Mott Corporation
Farmington, CT 06032 3159
Oct 15, 2009 Capable of accommodating flow rates of 300 and 650 sLpm in standard filter lengths of 3.31 or 5.0 in., respectively, High Flow Defender Series filters attain filtration efficiencies at 9 LRV (99.9999999% efficiency) down to 0.003 µm particles sizes. Porous metal filters are suited for use in semiconductor, flat panel display, and photovoltaic industries.

Water Maze Wash-Water Systems
Camas, WA 98607
Sep 29, 2009 Innovator Series is comprised of 4 modular products - EC2-20A treat and discharge system, CoAg2-20A chemical treatment system, Indexing Polishing Filter, and Clean Water Recycle Module - that can be used individually or together. Use of electro-coagulation and chemical treatment removes emulsified oils, heavy solids, and metals from industrial washing waste streams. Automated wastewater recycling equipment helps eliminate standing water in systems, which also eradicates odors.

AAF International
Louisville, KY 40223 6169
Sep 23, 2009 MEGAcel(TM) I filter with Helior(TM) ePTFE media is constructed with tapered aluminum separators to optimize pleat pack resistance. Its Helior HEPA/ULPA media is manufactured and tested in ISO Class 7 environment, eliminating any potential for contamination, and resists corrosion. Also, energy consumption is minimized due to low operating resistance. Filter is suited for healthcare, pharmaceutical, electronic, food processing, and laboratory environments.

Asahi/America
Malden, MA 02148
Sep 14, 2009 Designed for use when ball check valve is located in tank on suction side of pump, injected molded injection foot valve screens filter out larger debris before it can enter inside valve, pump, or process line. With no cemented joints or parts, units adapt to ball check valve using union nut. Screens are available in PVC, CPVC, PP, and PVDF, and in sizes ½ in. through 4 in. with flanged, socket, or threaded end connections.

Eaton Corp.
Cleveland, OH 44114
Aug 28, 2009 LOFMEM(TM) membrane filter; LOFPLEAT(TM) pleated filter; LOFTREX(TM) depth filter; as well as LOFSORB(TM), LOFMET(TM), and LOFCLEAN(TM) specialty filters handle range of liquid process applications. Absolute-rated LOFMEM provides sub-micron level filtration, while LOFPLEAT offers optimized surface area. Cylindrical LOFTREX has path designed to capture various particle sizes and gelatinous contaminants. Specialty models are constructed of extruded carbon, porous metal, and resin bonded materials.

Transor Filter U S A
Elk Grove Village, IL 60007
Aug 21, 2009 Replacing existing oil reservoir and pumps offered with grinder, Nano T Filtration System cleans oil to 1 micron, and, with integrated refrigerant system, controls oil temperature to ±0.2°C. Automatic backflushing procedure cleans filter elements and places debris in container for disposal or reclamation. Consisting of magnetic separator and mesh socks that remove large particles, MSK Combo pre-filter addresses applications involving magnetic materials or those with heavy stock removal.

Royal Products, Div. Curran Mfg. Corp.
Hauppauge, NY 11788
Jul 30, 2009 Equipped with curved drum vanes for optimal airflow, Filtermist FX Models have enlarged oil return channel, which allows units to process greater volume of liquid. Units effectively collect mist and smoke generated by all types of machines including CNC lathes, machining centers, grinders, screw machines as well as injection molding machines, gear hobbers, aqueous parts washers, and vacuum pumps.

Schroeder Industries LLC
Leetsdale, PA 15056-1025
Jul 13, 2009 Designed to eliminate 100% of free and 90% of dissolved water from small reservoirs, barrels, and gear boxes, Triton Dehydration Station(TM) utilizes proprietary design that reduces aeration of free and entrained gases of returned fluid. Patent pending mass transfer technology uses ambient air to optimize and control dewatering rates. Unit is portable using either central lifting port or optional cart to access tight areas.

Schroeder Industries LLC
Leetsdale, PA 15056-1025
Jul 13, 2009 Transfering fluid through 2 K9 filters in series for staged particulate or water/particulate removal, Filtration Station® is capable of flushing, filtering, and monitoring ISO cleanliness with user-defined, automatic features. It features water sensor that provides water saturation and temperature of fluid, both displayed through monitor. System runs continuously and displays ISO codes in manual mode, while in auto mode machine will run till required cleanliness codes are achieved.

Siemens Water Technologies
Warrendale, PA 15086
Jun 02, 2009 Pulsed-Bed Walnut Shell Filter utilizes 66 in. deep bed of 100% black walnut shells with surface characteristics suited for coalescing and filtration. Filter system uses raw process water and gas or air for backwashing. Process water passes through filter from top to bottom during filtration cycle and airlift pump, created by air or process gas, lifts contaminated media to vessel top where oil/solids are separated from shells with backwash water and gas.

Mott Corporation
Farmington, CT 06032 3159
May 11, 2009 Especially effective at preventing large particle agglomerations from migrating downstream, FLP Series accommodates high flow rates in very low pressure drop applications. Open media facilitates passage of low-pressure liquid source gas while having enough surface area to remove particles down to 0.003 µm. Constructed from 316LSS, filters can withstand elevated temperatures required to keep low-pressure gases and organometallics in vapor phase.

Algae-X International
Ft. Meyers Beach, FL 33932
May 01, 2009 Covering range of flow capacities and tank sizes, SMART FPS Series combines fully automated control and monitoring with fuel decontamination, water and sediment removal. Units function as on-board tank cleaning systems, and when used as fuel transfer systems, will supply completely clean and dry fuel to day tanks. Systems employ SFC-50 Smart Filtration Controller, which features programmable PLC with text interface, color-coded alarm indicator lights, and wiring harness.

Graver Technologies
Glasgow, DE 19702
Apr 10, 2009 Constructed of low carbon 316L SS, Aegis PowerGuard® stainless steel backwashable precoat septa incorporate Poroplate®, a sintered metal design that allows for precise control of porosity from 2 to 200 microns. Features include low pressure drop, elimination of contaminant leakage, resistance to corrosion and fatigue, and operating temperatures up to 1,000°F. Offering collapse strengths over 400 psid, septa are available as individual elements or as pre-assembled tube bundles.

Schroeder Industries LLC
Leetsdale, PA 15056-1025
Mar 17, 2009 Suitable for clearing up existing systems as well as for prefiltering new fluids for hydraulic systems, MFD Dual Filtration System features modular base that eliminates hoses and fittings between components, drip pan, and K9 base-ported filter housing. System produces just 72 dB at full load and comes equipped with D5 Dirt Alarm®, which indicates when filter element needs changing.

3M Co., Corporate Marketing & Public Affairs
St. Paul, MN 55144 1000
Mar 16, 2009 With absolute-rated performance from 1-70 µ, Cuno High Flow Triplex Skid is suitable for filtration of small to medium volumes of fluids ranging from 200-20,000 bbl in both deck-side offshore and onshore applications. System houses 3 vessels and each 6½ dia x 40 in. long cartridge provides 13 m² filtration area, resulting in total of 117 m² effective filtration area. Measuring 2.72 m², skid offers 99 kg total dirt loading capacity and connection to standard 4 in. service pipework.

Parker Hannifin Corp., The Filtration & Separation Div.
Tewksbury, MA 01876
Mar 16, 2009 Constructed in 316 SS or zinc alloy, Filter Regulators offers flow rates from 16-72 scfm and feature rolling diaphragm for accurate pressure regulation regardless of changing flow or inlet pressure. Suited for harsh environments such as chemical washdown areas, Mini Filters come in 316 SS and zinc alloy with coalescing filter media. Five regulator models are available in stainless steel and aluminum with ¼-1½ in. ports, max pressure capacity of 300 psig, and flow rates to 300 scfm.

RF Micro Devices, Inc.
Greensboro, NC 27409-9421
Mar 04, 2009 Along with single-pole nine throw pHEMT switch, RF1194 integrates quad-band GSM/GPRS/EDGE transmit low-pass filtering and 4 GSM/GPRS/EDGE receive surface acoustic wave filters. Model RF1195 integrates single-pole ten throw pHEMT switch and builds on RF1194 architecture by providing additional high-linearity port for 4 total symmetrical WCDMA/HSPA+ Tx/Rx ports. Both cellular switch filter modules come in pin-to-pin compatible, 4.5 x 4.5 x 1.2 mm packages.

Orival, Inc.
Englewood, NJ 07631
Mar 03, 2009 Featuring max capacity of 1,760 gpm, 10 in. ORG-100-LS filter stays online during 15 sec cleaning cycle without disrupting flow or pressure downstream. It uses 80% less water (typ) to clean itself when compared to similar-sized automatic filters. Along with cooling water, industrial process water, and reuse water, applications include irrigation, MF/UF/RO membrane pre-treatment, leach mining, and spray nozzle protection.

Nordfab Ducting
Thomasville, NC 27361
Feb 24, 2009 Mounted horizontally or vertically, Mist Recycler removes airborne liquid near pick-up point in air stream to promote filtration system efficiency as well as reduce moisture accumulation, leaks, and bacterial growth. Removable impingement baffle pre-filters vaporized water, oil, and grease from air stream, minimizing amount of liquid entering primary mist collector and extending filter life. Liquid collected in Mist Recycler drains into sump and is returned to machine.

Parker Hannifin Corp
Greenfield, TN 38230
Feb 23, 2009 Constructed of 304 Stainless and available in ¼-1 in. line sizes with flow capacities to over 700 Scfm, Balston® filters remove 99.99% of oil, water, rust and pipescale particles of 0.01 micron in size and larger from compressed air and gases. Filters suit applications in hospitals, food and beverage, chemical plants, refineries and pulp and paper mills.
