Bunting Magnetics Co.
Newton, KS 67114
Feb 02, 2006 Featuring neodymium magnets, NEO FF Series Drawer Magnet captures and holds small ferrous metal particles. EPDM drawer gasket resists heat aging and magnetic latch keeps No-Spill(TM) Slide Gate open under high vibration conditions. Mountable at injector throat and locked in place by high-torque nylon knobs, unit features SS housing and center drawer guide that facilitates easy removal and reinstallation of magnet drawer.

Power + Energy, Inc.
Ivyland, PA 18974
Feb 01, 2006 Based on palladium alloy membranes, commercial hydrogen separators are able to tolerate and remove sulfur from reformed fuel streams. Separators are designed to be coupled with fuel reformers, including methanol, ethanol, natural gas, propane, ammonia, gasoline, and diesel fuels. Membranes also provide capability to separate hydrogen from alternative fuels such as land-fill gases, synthesis gases, and biomass digesters.

Kason Corporation
Millburn, NJ 07041
Jan 27, 2006 Dust-tight Batch Sifter, constructed with stainless steel housing, motor, and stand, is offered in 18, 24, and 30 in. dia and can be equipped with single or twin imbalanced-weight gyratory motors. With gap-free flange arrangement, unit scalps oversize particles down to 38 microns from dry bulk powders or solids-laden slurries and may be disassembled without tools for sanitizing. Wire mesh screening material is offered in 304, 316, and magnetic 400-series stainless steel.

Rotex, Inc.
Cincinnati, OH 45223 1845
Jan 17, 2006 Measuring 10 x 10 x 12 ft, MEGATEX(TM) Screener provides 100-350 ft² of screen surface and evenly splits and distributes incoming flow of material to multiple, stacked 5 x 7 in. screen decks. Optional aspiration doors remove troublesome chaff that can contaminate surrounding environment and clog other pieces of equipment during load-out process. Doors can be built into new machine or provided as retrofit upgrade.

Tecan
Rancho Santa Margarita, CA 92688
Jan 13, 2006 Made via Photo ElectroForming (PEF) process, single-layer sieves and meshes ensure no sieved material is trapped during sieving, filtering, or grading. Meshes can be produced with aperture shapes and sizes relevant to application-specific particles, with aperture tolerances from ±2 microns. While offering consistent cross-sectional thickness, design can incorporate solid portions such as lateral supports. Products are supplied as flat sheets, flexible membranes, or 3D forms.

Dana Corp.
Toledo, OH 43697
Dec 16, 2005 Designed to help meet global emissions standards, MultiTwister(TM) axial cyclonic air/oil separator helps vehicles run cleaner by removing oil particles from engine's air stream. Double helix channels create spiral flow, which develops centrifugal forces that cause oil to coalesce along channels where it separates droplets from engine's airflow. Captured oil is returned to engine crankcase, eliminating excess oil from combustion process.

Rotex, Inc.
Cincinnati, OH 45223 1845
Nov 17, 2005 Designed to minimize blinding and bridging when screening difficult or sticky materials, Ultrasonex(TM) screens through meshes as fine as 20 µm. Transducer probe applies ultrasonic vibration directly to screening mesh in addition to vibratory motion of screener. Fully detachable probe incorporates titanium core for non-wear on contact surfaces. Featuring touch panel controls, Ultrasonex is available on new screeners and can be field retrofitted to existing screeners.

Rotex, Inc.
Cincinnati, OH 45223 1845
Nov 11, 2005 Designed to maximize product recoveries at material temperatures up to 400°F, Minerals Separator(TM) features screen deck slope of 6° to meet glass, filter, and frac sand specifications. Elliptical-linear motion equally distributes materials to all screen decks, ensures uniform bed-depth across screen surface, and provides aggressive blinding control. Lift-Rail(TM) system with non-binding stainless steel cam activation facilitates screen frame installation and removal.

AGM Container Controls, Inc.
Tucson, AZ 85716
Nov 09, 2005 Offering single connection purging with automatic operation, portable, self-contained NEPS 1000 Advantage delivers efficient use of nitrogen, with minimized consumption, by measuring dryness of purge gas as it leaves system being dried. Suitable for pipeline and continuous dryers, as well as containers and enclosures, user-programmable unit features choice of 3 pressure cycles. Pressure readout and dewpoint monitor enable gas dryness to be checked before purging.

Franklin Miller Delumper Mixer Div.
Livingston, NJ 07039
Nov 02, 2005 SPIRALIFT SC adds benefits of in-channel auger screening system to existing mechanical bar screen installation. Bar screen automatically removes solids from liquid channel and deposits them by gravity into SPIRALIFT SC hopper. Solids are reduced to small size by TASKMASTER® grinder, and are then washed to remove contaminants and organics, compacted, and conveyed from system by shaftless screw unit. SPIRALIFT SC unit is freestanding and includes PLC-based control system.

Tema
Cincinnati, OH 45249
Nov 01, 2005 Conturbex Worm Screen Centrifuge features 100 µm or larger screen to remove up to 50% of remaining free moisture from crystalline material. Process works by screw feeding belt filter cake into center of continuously operating centrifuge. Centrifuge spins cake at up to 1,200 g, driving free moisture through screen and continuously discharging solids to dryer with lower moisture.

Parker Hannifin Corp., Tube Fittings Div.
Columbus, OH 43228 9698
Oct 28, 2005 Offering nominal ratings from 65-480 microns, Protective Screen Fittings are available in sizes -4 through -12 for use with Triple-Lok® 37° flare and Seal-Lok(TM) O-ring face seal fittings. Constructed with stainless steel screen elements, -4 size features basket-style screen, while remaining sizes are dome style. Screen fittings are suited for gauge and instrumentation protection, as well as shielding of critical hydraulic components.

Kason Corporation
Millburn, NJ 07041
Oct 25, 2005 Configured for installation on mezzanine, Low Profile Centri-Sifter(TM) removes oversize contaminants, de-lumps manually dumped bulk materials, and gravity-discharges into process equipment. Centrifugal action created by rotating helical paddles accelerates rate at which particles pass through horizontal screen cylinder while de-lumping soft agglomerates. Bag Dump Screener is stainless steel and finished to industrial, food, 3-A dairy, and pharmaceutical standards.

Flowserve Corporation
Irving, TX 75039
Sep 28, 2005 Available as either new equipment or as upgrade to existing hydraulic decoking systems, AutoShift(TM) combination cutting tool enables automation of hydraulic decoking operations. Mode shifting is accomplished remotely by water pressurization and depressurization, thus avoiding personnel exposure to high pressure water, hot spots or steam eruptions, hydrogen sulfide vapors, and mechanical hazards. Manual shift feature is also provided.

Kason Corporation
Millburn, NJ 07041
Sep 16, 2005 Equipped with single or twin imbalanced-weight gyratory motors, VIBROSCREEN® scalps oversize particles as small as 38 microns from dry bulk materials or solids-laden slurries. It meets cGMP, 3-A, USDA, and FDA standards and can be disassembled without tools for sanitizing. Offered with wire mesh screening in 304, 316, and magnetic 400-series stainless steel, unit is offered in 18, 24, and 30 in. dia. Crevice-free interior is finished to sanitary standards.

JWC Environmental
Costa Mesa, CA 92626
Aug 31, 2005 Combining rotating drum screens and Muffin Monster® grinder, Channel Monster® XD grinds difficult solids to manageable particle size, protecting downstream equipment and preventing pump blockages. Models with stack height greater than 32 in. feature 40000 Macho Monster grinder technology, with 2½ in. hex drive shafts and 7½ in. diameter cutters. Powered by 5, 10, or 15 hp motor, Channel Monster handles flows greater than 10 mgd.

Donaldson Co., Inc.
Minneapolis, MN 55440-1299
Aug 25, 2005 DS Series removes condensate from compressed air system, wherever it forms, and discharges it in environmentally sound manner. When oil is present, condensate is purified to 100 ppm levels of residual oil content before discharged to public water treatment systems. Compressed air condensate oil/water separators feature multiple condensate inlet ports, tapered carbon bag chambers, knob-adjustable oil skimming tray, and attached, hinged lid.

Kason Corporation
Millburn, NJ 07041
Aug 08, 2005 Circular Vibratory Fluid Bed Dryer-Screener System reduces bulk material moisture content, removes agglomerates and dust, and discharges on-size material into bulk bags. It consists of 18–84 in. dia circular fluid bed processor, heater, blower, and 18–100 in. dia circular vibratory screener. Vibration, induced by 2 vibratory motors and spring suspension, separates and fluidizes individual particles; undersize material is sent through spout for reprocessing.

GE Energy
Atlanta, GA 30339
Jul 08, 2005 Suited for oil and gas industries, SmartScan™ performs in-line corrosion inspection of pipelines deemed unpiggable because of valve restrictions, multiple pipeline diameters, or multiple sharp bends. Flexible structure allows it to navigate pipeline diameter variations from 16–20, 20–26, and 24–30 in. Operators can launch and receive SmartScan via use of hot tap access hole, which is drilled into pipeline walls without interruption of service.

Franklin Miller Delumper Mixer Div.
Livingston, NJ 07039
Jun 23, 2005 Suited for heavy, solids-laden wastewater applications, TASKMASTER TM1600 Grinders process gravity or conveyor fed sewage screenings and provide in-channel grinding as well as bulk solids shredding. Twin-shaft Model TM1634 features 16 x 34 in. cutting chamber, right angle planetary gear reducer, and counter-rotating shredding mechanism employing cutter cartridges. Hardened alloy 2¾ in. hexagonal shafting handles up to 15 hp motor and drives.
