Sterling
New Berlin, WI 53151
Jun 02, 2009 Available in air- and water-cooled versions, GP Series features leaving coolant temperature range of 20-80°F and electronic modulating capacity control that maintains temperature to within 0.1°F. Electronic sensors monitor leaving/entering fluid temperatures, compressor suction/discharge pressure, condenser inlet temperature, pump pressure, and tank level. LCD shows operating status, set point, and to-process temperature on multiple screens. R410a refrigerant is chlorine-free.

American Power Conversion
West Kingston, RI 02892
May 28, 2009 Featuring up to 7 kW of cooling capacity, 600 mm wide rack enclosure, as well as front and rear containment options, InRow® SC Systems can be deployed as fully contained IT environment or partially contained system that can be added as retrofit. Self-contained solutions monitor and actively adjust cooling capacity to ensure proper server inlet temperatures. Intelligent and manageable components make the system network-enabled and self-monitoring.

Visionaire, Inc.
Grand Prairie, TX 75051
May 15, 2009 With internal hydraulic compressor drive that requires flow of 8 gpm at 1,200-1500 psi, Model 3110 condenser unit for work equipment can be paired with wide variety of in-cab air conditioners and heater components. It is rated at 24,000 BTU/hr and features formed and welded steel construction, powder coating, and fully hydraulic component isolation. Optional equipment includes diesel fired coolant heater and variety of cab air filtration and pressurization systems.

Trantech Radiator Products
Edgefield, SC 29824
May 11, 2009 As 520 mm radiator, E4 optimizes heat dissipation via header diameter on inlet and exit path of oil. Enlarged sump conveys oil from inlet header to plates of radiator on inlet side, and similarly enlarged neck conveys oil from plates to exit header on outlet side. Plate spacing increases hydraulic diameter in plate for same perimeter, reducing friction factor for external flow of air. Improves heat transfer coefficient 18-22%, radiator maintains minimal valves and other connections.

DuCool
Miami Beach, FL 33140
May 06, 2009 DuHybrid system combines desiccant dehumidification with evaporative/geothermal cooling, utilizing solar thermal energy but automatically switching to electric power when needed. In renewable energy mode, unit can generate over 20 tons of refrigeration, while in electric mode, waste heat of compressor is used as energy source. System allows independent control of humidity/temperature and has liquid desiccant cooling process to eliminate bacteria/particles.

Elma Electronic Inc.
Fremont, CA 94538
Apr 29, 2009 Aluminum based black anodized Elma front panel heat sinks dissipate heat while covering open sections of enclosure. Cooling fin extrusion has width of 42 HP and comes in 1U high increments. Each fin is built upon 1.5 HP pitch to leave enough space in between for screw heads. Heat sink front panels come in various sizes and configurations, but are specifically designed for 19 in. technology. EMC versions with mounting bracket for gaskets are also available.

Visionaire, Inc.
Grand Prairie, TX 75051
Apr 10, 2009 Available as cool only or as air conditioner and heater for on/off-road heavy duty equipment, Model 4050 can be mounted on either wall or ceiling. With footprint of 18.5 x 6.5 x 17.25 in. for cool only and 18.5 x 6.5 x 20.5 in. with optional heater, unit has 18,500 BTU cooling and 32,000 BTU heating capability. Ducting options and remote mount controls also allow for installation behind seat.

Taco, Inc.
Cranston, RI 02920
Mar 23, 2009 Featuring microprocessor-based, variable speed differential controller, Delta T 00 Circulator enables users to accurately calculate and adjust for heat loss because it automatically adjusts to deliver optimal heat transfer based on actual operation of system on continuing basis. Unit is suitable for use in multi-zone radiant manifolds with loop actuator and in series loop systems using zone valves.

Hawco
Surrey GU7 2QN  United Kingdom
Mar 17, 2009 Incorporating energy-efficient hermetic compressors and condenser coils with energy-efficient Zeil-EBM fan, Hawco Extra Cold is available for R404a refrigerant across high, medium, and low temperature ranges. It can be directly balanced with Lu-Ve Contardo SHC and SHA evaporators. Customizable unit is fabricated from galvanized steel to ensure rugged, weatherproof module that can be flat roof, wall, or ground mounted, and provides low operating noise level of 33-47 dBA.

Scott Brothers Ltd
Cheshire, CW10 9LT   United Kingdom
Mar 13, 2009 Working on principle of natural air cooling, SCOTTair Evaporative Coolers use fan and evaporation of cool tap water to reduce ambient room temperature by up to 30°C. With centrifugal fan delivering 1,500 m³/hr and 170 W motor, SCOTTair SA15 cools areas up to 30 m². SCOTTair SA35 generates 3,500 m³/hr air flow rate from 280 W motor for areas up to 45 m². Equipped with axial-mounted fan with max airflow of 6,000 m³/hr and 290 W motor, SCOTTair SA06 cools areas up to 80 m².

Trans/Air Manufacturing Corporation
Dallastown, PA 17313
Mar 03, 2009 Designed for use in heavy duty transit applications, UL Series has chassis design that utilizes lightweight recyclable materials for reduced fuel consumption, overall weight reduction, and reduced noise emission. UL500, 700, 800, 900 operate with heavy duty transit type compressor, while UL500 is also available with hermetic compressor for use on electric/hybrid vehicles. All models work with either high efficiency R134a or optional environmentally friendly CO2 refrigerant (R744).

Trans/Air Manufacturing Corporation
Dallastown, PA 17313
Mar 03, 2009 Rated at 120,000 Btu/hr, RTC-120 roof mounted condenser is designed for severe duty transit applications or where skirt space is limited or unavailable. Lightweight condenser utilizes 6 high capacity fans for maximum air flow, and features ABS or powder coated metal cover.

Building Register Limited
Maidstone   United Kingdom
Feb 25, 2009 Optimized for comfort and efficiency, CMSQ inverter-controlled R-410A system offers COP up to 4.1 in heating mode and allows individual control of up to 4 indoor air conditioning units. Piping lengths to 200 m allow flexible outdoor unit placement, and sound levels reach 57 dBA during normal operation or 45 dBA in night mode. Individually controlled indoor units - Roundflow cassette (FMCQ) and concealed ceiling unit (FMDQ) - come in capacities from 5-12.5 kW in cooling mode.

Linde, Inc.
Murray Hill, NJ 07974
Feb 16, 2009 LINSPRAY® carbon dioxide (CO2)-based cooling system maintains correct temperature and minimizes risk of overheating when working on parts with thin walls or heat-sensitive substrate materials such as titanium, magnesium, and aluminum. Able to reduce cooling time in thermal spray process, nozzles convert CO2 to snow and enable uniform, directed, and continuous cooling results without any clogging. CO2 storage and delivery can be tailored to application requirements.

Thermal Care Inc.
Niles, IL 60714
Feb 11, 2009 Available from 50-125 tons in water-cooled and remote condenser models, MX Series R-134A rotary screw central chillers are designed to meet industrial requirements. Each unit features one refrigeration circuit with brazed plate evaporator, Allen-Bradley compact Logix PLC, and modular design that promotes access to controls and components allowing multiple circuits (up to 4) to be linked together with common control system.

Nextreme Thermal Solutions
Durham, NC 27003
Jan 29, 2009 Designed for optoelectronics and telecommunications industries, OptoCooler HV14 is optimized for standard circuitry and power requirements. It can pump up to 1.5 W of heat and operates at max voltage of 2.7 V and peak current of 1 A. Occupying 2.8 mm² footprint, unit can create temperature differential up to 51°C between its hot and cold sides. Thermal Copper Pillar Bump acts as solid-state heat pump to add thermal management functionality locally on surface.

Advanced Inspection Technologies
Melbourne, FL 32940
Jan 22, 2009 Videoscope cooling sleeve allows borescope inspectors to insert a videoscope into sleeve for remote visual inspection of high temperature applications. It keeps scope cool by surrounding it in vortex of compressed air, allowing users to inspect steam lines and turbines. Shop air is connected, which maintains appropriate temperature for videoscope to operate. Constructed of high temperature polyurethane, sleeve works with 3.0 m long videoscope.

Hamilton Storage Technologies
Hopkinton, MA 01748
Jan 07, 2009 Using external magnetic couplers to drive internal robotics, -20°C Sample Access Manager (SAM) offers temperature-controlled (+20 to -40°C) environment for storing DNA/RNA, compounds, tissue, and protein samples. This piece of laboratory automation equipment also integrates functionality for cherry-picking, sample tracking, and multiple sample type capabilities. Along with software, system provides integrated Tube Picking Module (TPM), LN2 back up system, and complete audit trail.

Emerson Network Power
St. Louis, MO 63136
Jan 05, 2009 Available in upflow and downflow configurations, Liebert CW(TM) chilled water-based computer room air conditioner (CRAC) delivers precision cooling and humidity control matched to needs of data center equipment. Cooling capacities are available up to 181 kW, and unit uses building's existing chilled water supply as cooling source. Larger downflow models are available with optional energy-efficient EC plug fans, while all versions are offered with optional variable-speed drive fans.

Caliente LLC
Fort Wayne, IN 46803
Dec 31, 2008 Suited for cooling and heating small to medium sized enclosures, Frio Thermoelectric Cooler is built with standard IP55 sealed and 7.5 year fans on both sides. Unit offers low noise levels of 45 dBA and is available with thermostat. Control platform includes options such as PWM and alarms.
