Madison Company
Branford, CT 06405
Jul 31, 2006 Madison-Omni® compact RTD temperature sensors are comprised of Madison-Omni® integrated display/control unit and platinum RTD temperature sensor tip. User-programmable display interface allows for setting of 2 alarm points and offers uniform readout for several sensor monitoring options. Available in 12 configurations, sensors offer various temperature ranges, depending on model.

BiODE, Inc.
Westbrook, ME 04092
May 16, 2006 Measuring 1.3 x 1.1 x 0.4 in., solid-state BiODE ViSmart(TM) with USB option can be integrated into any computer platform or control system to instantaneously acquire real-time viscosity and temperature data. Sealed unit has no moving parts, requires no calibration, and is unaffected by vibration or flow conditions. Sensor is suited for challenging embedded applications such as helicopter transmissions, oil well drills, and paint and coating manufacturing.

Minco Products, Inc.
Minneapolis, MN 55432 3177
May 10, 2006 Designed for HVAC and building automation markets, Thermal Vial(TM) provides accurate measurement and documentation of freezing, process, and storage methodology. It builds on existing sensors with additional options such as vial size, multiple thermowell configurations, loop-powered indication, and 3 levels of calibration accuracy. For real-time verification, Thermal Vial Sensor encompasses wire-wound element capable of -200°C operation.

ASI
El Cajon, CA 92020
Apr 17, 2006 Offered in sizes from 4-30 mm, Inductive Sensors are available in square or rectangular models with options such as NAMUR, AC/DC, NPN or PNP output, NO or NC output, and programmable output. For high-heat and standard applications, choice between shielded or unshielded sensors is available. Sensors come in 2, 3, or 4-wire configurations with connector or cable and 360° LED indicator, which produces amplified detection.

Exergen Corp.
Watertown, MA 02472
Apr 05, 2006 Combining IR temperature sensor with Smart microprocessor, Smart-microIRt/c offers 4 different sensor heads. Outputs include 4-20 mA, 0-5 V, 0-10 V, and RS232, and temperature ranges are -30 to 70°C, 0-100°C, 0-250°C, and 0-500°C. Powered from 12 or 24 Vdc, sensor features stainless steel head, hermetically sealed with NEMA 4X rating. While performing complex algorithms determining output, Smart processor calibrates itself once/sec, eliminating drift or sudden changes.

E Instruments Group LLC
Langhorne, PA 19047
Mar 13, 2006 Non-contact infrared temperature sensor/transmitter, Rayomatic 6, delivers accuracy of +2% of rdg and optical resolution of 6:1 (180 mm at 1,000 mm). Sensor incorporates microcontroller technology and offers linear mV or thermocouple analog output. Emissivity, response time, and measuring range are PC configurable, and report of calibration is available with unit.

Agilent Technologies, Inc.
Palo Alto, CA 94303
Feb 21, 2006 Fiber-based distributed temperature sensing systems, Models N4385A and N4386A monitor temperature over long distances to optimize production or to detect leaks or fires. Using Raman effect, indoor Model N4385A, used for fire and power cable applications, and outdoor Model N4386A, suited for oil and pipeline applications, provide temperature profile across distances up to 8 km, with spatial resolution of less than 1 m, and temperature resolution of less than 0.1°C/0.2°F.

Honeywell Sensing and Control
Golden Valley, MN 55422 3935
Jan 23, 2006 RoHS compliant, miniaturized Platinum RTD Series 700 is produced in Class 1000 clean room using vapor deposition, photolithography, and etching technologies. Featuring linear resistance, sensors come in leaded and SMT configurations in both DIN A and DIN B tolerances, and are suitable for use in HVAC, electronic assemblies, process control, appliances, automotive, and instrumentation.

Minco Products, Inc.
Minneapolis, MN 55432 3177
Jan 11, 2006 Designed for HVAC and building automation industries, Chill-Out(TM) Combination Sensor integrates low-temperature cut-out sensor (freeze stat) and averaging resistance temperature sensor in one self-contained unit. This air handling system sensor features solid-state design, with relay integral to tubing. Available in 3/8 in. tubing in bendable aluminum and ultra-flex brass armor, product is sensitive to low temperatures in any direction up to 6 in.

Schroeder Industries LLC
Leetsdale, PA 15056-1025
Jan 10, 2006 Designed to continuously monitor hydraulic and lubrication fluids, Testmate(TM) Water Sensor Model TWS-C measures water content relative to percent saturation of fluid in range of 0-100%. Capacitance sensor absorbs water molecules from fluid and changes capacity value that is directly related to saturation level. Integrated thermoelement on sensor measures temperature of fluid from -13º to 212ºF. Temperature and degree of saturation are reported as 4-20 mA signal.

Minco Products, Inc.
Minneapolis, MN 55432 3177
Dec 26, 2005 Flexible Heaters Prototype Design Kit includes 12 flexible heaters in polyimide and silicon rubber insulation, 100 ohm platinum RTD sensor, and PSA and Silicone RTV adhesive. Non-invasive Sensors Design Kit comes with 5 Thermal-Ribbon, Thermal-Tab, and Bolt-on RTDs to accurately sense temperatures, as well as miniature TempTran(TM) temperature transmitter with 4-20 mA output and silicone stretch tape. Both provide instructional tutorial for experimenting and prototyping.

Advanced Thermal Products, Inc.
St. Marys, PA 15857
Dec 13, 2005 Featuring standard cable length of 10 ft, sensor is designed with epoxy coated NTC thermistor as part of internal construction to seal sensing element from outside environment. Sensor assembly is thermally tied to pipe via copper clip, which facilitates installation of housing onto straight section of 3/8 in. copper tubing and remains snug even after being removed and installed numerous times. Available with 4 ratings from 2,252 W to 10 kW.

Advanced Thermal Solutions Inc.
Norwood, MA 02062
Dec 09, 2005 Designed to characterize thermal conditions in electronic systems, Model MS 1000-CS-WC provides temperature measurements from -30 to +150°C, ±1°C and velocity measurements from 0-51 m/s, ±2%. Unit features 9.5 mm diameter base and comes in heights of 9, 12, and 20 mm. Narrow, low-profile design minimizes disturbance of heat flow in test domain, while plastic-sleeved stem facilitates installation and repositioning during testing process.

Love Controls
Michigan City, IN 46361
Nov 23, 2005 Constructed with 4 environmentally-sealed temperature sensing modules spaced evenly along 12 ft. bendable aluminum probe coil, Series AVG Sensors measure average supply air temperature in large ducts. Probe terminates into rugged steel housing that meets NEMA4/IP65 requirements.

Love Controls
Michigan City, IN 46361
Nov 08, 2005 Surface Mount Series S provides temperature measurement solution for conditioned water pipes, low-pressure steam, and refrigerant lines. Waterproof sensors can be installed on outer-wall pipe surfaces with nylon ties. Constructed with 2 in. 304 stainless steel probe and 6 ft plenum-rated cable, units are available in variety of types including platinum, nickel, and Balco RTDs and thermistors.

Love Controls
Michigan City, IN 46361
Nov 02, 2005 Constructed with hermetically sealed sheath, Series AD Air/Duct Temperature Sensors are unaffected by high humidity, contamination, thermal shock, or vibration. Units can be installed in air handlers, fan coil units, ducts, furnaces, freezers, and ovens. Flanged mount assemblies offer low profile installation with fixed insertion depth, while bulkhead mounted units include brass bulkhead fitting and compression sleeve for applications requiring adjustable insertion depth.

Zettler Controls, Inc.
Aliso Viejo, CA 92656
Oct 13, 2005 With temperature range of -40 to 300°C, Series TS offers precision control in heating and temperature regulation applications. Negative temperature coefficient protects against inrush currents, which can be harmful to circuitry. Specifications for TS Series are fully customizable. Applications include heating, central air, water temperature control systems, and appliances.

Banner Engineering Corp.
Minneapolis, MN 55440
Sep 02, 2005 Non-contact, passive T-GAGEâ„¢ sensors detect objects that are hotter or colder than ambient condition and trigger output. Set-up is facilitated via Manual or Dynamic TEACH-mode push-button programming, which requires no potentiometer adjustments. Able to operate even if product is not moving, sensors detect temperatures from 0–300°C and changes as small as 3°C. Self-contained unit has stainless steel barrel construction and 25 msec response time.

TURCK, Inc.
Plymouth, MN 55441
Jun 06, 2005 Self-contained Digital Read Out flow sensor operates on calorimetric principle and features solid-state construction with 316 stainless steel wetted parts. Along with 3-digit display, unit provides adjustable on and off delay feature, programmable set points, and adjustable filter. In-line-mounted unit, available with transistor, relay, or analog output, monitors changes in flow between 0.2 and 12 gpm. It operates with fluids such as water and glycol.

Texas Instruments, Inc., Semiconductors
Dallas, TX 75243
May 05, 2005 Manufactured in SOT23-6 and MSOP-8 packages, TMP141 measures temperature from -40 to 125°C without external sensing components. It features 10-bit resolution digital output and single-wire SensorPathâ„¢ interface protocol. Suited for space-restricted applications, product has 170 µA max operating current and extended supply range of 2.7–5.5 V. It is suited for monitoring hardware systems in servers and PCs as well as battery-powered instruments.
