned optimally into ARM Cortex-A9 Software and FPGA Hardware on Xilinx Zynq-7000 All Programmable SoCs, Hybrid HEVC (H.265) Decoder enables flexible, highly integrated video systems. Since decoder only uses portion of FPGA logic resources on Zynq-7000 SoC, remaining hardware resources can be used to integrate external display interfaces like DisplayPort, SD/HD/3G-SDI, and LVDS for single or multi-panel displays. Decoder is compliant to HM version 13.0 and scalable from HD to Ultra HD. Read More

Communication Systems & Equipment, Optics & Photonics, Electronic Components & Devices

Transimpedance Amplifier targets optical networking systems.

September 29, 2014

Intended for 100G optical networking market, 4-channel ONET2804T provides less than 2 µA input-referred noise and virtually no cross talk between channels. Internal circuit provides photodiode reverse bias voltage and senses average photocurrent supplied to each photodiode. Available in 750 µm channel-pitch bare die, TIA serves parallel optical interconnects in applications with data rates up to 28 Gbps, such as optical line cards, point-to-point microwave backhauls, and video over fiber. Read More

Electronic Components & Devices, Communication Systems & Equipment

Low-Noise L-Band VCO comes in 0.5 x 0.5 x 0.22 in. package.

September 25, 2014

Operating at 1,878–1,879 MHz with 1–4 Vdc tuning voltage range, ceramic resonator-based CRO1878A-LF features SSB spectral purity of -138 dBc/Hz @ 100 kHz offset and operates with average tuning sensitivity of 5 MHz/V. RoHS-compliant VCO delivers 4±2 dBm of output power into 50 Ω load while operating off 5 Vdc supply and drawing 25 mA typ. Operating from -40 to 85°C, low-noice VCO pushes <0.5 MHz/V and pulls <0.5 MHz with 12 dB return loss. Typ second harmonic suppression is -20 dBc. Read More

Communication Systems & Equipment, Optics & Photonics

Serial Data Link Products withstand severe-duty conditions.

September 25, 2014

Serving as direct replacement for Garrettcom/Dymec5800 series of serial data over optical fiber products, Reliance RLFDX Series includes substation-rated fiber optic RS-232, RS-422, RS-485 2/4 Wire as well as TTL Logic Data Link/Repeater. Products can transmit serial data up to 30 Km and feature electrical isolation. Areas of use include such electric power transmission and utilities, factory floor, water treatment, petroleum refining markets, and all out-of-plant installations. Read More

Communication Systems & Equipment

Fixed Frequency Synthesizer focuses on phase noise performance.

September 24, 2014

Measuring 1.0 x 1.0 x 0.22 in., SFS12000H-LF generates output signal at 12 GHz while fixed to external 100 MHz reference oscillator. X-Band PLL is enhanced by phase noise performance of -98 dBc/Hz at 1 kHz and -103 dBc/Hz at 10 kHz offset. Delivering nominal output power of 0 dBm into 50 Ω load, RoHS-compliant product operates with 5 Vdc VCO supply while drawing 85 mA typ and 3 Vdc PLL voltage while drawing 40 mA typ. Harmonic suppression is -30 dBc, and spurious suppression is -65 dBc. Read More

Test & Measuring Instruments, Electronic Components & Devices, Communication Systems & Equipment, Electrical Equipment & Systems

Analog-to-Digital Converters offer speeds up to 160 MSPS.

September 23, 2014

Offering 12- and 14-bit options, ADC3k Series is available with 2 or 4 channels, speeds from 50–160 MSPS, and either LVDS or JESD204B interfaces. JESD204B variants are compliant with subclass 0, 1, and 2 at up to 3.2 Gbps. At fastest sampling rate of 160 MSPS, devices use only 200 mW/ch. Converters support industrial ambient temperature range of -40 to 85°C for use in motor control, medical imaging, and portable test and measurement, as well as defense and communications applications. Read More

Communication Systems & Equipment, Electrical Equipment & Systems

SP4T Broadband RF Switches consume 120 µA.

September 23, 2014

Delivering alternative to GaAs technology, PE42542 and PE42543 are based on UltraCMOS® technology and offer bandwidth that maintains performance across 9 kHz to 18 GHz range. Respective values for PE42542 and PE42543 include linearity of 58 and 59 dBm IIP3 (118 and 113 dBm IIP2), switching time of 3 µsec and 500 nsec, and ESD ratings of 3.5/2.5 kV HBM, 150 V MM, and 500/250 V CDM on all pins. Settling time of 7 µsec (PE42542) eliminates gate lag, and PE42543 has 2 µsec settling time. Read More
